WHAT IS NOT COVERED WARRANTY PARTS LIST
These warranty obligations do not apply to failures or noncompliance
caused by:
The use of replacement parts not certified in accordance with
aftermarket parts certification regulations.
The use of replacement parts not equivalent in quality or design
to original equipment parts.
Provisions under the “What Is Not Covered” section of the New Vehicle
Limited Warranty also apply to this warranty.
Air/Fuel Metering System

Air/fuel ratio feedback control system
Electronic fuel injection system components
– Airflow sensor
– Engine control module (8/80)
– Throttle body
– Other components
Air Induction System

Intake manifold and intake air surge tank
Catalyst System

Catalytic converter and protector (8/80)
Constricted fuel filler neck
Exhaust manifold
Exhaust pipe (manifold to catalyst and/or catalyst to catalyst)
Your Warranties in Detail16
FEDERAL EMISSION CONTROL WARRANTY
8/80 = Covered for eight years or 80,000 miles, whichever occurs first.
17365.Guts.qxd:62791_Toyota_text 7/22/10 11:39 PM Page 16

Evaporative Control System

Charcoal canister
Diaphragm valve
Fuel filler cap
Fuel tank
Hybrid System

Battery control module (8/80)*
Battery thermistor
Generator
Hybrid battery*
Hybrid control module (8/80)*
Inverter with converter*
Motor
System main relay and battery current sensor
Ignition System

Distributor and internal parts
Ignition coil and ignitor
Ignition wires
Spark plugs†
Positive Crankcase Ventilation (PCV) System

Oil filler cap
PCV valve or orifice
Other Parts Used in Above Systems

Data link connector (8/80)
Hoses, clamps, fittings, tubing and mounting hardware
Malfunction indicator light and bulb (8/80)
Pulleys, belts and idlers
Sealing gaskets and devices
Sensors, solenoids, switches and valves
FEDERAL EMISSION CONTROL WARRANTY
*
8/80 = Covered for eight years or 80,000 miles, whichever occurs first.
Covered under the Hybrid System Warranty for eight years or 100,000
miles, whichever occurs first.†Warranted until first required maintenance under terms of the California
Emission Control Warranty.
Your Warranties in Detail17
17365.Guts.qxd:62791_Toyota_text 7/22/10 11:39 PM Page 17

Parts List: Long-Term Emission Defect Warranty
(Pennsylvania and Washington Vehicles Only*)
The parts listed here are covered for seven years or 70,000 miles,
whichever occurs first.
Air/Fuel Metering System
Engine control computer (engine control module)
Throttle body
Air Induction System
Intake manifold and intake air surge tank
Catalyst System
Catalytic converter (warm-up three-way catalyst)
Exhaust front pipe
Exhaust manifoldEvaporative Control System
Charcoal canister
Fuel tank
Hybrid System
Battery control module†
Battery voltage sensor
Generator
Hybrid battery†
Hybrid control module†
Inverter with converter†
Motor
CALIFORNIA EMISSION CONTROL WARRANTY
Applies to Pennsylvania and Washington vehicles equipped with a California
Certified Emission Control Warranty.*†Covered under the Hybrid System Warranty for eight years or 100,000
miles, whichever occurs first.
Your Warranties in Detail23
