TOYOTA CAMRY CNG 2001 Owners Manual

’01CAMRY CNG (L/O0009)
2052001 CAMRY CNG_U (OM33542U)
Service specifications
ENGINE
Valve clearance (engine cold), mm (in.):
Intake 0.19—0.29 (0.007—0.011)
Exhaust 0.28—0.38 (0.011—0.015)
Spark plug type:
DENSO PK20TR8−G
Spark plug gap, mm(in.):
0.8 (0.031)
Drive belt tension measured with
Borroughs drive belt tension gauge
No.BT−33−73F (used belt), Ibf:
Generator belt 13010
Power steering pump belt 8020ENGINE LUBRICATION
Oil capacity (drain and refill), L (qt., Imp.
qt.):
With filter 3.6 (3.8, 3.2)
Without filter 3.4 (3.6, 3.0)
Oil grade:
API grade SJ, “Energy−Conserving” or
ILSAC multigrade engine oil is recom-
mended.
Recommended oil viscosity (SAE):
5W-30 Preferred
Temperature range anticipated before
next oil change
COOLING SYSTEM
Total capacity, L (qt., Imp. qt.):
6.9 (7.3, 6.1)
Coolant type:
“TOYOTA Long Life Coolant” or equiva-
lent
With ethylene−glycol type coolant for a
proper corrosion protection of aluminum
components
Do not use alcohol type antifreeze or
plain water alone.
BATTERY
Open voltage
∗ at 20C (68F):
12.6—12.8V Fully charged
12.2—12.4V Half charged
11.8—12.0V Discharged
∗: Voltage that is checked 20 minutes af-
ter the key is removed with all the
lights turned off
Charging rates:
5 A max.
Note: If the replacement is necessary,
make sure to do so with a battery that is
the same standard as the original.

’01CAMRY CNG (L/O0009)
2062001 CAMRY CNG_U (OM33542U)
AUTOMATIC TRANSAXLE
Automatic transmission
Fluid capacity (drain and refill),
L (qt., Imp. qt.):
Up to 2.5 (2.6, 2.2)
Fluid type:
Automatic transmission fluid D−ll or
DEXRONIIl (DEXRONII)
Differential
Fluid capacity L (qt., Imp. qt.):
1.6 (1.7, 1.4)
Fluid type:
Automatic transmission fluid D−II or
DEXRONIII (DEXRONII)
BRAKES
Minimum pedal clearance when depressed
with the force of 490 N (50 kgf, 110 lbf)
with the engine running, mm (in.):
70 (2.8)
Pedal free play, mm (in.):
1—6 (0.04—0.24)
Pad wear limit, mm (in.):
1.0 (0.04)
Lining wear limit, mm (in.):
1.0 (0.04)
Parking brake adjustment when pulled with
the force of 196 N (20 kgf, 44 lbf):
5—8 clicksFluid type:
SAE J1703 or FMVSS No.116 DOT 3
STEERING
Wheel free play:
Less than 30 mm (1.2 in.)
Power steering fluid type:
Automatic transmission fluid DEXRONII
or III

’01CAMRY CNG (L/O0009)
2072001 CAMRY CNG_U (OM33542U)
TiresFuses
Engine compartment
Tire size:
Spare tire T145/80R16 105M
Except spare tire P205/65R15 92H
Tire pressure, kPa (kgf/cm
2 or bar, psi):
Spare tire 420 (4.2, 60)
Except spare tire
When driving under the above vehicle load conditions at sustained high speeds
above 160 km/h (100 mph), in countries where such speeds are permitted
by−law, inflate the front and rear tires to 240 kPa (2.4 kgf/cm
2 or bar, 35 psi)
provided that it does not exceed the maximum cold tire pressure molded on
the tire sidewall.
Normal
drivingFor all loads including full rated loads
For reduced loads (1 to 4 passengers)
Trailer driving220 (2.2, 32)
200 (2.0, 29)
220 (2.2, 32)
Wheel nut torque, N·m (kgf·m, ft·lbf):
104 (10.5, 77) Wheel size:
Spare tire 4T
Except spare tire 156JJ
NOTE: For a complete information on tires (e.g. replacing tires or replacing
wheels), see “Checking tire pressure” through “Replacing wheels” in Section
7−2.

’01CAMRY CNG (L/O0009)
2082001 CAMRY CNG_U (OM33542U)
Engine compartment
Fuses (type A)
1. A/C 10 A: Air conditioning system
2. SPARE 10 A: Spare fuse
3. SPARE 15 A: Spare fuse
4. SPARE 30 A: Spare fuse
5. ALT−S 5 A: Charging system
6. HEAD (RH) 20 A: Right−hand headlight
7. EFI 20 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system, A/F sensor
8. HORN 10 A: Horn
9. HAZARD 15 A: Emergency flasher
Engine compartment
10. AM2 30 A: Gauge and meter, SRS
airbag system, seat belt pretensioners,
multiport fuel injection system/sequen-
tial multiport fuel injection system,
“IGN” and “STARTER” fuses
11 . T E L 5 A : No circuit
12. HEAD (LH) 20 A: Left−hand headlight
13. RADIO NO.1 20 A: Audio system
14. DOME 7.5 A: Clock, ignition switch
light, trunk light, interior light, power
door lock system
15. ECU−B 10 A: Anti−lock brake system,
SRS airbag system, seat belt preten-
sioners
Instrument panel
16. A/F HTR 25 A: No circuit
17. DOOR SUB 25A: No circuit
18. INJ 20 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system, starting system
19. DRL NO.2 5 A: No circuit
20. H−LP LH (LWR) 15 A: No circuit
21. H−LP RH (LWR) 15 A: No circuit
22. SEAT−HEATER 20 A: No circuit
23. HEATER 10 A: Air conditioning system,
rear window defogger

’01CAMRY CNG (L/O0009)
2092001 CAMRY CNG_U (OM33542U)
24. GAUGE 10 A: Gauges and meters,
back−up lights, cruise control system,
charging system, power windows, ser-
vice reminder indicators and warning
buzzers
25. WIPER 25 A: Windshield wipers and
washer
26. MIRROR−HEATER 10 A: Outside rear
view mirror defogger
27. ECU−IG 15 A: Cruise control system,
anti−lock brake system, SRS airbag
system, seat belt pretensioners, shift
lock control system, multiport fuel in-
jection system/sequential multiport fuel
injection system
28. IGN 5 A: Gauges and meters, charging
system, SRS airbag system, seat belt
pretensioners, multiport fuel injection
system/sequential multiport fuel injec-
tion system
29. STOP 15 A: Stop lights, cruise control
system, high−mounted stoplight, anti−
lock brake system, shift lock control
system, multiport fuel injection system/
sequential multiport fuel injection sys-
tem30. TAIL 10 A: Parking lights, license plate
lights, tail lights, front side marker
lights, multiport fuel injection system/
sequential multiport fuel injection sys-
tem
31. POWER−OUTLET 15 A: Power outlet
32. OBD 7.5 A: On−board diagnosis sys-
tem
33. FOG 15 A: No circuit
34. STARTER 5 A: Gauges and meters,
multiport fuel injection system/sequen-
tial multiport fuel injection system
35. DOOR 25 A: Power door lock system
36. PANEL 7.5 A: Gauge and meter, audio
system, cigarette lighter, glove box
light, clock, instrument panel light con-
trol, service reminder indicators, air
conditioning control panel lights, ash-
tray light, emergency flasher, rear win-
dow defogger, electronically controlled
automatic transmission system
37. TURN 7.5 A: Emergency flasher
38. RAD−NO.2 7.5 A: Audio system
39. CIG 15 A: Cigarette lighter, shift lock
control system, power rear view mirror
controls, power door lock system, SRS
airbag system, seat belt pretensioners,
air conditioning systemFuses (type B)
40. CDS 30 A: Electric cooling fans
41. RDI 30 A: Electric cooling fans
42. MAIN 40 A: “HEAD (RH)” and “HEAD
(LH)” fuses
43. HTR 50 A: “AM1” and “A/C” fuses
44. DEF 40 A: Rear window defogger
45. PWR 30 A: Power window control sys-
tem
46. AM1 40 A: “POWER−OUTLET”, “CIG”,
“RAD−NO.2”, “TURN”, “WIPER”, “ECU−
IG”, “GAUGE”, and “HEATER” fuses
47. CDS NO.2 30 A: No Circuit
Fuses (type C)
48. ALT 100 A: “RDI” and “CDS” fuses
49. FL ABS 60 A: Anti−lock brake system

’01CAMRY CNG (L/O0009)
2102001 CAMRY CNG_U (OM33542U)

’01CAMRY CNG (L/O0009)
2112001 CAMRY CNG_U (OM33542U)
REPORTING SAFETY DEFECTS FOR U.S.
OWNERS AND UNIFORM TIRE QUALITY
GRADING
Reporting safety defects for U.S. owners212 . . . . . . . . . . . . . . . . . . . . . .
Uniform tire quality grading212 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 9

’01CAMRY CNG (L/O0009)
2122001 CAMRY CNG_U (OM33542U)
If you believe that your vehicle
has a defect which could cause a
crash or could cause injury or
death, you should immediately in-
form the National Highway Traffic
Safety Administration (NHTSA) in
addition to notifying Toyota Motor
Sales, U.S.A., Inc.
(Toll−free: 1−800−331−4331).
If NHTSA receives similar com-
plaints, it may open an investiga-
tion, and if it finds that a safety
defect exists in a group of ve-
hicles, it may order a recall and
remedy campaign. However,
NHTSA cannot become involved
in individual problems between
you, your dealer, or Toyota Motor
Sales, U.S.A., Inc.To contact NHTSA, you may ei-
ther call the Auto Safety Hotline
toll−free at 1−800−424−9393 (or
366−0123 in Washington, D.C.
area) or write to: NHTSA, U.S.
Department of Transportation,
Washington, D.C. 20590. You can
also obtain other information about
motor vehicle safety from the Hot-
line.Uniform tire quality gradingThis information has been prepared in ac-
cordance with regulations issued by the
National Highway Traffic Safety Adminis-
tration of the U.S. Department of Trans-
portation. It provides the purchasers and/
or prospective purchasers of Toyota
vehicles with information on uniform tire
quality grading.
Your authorized Toyota CNG dealer will
help answer any questions you may have
as you read this information.
DOT quality grades—All passenger car
tires must conform to Federal Safety
Requirements in addition to these
grades. Quality grades can be found
where applicable on the tire sidewall
between tread shoulder and maximum
section width. For example: Treadwear
200 Traction AA Temperature A
Reporting safety defects
for U.S. owners

’01CAMRY CNG (L/O0009)
2132001 CAMRY CNG_U (OM33542U)
Treadwear—The treadwear grade is a
comparative rating based on the wear rate
of the tire when tested under controlled
conditions on a specified government test
course. For example, a tire graded 150
would wear one and a half (1−1/2) times
as well on the government course as a
tire graded 100. The relative performance
of tires depends upon the actual condi-
tions of their use, however, and may de-
part significantly from the norm due to
variations in driving habits, service prac-
tices and differences in road characteris-
tics and climate.
Traction AA, A, B, C—The traction
grades, from highest to lowest, are AA, A,
B, and C, and they represent the tire’s
ability to stop on wet pavement as mea-
sured under controlled conditions on spe-
cified government test surfaces of asphalt
and concrete. A tire marked C may have
poor traction performance.
Warning: The traction grade assigned to
this tire is based on braking (straight
ahead) traction tests and does not include
cornering (turning) traction.Temperature A, B, C—The temperature
grades are A (the highest), B, and C,
representing the tire’s resistance to the
generation of heat and its ability to dissi-
pate heat when tested under controlled
conditions on a specified indoor laboratory
test wheel. Sustained high temperature
can cause the material of the tire to de-
generate and reduce tire life, and exces-
sive temperature can lead to sudden tire
failure. The grade C corresponds to a lev-
el of performance which all passenger car
tires must meet under the Federal Motor
Vehicle Safety Standard No. 109. Grades
B and A represent higher levels of perfor-
mance on the laboratory test wheel than
the minimum required by law.
Warning: The temperature grades for this
tire are established for a tire that is prop-
erly inflated and not overloaded. Exces-
sive speed, underinflation, or excessive
loading, either separately or in combina-
tion, can cause heat buildup and possible
tire failure.

’01CAMRY CNG (L/O0009)
2142001 CAMRY CNG_U (OM33542U)
