783-1. Basic operation
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
1Press the “MAP” button.
2 Check that the current posi-
tion map is displayed.
 To correct the current posi-
tion manually:  P. 1 1 7
●While driving, the cu rrent position
mark is fixed on the screen and
the map moves.
●The current position is automati-
cally set as the vehicle receives
signals from the GPS (Global
Positioning System). If the current
position is not correct, it is auto-
matically corrected after the vehi-
cle receives signals from the GPS.
●After the 12-volt battery discon-
nection, or on a new vehicle, the
current position may not be cor-
rect. As soon as the navigation
system receives signals from the
GPS, the correct c urrent position
is displayed.
1 Select or to change
the scale of the map screen.
●The scale indicator bar appears at
the bottom of the screen.
●Select and hold or to con-
tinue changing the scale of the
map screen.
●The scale of the map screen can
also be changed by selecting the
scale bar directly. This function is
not available while driving.
●Pinch outward on the screen to
zoom in and pinch inward to zoom
out.
●In areas where a micro city map is
available, will change to
when the map screen is set to the
smallest scale.
Map screen operation
Current position display
Map scale

793-1. Basic operation
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
For areas covered by the micro
city map (some major cities), a
micro city map on a scale of 75
ft. (25 m) can be selected.
When the map is scaled down to
150 ft. (50 m), changes to and can be selected to dis-
play the micro city map.
1 Select on the map
screen.
2 Check that the micro city
map is displayed.
●To return to the normal map dis-
play, select .
●If the map or the c urrent position
is moved to the are a which is not
covered by the micro city map, the
screen scale automatically
changes to 150 ft. (50 m).
●On the micro city map, a one way
street is displayed by .
●Scrolling the micro city map is not
available while driving.
●Certification
Building micro cities in the database
were created and provided by
HERE.
The orientation of the map can
be changed between 2D
north-up, 2D heading-up and 3D
heading-up by selecting the ori-
entation symbol displayed at the
top left of the screen.
: North-up symbol
Regardless of the direction of
vehicle travel, north is always
up.
: Heading-up symbol
The direction of vehicle travel is
always up.
: 3D Heading-up symbol
The direction of vehicle travel is
always up.
 The letter(s) under this sym-
bol indicate the vehicle’s
heading direction (e.g. N for
north).
Micro city map
Orientation of the map

813-1. Basic operation
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
some countries or areas.
1 Select on the map
screen. ( P.76)
2 Select “Map Mode”.
3 Select the desired configura-
tion button.
Select to display the single
map screen.
Select to display the dual
map screen. ( P.81)
Select to display the com-
pass mode screen. ( P. 8 2 )
Select to display the turn list
screen. ( P.104)
Select to display the freeway
exit list screen. ( P.101)
Select to display the intersec-
tion guidance screen or the
guidance screen on the free-
way. ( P.103)
Select to display the
turn-by-turn arrow screen.
( P.104)
 Depending on the conditions,
certain screen configuration
buttons cannot be selected. The map on the left is the main
map. The right side map can be
edited.
1
Select any point on the right
side map.
2 Select the desired item.
Select to change the orienta-
tion of the map. ( P. 7 9 )
Select to display POI icons.
( P.82)
Select to show traffic infor-
mation.
* (  P. 8 4 )
Select to change the map
scale. ( P. 7 8 )
*: This function is not available in
some countries or areas.
3 Select “OK”.
Switching the map mode
A
B
C
D
E
F
G
'XDOPDS
A
B
C
D

833-1. Basic operation
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
3 Check that the selected POI
is displayed on the map
screen.
The traveled route can be stored
and retraced on the map screen.
This feature is available when
the map scale is 30 miles (50
km) or less.
1 Select on the map
screen. ( P.76)
2 Select “Route Trace”.
 The route trace starts.
3 Check that the traveled line is
displayed.
1 Select on the map
screen. ( P.76)
2 Select “Route Trace” again.
3 A confirmation screen will be
displayed.
“Yes”: Select to keep the recorded route trace.
“No”: Select to erase the recorded
route trace.
●The traveled route can be stored
up to approximately 621 miles
(1000 km).
When the cursor is placed over
an icon on the map screen, the
name is displayed at the top of
the screen. If is shown to the
right of the name, detailed infor-
mation can be displayed.
1
Place the cursor over an
icon.
2 Select .
3 Check that the information
screen is displayed.
“ Save”: Select to register as a
Route trace
Start recording the route
trace
Stop recording the route
trace
Displaying information
about the icon where the
cursor is set

853-1. Basic operation
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
Select to display nearby traf-
fic information. ( P.85)
Select to display a map with
predictive traffic data.
( P. 8 6 )
Select to display traffic along
the saved routes. ( P.86)
When the route has been set
Select to display traffic infor-
mation for the set route.
( P. 8 5 )
Select to display nearby traf-
fic information. ( P.85)
Select to display a map with
predictive traffic data.
( P. 8 6 )
Select to display traffic along
the saved routes. ( P.86)
●If a large amount of information is
being received, it may take longer
than normal for the information to
be displayed on the screen.
●If traffic information cannot be
received because the vehicle is
outside of HD Ra dio coverage
area, it may still be able to be
received using DCM. ( P.180)
A list of current traffic informa-
tion can be displayed along with
information on the location of
each incident.
1 Display the traffic incidents
screen. ( P. 8 4 )
2 Select “Traffic Events on Cur-
rent Road”, “Traffic Events on
Current Route” or “Traffic
Events Nearby”.
3 Select the desired traffic
information.
When “Traffic Events Nearby”
is selected, depending on
whether the traffic flow infor-
mation is enabled/disabled,
the following will be displayed:
When enabled: Traffic event and
congestion information
When disabled: Traffic event infor-
mation only
4Check that the traffic informa-
tion is displayed.
“Detail”: Select to display detailed
traffic information.
B
C
D
A
B
C
D
Displaying traffic informa-
tion

873-2. Destination search
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
3-2.Destination search
The destination screen enables
to search for a destination. The
destination screen can be
reached by the following meth-
ods:
■From the map screen
1 Press the “MAP” button.
2 Select .
3 Follow the steps in “From the
menu screen” from step 3.
( P. 8 7 )
■From the menu screen
1 Press the “MENU” button.
2 Select “Destination”.
3 Select the desired search
method.
Select to set a destination by home. (
P.88)
Select to search for a desti-
nation by entering keywords.
( P.88)
Select to search for a desti-
nation via the Toyota
response center.
* (  P.240)
Select to search for a desti-
nation from a registered entry
in “Favorites”. ( P. 8 9 )
Select to search for a desti-
nation from recent set desti-
nations. ( P. 8 9 )
Select to search for a desti-
nation from emergency ser-
vice points. ( P.90)
Select to search for a desti-
nation by address. ( P. 9 1 )
Select to search for a desti-
nation by point of interest.
( P.91)
Select to search for a desti-
nation from contact data
which had been transferred
to the navigation system from
a registered Bluetooth
®
phone. ( P.90)
*: This function is not available in
some countries or areas.
●To hide the destination screen,
touch any part of the map screen.
Destination search
operation
Destination screen
A
B
C
D
E
F
G
H
I

883-2. Destination search
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
The selected state (province)
can be changed to set a desti-
nation from a different state
(province) by using “Address” or
“Point of Interest”.
1Display the destination
screen. ( P.87)
2 Select “Address” or “Point of
Interest”.
3 Select “Change State/Prov-
ince”.
4 Select the desired state
(province).
 To change countries, select
“Change Country”.
To use this function, it is neces-
sary to register a home address.
( P.110)
1 Display the destination
screen. ( P.87)
2 Select “Home”.
 The navigation system per-
forms a search for the route
and the route overview is dis- played. (
P.96)
The destination can be
searched by entering various
keywords.
1 Display the destination
screen. ( P. 8 7 )
2 Select “Search”.
3 Enter characters on the key-
board.
4 Select “Search”.
5 When there is more than 1
result, select the desired item
from the list.
: Select to display updated infor-
mation about the selected entry.
This function is displayed only
when there is information from the
Cloud.
●To search for a facility name using
multiple search words, put a
space between each word.
●Search results may differ depend-
ing on the connected services
subscription status and communi-
cation status.
Selecting search area
Setting home as destina-
tion
Searching by keyword

893-2. Destination search
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
To use this function, it is neces-
sary to register a favorites list
entry. ( P. 111 )
1 Display the destination
screen. ( P.87)
2 Select “Favorites”.
3 Select the desired favorites
list entry.
*: This function is not available in
some countries or areas.
A Destination Assist operator
can search for a destination.
You can request a specific busi-
ness, address, or ask for help
locating your desired destina-
tion. ( P.240)
1 Display the destination
screen. ( P.87)
2 Select “Dest Assist”. 1
Display the destination
screen. ( P. 8 7 )
2 Select “Recent”.
3 Select the desired destina-
tion.
“Sort/Delete”: Sele ct to sort (date,
name) or delete destination(s).
●Up to 100 previous ly set destina-
tions are displayed on the screen.
1 Select “Sort/Delete”.
2 Select “Delete Recent Desti-
nations”.
3 Select the desired recent
destination(s) to be deleted.
4 Select “Yes” when the confir-
mation screen appears.
“Sort/Delete All”: Select to sort
(date, name) desti nations or delete
all.
Searching by favorites list
Searching by Destination
Assist*
Searching by recent desti-
nations
Deleting recent destina-
tions

903-2. Destination search
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
1Display the destination
screen. ( P.87)
2 Select “Emergency”.
3 Select the desired emer-
gency category.
4 Select the desired destina-
tion.
●The navigation system does not
guide in areas where route guid-
ance is unavailable. ( P.123)
To use this function, it is neces-
sary to have contact data which
had been transferred to the nav-
igation system from a registered
Bluetooth
® phone. ( P.199)
1 Display the destination
screen. ( P. 8 7 )
2 Select “Contacts”.
3 Select the desired contact.
4 Select “Addresses”.
5 Select the desired address.
6 Follow the steps in “Search-
ing by keyword” from step 4.
( P.88)
●This function may not be available
depending on the type of Blue-
tooth
® phone.
Searching by emergencySearching by contact

913-2. Destination search
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
1 Display the destination
screen. ( P.87)
2 Select “Address”.
 If a state (province) has not
been selected yet,
“State/Province” screen is dis-
played. ( P. 8 8 )
3 Enter a house number and
select “Search”.
4 Enter a street name and
select “Search”.
5 Select the desired street
name.
6 Enter a city name and select
“Search”.
7 Select the desired city name.
 If multiple locations with the
same address exist, the
address list screen will be dis-
played. Select the desired
address.
●A street name ca n be searched
using only the body part of its
name.
For example: S WESTERN AVE
• A search can be performed by entering “S WESTERN AVE”,
“WESTERN AVE” or “WEST-
ERN”.
There are 3 methods to search
for a destination by Points of
Interest.
1 Display the destination
screen. ( P. 8 7 )
2 Select “Point of Interest”.
3 Select the desired search
method.
Select to change the search
area. ( P. 8 8 )
Select to search by name.
( P.92)
Select to search by category.
( P.92)
Select to search by phone
number. ( P.93)
 When selecting some search
methods, if a state (province)
has not been selected yet,
“State/Province” screen is dis-
played. ( P.88)
Searching by addressSearching by point of
interest
A
B
C
D
