spark plug TOYOTA CAMRY 2010 XV40 / 8.G Owners Manual

488 6-1. Specifications
Cooling system
Ignition system
Capacity
(Reference)2.5 L 4-cylinder (2AR-FE) engine
7.5 qt. (7.1 L, 6.2 Imp. qt.)
3.5 L V6 (2GR-FE) engine
9.5qt. (9.0 L, 7.9 Imp. qt.)
Coolant typeUse either of the following.
• “Toyota Super Long Life Coolant”
• Similar high-quality ethylene glycol-based non-silicate, non-amine, non-nitrite, and non-borate coolant with
long-life hybrid organic acid technology
Do not use plain water alone.
Spark plug
Make
Gap 2.5 L 4-cylinder (2AR-FE) engine
DENSO SK16HR11
3.5 L V6 (2GR-FE) engine
DENSO FK20HR11
0.043 in. (1.1 mm)
NOTICE
■ Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust spark plug gap.

530 Alphabetical index
Seat beltsAdjusting the seat belt .............57
Automatic Locking
Retractor ...............................60
Child restraint system
installation ........................... 108
Cleaning and maintaining the seat belts ...................... 351
Emergency Locking Retractor ...............................60
How to wear your seat belt......57
How your child should wear
the seat belt ..........................61
Pregnant women, proper seat
belt use .................................60
Reminder light ....................... 435
Seat belt extenders .................61
Seat belt pretensioners ...........59
Seat heaters.............................. 330
Seating capacity....................... 178
Seats Adjustment ........................51, 53
Adjustment precautions........... 52
Child seats/child restraint system installation .............. 108
Cleaning ................................ 350
Head restraint..........................55
Properly sitting in the seat .......85
Rear seat folding down ...........54
Seat heaters .......................... 330 Service reminder
indicators .............................. 151
Shift lever Automatic transmission ......... 138
If the shift lever cannot be shifted from P ................ 467
Manual transmission ............. 142
Shift lock system ..................... 467
Side airbags ............................... 87
Side marker lights Replacing light bulbs ............. 418
Switch ................................... 159
Wattage................................. 494
Side mirror
Adjusting ................................. 68
Smart key system Entry function .......................... 27
Starting the engine ................ 131
Spare tire Inflation pressure .................. 392
Storage location .................... 454
Spark plug ................................ 488
Specifications .......................... 482
Speedometer ............................ 147
Steering Column lock release ..... 133, 136
Steering wheel Adjustment .............................. 65
Air conditioning system switches .............................. 201
Audio switches ...................... 260S
