check engine TOYOTA CAMRY HYBRID 2020 (in English) Owner's Manual

5177-2. Steps to take in an emergency
7
When trouble arises
After stopping the hybrid system and waiting for 5 minutes or
more, start the hybrid system again and check for the multi-infor-
mation display.
If the message d oes not disappear:
Stop the hybrid system and contact your Toyota dealer.
If the message is not displayed:
The hybrid system temperature has dropped and the vehicle
may be driven normally.
However, if the message appears again frequently, contact your To y o t a
dealer.
WARNING
■ To prevent an accident or injury when inspecting under the hood of
your vehicle
Observe the following precautions.
Failure to do so may result in serious injury such as burns.
● If steam is seen coming from under the hood, do not open the ho od until
the steam has subsided. The engine compartment may be very hot.
● After the hybrid system has been turned off, check that the “READY” indi-
cator is off. When the hybrid system is operating, the gasoline engine may
automatically start, or the cooling fan may suddenly operate even if the
gasoline engine stops. Do not touch or approach rotating parts such as the
fan, which may lead to fingers or clothing (especially a tie, a scarf or a muf-
fler) getting caught, resulting in serious injury.
● Do not loosen the radiator cap and the coolant reservoir cap wh ile the
hybrid system and radiator are hot.
High temperature steam or coolant could spray out.
NOTICE
■ When adding engine/power control unit coolant
Wait until the hybrid system has cooled down before adding engine/power
control unit coolant.
When adding coolant, do so slowly. Adding cool coolant to a hot hybrid sys-
tem too quickly can cause damage to the hybrid system.
■ To prevent damage to the cooling system
Observe the following precautions:
● Avoid contaminating the coolant with foreign matter (such as sa nd or dust
etc.).
● Do not use any coolant additives.
6

5248-1. Specifications
*: Checking your vehicle’s model: P. 523
Engine
ModelA25A-FXS
Type4-cylinder in line, 4-cycle, gasoline
Bore and stroke 3.44  4.07 in. (87.5  103.4 mm)
Displacement 151.8 cu. in. (2487 cm3)
Valve clearance Automatic adjustment
Fuel
Fuel type Unleaded gasoline only
Octane rating87 (Research Octane Number 91) or higher
Fuel tank capacity
(Reference)13 gal. (49.3 L, 10.8 Imp. gal.)
Electric motor (Traction motor)
Type
Permanent magnet synchronous motor
Maximum output 88 kW
Maximum torque 149 ft•lbf (202 N•m, 20.6 kgf•m)
Hybrid battery (Traction battery)
AXVH70 model*AXVH71 models*
TypeLithium-ion battery Nickel-metal hydride bat-
tery
Voltage
3.7 V/cell 7.2 V/module
Capacity4.0 Ah 6.5 Ah (3HR)
Quantity70 cells 34 modules
Nominal voltage 259 V 244.8 V

5258-1. Specifications
8
Vehicle specifications
■Oil capacity (Drain and refill [Reference*])
*: The engine oil capacity is a reference quantity to be used when changing
the engine oil. Warm up the engine and turn off the hybrid system, wait
more than 5 minutes, and check the oil level on the dipstick.
■
Engine oil selection
“Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use
Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat -
isfy the following grade and viscosity.
Oil grade: API SN/RC multigrade engine oil
Recommended viscosity: SAE 0W-16
SAE 0W-16 is the best choice for
good fuel economy and good start-
ing in cold weather.
If SAE 0W-16 is not available, SAE
0W-20 oil may be used. However,
it must be replaced with SAE 0W-
16 at the next oil change.
Oil viscosity (0W-16 is explained here as an example):
• The 0W in 0W-16 indicates the characteristic of the oil which allows cold
startability. Oils with a lower value before the W allow for ea sier starting of
the engine in cold weather.
• The 16 in 0W-16 indicates the viscosity characteristic of the oil when the
oil is at high temperature. An oil with a higher viscosity (one with a higher
value) may be better suited if the vehicle is operated at high speeds, or
under extreme load conditions.
How to read oil container label:
API registered marks is added
to some oil containers to help
you select the oil you should
use.
Lubrication system
With filter 4.8 qt. (4.5 L, 4.0 Imp. qt.)
Without filter4.4 qt. (4.2 L, 3.7 Imp. qt.)
Outside temperature

580Alphabetical index
Emergency, in case ofIf a warning buzzer sounds ................................ 475
If a warning light turns on...... 475
If a warning message is displayed ............................ 485
If the 12-volt battery is
discharged .......................... 507
If the electronic key does not operate properly ................. 504
If the hybrid system will not start ........................ 502
If the vehicle is trapped in
rising water ......................... 470
If you have a flat tire ............. 491
If you lose your keys ............. 151
If you think something is wrong.................................. 474
If your vehicle becomes
stuck ................................... 518
If your vehicle has to be stopped in an emergency ... 469
If your vehicle needs to be towed .................................. 471
If your vehicle overheats ....... 514
Engine ACCESSORY mode ............. 210
Compartment ........................ 410
Engine switch........................ 208
Hood ..................................... 408
How to start the hybrid system ......... ....................... 208
Identification number ............ 523
If your vehicle has to be stopped in an
emergency.......................... 469
Ignition switch
(power switch) .................... 208
Overheating .......................... 514
Power switch......................... 208 Engine coolant
Capacity................................ 526
Checking............................... 414
Preparing and checking before winter ...................... 343
Engine coolant temperature gauge ..................................... 102
Engine oil Capacity................................ 525
Checking............................... 411
Preparing and checking before winter ...................... 343
Engine switch .......................... 208
Enhanced VSC ......................... 288
EPS (Electric Power Steering) ..... 289
Warning light......................... 476
EV drive mode ......................... 215
Event data recorder (EDR).......... 9
Exclusive jump starting terminal .................................. 507

585Alphabetical index
