TOYOTA COROLLA 1996 Repair Manual

56
4. If your child restraint system requires
the use of a top strap, latch the hook onto
the tab of the rear center belt and tighten
the top strap.
CAUTION!
Make sure the seat belt is securely
locked. Also make sure the child re-
straint system is secure by pushing
and pulling it in different direc-
tions.
5. To remove the child restraint system,
press the buckle-release button and al-
low the belt to retract. Unhook the top
strap.
ProCarManuals.com

57
To change the steering wheel angle,
pull up the lock release lever, tilt the
steering wheel to the desired angle
and release the lever.
CAUTION!

Do not adjust the steering wheel
while the vehicle is moving.

After adjusting the steering wheel,
try moving it up and down to make
sure it is locked in position.
Adjust the mirror so you can see the
side of your vehicle in the mirror.
Be careful when judging the size or dis-
tance of any object seen in the outside
rear view mirror on the passenger's side.
It is a convex mirror with a curved surface.
Any object seen in a convex mirror will
look smaller and farther away than when
seen in a flat mirror.To adjust the rear view mirror, simply
operate the control lever.
If ice should jam the mirror, do not
operate the control or scrape the
mirror face. Use a spray de-icer to
free the mirror.
NOTICE
Tilt steering wheel Outside rear view mirrorsÐÐRear view mirror remote
control
ProCarManuals.com

58
To adjust a power rear view mirror, first
push the master switch in Lº (left) or
Rº (right) depending on which mirror
needs adjusting, then push the con-
trol switch in desired direction.
If the engine is not running, the key must
be in the ACCº position.
If ice should jam the mirror, do not
operate the control or scrape the
mirror face. Use a spray de-icer to
free the mirror.
NOTICE
To fold the rear view mirror, push back-
ward.
The rear view mirrors can be folded back-
ward for parking in restricted areas.Pull the lever toward you to reduce
glare from the headlights of the ve-
hicle behind you during night driving.
Before adjusting the mirror to the position
with most clarity, push the day-night
change lever away from you (daylight
driving position).
Remember that by reducing glare you
also lose some rear view clarity.
Anti-glare inside rear view
mirror ÐFolding rear view mirrors ÐPower rear view mirror
control
ProCarManuals.com

Part 1Headlights and turn signals
59
OPERATION OF
INSTRUMENTS
AND CONTROLSÐ
Chapter 1-4
Lights, Wipers and
Defogger

Headlights and turn signals

Emergency flashers

Instrument panel light control

Interior light

Personal light

Luggage compartment light

Windshield wipers and washer

Rear window wiper and washer

Rear window defoggerTo turn the lights on, twist the knob on
the end of the lever.
Daytime running light system (Canada
only)ÐThe headlights turn on when the
parking brake is released with the engine
started, even with the light switch in the
OFFº position. They will not go off until
the ignition switch is turned off.
To turn on the other exterior lights and in-
strument panel lights, twist the knob to the
first clickstop.
Under the daytime running light system,
the headlights turn on at reduced intensi-
ty. Twist the knob to the second clickstop
to turn to full intensity for driving at night.FIRST CLICKSTOP: Only the parking,
tail, license plate, side marker and instru-
ment panel lights turn on.
SECOND CLICKSTOP: The headlights
also turn on.
If you remove the key with the headlights
left on, a buzzer reminds you to turn the
lights off when you open the driver's door.
NOTICE
To prevent the battery from being
discharged, do not leave the lights
on for a long period when the
engine is not running.
ProCarManuals.com

60
For high beam, push the lever away
from you. Pull it toward you for low
beam. For the headlight flasher, pull it
further back.
A blue light in the instrument panel indi-
cates high beam is on.
The headlight flasher works even when
the headlight switch is off.For signaling turns, move the lever up
or down in the conventional manner.
The key must be in the ºONº position.
The turn signal is self-cancelling after a
turn, but after a lane change, you may
have to cancel it by hand. You can also
signal a lane change by moving the turn
signal lever partway and holding it there.
If the green light in the instrument panel
flashes faster than normal, it indicates
that the front or rear turn signal bulb has
burned out.To turn on the emergency flashers,
push the switch.
All the turn signal lights will flash.
Turn on the emergency flashers to warn
other drivers if your vehicle must be
stopped where it might be a traffic hazard.
Always pull as far off the road as possible.
The turn signal light switch will not work
when the emergency flashers are operat-
ing.
NOTICE
To prevent the battery from being
discharged, do not leave the switch
on longer than necessary when the
engine is not running.
Emergency flashers
ProCarManuals.com

61
To adjust the brightness of the instru-
ment panel lights, turn the dial.To turn on the interior light, slide the
switch.
With the switch in the DOORº position,
the light comes on when any of the side
doors and back door are opened.To turn on the personal light, push the
switch. To turn it off, push the switch
once again.
Instrument panel light control Interior light Personal light
ProCarManuals.com

62
To turn the luggage compartment light
on, open the back door and push the
switch. Closing the back door will turn
the light off.To turn the wipers on, move the lever.
To make the washer squirt, push the
button on the end of the lever.
The key must be in the ºONº position.
The wipers will operate at intervals when
the lever is in the ºINTº position.
If the washer does not work, check to see
whether the washer tank is empty. For in-
formation on adding washer fluid, see
Adding washer fluidº in Chapter 7-3.
In cold weather, warm the windshield with
the defroster before using the washer.
This will help prevent icing, which could
block your vision.
NOTICE
Do not operate the wipers if the
windshield is dry. It may scratch the
glass.
Luggage compartment light
(wagon)Windshield wipers and washer
(intermittent type without
interval adjuster)
ProCarManuals.com

63
To turn the wipers on, move the lever.
To make the washer squirt, push the
button on the end of the lever.
The key must be in the ONº position.
The wipers will operate at intervals when
the lever is in the INTº position. With the
lever in this position, the wipers can be ad-
justed to operate at intervals of 3 to 10 se-
conds depending on the interval adjuster
setting between Sº and Fº.
Also, the wipers will automatically operate
a couple of times after the washer squirts
even with the lever in the OFFº position.If the washer does not work, check to see
whether the washer tank is empty. For in-
formation on adding washer fluid, see
Adding washer fluidº in Chapter 7-3.
In cold weather, warm the windshield with
the defroster before using the washer.
This will help prevent icing, which could
block your vision.
NOTICE
Do not operate the wipers if the
windshield is dry. It may scratch the
glass.
To turn the wipers on, move the lever.
To make the washer squirt, push the
button on the end of the lever.
The key must be in the ONº position.
If a single wipe is desired in mist, push the
lever to the MISTº position and release it.
If the washer does not work, check to see
whether the washer tank is empty. For in-
formation on adding washer fluid, see
Adding washer fluidº in Chapter 7-3.
In cold weather, warm the windshield with
the defroster before using the washer.
This will help prevent icing, which could
block your vision.
Windshield wipers and washer
(intermittent type with interval
adjuster)Windshield wipers and washer
(mist type)
ProCarManuals.com

64
NOTICE
Do not operate the wipers if the
windshield is dry. It may scratch the
glass.
To turn the rear wiper and washer on,
twist the knob at the end of the lever.
The key must be in the ONº position.
The wipers will operate at intervals when
the lever is in the INTº position.
The washer squirts at the two marked knob
positions. The knob will automatically re-
turn from these positions when it is re-
leased.
If the washer does not work, check to see
whether the washer tank is empty. For in-
formation on adding washer fluid, see
Adding washer fluidº in Chapter 7-3.
NOTICE
Do not operate the rear wiper if the
rear window is dry. It may scratch
the glass.
To defog or defrost the rear window,
push the switch.
The key must be in the ONº position.
The thin heater wires on the inside of the
rear window will quickly clear the sur-
faces. An indicator light will illuminate to
indicate the defogger is operating.
Push the switch once again to turn the de-
fogger off.
With timer: The system will automatically
shut off after the defogger has operated
about 15 minutes.
Rear window defogger Rear window wiper and washer
ProCarManuals.com

65
Make sure you turn the defogger off when
the window is clear. Leaving the defogger
on for a long time could cause the battery
to discharge, especially during stop-and-
go driving. The defogger is not designed
for drying rain water or for melting snow.
NOTICE
Without timer: To prevent the bat-
tery from being discharged, turn
the switch on when the engine is
running.
When cleaning the inside of the
rear window, be careful not to
scratch or damage the heater
wires.
