hood release TOYOTA CAMRY 2009 XV40 / 8.G Owners Manual

13
Gauges and meters
Multi-information display
∗
P. 141
P. 149
Tilt and telescopic steering control lever P. 64
Pictorial index
Trunk opener P. 47
Headlight switch
Turn signal lever
Fog light switch
∗
P. 152
P. 138
P. 156
Instrument panel
Audio system
Navigation system *1
P. 201
Windshield wiper and washer switch P. 157
Clock
Security indicator P. 277
P. 78, 80
Outside rear view
mirror switches
P. 67
Tire pressure warning
reset switch
P. 336
Parking brake pedal ∗ P. 139
Hood lock release
lever
P. 313
Fuel filler door opener
P. 74
Auxiliary box P. 272∗: If equipped
*1: Refer to “Navigation System Owner’s Manual”.
Emergency
flasher switch

313
4-3. Do-it-yourself maintenance
4
Maintenance and care
Hood
CAUTION
■Pre-driving check
Check that the hood is fully closed and locked.
If the hood is not locked properly, it may open while the vehicle is in motion
and cause an accident, which may result in death or serious injury.
Release the lock from the inside of the vehicle to open the hood.
Pull the hood release lever.
The hood will pop up slightly.
Lift the hood catch and lift the
hood.
STEP1
STEP2

422 5-2. Steps to take in an emergency
■Overheating
If you observe the following, your vehicle may be overheating.
●The engine coolant temperature gauge enters the red zone or a loss of
power is experienced.
● Steam is coming from under the hood.
CAUTION
■To prevent an accident or injury when inspecting under the hood of
your vehicle
● If steam is seen coming from under the hood, do not open the hood until
the steam has subsided. The engine compartment may be very hot, caus-
ing serious injury such as burns.
● Keep hands and clothing away from the fan and other belts while the
engine is running.
● Do not loosen the coolant reservoir cap while the engine and radiator are
hot.
Serious injury, such as burns, may result from hot coolant and steam
released under pressure.
Add engine coolant if neces-
sary.
Water can be used in an emer-
gency if engine coolant is
unavailable.
(→P. 433)
Have the vehicle checked at the nearest Toyota dealer as soon as
possible.
STEP6

480
GAS STATION INFORMATION
Auxiliary catch leverP. 313Trunk openerP. 4 7Fuel filler door P. 7 4
Hood lock release lever
P. 3 1 3
Fuel filler door opener P. 7 4Tire inflation pressure
P. 436
Fuel tank capacity 18.5 gal. (70 L, 15.4 lmp.gal.)
Fuel type Unleaded gasoline only P. 75, 430
Cold tire inflation pressure P. 436
Engine oil
capacity
(Drain and refill)
2.4 L 4-cyl-
inder (2AZ-
FE) engineqt. (L, lmp.qt)
With filter 4.5 (4.3, 3.8)
Without filter 4.3 (4.1, 3.6)
3.5 L V6
(2GR-FE)
engine With filter 6.4 (6.1, 5.4)
Without filter 6.0 (5.7, 5.0)
Engine oil type Toyota Genuine Motor Oil or equivalent
Oil grade: ILSAC multigrade engine oil
P. 4 3 1
Recommended oil viscosity:
SAE 5W-20 or 0W-20 (2.4 L 4-cylinder
[2AZ-FE] engine) SAE 5W-30 (3.5 L V6
[2GR-FE] engine)
