4448-1. Specifications
8-1.Specifications
*1: Unladen vehicles
*2: LE or XLE grade vehicles
*3: S, SE or XSE grade vehicles
*4: Vehicles with 215/65R17 tires
*5: Vehicles with 225/55R18 tires
■Vehicle identification num-
berThe vehicle identification num-
ber (VIN) is the legal identifier
Maintenance data (fuel, oil level, etc.)
Dimensions and weight
Overall length175.6 in. (4460 mm)*2
176.8 in. (4490 mm)*3
Overall width71.9 in. (1825 mm)
Overall height*164.8 in. (1645 mm)
Wheelbase103.9 in. (2640 mm)
Tread*1
Front61.7 in. (1566 mm)*4
61.3 in. (1556 mm)*5
Rear
61.7 in. (1567 mm)*2,4
61.7 in. (1568 mm)*3,4
61.3 in. (1557 mm)*2,5
61.3 in. (1558 mm)*3,5
Vehicle capacity weight
(Occupants + luggage)940 lb. (425 kg)
Trailer Weight Rating
(Trailer weight + cargo weight)1500 lb. (680 kg)
Seating capacity
Seating capacity5 (Front 2, Rear 3)
Vehicle identification

4558-1. Specifications
8
Vehicle specifications
Speed symbol (alphabet with
one letter)
■Tire dimensionsSection width
Tire height
Wheel diameter
Bead
Sidewall
Shoulder
Tread
Belt
Inner liner
Reinforcing rubber
Carcass
Rim lines
Bead wires Chafer
This information has been pre-
pared in accordance with regu-
lations issued by the National
Highway Traffic Safety Adminis-
tration of the U.S. Department of
Transportation.
It provides the purchasers
and/or prospective purchasers
of Toyota vehicles with informa-
tion on uniform tire quality grad-
ing.
Your Toyota dealer will help answer
any questions you may have as you
read this information.
■DOT quality grades
All passenger vehicle tires must
conform to Federal Safety
Requirements in addition to
these grades. Quality grades
can be found where applicable
on the tire sidewall between
tread shoulder and maximum
section width.
For example: Treadwear 200 Trac-
tion AA Temperature A
■Treadwear
The treadwear grade is a com-
parative rating based on the
wear rate of the tire when tested
under controlled conditions on a
specified government test
course.
For example, a tire graded 150
Tire section names
Uniform Tire Quality
Grading

491Alphabetical Index
Windshield............................ 300
Differential Rear differential oil ............... 448
Dimensions ............................. 444
Dinghy towing ........................ 173
Display Cruise control ....................... 246
Dynamic radar cruise control 238
Energy monitor ..................... 105
Intuitive parking assist .......... 268
Multi-information display .. 90, 98
RCTA .................................... 258
Warning message ................ 412
Display change button ....... 85, 89
Do-it-yourself maintenance ... 341
Door lock Back door ............................. 119
Side doors ............................ 115
Smart key system................. 129
Wireless remote control ....... 113
Doors Automatic door locking and unlocking system................ 118
Back door ............................. 119
Door glasses ........................ 143
Door lock .............................. 119
Open door warning buzzer . 116, 11 8
Outside rear view mirrors ..... 141
Rear door child-protectors.... 118
Drive distance ................... 95, 102
Drive information ............. 95, 102
Drive-Start Control (DSC) Sudden start restraint control159
Driving Break-in tips ......................... 154
Correct driving posture ........... 23
Driving mode select switch... 283
Hybrid vehicle driving tips .... 289
Procedures ........................... 153
Winter drive tips ................... 291
Driving information display91, 99 Driving range ......................92, 99
Driving support system informa-
tion display......................95, 102
DSC (Drive-Start Control) Sudden start restraint control159
Dynamic radar cruise control 235
E
ECO Accelerator Guidance....93, 100
Eco score ..........................93, 100
EDR (Event data recorder) .........8
E-Four ......................................285
Elapsed time .....................95, 102
Electric motor (t raction motor)68
Electric Power Steering (EPS) ...............................................285Warning light.........................405
Electronic key ......................... 112 Battery-saving function .........130
If the electronic key does not operate properly .................431
Replacing the battery ...........382
Emergency Driving Stop System ...............................................250
Emergency flashers ...............394
Emergency tire puncture .......417
Emergency, in case of If a warning buzzer sounds ..402
If a warning light turns on .....402
If a warning message is dis-played .................................412
If the 12-volt battery is dis- charged ..............................433
If the electronic key does not operate properly .................431
If the fuel filler door cannot be opened ...............................430
If the hybrid sys tem will not start
...........................................428
If the vehicle is submerged or water on the road is rising ..396
