When waxing your vehicle, make sure that
the washer nozzles do not become
blocked. If a nozzle becomes blocked,
contact your Toyota dealer to have the
vehicle serviced.
NOTICE
If a nozzle becomes blocked, do not
try to clear it with a pin or other
object. The nozzle will be damaged.
To defog or defrost the rear window,
push the switch.
The “POWER” switch must be set at ON.
The thin heater wires on the inside of the
rear window will quickly clear the sur-
faces. An indicator light will illuminate to
indicate the defogger is operating.
Heater panels in the outside rear view
mirrors will also quickly clear the sur-
faces.
Push the switch once again to turn the
defogger off.The system will automatically shut off
when the operation time has been com-
pleted. The operation time is between 15
minutes and 1 hour depending on the am-
bient temperature and vehicle speed.
CAUTION
Since the mirror surfaces can get hot
do not touch them when the defogger
switch is on.
Make sure you turn the defoggers off
when the surfaces are clear. Leaving the
defoggers on for a long time could cause
the 12 volt battery to discharge, especially
during stop−
and−go driving. The defoggers
are not designed for drying rain water or
for melting snow.
If the outside rear view mirrors are heavi-
ly coated with ice, use a spray de −icer
before operating the switch.
NOTICE
When cleaning the inside of the rear
window, be careful not to scratch or
damage the heater wires or connec-
tors.
Rear window and outside rear
view mirror defoggers

’07Camry hybrid_U (L/O 0610)
130
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)

’07Camry hybrid_U (L/O 0610)
131
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Gauges, Meters and Service reminder indicators
Fuel gauge132
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . .
Engine coolant temperature gauge 132
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel economy meter 133
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . .
Multi −information display 134
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
Service reminder indicators and warning buzzers 150
. . . . . . . . . . . . . .
SECTION 1 6

’07Camry hybrid_U (L/O 0610)
132
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
The gauge indicates the approximate
quantity of fuel remaining in the tank
when the “POWER” switch is set at ON.
Nearly full—Needle at “F”
Nearly empty—Needle at “E”
It is a good idea to keep the tank over
1/4 full.
If the fuel level approaches “E” or the low
fuel level warning light comes on, fill the
fuel tank as soon as possible.
On inclines or curves, due to the move-
ment of fuel in the tank, the fuel gauge
needle may fluctuate or the low fuel level
warning light may come on earlier than
usual.If the fuel tank is completely empty, the
malfunction indicator lamp comes on. Fill
the fuel tank immediately.
The indicator lamp goes off after driving
several times. If the indicator lamp does
not go off, contact your Toyota dealer as
soon as possible.The gauge indicates the engine coolant
temperature when the “POWER” switch
is set at ON. The engine operating tem-
perature will vary with changes in
weather and engine load.
1. Red zone
2. Blue zone
If the needle moves into the red zone,
your engine is too hot. If your vehicle
overheats, stop your vehicle and allow the
engine to cool.
Fuel gauge Engine coolant temperature
gauge

’07Camry hybrid_U (L/O 0610)
133
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
When the needle is in the blue zone, the
coolant temperature is cold. Heat may not
be available while the coolant temperature
is the blue zone.
Your vehicle may overheat during severe
operating conditions, such as:
Driving up a long hill on a hot day.
Reducing speed or stopping after high
speed driving.
Idling for a long period with the air
conditioning on in stop−and− go traffic.
NOTICE
Do not remove the thermostat in
the engine cooling system as this
may cause the engine to overheat.
The thermostat is designed to con-
trol the flow of coolant to keep the
temperature of the engine within
the specified operating range.
 Do not continue driving with an
overheated engine. See “If your ve-
hicle overheats” on page 317 in
Section 4.The fuel economy meter indicates the
current fuel consumption in analog
form when the engine is running. When
only the traction motor powers the ve-
hicle, the needle indicates “E MODE”.
The needle may indicate the best rate
on the meter when the engine is run-
ning but the fuel is not consumed.
The needle may indicate the best rate
on the meter when fuel consumption is
less than the indicated value.
The needle may indicate the worst rate
on the meter when fuel consumption is
more than the indicated value.
Fuel economy meter

’07Camry hybrid_U (L/O 0610)
134
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
The following information is displayed
on the multiinformation display when
the “POWER” switch is set at ON.
Outside temperature and cruise in-
formation
Odometer and two trip meters
Messages
During ordinary driving, the information is
displayed. However, in case the vehicle
has a system malfunction or if there is
some information that the driver should be
informed of, a message appears on the
display. See “—Messages” on page 140
for details.
If the electrical power source has been
disconnected from the cruise information
display, the display will automatically be
set to the initial mode.
When the instrument panel lights are
turned on, the brightness of the display
will be reduced.
At extremely low temperatures, the mul-
ti −information display may respond slow-
ly.
CAUTION
Do not adjust the display while the
vehicle is moving. Be sure to adjust
the display only when the vehicle is
stopped.
Multiinformation display—

’07Camry hybrid_U (L/O 0610)
135
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
Each time you push the “DISP” button,
the display toggles through the follow-
ing information.1. Outside temperature
2. Cruising range
3. Average fuel consumption after refuel- ing
4. Driving distance
5. Average vehicle speed
6. Cruise information off
7. Zoom display of odometer and trip me- ter
8. Energy monitor
9. Eco drive level
The display will return to the outside tem-
perature display with pushing and holding
the “DISP” button for 1 second.
The displayed values in the cruise infor-
mation display indicate general driving
conditions. Accuracy varies with driving
habits and road conditions.
When the “POWER” switch is set at ON,
the last previously used mode displayed
just before the “POWER” switch is turned
off will appear.
—Outside temperature and cruise information

’07Camry hybrid_U (L/O 0610)
136
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
1. Outside temperature (“OUTSIDE TEMP”)
The outside temperature display indi-
cates the outside air temperature.
The displayed temperature ranges from
− 40 C ( −40 F) up to 50 C (122 F).
If an abnormality exists in the connection
of the outside air temperature sensor, “ −−”
or “E” will appear on the display. If “ −−”
or “E” appears on the display, contact
your Toyota dealer.
There may be a case that “−−” appears
momentarily when the “POWER” switch is
quickly set to ON. It is normal if it goes
out soon. 2. Driving range
(“CRUISING RANGE”)
The distance the vehicle can travel with
the remaining fuel is calculated and
displayed based on the quantity of re-
maining fuel and past fuel consumption.
The driving range display indicates the
approximate distance that you can drive
until the fuel gauge reaches “E”. It is
different from the actual distance traveled.
If the fuel gauge malfunctions, the mileage
figure will not appear.
When the vehicle is refueled, the driving
range is recalculated.
The actual driving range varies with driv-
ing habits and road conditions. If fuel con-
sumption is good, the driving range will be
longer than indicated. If fuel consumption
is poor, the driving range will be shorter
than indicated.
If the low fuel level warning light comes
on, refuel the vehicle even if the display
indicates that the vehicle can be driven
further. 3. Average fuel consumption after re-
fueling (“TANK AVG”)
Average fuel consumption after refuel-
ing is calculated and displayed based
on total driving distance and total fuel
consumption.
Every time you refuel the vehicle, the dis-
played value is reset.
4. Driving distance (“SINCE START”)
The driving distance after the hybrid
system started is displayed.
Every time you turn on the hybrid system,
the driving distance display is reset. 5. Average vehicle speed (“AVG SPEED”)
Average vehicle speed is calculated and
displayed based on total driving dis-
tance and total driving time.

’07Camry hybrid_U (L/O 0610)
137
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
6. Cruise information off
The display indicates only odometer and
two trip meters.
7. Zoom display of odometer and trip meter
The odometer and one of the trip meters
are displayed simultaneously. See
“—Odometer and two trip meters” de-
scribed below. 8. Energy monitor
The operating condition of the hybrid
system appears on the display.
See “Energy monitor” on page 3 for de-
tails.
9. Eco drive level
The eco drive level is visually displayed
on the multiinformation display, and it
indicates the average fuel consumption
after the hybrid system is turned on. In
accordance with the average fuel con-
sumption, the levels are displayed as
follows:
Level 0—25 MPG or less or 9.0 L/100 km or more
Level 1—26 to 30 MPG or 8.8 to 8.0 L/100 km
Level 2—31 to 35 MPG or
7.8 to 7.0 L/100 km
Level 3—36 MPG or more or 6.8 L/100 km or lessThe brightness of the arcs around the fuel
economy meter and speedometer change
according to the eco drive level. The high-
er the fuel economy, the brighter the light
becomes.
Level 0—Does not illuminate
Level 1—Illuminates weakly
Level 2—Illuminates brightly
Level 3—Illuminates most brightly
This function works even if a display other
than the eco drive level is shown on the
multi−information display.

’07Camry hybrid_U (L/O 0610)
138
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
When the hybrid system is turned off, the
eco drive level is displayed for a few
seconds to show the average fuel con-
sumption for the most recent trip.
If the average fuel consumption is in level
3, “EXCELLENT!” is simultaneously dis-
played under the eco drive level.Normal display
Zoom display
This meter displays the odometer and
two trip meters.
Selecting the zoom display of the
odometer and trip meter when the
cruise information is displayed causes
the odometer and one of the trip me-
ters to be displayed simultaneously.1. Odometer—Shows the total distance the vehicle has been driven.
2. Two trip meters—Show two different distances independently driven since
the last time each trip meter was set
to zero.
You can use one trip meter to calculate
the fuel economy and the other to
measure the distance on each trip. All
trip meter data is cancelled if the elec-
trical power source is disconnected.
—Odometer and two trip
meters
