TOYOTA COROLLA 2016 11.G Owners Manual

1814-2. Driving procedures
4
Driving
COROLLA_TMMMS_TMMC_U (OM12J84U)
*1: To improve fuel efficiency and reduce noises, set the shift lever in D fornormal driving.
*2: Selecting gear step using the M position achieves suitable engine brakingforces by operating the shift lever.
Press the switch.
For powerful acceleration and driv-
ing in mountainous regions.
Press the switch again to return to
normal mode.
To drive in temporary gear steps selection mode, operate the “-” and
“+” paddle shift switches. The gear steps can then be selected by
operating the “-” and “+” paddle shift switches. By selecting gear step
using paddle shift switches, you can control engine braking forces.
Upshifting
Downshifting
The selected gear step, from D1 to
D7, will be displayed in the meter.
To return to normal D position driv-
ing, the “+” paddle shift switch must
be held down for a period of time.
Shift position purpose
Shift positionObjective or function
PParking the vehicle/starting the engine
RReversing
NNeutral
DNormal driving*1
M7-speed sport sequential shiftmatic mode driving*2
( P. 182)
Sport mode
Temporarily engaged gear steps selection mode in the D posi-
tion
1
2

1824-2. Driving procedures
COROLLA_TMMMS_TMMC_U (OM12J84U)
To enter 7-speed sport sequential shiftmatic mode, shift the shift lever
to M. Gear steps can then be selected by operating the shift lever,
allowing you to drive in the gear step of your choosing.Upshifting
Downshifting
The gear changes once every time
the shift lever is operated.
The selected gear step, from M1 to
M7, will be displayed in the meter.
However, even when in the M posi tion, the gear steps will be auto-
matically changed if the engine s peed is too high, or too low.
nGear step functions
lYou can choose from 7 levels of engine braking force.
l A lower gear step will provide greater engine braking force than a higher
gear step, and the engine speed will also increase.
n If the “M” indicator flashes or a buzze r beeps after shifting the shift lever
to M
This may indicate a malfunction in the continuously variable transmission
system. Have the vehicle inspected by your Toyota dealer immediately.
(In this situation, the transmission will operate in the same manner as when
the shift lever is in D.)
n When the vehicle comes to a stop with the shift lever in the M position
l The transmission will automatically downshift to M1 once the vehicle is
stopped.
l After a stop, the vehicle will start off in M1.
l When the vehicle is stopped, the transmission is set at M1.
Changing gear steps in the M position
1
2

1834-2. Driving procedures
4
Driving
COROLLA_TMMMS_TMMC_U (OM12J84U)n
When driving with cruise control activated
Even when performing the following actions with the intent of enabling engine
braking, engine braking will not activate because cruise control will not be
canceled.
lWhile driving in D or 7-speed sport sequential shiftmatic mode, downshifting
to 6, 5 or 4. ( P. 182)
l When switching the driving mode to sport mode while driving in D position.
(P. 181)
n Downshifting restrictions warning buzzer
To help ensure safety and driving performance, downshifting operation may
sometimes be restricted. In some circumstances, downshifting may not be
possible even when the shift lever is operated. (A buzzer will sound twice.)
n Sport mode automatic deactivation
Sport mode is automatically deactivated if the engine switch is turned off after
driving in sport mode.
n If the shift lever cannot be shifted from P
P. 534
CAUTION
nWhen driving on slippery road surfaces
Be careful of downshifting and sudden acceleration, as this could result in
the vehicle skidding to the side or spinning.

1844-2. Driving procedures
COROLLA_TMMMS_TMMC_U (OM12J84U)
Fully depress the clutch pedal before operating the shift lever, and
then release it slowly.
Shift the shift lever to R while lift-
ing up the ring section.
Manual transmission
: If equipped
Shifting the shift lever
Shifting the shift lever to R

1854-2. Driving procedures
4
Driving
COROLLA_TMMMS_TMMC_U (OM12J84U)
nMaximum allowable speeds
Observe the following maximum allowable speeds in each gear when maxi-
mum acceleration is necessary.
mph (km/h)
Shift position
Maximum speed
Vehicles with 15-inch and 16-inch tiresVehicles with 17-inch tires
130 (49)30 (49)
256 (91)56 (90)
382 (133)82 (132)
4111 (179)111 ( 1 7 9 )
5
NOTICE
nTo prevent damage to the transmission
lDo not lift up the ring section except when shifting the lever to R.
l Shift the shift lever to R only when the vehicle is stationary.
lDo not shift the shift lever to R without
depressing the clutch pedal.

1864-2. Driving procedures
COROLLA_TMMMS_TMMC_U (OM12J84U)
Right turn
Lane change to the right (move
the lever partway and release
it)
The right hand signals will flash 3
times.
Lane change to the left (move
the lever partway and release
it)
The left hand signals will flash 3
times.
Left turn
nTurn signals can be operated when
Vehicles without a smart key system
The engine switch is in the “ON” position.
Vehicles with a smart key system
The engine switch is in IGNITION ON mode.
n If the indicator flashes faster than usual
Check that a light bulb in the front or rear turn signal lights has not burned
out.
n Customization
The number of times the turn signals flash during a lane change can be
changed. (Customizable feature P. 576)
Turn signal lever
Operating instructions
1
2
3
4

1874-2. Driving procedures
4
Driving
COROLLA_TMMMS_TMMC_U (OM12J84U)
To set the parking brake, fully
pull the parking brake lever
while depressing the brake
pedal.
To release the parking brake,
slightly raise the lever and
lower it completely while press-
ing the button.
*1:For U.S.A.
*2: For Canada
nParking brake engaged warning buzzer
A buzzer will sound if the vehicle is driven at a speed of approximately 3 mph
(5 km/h) or more with the parking brake engaged. ( P. 498, 510)
n Usage in winter time
P. 221
Parking brake
Operating instructions
*1*2
1
2
NOTICE
nBefore driving
Fully release the parking brake.
Driving the vehicle with the parking brake set will lead to brake components
overheating, which may affect braking performance and increase brake
wear.

188
COROLLA_TMMMS_TMMC_U (OM12J84U)
4-3. Operating the lights and wipers
Turning the end of the lever turns on the lights as follows:
Ty p e AThe daytime running
lights turn on.
( P. 192)
The side marker, park-
ing, tail, license plate,
daytime running lights
(  P. 192) and instru-
ment panel lights turn
on.
The headlights and all
the lights listed above
(except daytime run-
ning lights) turn on.
The daytime running
lights turn off.
*: Vehicles with a multi-information display
Headlight switch
The headlights can be operated manually or automatically.
Operating instructions
*
1
2
3
4

1894-3. Operating the lights and wipers
4
Driving
COROLLA_TMMMS_TMMC_U (OM12J84U)
Ty p e BThe daytime running
lights turn on ( P. 192)
The side marker, park-
ing, tail, license plate,
daytime running lights
(  P. 192) and instru-
ment panel lights turn
on.
The headlights and all
the lights listed above
(except daytime run-
ning lights) turn on.
*: Vehicles with a multi-information display
*
1
2
3

1904-3. Operating the lights and wipers
COROLLA_TMMMS_TMMC_U (OM12J84U)
Ty p e CThe headlights and all
the lights listed below
turn on and off auto-
matically.
(Vehicles without a
smart key system:
When the engine
switch is in the “ON”
position)
(Vehicles with a smart
key system: When the
engine switch is in
IGNITION ON mode)
The side marker, park-
ing, tail, license plate,
daytime running lights
( P. 192) and instru-
ment panel lights turn
on.
The headlights and all the lights listed above (except day-
time running lights) turn on.
The daytime running lights turn off.
*: Vehicles with a multi-information display
*
1
2
3
4
