893-2. Destination search
COROLLA_H/B_Navi_U
3
Navigation system
2 Select the desired item.
Select to add destinations.
( P. 8 9 )
Select to delete destinations.
( P. 8 9 )
Select to reorder destina-
tions. ( P.95)
Select to set route prefer-
ences. ( P.95)
When the vehicle is stopped
1 Select “Add”.
2 Search for an additional des-
tination in the same way as a
destination search. ( P. 7 9 )
 Up to 5 destinations can be
set.
3 Select “Add Destination
Here” at the position in the
route which you want to add
the destination.
While driving
1 Select “Add”.
2 Search for an additional des-
tination in the same way as a
destination search. ( P. 7 9 ) 
Up to 5 destinations can be
set.
3 Select “Beginning” or “End”.
1 Select “Delete”.
2 Select “Yes” when the confir-
mation screen appears.
 If more than 1 destination has
been set, select the destina-
tion(s) to be deleted. (The
navigation system will recal-
culate route(s) to the remain-
ing set destination(s).)
*: This function is not made avail-
able in some countries or areas.
When starting route guidance or
rerouting, a route can be pro-
vided automatically by the
Toyota Entune center. This func-
tion is available when dynamic
route setting is enabled.
( P.102)
Adding destinations
A
B
C
D
'HOHWLQJGHVWLQDWLRQV
$URXWHIURPWK\
H7R\RWD
(QWXQHFHQWHU
9HKLFOHV
ZLWK'&0\f

913-3. Route guidance
COROLLA_H/B_Navi_U
3
Navigation system
2 Check that the list of the dis-
tance and time is displayed.
 By selecting one of the num-
ber buttons, the desired route
information is displayed.
“Arrival Time”: Select to display the
estimated arrival time.
“Time to Dest.”: Select to display
the estimated travel time.
●When the vehicle is on the guid-
ance route, the distance mea-
sured along the route is displayed.
Travel time and arrival time are
calculated based on the average
speed of the specified speed limits
and current traffic information.
●When the vehicle gets off the
guidance route, the arrow facing
the destination is displayed
instead of the estimated
travel/arrival time.
●The route information bar fills from
left to right as the vehicle pro-
gresses along the route.
During freeway driving, the free-
way information screen can be
displayed. Distance from the current
position to the freeway
exit/rest area
Name of the freeway exit/rest
area
POIs that are close to a free-
way exit
Select to display the selected
map of the exit vicinity.
Select to display the nearest
freeway exits/rest areas from
the current position.
: Select to scroll to farther free-
way exits/rest areas.
: Select to scroll to closer free-
way exits/rest areas.
When the vehicle approaches
an exit or junction, the freeway
guidance screen will be dis-
played.
During freeway driving
When approaching free-
way exit or junction
A
B
C
D
E

933-3. Route guidance
COROLLA_H/B_Navi_U
3
Navigation system
an intersection, the intersection
guidance screen will be dis-
played. Next street name
Distance to the intersection
Select to hide the intersection
guidance screen.
• To return to the intersection guid-ance screen, press the “MAP”
button.
Remaining distance bar to
the guidance point
●This function is available when
“Intersection Zoom Map” is set to
on. ( P.102)
1Select “Turn List” on the map
mode screen. ( P.73)
2 Check that the turn list
screen is displayed.
Turn direction Distance between turns
Next street or destination
name
On this screen, information
about the next turn on the guid-
ance route can be displayed.
1 Select “Turn-by-Turn Arrow”
on the map mode screen.
( P.73)
2 Check that the turn-by-turn
arrow screen is displayed.
Exit number or street name
Turn direction
Distance to the next turn
Turn list screen
A
B
C
D
A
7XUQE\WXUQD\
UURZVFUHHQ
B
C
A
B
C

943-3. Route guidance
COROLLA_H/B_Navi_U
●If a voice guidance command can-
not be heard, press the “MAP”
button to hear it again.
●To adjust the voice guidance vol-
ume: P. 6 0
●To mute the voice guidance:
 P. 9 0
●Voice guidance may be made
early or late.
●If the navigation system cannot
determine the current position cor-
rectly, you may not hear voice
guidance or may not see the mag-
nified intersection on the screen.
1 Select on the map
screen. ( P. 6 8 )
2 Select the desired item to be
set.
Select to display the over-
view of the entire route.
( P.87)
Select to reorder destina-
tions. ( P.95)
Select to change route type.
( P.95)
Select to set route prefer-
ences. ( P. 9 5 )
Select to set detours.
( P.95)
Select to start from adjacent
road. ( P. 9 6 )
 To hide the route options
screen, touch any part of the
map screen.
3 Check that the route over-
view is displayed. ( P.87)
Typical voice
guidance prompts
As the vehicle approaches
an intersection, or point,
where maneuvering the
vehicle is necessary, the
navigation system’s voice
guidance will provide vari-
ous messages.
WA R N I N G
●Be sure to obey the traffic regu-
lations and keep the road condi-
t i o n i n m i n d e s p e c i a l l y w h e n y o u
are driving on IPD roads (roads
that are not completely digitized
in our database). The route
guidance may not have the
updated information such as the
direction of a one way street.
Editing route
Displaying the edit route
screen
A
B
C
D
E
F

953-3. Route guidance
COROLLA_H/B_Navi_U
3
Navigation system
When more than 1 destination
has been set, the arrival order of
the destinations can be
changed.
1 Select on the map
screen. ( P.68)
2 Select “Reorder”.
3 Select the desired destina-
tion and select “Move Up” or
“Move Down” to change the
arrival order. Then select
“OK”.
1 Select on the map
screen. ( P.68)
2 Select “Route Type”.
3 Select the desired route type.
 The entire route from the
starting point to the destina-
tion is displayed. ( P.87)
 During driving, the route guid-
ance starts after selecting the
desired route type.
The conditions to determine the
route can be selected from vari-
ous choices such as freeways,
toll roads, ferries, etc.
1 Select on the map
screen. ( P.68)
2 Select “Preference”. 3
Select the desired route pref-
erences and select “OK”.
●Even if the “Freeways” route pref-
erence is turned off, the route may
not be able to avoid freeways in
some cases.
●If the calculated route includes a
trip by ferry, the route guidance
shows a sea route. After traveling
by ferry, the curre nt position may
be incorrect. Upon reception of
GPS signals, it is automatically
corrected.
During the route guidance, the
route can be changed to detour
around a section of the route
where a delay is caused by road
repairs, an accident, etc.
1 Select on the map
screen. ( P. 6 8 )
2 Select “Detour”.
3 Select the desired detour dis-
tance.
Select to detour within 1 mile
of the current position.
Select to detour within 3
miles of the current position.
Select to detour within 5
miles of the current position.
Reordering destinations
Selecting route type
Setting route preferences
Detour setting
A
B
C

963-3. Route guidance
COROLLA_H/B_Navi_U
Select to detour on the entire
route.
Select to make the navigation
system search for the route
based on traffic congestion
information received from
traffic information.
* ( P. 7 6 )
*: This function is not made avail-
able in some countries or areas.
●This picture shows an example of
how the navigation system would
guide around a delay caused by a
traffic jam.
This position indi cates the loca-
tion of a traffic jam caused by
road repairs, an accident, etc.
This route indicates the detour
suggested by the navigation sys-
tem.
●When the vehicle i s on a freeway,
the detour distance selections are
5, 15 and 25 miles (or 5, 15 and
25 km if units are in km).
●The navigation system may not be
able to calculate a detour route
depending on the selected dis-
tance and surrounding road condi-
tions.
When a freeway and a surface
road run in parallel, the naviga-
tion system may show the guid- ance route going on the freeway
while driving on the surface
road, or vice versa.
If this happens, you can
instantly choose the adjacent
road for the route guidance.
1
Select on the map
screen. ( P. 6 8 )
2 Select “Adjacent Road”.
●When there is no adjacent road,
this screen butt on will not be dis-
played.
Adjacent road
D
E
A
B

973-4. Setup
COROLLA_H/B_Navi_U
3
Navigation system
3-4.Setup
1 Press the “MENU” button.
2 Select “Setup”.
3 Select “Navigation”.
4 Select the desired item to be
set. Select to set home. (
P. 9 7 )
Select to set the favorites list.
( P.98)
Select to set areas to avoid.
( P.100)
Select to set detailed naviga-
tion settings. ( P.102)
●When “Useful Navi. Information
Settings” is displayed on the
screen: P. 1 1 0
If home has been registered,
that information can be recalled
by selecting on the destina-
tion screen. ( P. 7 9 )
1 Display the navigation set-
tings screen. ( P.97)
2 Select “Home”.
Navigation settings
Home, favorites list entries,
areas to avoid can be set as
memory points. The regis-
tered points can be used as
the destinations. ( P.79)
Registered areas to avoid,
will be avoided when the
navigation system searches
for a route.
Displaying navigation set-
tings screen
Navigation settings
screen
Setting up home
A
B
C
D

983-4. Setup
COROLLA_H/B_Navi_U
3Select the desired item to be
set.
Select to register home.
( P. 9 8 )
Select to edit home. ( P.98)
Select to delete home.
( P. 9 8 )
1 Select “Save Home”.
2 Select the desired item to
search for the location.
( P. 7 9 )
3 Select “OK” when the editing
home screen appears.
1 Select “Edit”.
2 Select the desired item to be
edited.
Select to edit the home name. (
P.99)
Select to set display of the
home name on/off.
Select to edit location infor-
mation. ( P. 9 9 )
Select to change the icon to
be displayed on the map
screen. ( P.100)
3 Select “OK”.
1 Select “Delete”.
2 Select “Yes” when the confir-
mation screen appears.
Points on the map can be regis-
tered.
1 Display the navigation set-
tings screen. ( P.97)
2 Select “Favorites”.
3 Select the desired item.
Select to register favorites list
entries. ( P. 9 9 )
Select to edit favorites list
entries. ( P. 9 9 )
Select to delete favorites list
Registering home
Editing home
A
B
C
A
'HOHWLQJKRPH
6HWWLQJXSID\
YRULWHVOLVW
B
C
D
A
B
C

993-4. Setup
COROLLA_H/B_Navi_U
3
Navigation system
entries. ( P.100)
1 Select “New”.
2 Select the desired item to
search for the location.
( P. 7 9 )
3 Select “OK” when the editing
favorites list screen appears.
( P. 9 9 )
●Up to 100 favorites list entries can
be registered.
The icon, name, location and/or
phone number of a registered
favorites list entry can be edited.
1Select “Edit”.
2 Select the desired favorites
list entry.
 Each time a star icon is
selected, its color will change.
Colored star icons indicate
that the favorite is registered
to the corresponding preset
destination button. Up to 2
entries can be registered as
quick favorite destinations.
( P. 8 5 ) 3
Select the desired item to be
edited.
Select to edit the favorites list
entry name. ( P.99)
Select to set display of the
favorites list entry name
on/off.
Select to edit location infor-
mation. ( P. 9 9 )
Select to edit the phone num-
ber. ( P.100)
Select to change the icon to
be displayed on the map
screen. ( P.100)
4 Select “OK”.
1 Select “Name”.
2 Enter a name and select
“OK”.
1 Select “Location”.
2 Scroll the map to the desired
point ( P.72) and select
“OK”.
Registering favorites list
entries
Editing favorites list
entries
Changing the name
Changing the location
A
B
C
D
E

1003-4. Setup
COROLLA_H/B_Navi_U
1Select “Phone #”.
2 Enter the phone number and
select “OK”.
1 Select “Icon”.
2 Select the desired icon.
 “Page 1”/“Page 2”: Select to
change pages.
“With Sound”: Select the desired
icons with sound
■When “With Sound” is
selected
A sound for some favorites list
entries can be set. When the
vehicle approaches the location
of the favorites list entry, the
selected sound will be heard.
1 Select “With Sound”.
2 Select the desired sound
icon.
: Select to play the sound.
●When “Bell (with Direction)” is
selected, select an arrow to adjust
the direction and select “OK”.
●The bell sounds only when the
vehicle approaches this point in
the direction th at has been set.
1Select “Delete”.
2 Select the desired item to be
deleted.
“Sort/Delete All”: Select to sort
(date, name, icon) or delete all
favorite list entries.
3Select “Yes” when the confir-
mation screen appears.
Areas to be avoided because of
traffic jams, construction work or
other reasons can be registered
as “Areas to Avoid”.
1 Display the navigation set-
tings screen. ( P.97)
2 Select “Areas to Avoid”.
3 Select the desired item.
Select to register areas to
avoid. ( P.101)
Select to edit areas to avoid.
( P.101)
Select to delete areas to
avoid. ( P.102)
Changing phone number
Changing the icon
Deleting favorites list
entries
Setting up areas to avoid
A
B
C
