TOYOTA CAMRY 2009 XV40 / 8.G Navigation Manual

OTHER FUNCTIONS
171

Changing the Bluetooth
settings
You can change the display and settings of
Bluetooth  information on the system.
The information displays the following
items.
“Device Name” The name in the Bluetooth
. . . . .
network. You can change it.
“Passkey” The password when you regis-
. . . . .
ter your cellular phone in the
system. You can change it into
the figure of 4− 8 digits.
“Bluetooth
∗ Device Address” The address peculiar to the
. . . . .
system. Y ou can not change it.
If you have registered two
Bluetooth  phones with the
same Device Name or Pass-
key and you cannot distinguish
one from the other, refer to it. When you change the device name or
Passkey, do
the followings.
1. Touch “Bluetooth∗”.
2. Touch “Change” of “Device Name”
or “Passkey”.
3. Use the software keyboard to input
the device name.
You can input up to 20 characters.
∗: Bluetooth is a registered trademark of
Bluetooth SIG. Inc.

OTHER FUNCTIONS
172
4. Input a Passkey with 4 8 digits.
When you touch  , the input number is de-
leted.
5. When you complete the setting,
touch
.
Initializing the Bluetooth  settings
You can initialize the settings.
1. Touch “Default”.
2. Touch “Yes”.

OTHER FUNCTIONS
173

Deleting a Bluetooth
phone
1. Touch “Delete” of “Bluetooth∗ Tele-
phone”.
2. Select the telephone you want to de-
lete and touch “OK”.
3. Touch “Yes”.
∗: Bluetooth is a registered trademark of Bluetooth SIG. Inc.
Displaying the information of the
Bluetooth  phone you delete
You can display the information of the
Bluetooth  phone before you delete it
and you can make sure whether the
telephone you delete is correct or not.
1. Select the telephone you want to
display the information about.
2. When you complete confirming it,
touch
.

OTHER FUNCTIONS
174
The speech command system enables
you to operate the navigation system
and audio system by giving a com-
mand.
Type A
Type B
1. Push the talk switch.
A beep sounds and on screen message is
displayed with an indicator at the top left.
2. Say a command while the indicator
is shown on the display.
If you want to check the command list,
touch “Help” to display the help screen.
(See “Help screen” on page 177.) When
you touch “Cancel”, the previous
screen returns.
If the navigation system does not respond
or the confirmation screen does not disap-
pear, please push the talk switch and try
again.
If no command is given, a beep sounds
and the indicator disappears 6 seconds
later.
If the system does not recognize your
speech, the system will respond with this
message (“System does not recognize
this command, please rephrase your com-
mand.”). Start the operation from the be-
ginning.
Speech command system

OTHER FUNCTIONS
175
Microphone
It is unnecessary to speak directly into
the microphone when giving a com-
mand. Speech command example: Searching
for a route to your home.
1. Push the talk switch.
2. Say
“Home” .
You can also say the street name or ad-
dress.
∗ (ex. say “Woodridge Avenue” .)∗: “Hawaii” or Hawaii area is not covered by
the voice recognition.
If your home is not registered, you will hear
“Home is not registered”.
3. If the system recognized the com-
mand, the recognition result “Home” is
displayed on the top of the screen with
the screen message. (Displayed mes-
sage and the touch screen buttons on
the screen depend on the situation.)
Touch or say “Cancel” , and the system will
be canceled. Touch or say “Help”, and dis-
plays the help screen.

OTHER FUNCTIONS
176
4. Touch “Enter” or say “Enter des-
tination”, and the system starts search-
ing for a route to your home. (If the des-
tination is already registered, “Add to
” or “Replace ” is displayed on the
screen.)
Touch or say “Cancel” , and the search will
be canceled. When you search the destination by
“POI Name”, this screen is displayed.
Touch
“Enter” or say “Enter destination” .
When you touch “Show List”, you can
search another spot in its category.
INFORMATION
In the following conditions, the sys-
tem may not recognize the command
properly.
The command is not correct or
clear.
There are some noises such as
wind noise, etc.

OTHER FUNCTIONS
177
This system has a function which dis-
plays the voice recognition help
screen. You can see the command list
and operating guide on it.
(a) Command list
1. If the “Operating Guide” screen is
displayed, touch “Command List” on
the upper side of the screen.
2. Select the desired category by
touching the buttons on the right side of
the “Command List” screen.
3. You can scroll through the list of the
command list by touching
or .
Touch “OK” after you check it. (b) Operating guide
1. If the “Command List” screen is dis-
played,
touch “Operating Guide” on the
upper side of the screen.
2. Select the desired category by
touching the buttons on the ri ght side of
the “Operating Guide” screen.
3. You can scroll through the list of the
operating guide by touching
or .
Touch “OK” after you check it.
Help screen

OTHER FUNCTIONS
178
The brightness or contrast of the screen
can be adjusted depending on the bright-
ness of your surroundings. You can also
turn the display off.
1. Push the “DISP” button.
2. Touch the desired button to adjust
contrast and brightness.
“Contrast” “+”: Strengthens the contrast
of the screen.
“Contrast” “–”: Weakens the contrast of
the screen.
“Brightness” “+”: Brightens the screen.
“Brightness” “–”: Darkens the screen.
3. After adjusting the screen, touch
“OK”. The screen goes off when
“Screen Off” is
touched. To turn the display screen back
on, push any button such as “INFO”, etc.
The selected screen appears.
INFORMATION
When you do not touch any button on
the “Display” screen for 20 seconds,
the previous screen will be displayed.
Screen adjustment

OTHER FUNCTIONS
179
Depending on the position of the headlight
switch, the screen changes to the day
mode or night mode.
To display the screen in the day mode even
with the headlight switch on, touch “Day
Mode” on the adjustment screen for
brightness and contrast control.
If the screen is set in the day mode with the
headlight switch turned on, this condition is
memorized in the system even with the en-
gine turned off.
1. Push the “INFO” button.
2. Touch “Screen Setting”.
Screen setting

OTHER FUNCTIONS
180
(a) Automatic transition
You can select a function that enables au-
tomatic return to the navigation screen
from the audio screen.
Select “ON” or “OFF” and then touch
“OK”.
“ON”: The navigation screen automatical-
ly returns from the audio screen 20 sec-
onds after the end of audio screen opera-
tion.
“OFF”: The audio screen remains on. (b) Switch color
You can select the color of the touch
screen buttons.
Select “Green” or “Orange” and then
touch “OK”.
