Your automatic transmission has a shift
lock system to minimize the possibility of
incorrect operation. This means you can
only shift out of Pº position when the
brake pedal is depressed (with the ignition
switch in ONº position and the lock re-
lease button depressed).
(a) Normal Driving
1. Start the engine as instructed in How
to start the engineº in Part 3. The trans-
mission must be in Pº or Nº.
2. With your foot holding down the brake
pedal, shift the selector lever to Dº.
In Dº position, the automatic transmis-
sion system will select the most suitable
gear for running conditions such as nor-
mal cruising, hill climbing, hard towing,
etc.
Always turn the overdrive switch on for
better fuel economy and quieter driving. If
the engine coolant temperature is low, the
transmission will not shift into the over-
drive gear even with the overdrive switch
on.
Never put your foot on the accelera-
tor pedal while shifting.CAUTION
!
3. Release the parking brake and brake
pedal. Depress the accelerator pedal
slowly for smooth starting.(b) Using engine braking
To use engine braking, you can downshift
the transmission as follows:

Turn off the overdrive switch. The O/D
OFFº indicator light will come on and
the transmission will downshift to the
third gear.

Shift into the 2º position. The trans-
mission will downshift to the second
gear when the vehicle speed drops
down to or lower than the maximum al-
lowable speed for second gear, and
more powerful engine braking will be
obtained.

Shift into the Lº position. The trans-
mission will downshift to the first gear
when the vehicle speed drops down to
or lower than the maximum allowable
speed for Lº position and maximum
engine braking will be applied.
MAXIMUM ALLOWABLE SPEEDS
2º 110 km/h (68 mph). . . . . . . . . . . .
Lº 60 km/h (38 mph). . . . . . . . . . . . .
ProCarManuals.com

77
Be careful when downshifting on a
slippery surface. Abrupt shifting
could cause the vehicle to spin or
skid.CAUTION
!
NOTICE
Be careful not to overrev the en-
gine. Watch the tachometer to keep
engine rpm from going into the red
zone. The maximum allowable
speed (approximate) for each posi-
tion is given above for your refer-
ence.
Do not continue hill climbing for a
long time in the 2º or Lº position.
This may cause severe automatic
trasmission damage from over-
heating. To prevent such damage,
use Dº position for hill climbing
or hard towing.
(c) Backing up
1. Bring the vehicle to a complete stop.
2. With the brake pedal held down with
your foot, shift the selector lever to the Rº
position.
NOTICE
Never shift into reverse while the
vehicle is moving.
(d) Parking
1. Bring the vehicle to a complete stop.
2. Pull the parking brake lever up fully to
securely apply the parking brake.
3. With the brake pedal pressed down,
shift the selector lever to the Pº position.
While the vehicle is moving never
attempt to move the selector lever
into Pº position under any circum-
stances. Serious mechanical da-
mage and loss of vehicle control
may result.CAUTION
!
(e) Good driving practice

If the transmission is repeatedly up-
shifted and downshifted between third
gear and overdrive when climbing a
gentle slope, the overdrive switch
should be turned off. Be sure to turn
the switch on immediately afterward.

When towing a trailer, in order to main-
tain engine braking efficiency, do not
use overdrive.
Always keep your foot on the brake
pedal while stopped with the engine
running. This prevents the vehicle
from creeping.CAUTION
!
NOTICE
Do not hold the vehicle on an
upgrade with the accelerator pedal.
It can cause the transmission to
overheat. Always use the brake
pedal or parking brake.
(f) If you cannot shift the selector lever
out of Pº position
If you cannot shift the selector lever from
Pº position even though the brake pedal
is depressed, use the shift lock override
button. For instructions, see If you can-
not shift automatic transmission slelector
leverº in Part 4.
ProCarManuals.com

78
The shift pattern is conventional as
shown above.
Press the clutch pedal down fully while
shifting, and then release it slowly. Do not
rest your foot on the pedal while driving,
because it will cause clutch trouble. And
do not use the clutch to hold the vehicle
when stopped on an uphill gradeÐuse the
parking brake.
Recommended shifting speeds
The transmission is fully synchronized
and upshifting or downshifting is easy.For the best compromise between fuel
economy and vehicle performance, you
should upshift or downshift at the follow-
ing speeds:
Low altitude
Ð1219 m (4000 ft) or lower
gear km/h (mph)
1 to 2 or 2 to 1 24 (15)
2 to 3 or 3 to 2 37 (23)
3 to 4 or 4 to 3 64/45*
1 (40/28*1)
4 to 5 or 5 to 4 72/64*1 (45/40*1)
*1: For constant-speed cruise or
constant-speed cruise after decel-
eration.
High altitude
ÐHigher than 1219 m (4000 ft)
Upshifting
gear km/h (mph)
1 to 2 24 (15)
2 to 3 40/57*
2(25/36*2)
3 to 4 64/72*2(40/45*2)
4 to 5 72/88*2(45/55*2)
Downshifting
gear km/h (mph)
2 to 1 24 (15)
3 to 2 40 (25)
4 to 3 64 (40)
5 to 4 72 (45)
*
2: 4A-FE onlyÐApplicable under heavy
acceleration conditions.Upshifting too soon or downshifting too late
will cause lugging, and possibly pinging.
Regularly revving the engine to maximum
speed in each gear will cause excessive
engine wear and high fuel comsumption.
Maximum allowable speeds
To get on a highway or to pass slower traf-
fic, maximum acceleration may be neces-
sary. Make sure you observe the following
maximum allowable speeds in each gear:
4A-FE engine
gear km/h (mph)
1 46 (29)
2 86 (54)
3 126 (78)
4 170 (106)
7A-FE engine
gear km/h (mph)
1 53 (33)
2 88 (55)
3 128 (80)
4 173 (108)
NOTICE
Do not downshift if you are going
faster than the maximum allowable
speed for the next lower gear.
Manual transmission
ProCarManuals.com

79 Good driving practice

If it difficult to shift into reverse, put the
transmission in neutral, release the
clutch pedal momentarily, and then try
again.

When towing a trailer, in order to main-
tain engine braking efficiency, do not
use the fifth gear.
Be careful when downshifting on a
slippery surface. Abrupt shifting
could cause the vehicle to spin or
skid.CAUTION
!
NOTICE
Make sure the vehicle is completely
stopped before shifting into reverse.
To set: Pull up the lever.
To release: Pull up slightly, press the
thumb button, and lower.
Before leaving your vehicle, firmly apply
the parking brake. For better holding pow-
er, first depress the brake pedal and hold
it while setting the parking brake.
Before driving, be sure the parking
brake is fully released and the park-
ing brake reminder light is off.CAUTION
!
The cruise control allows you to cruise
the vehicle at a desired speed over 40
km/h (25 mph) even with your foot off
the accelerator pedal.
Your cruising speed can be maintained up
or down grades within the limits of engine
performance, although a slight speed
change may occur when driving up or down
the grades. On steeper hills, a greater
speed change will occur so it is better to
drive without the cruise control.
Parking brake Cruise control
ProCarManuals.com

80

To help maintain maximum control
of your vehicle, do not use the
cruise control when driving in
heavy or varying traffic, or on slip-
pery (rainy, icy or snow-covered)
or winding roads.

Avoid vehicle speed increases
when driving downhill. If the ve-
hicle speed is too fast in relation to
the cruise control set speed, can-
cel the cruise control then down-
shift the transmission to use en-
gine braking to slow down.CAUTION
!
TURNING ON THE SYSTEM
To operate the cruise control, push the
CRUISE ON-OFFº switch. This turns the
system on. The indicator light in the instru-
ment panel shows that you can now set
the vehicle at a desired cruising speed.
Another push will turn the system com-
pletely off.
To avoid accidental cruise control
engagement, keep the CRUISE ON-
OFFº switch off when not using the
cruise control.CAUTION
!
SETTING AT A DESIRED SPEED
On vehicles with automatic transmission,
the transmission must be in Dº before
you set the cruise control speed.
Bring your vehicle to the desired speed,
press the SET/COASTº direction and re-
lease it. This sets the vehicle at that
speed. Now you may take your foot off the
accelerator pedal. If you need accelera-
tionÐfor example, when passingÐde-
press the accelerator pedal enough for
the vehicle to exceed the set speed.
When you release it, the vehicle will return
to the speed set prior to the acceleration.
For manual transmission:
While driving with the cruise control
on, do not shift to neutral without
depressing the clutch pedal, as this
may cause engine racing or overrev-
ing.CAUTION
!
CANCELLING THE PRESET SPEED
You can cancel the preset speed by:
a. Pulling the control lever in the CAN-
CELº direction and releasing it.
b. Depressing the brake pedal.
c. Depressing the clutch pedal (manual
transmission).If the vehicle speed falls below about 40
km/h (25 mph), the preset speed will auto-
matically cancel out.
If the vehicle speed drops 16 km/h (10
mph) below the preset speed, the preset
speed will also automatically cancel out.
If the preset speed automatically cancels
out other than for the above cases, have
your vehicle checked by your Toyota deal-
er at the earliest opportunity.
RESETTING AT A FASTER SPEED
Press the control lever upward in the
RES/ACCº direction and hold it. Release
the lever when the desired speed is at-
tained. While the lever is held upward, the
vehicle will gradually gain speed.
However, a faster way to reset is to accel-
erate the vehicle and then press the lever
downward in the SET/COASTº direction.
RESETTING AT A SLOWER SPEED
Push the control lever downward in the
SET/COASTº direction and hold it. Re-
lease the lever when the desired speed is
attained. While the lever is held down-
ward, the vehicle speed will gradually de-
crease.
ProCarManuals.com

81 However, a faster way to reset is to de-
press the brake pedal and then press the
control lever downward in the SET/
COASTº direction.
RESUMING THE PRESET SPEED
If the preset speed is cancelled by pulling
the control lever or by depressing the
brake pedal or clutch pedal, pushing the
lever up in the RES/ACCº direction will
restore the speed set prior to cancellation.
However, once the vehicle speed falls be-
low about 40 km/h (25 mph), the preset
speed will not be resumed.
CRUISE CONTROL FAILURE WARNING
If the CRUISEº indicator light in the in-
strument cluster flashes when using the
cruise control, there is some trouble in the
cruise control system. Contact your Toyo-
ta dealer and have your vehicle inspected.ProCarManuals.com

82ProCarManuals.com

Part 1Car audio system operating tips
83
OPERATION OF
INSTRUMENTS
AND CONTROLSÐ
Chapter 1-7
Car audio system
and Air conditioning
system
Car audio system operating tips
AM-FM radio with electronic
tuner
AM-FM radio with electronic
tuner and cassette tape player
Air conditioning controls
Heater controls
Side vents
You can listen to the car audio system
when the ignition key is at ONº or
ACCº. However, if the engine is not
running, the key must be in the ACCº
position.
ILLUMINATION CONTROL LOGIC
On some audio-units, when the instru-
ment panel lights are on, the letters on op-
erable buttons of the mode in current use
light up together with the mode selection
and eject buttons.
RADIO
FM reception tips
Most of us are not aware that a vehicle is
not an ideal place to listen to a radio. Be-
cause it moves, reception conditions
change continuously. Buildings, terrain,
signal distance and noise from other ve-
hicles are all working against good recep-
tion. Some FM reception conditions may
appear to be problems even though they
are normal.
The following characteristics are normal
for a given reception area, and they do not
indicate any problem with the radio itself.
Fading and Drifting: On the average,
the broadcast range of FM stations is
limited to about 40 km (25 miles), ex-
cept for some high power stations.If a vehicle is moving away from the
desired station's transmitter, the signal
will tend to fade and/or drift. This phe-
nomenon is more noticeable with FM
than with AM, and is accompanied by
distortion.
Fading and drifting can be minimized
to a certain degree by fine tuning, or
you should tune in to a stronger signal.
Static and Fluttering: When the line-
of-sight path between a transmitter
and vehicle is blocked by large build-
ings or the like, static or fluttering may
occur because of the characteristic of
FM. In a similar effect, a fluttering
noise is sometimes heard when driv-
ing along a tree-lined road.
This static and fluttering can be re-
duced by adjusting the tone control for
greater bass response until the distur-
bance has passed.
Multipath: Because of the reflection
characteristics of FM, direct and re-
flected signals may reach the antenna
at the same time (a phenomenon
called multipath reception) and cancel
each other out. As a vehicle moves
through these electronic dead spots,
the listener may hear a momentary
flutter or lose reception.

ProCarManuals.com

84Station swapping: When two FM sta-
tions are close to each other, and an
electronic dead spot, such as is
caused by static or multipath recep-
tion, interrupts the original signal,
sometimes the stronger second signal
is picked up automatically until the
original one returns. This swapping
can also occur as you drive away from
the selected station and approach
another station with a stronger signal.
On models with a power antenna, the an-
tenna automatically extends to its full
height when the radio and ignition are
turned on.
To lower the power antenna, turn off the
audio system by pushing PWR.VOLº, or
turn the ignition key to LOCKº.
On some models, the power antenna au-
tomatically retracts when the radio mode
is switched off to turn on the cassette tape
player.
Before extending the power antenna,
confirm that no one is close enough to get
injured by it.
To prevent damage to the antenna,
make sure it is retracted before
driving your vehicle through an
automatic car wash.
NOTICE
CASSETTE TAPE PLAYER
Use only undamaged cassette tapes of
good quality. Avoid using tapes with a
total playing time longer than 90 min-
utes.
Using damaged tapes will cause trouble
with the tape player. Longer tapes are not
recommended because of their thinness.
Before inserting a cassette, make sure
the tape is not slack and that the label
is firmly stuck on the shell.
Wind the tape firmly by turning the hub
with a pencil or the like.
Be careful not to touch the exposed tape
surface.
When not in use, take the cassette out
of the player, put it back into its case
and store it away from dust, magnets
and direct sunlight.
Leaving cassettes on the dashboard in
the sun could damage your tapes.
Keep the playback head, capstan and
pinch roller clean.
Remove tape coating residue accumu-
lated on the head, capstan and pinch roll-
er once or twice a month. A cleaning tape
is available on the market.
Do not oil any part of the player and
do not insert anything other than
cassette tapes into the slot, or the
tape player may be damaged.
NOTICE
ProCarManuals.com

85
AMFM radio with electronic tuner (type A)
ProCarManuals.com
