4246-3. Do-it-yourself maintenance
Check if the treadwear indicators are showing on the tires. Also check
the tires for uneven wear, such as excessive wear on one side o f the
tread.
Check the spare tire condition and pressure if not rotated.
New tread
Worn tread
Treadwear indicator
The location of treadwear indicators is shown by a “TWI” or “” mark,
etc., molded into the s idewall of each tire.
Replace the tires if the treadwear indicators are showing on a tire.
Rotate the tires in the order
shown.
To equalize tire wear and extend
tire life, Toyota recommends that
tire rotation is carried out at the
same interval as tire inspection.
Do not fail to initialize the tire
pressure warning system after
tire rotation.
Tires
Replace or rotate tires in accordance with maintenance sched-
ules and treadwear.
Checking tires
Tire rotation
1
2
3
Front

4927-2. Steps to take in an emergency
●Stop the vehicle in a safe place on a hard, flat surface.
● Set the parking brake.
● Shift the shift lever to P.
● Stop the hybrid system.
● Turn on the emergency flashers. ( P. 470)
If you have a flat tire
Your vehicle is equipped with a spare tire. The flat tire can b e
replaced with the spare tire.
For details about tires: P. 4 2 4
WARNING
■If you have a flat tire
Do not continue driving with a flat tire.
Driving even a short distance wit h a flat tire can damage the tire and the
wheel beyond repair, which cou ld result in an accident.
Before jacking up the vehicle
Location of the spare tire, jack and tools
Luggage floor cover
Wheel nut wrench
Jack Spare tire
Jack handle1
2
3
4
5

5358-1. Specifications
8
Vehicle specifications
Tire size (P. 537)
Summer tires or all season tires ( P. 4 3 1 )
An all season tire has “M+S” on the sidewall. A tire not marked “M+S”
is a summer tire.
TUBELESS or TUBE TYPE
A tubeless tire does not have a tube and air is directly put into the tire.
A tube type tire has a tube insi de the tire and the tube mainta ins the air
pressure.
Radial tires or bias-ply tires
A radial tire has “RADIAL” on the sidewall. A tire not marked “ RADIAL”
is a bias-ply tire.
DOT and Tire Identification Number (TIN) ( P. 5 3 6 )
Location of treadwear indicators ( P. 4 2 4 )
Uniform tire quality grading
For details, see “Uniform Tire Q uality Grading” that follows.
Maximum cold tire in flation pressure (P. 528)
This means the press ure to which a tire may be inflated.
Load limit at maximum cold tire inflation pressure ( P. 430)
Tire ply composition and materials
Plies are layers of rubber-coated parallel cords. Cords are the strands
which form the p lies in a tire.
“TEMPORARY USE ONLY”
A compact spare tire is identified by the phrase “TEMPORARY USE
ONLY” molded on its sidewall. This tire is designed for tempora ry
emergency use only.
1
2
3
4
5
6
7
8
9
10
11

588Alphabetical index
Shift lever ................................. 219Hybrid transmission .............. 219
If the shift lever cannot be shifted from P ................ 223
S mode ................................. 221
Shift lock system ..................... 223
Side airbags ............................... 35
Side marker lights ................... 233 Light switch ........................... 233
Replacing light bulbs ................... 458, 463, 466
Wattage ................................ 530
Side mirrors ............................. 185
Adjusting and folding ............ 185
BSM (Blind Spot Monitor) ..... 297
Side turn signal lights
Replacing light bulbs............. 466
Turn signal lever ................... 225
Smart key system .................... 166
Antenna location ................... 166
Entry functions .............. 156, 162
Starting the hybrid system .... 210
Snow tires ................................ 347
Spare tire .................................. 492 Inflation pressure .................. 528
Storage location .................... 492
Spark plug ................................ 526
Specifications .......................... 522 Speedometer............................ 102
Sport mode .............................. 340
Steering lock
Column lock release ............. 213
Steering wheel ......................... 181 Adjustment............................ 181
Audio switches
*
Meter control switches ..................... 107, 119
Stoplights
Replacing light bulbs ............ 466
Storage feature ........................ 363
Stuck If the vehicle becomes stuck ................................... 519
Sun visors ................................ 370
Sunshade
Roof ...................................... 191
Switches
Audio remote control switches
*
Automatic High Beam switch ................................. 236
Brake hold switch ................. 230
Cruise control switch ............ 276
Door lock switches................ 158
Driving mode select switches ............................. 340
Emergency flasher switch..... 470
EV drive mode switch ........... 216
