852-1. Instrument cluster
2
Vehicle status information and indicators
This distance is computed based
on your average fuel consumption.
As a result, the actual distance that
can be driven may differ from that
displayed.
When only a small amount of fuel is
added to the tank, the display may
not be updated.
When refueling, turn the engine
switch off. If the vehicle is refueled
without turning the engine switch
off, the display may not be updated.
■Eco Driving Indicator
Eco Driving Indica tor will not oper-
ate under the following conditions:
●The shift lever is in any position
other than D.
●The vehicle speed is approxi-
mately 80 mph (130 km/h) or
higher.
■Driving support system
information
Select to display the operational
status of the following systems:
 LTA (Lane Tracing Assist)
( P.208)
 LDA (Lane Departure Alert)
( P.213)
 PCS (Pre-Collision System)
( P.198)
 Dynamic radar cruise control
( P.220)
 RSA (Road Sign Assist) (if
equipped) ( P.218)
■Navigation system-linked
display (if equipped)
Select to display the following
navigation system-linked infor-
mation:
 Route guidance to destination
 Compass display (head-
ing-up display)
Select to enable selection of an
audio source or track on the
meter using the meter control
switches.
This menu icon can be set to be
displayed/not displayed in .
■Drive information
Displays drive info rmation such as
the following:
Drive information type
Drive information items
Displays the following depend-
ing on which drive information
Driving support system
information display
Audio system-linked dis-
play (if equipped)
Vehicle information dis-
play

912-1. Instrument cluster
2
Vehicle status information and indicators
Eco Driving Indicator Light
During Eco-friendly acceleration
(Eco driving), the Eco Driving Indi-
cator Light will turn on. When the
acceleration exceeds the Zone of
Eco driving, or when the vehicle is
stopped, the light turns off.
Eco Driving Indicator Zone
Display
Suggests the Zone of Eco driving
with current Eco driving ratio based
on acceleration.
Eco driving ratio based on
acceleration
If the acceleration exceeds the
Zone of Eco driving, the right side
of the Eco Driving Indicator Zone
Display will illuminate.
At this time, the Eco Driving Indica-
tor Light will turn off.
Zone of Eco driving
 Driving range
Displays driving range with remain-
ing fuel. Use the d isplayed values
as a reference only. This distance is computed based
on your average f
uel consumption.
As a result, the actual distance that
can be driven may differ from that
displayed.
When only a small amount of fuel is
added to the tank, the display may
not be updated.
When refueling, turn the engine
switch off. If the ve hicle is refueled
without turning the engine switch
off, the display may not be updated.
■Eco Driving Indicator
Eco Driving Indicator will not oper-
ate under the following conditions:
●The shift lever is in any position
other than D.
●The vehicle spe ed is approxi-
mately 80 mph (130 km/h) or
higher.
■Driving support system
information
Select to display the operational
status of the following systems:
 Dynamic radar cruise control
( P.220)
 LTA (Lane Tracing Assist)
( P.208)
 LDA (Lane Departure Alert)
( P.213)
■Navigation system-linked
display (if equipped)
Select to display the following
navigation system-linked infor-
mation:
Driving support system
information display

2184-5. Using the driving support systems
*: If equipped
When the front camera detects a sign or information
of a sign is available from the
navigation system, the sign
will be displayed on the dis-
p l a y.
 Multiple signs can be dis-
played.
Depending on the specifications of
the vehicle, the number of dis-
played signs may be limited.
■Operating conditions of sign
display
Signs will be displayed when the fol-
lowing conditions are met:
●The system has detected a sign
In the following si tuations, a dis-
played sign may stop being dis-
played:
●When a new sign has not been
detected for a certain distance
●When the system determines that
the road being driven on has
changed, such as after a left or
right turn
■Situations in which the display
function may not operate prop-
erly
In the following situ ations, the RSA
system may not operate properly
and may not detect signs or may
display the incorrect sign. However,
this does not indicate a malfunction.
●When a sign is dirty, faded, tilted
or bent
●When the contrast of an electronic
sign is low
●When all or part of a sign is hidden
by a tree, utility pole, etc.
●When a sign is d etected by the
front camera for a short amount of
time
●When the driving state (turning,
changing lanes, etc.) is judged
incorrectly
RSA (Road Sign
Assist)*
The RSA system detects
specific road signs using
the front camera and/or nav-
igation system (when speed
limit information is avail-
able) and warns the driver
via displays and buzzers.
WARNING
■For safe use
●Driving safely is solely the
responsibility of the driver. Pay
careful attention to the sur-
rounding conditions in order to
ensure safe driving.
●Do not rely solely upon the
RSA. The RSA assists the
driver by providing road sign
information, but it is not a
replacement for the driver’s own
vision and awareness. Driving
safely is solely the responsibility
of the driver. Pay careful atten-
tion to the surrounding condi-
tions in order to ensure safe
driving.
■Situations in which the RSA
should not be used
●When it is necessary to disable
the system: P. 1 9 2
■Situations in which the sys-
tem may not operate properly
●Situations in wh ich the sensors
may not operate properly:
 P. 1 9 6
Display Function

2194-5. Using the driving support systems
4
Driving
●When a sign is immediately after a
freeway junction or in an adjacent
lane just before merging
●When stickers are attached to the
rear of a preceding vehicle
●When a sign similar to a system
compatible sign is detected as a
system compatible sign
●When a speed limit sign for a
frontage road is within detection
range of the front camera
●When driving around a round-
about
●When a sign intended for trucks,
etc. is detected
●When the navigation system map
data is out of date
●When the navigation system can-
not be used
In this case, the speed limit signs
displayed on the multi-information
display and navigat ion system dis-
play may differ.
In the following situations, the
RSA system will output a warn-
ing to notify the driver.
 If the vehicle speed exceeds
the speed warning threshold
of the speed limit sign dis-
played on the display, the sign
display will be emphasized
and a buzzer will sound.
 When the RSA system
detects a do not enter sign
and determines that the vehi-
cle has entered a no-entry
area, the do not enter sign
displayed on the display will
flash and a buzzer will sound.
■Operating conditions of the
notification functions
●Excess speed notification function
This function will operate when the
following condition is met:
• A speed limit road sign is recog- nized by the system.
●No entry notification function
This function will operate when all of
the following conditions are met:
• More than one no entry road signs are recognized by the system
simultaneously.
• The vehicle is passing between no entry road signs recognized by the
system.
 The following types of road
signs can be displayed.
However, non-standard or recently
introduced traffic signs may not be
displayed.
Notification function
Types of road signs sup-
ported
Speed limit
Do Not Enter
No U-turn
No Turn On Red

481Alphabetical Index
M
MaintenanceDo-it-yourself maintenance .. 340
General maintenance ........... 336
Maintenance data................. 428
Maintenance requirements... 334
Malfunction indicator lamp.... 392
Manual air conditioning system ............................................... 286
Menu icons ......................... 82, 89
Meter Clock ................................ 76, 79
Indicators................................ 74
Instrument panel light control78, 81
Meter control switches ..... 82, 89
Meters .............................. 76, 79
Multi-information display .. 82, 89
Settings ............................ 86, 93
Warning lights....................... 391
Warning message ................ 401
Mirrors Inside rear view mirror.......... 129
Outside rear view mirror defog-gers ............................ 288, 295
Outside rear view mirrors ..... 130
Vanity mirrors ....................... 318
Moon roof Door lock linked moon roof oper-ation ................................... 135
Jam protection function ........ 135
Operation ............................. 135
Multi-information display Audio system-linked display . 85, 92
AWD Control .......................... 86
Clock ................................ 78, 81
Cruise control ....................... 231
Driving information display83, 90
Driving support system informa- tion display ..................... 85, 91 Dynamic radar cruise control 223
Eco Driving Indicator ........84, 90
Fuel economy ...................83, 90
Menu icons .......................82, 89
Meter control switches......82, 89
Navigation system-linked display
.......................................85, 91
Settings ............................86, 93
Stop & Start system information .............................................87
Suggestion function ..........87, 94
Tire pressure ...... ............86, 353
Vehicle information display85, 92
Warning message.................401
N
Navigation system-linked display ...........................................85, 91
Noise from under ve hicle...........5
O
Odometer.............................77, 80
Odometer and trip meter display
Display change button ......77, 80
Display items ....................77, 81
Oil Engine oil..............................430
Rear differential oil................433
Open tray .................................306
Opener Back door ..................... 111, 112
Fuel filler door.......................188
Hood .....................................342
Outside rear view mirrors Adjustment ...........................131
BSM (Blind Spot M onitor) .....243
Folding..................................131
Outside rear view mirror defog- gers ............................288, 295
RCTA function.......................248
Safe Exit Assist.....................254

486Alphabetical Index
LTA (Lane Tracing Assist) ... 208, 395
Open door ......... ........... 105, 107
Seat belt ....................... 394, 395
Warning lights ........................ 391 ABS ...................................... 393
Brake hold operated indicator........................................... 398
Brake Override System ........ 393
Brake system ....................... 391
Charging system .................. 392
Cruise control indicator ........ 397
Drive-Start Control ............... 393
Driving assist information indica- tor ....................................... 397
Dynamic radar cruise control indicator.............................. 396
Electric power steering ......... 393
High coolant temperature ..... 391
Intuitive parking assist OFF indi- cator ................................... 396
LDA indicator ........................ 396
Low engine oil pressure ....... 392
Low fuel level ....................... 394
LTA indicator ......................... 395
Malfunction indicator lamp ... 392
Parking brake indicator ........ 398
Pre-collision system ............. 396
Seat belt reminder light 394, 395
Slip indicator......................... 397
SRS ...................................... 392
Stop & Start cancel indicator 396
Tire pressure ........................ 395
Warning messages................. 401
Washer Checking .............................. 350
Preparing and c hecking before
winter.................................. 279
Switch................................... 184
Washing and waxing .............. 328
Weight Cargo capacity ..................... 150 Load limits ............................150
Wheels .....................................365 Replacing .............................365
Size ......................................434
Window lock switch ...............134
Windows Power windows ....................132
Rear window defogger .288, 295
Washer .................................184
Windshield wiper de-icer289, 298
Windshield wipers ..................184
Winter driving tips ..................279
Wireless charger.....................310
Wireless remote control Battery-Saving Function ....... 119
Locking/Unlocking ................100
Replacing the battery ...........368
For vehicles with Audio Plus or Premium Audio,
refer to “MULTIMEDIA
OWNER’S MANUAL” for
information regarding the
equipment listed below.
· Navigation system
· Audio/visual system
· Rear view monitor system
