coolant TOYOTA CAMRY 2016 XV50 / 9.G Quick Reference Guide

4
OVERVIEW
Instrument cluster
SRS airbag warning1
Electric power steering system warning1
Low fuel level warning
1 If indicator does not come on or does not turn off within a few seconds of starting engine, there
may be a malfunction. Have vehicle inspected by your Toyota dealer.
Service indicators and reminders
Tachometer
Outside temperature display
Speedometer
Display change button
Fuel gauge
Odometer/Trip meter
Multi-information display
Shift position/Shift range display
Engine coolant temperature display
Instrument panel light control button
Driver/Front passenger seat belt reminder
(alarm will sound if speed is over 12 mph)
Indicator symbols
Brake system warning1
For details, refer to “Indicators and warning lights,” Section 2-2, 2016 Owner’s
Manual.
Pre-collison system warning1,2
Malfunction/Check Engine indicator1
Master system warning1

OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
9
Hood release
Pull up latch and raise hood
Pull
Engine oil filler cap
Engine oil level dipstick
Engine coolant reservoir
Windshield washer fluid tank
NOTE: Regularly scheduled maintenance, including oil changes, will help
extend the life of your vehicle and maintain performance. Please refer
to the “Warranty Maintenance Guide.”
Engine maintenance
4 cylinder (2AR-FE) engineV6 (2GR-FE) engine
