TOYOTA CAMRY CNG 2000 Owners Manual

’00CAMRY CNG (L/O9908)
2012000 CAMRY CNG (OM33519U)
TiresFuses
Engine compartment
Tire size:
Spare tire T145/80R16 105M
Except spare tire P205/65R15 92H
Tire pressure, kPa (kgf/cm
2 or bar, psi):
Spare tire 420 (4.2, 60)
Except spare tire
When driving under the above vehicle load conditions at sustained high speeds
above 160 km/h (100 mph), in countries where such speeds are permitted
by−law, inflate the front and rear tires to 240 kPa (2.4 kgf/cm
2 or bar, 35 psi)
provided that it does not exceed the maximum cold tire pressure molded on
the tire sidewall.
Normal
drivingFor all loads including full rated loads
For reduced loads (1 to 4 passengers)
Trailer driving220 (2.2, 32)
200 (2.0, 29)
220 (2.2, 32)
Wheel nut torque, N·m (kgf·m, ft·lbf):
104 (10.5, 77) Wheel size:
Spare tire 4T
Except spare tire 156JJ

’00CAMRY CNG (L/O9908)
2022000 CAMRY CNG (OM33519U)
Engine compartment
Fuses (type A)
1. A/C 10 A: Air conditioning system
2. SPARE 10 A: Spare fuse
3. SPARE 15 A: Spare fuse
4. SPARE 30 A: Spare fuse
5. ALT−S 5 A: Charging system
6. HEAD (RH) 20 A: Right−hand headlight
7. EFI 20 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system, A/F sensor
8. HORN 10 A: Horn
9. HAZARD 15 A: Emergency flasher
Instrument panel
10. AM2 30 A: Gauge and meter, SRS
airbag system, seat belt pretensioners,
multiport fuel injection system/sequen-
tial multiport fuel injection system,
“IGN” and “STARTER” fuses
11 . T E L 5 A : No circuit
12. HEAD (LH) 20 A: Left−hand headlight
13. RADIO NO.1 20 A: Audio system
14. DOME 7.5 A: Clock, ignition switch
light, trunk light, interior light, power
door lock system
15. ECU−B 10 A: Anti−lock brake system,
SRS airbag system, seat belt preten-
sioners16. A/F HTR 25 A: No circuit
17. DOOR SUB 25A: Power door lock sys-
tem
18. SEAT−HEATER 20 A: No circuit
19. HEATER 10 A: Air conditioning system,
rear window defogger
20. GAUGE 10 A: Gauges and meters,
back−up lights, cruise control system,
charging system, power windows, ser-
vice reminder indicators and warning
buzzers
21. WIPER 25 A: Windshield wipers and
washer
22. MIRROR−HEATER 10 A: Outside rear
view mirror defogger
23. ECU−IG 15 A: Cruise control system,
anti−lock brake system, SRS airbag
system, seat belt pretensioners, shift
lock control system, multiport fuel in-
jection system/sequential multiport fuel
injection system
24. IGN 5 A: Gauges and meters, charging
system, SRS airbag system, seat belt
pretensioners, multiport fuel injection
system/sequential multiport fuel injec-
tion system

’00CAMRY CNG (L/O9908)
2032000 CAMRY CNG (OM33519U)
25. STOP 15 A: Stop lights, cruise control
system, high−mounted stoplight, anti−
lock brake system, shift lock control
system, multiport fuel injection system/
sequential multiport fuel injection sys-
tem
26. TAIL 10 A: Parking lights, license plate
lights, tail lights, front side marker
lights, multiport fuel injection system/
sequential multiport fuel injection sys-
tem
27. POWER−OUTLET 15 A: Power outlet
28. OBD 7.5 A: On−board diagnosis sys-
tem
29. FOG 15 A: No circuit
30. STARTER 5 A: Gauges and meters,
multiport fuel injection system/sequen-
tial multiport fuel injection system
31. DOOR 25 A: Power door lock system
32. PANEL 7.5 A: Gauge and meter, audio
system, cigarette lighter, glove box
light, clock, instrument panel light con-
trol, service reminder indicators, air
conditioning control panel lights, ash-
tray light, emergency flasher, rear win-
dow defogger, electronically controlled
automatic transmission system
33. TURN 7.5 A: Emergency flasher34. RAD−NO.2 7.5 A: Audio system
35. CIG 15 A: Cigarette lighter, shift lock
control system, power rear view mirror
controls, power door lock system, SRS
airbag system, seat belt pretensioners,
air conditioning system
Fuses (type B)
36. CDS 30 A: Electric cooling fans
37. RDI 30 A: Electric cooling fans
38. MAIN 40 A: “HEAD (RH)” and “HEAD
(LH)” fuses
39. HTR 50 A: “AM1” and “A/C” fuses
40. DEF 40 A: Rear window defogger
41. PWR 30 A: Power window control sys-
tem
42. AM1 40 A: “POWER−OUTLET”, “CIG”,
“RAD−NO.2”, “TURN”, “WIPER”, “ECU−
IG”, “GAUGE”, and “HEATER” fuses
43. CDS NO.2 30 A: No Circuit
Fuses (type C)
44. ALT 100 A: “RDI” and “CDS” fuses
45. ABS 60 A: Anti−lock brake system

’00CAMRY CNG (L/O9908)
2042000 CAMRY CNG (OM33519U)

’00CAMRY CNG (L/O9908)
2052000 CAMRY CNG (OM33519U)
REPORTING SAFETY DEFECTS FOR U.S.
OWNERS AND UNIFORM TIRE QUALITY
GRADING
Reporting safety defects for U.S. owners206 . . . . . . . . . . . . . . . . . . . . . .
Uniform tire quality grading206 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 9

’00CAMRY CNG (L/O9908)
2062000 CAMRY CNG (OM33519U)
If you believe that your vehicle
has a defect which could cause a
crash or could cause injury or
death, you should immediately in-
form the National Highway Traffic
Safety Administration (NHTSA) in
addition to notifying Toyota Motor
Sales, U.S.A., Inc.
(Toll−free: 1−800−331−4331).
If NHTSA receives similar com-
plaints, it may open an investiga-
tion, and if it finds that a safety
defect exists in a group of ve-
hicles, it may order a recall and
remedy campaign. However,
NHTSA cannot become involved
in individual problems between
you, your dealer, or Toyota Motor
Sales, U.S.A., Inc.To contact NHTSA, you may ei-
ther call the Auto Safety Hotline
toll−free at 1−800−424−9393 (or
366−0123 in Washington, D.C.
area) or write to: NHTSA, U.S.
Department of Transportation,
Washington, D.C. 20590. You can
also obtain other information about
motor vehicle safety from the Hot-
line.Uniform tire quality gradingThis information has been prepared in ac-
cordance with regulations issued by the
National Highway Traffic Safety Adminis-
tration of the U.S. Department of Trans-
portation. It provides the purchasers and/
or prospective purchasers of Toyota
vehicles with information on uniform tire
quality grading.
Your authorized Toyota CNG dealer will
help answer any questions you may have
as you read this information.
DOT quality grades—All passenger car
tires must conform to Federal Safety
Requirements in addition to these
grades. Quality grades can be found
where applicable on the tire sidewall
between tread shoulder and maximum
section width. For example: Treadwear
200 Traction AA Temperature A
Reporting safety defects
for U.S. owners

’00CAMRY CNG (L/O9908)
2072000 CAMRY CNG (OM33519U)
Treadwear—The treadwear grade is a
comparative rating based on the wear rate
of the tire when tested under controlled
conditions on a specified government test
course. For example, a tire graded 150
would wear one and a half (1−1/2) times
as well on the government course as a
tire graded 100. The relative performance
of tires depends upon the actual condi-
tions of their use, however, and may de-
part significantly from the norm due to
variations in driving habits, service prac-
tices and differences in road characteris-
tics and climate.
Traction AA, A, B, C—The traction
grades, from highest to lowest, are AA, A,
B, and C, and they represent the tire’s
ability to stop on wet pavement as mea-
sured under controlled conditions on spe-
cified government test surfaces of asphalt
and concrete. A tire marked C may have
poor traction performance.
Warning: The traction grade assigned to
this tire is based on braking (straight
ahead) traction tests and does not include
cornering (turning) traction.Temperature A, B, C—The temperature
grades are A (the highest), B, and C,
representing the tire’s resistance to the
generation of heat and its ability to dissi-
pate heat when tested under controlled
conditions on a specified indoor laboratory
test wheel. Sustained high temperature
can cause the material of the tire to de-
generate and reduce tire life, and exces-
sive temperature can lead to sudden tire
failure. The grade C corresponds to a lev-
el of performance which all passenger car
tires must meet under the Federal Motor
Vehicle Safety Standard No. 109. Grades
B and A represent higher levels of perfor-
mance on the laboratory test wheel than
the minimum required by law.
Warning: The temperature grades for this
tire are established for a tire that is prop-
erly inflated and not overloaded. Exces-
sive speed, underinflation, or excessive
loading, either separately or in combina-
tion, can cause heat buildup and possible
tire failure.

’00CAMRY CNG (L/O9908)
2082000 CAMRY CNG (OM33519U)

’00CAMRY CNG (L/O9908)
i2000 CAMRY CNG (OM33519U)
Foreword
Welcome to the growing group of value−conscious people who drive Toyotas. We
are proud of the advanced engineering and quality construction of each vehicle we
build.
This Owner ’s Manual explains the features of your new Toyota. Please read it and
follow the instructions carefully so that you can enjoy many years of safe motoring.
When it comes to service, remember that your authorized Toyota CNG dealer knows
your vehicle best and is interested in your complete satisfaction. He will provide
quality maintenance and any other assistance you may require.
Please leave this Owner ’s Manual in this vehicle at the time of resale. The next
owner will need this information also.
All information and specifications in this manual are current at the time of
printing. However, because of Toyota’s policy of continual product improve-
ment, we reserve the right to make changes at any time without notice.
Please note that this manual applies to all models and explains all equipment,
including options. Therefore, you may find some explanations for equipment
not installed on your vehicle.
©1999 TOYOTA MOTOR CORPORATION
All rights reserved. This material may not be reproduced or copied, in whole or in
part, without the written permission of Toyota Motor Corporation.

’00CAMRY CNG (L/O9908)
2000 CAMRY CNG (OM33519U)
Publication No. OM33519U
Part No. 01999-33519
Printed in Japan 01−9908−00
CNG (U)
Quick index
If a service reminder indicator or warning buzzer comes on 66. . . . . . . . . .
If your vehicle will not start 138. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your engine stalls while driving 141. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your vehicle overheats 141. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If you have a flat tire 142. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your vehicle needs to be towed 150. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tips for driving during break−in period 112. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How to start the engine 126. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General maintenance 163. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gas station information
Fuel type:
Compressed natural gas
See page 112 for detailed information.
Service pressure:
24800 kPa (3600 psig)
Equivalent gasoline capacity:
43 L (11.4 gal., 9.5 lmp. gal.)
Water volume:
135 L (35.7 gal., 29.7 lmp. gal.)
See page 114 for detailed information.
Engine oil:
API grade SJ, “Energy−Conserving” or ILSAC multigrade engine oil
is recommended.
See page 174 for detailed information.
Automatic transmission fluid:
Automatic transmission fluid D−II or DEXRONIII (DEXRONII)
Tire information: See pages 178 through 181.
Tire pressure: See page 201.
I
U2
