display TOYOTA COROLLA HATCHBACK 2019 Accessories, Audio & Navigation (in English)

1013-4. Setup
COROLLA_H/B_Navi_U
3
Navigation system
1 Select “New”.
2 Select the desired item to
search for the location.
( P. 7 9 )
3 Select either or to
change the size of the area to
be avoided and select “OK”.
4 Select “OK” when the area to
avoid screen appears.
●If a destination is entered in the
area to avoid or th e route calcula-
tion cannot be made without run-
ning through the a rea to avoid, a
route passing through the area to
be avoided may be shown.
●Up to 10 locations can be regis-
tered as points/areas to avoid.
The name, location and/or area
size of a registered area can be
edited.
1 Select “Edit”.
2 Select the desired area. 3
Select the desired item to be
edited.
Select to edit the name of the
area to avoid. ( P.101)
Select to set display of the
area to avoid name on/off.
Select to edit area location.
( P.101)
Select to edit area size.
( P.101)
Select to set the area to
avoid function on/off.
4 Select “OK”.
1 Select “Name”.
2 Enter a name and select
“OK”.
1 Select “Location”.
2 Scroll the map to the desired
point ( P.72) and select
“OK”.
1 Select “Size”.
Registering areas to avoid
Editing areas to avoid
Changing the name
Changing the location
Changing the area size
A
B
C
D
E

1023-4. Setup
COROLLA_H/B_Navi_U
2Select either or to
change the size of the area to
be avoided and select “OK”.
1 Select “Delete”.
2 Select the desired area to be
deleted.
3 Select “Yes” when the confir-
mation screen appears.
1Press the “MENU” button.
2 Select “Setup”.
3 Select “Navigation”.
4 Select “Detailed Navi. Set-
tings”.
5 Select the desired items to
be set.
Deleting areas to avoidDetailed navigation
settings
Settings are available for
pop-up information, favor-
ite POI categories, low fuel
warning, etc.
Displaying the detailed
navigation settings
screen

1033-4. Setup
COROLLA_H/B_Navi_U
3
Navigation system
 “Low Fuel Warning Pop-up”
Select to set display of low fuel
warning on/off. ( P.103)
 “Unverified Roads Guidance
Warning”
Select to set unverified roads guid-
ance warning on/off.
“Guidance on Unverified
Roads”
Select to set IPD road (roads that
are not completely digitized in our
database) guidance on/off.
“Guidance with Street Names”
Select to set the voice guidance for
the next street name on/off.
“Favorite POI Categories”
Select to set favorite POI catego-
ries that are used for POI selection
to display on the map screen.
(  P.104)
 “Calibration”
Select to adjust the current position
mark manually or to adjust miscal-
culation of the di stance caused by
tire replacement. ( P.104)
 “Adaptive Route”
Select to enable/d isable adaptive
routes. When enabled, the naviga-
tion system will provide frequently
used routes.
 “Reset Adaptive Route”
Select to erase adaptive route data.
“Automatic Destination List
Info”
Select to set automatic destination
list information on/off. When set to
on, the estimated time of arrival to
the registered ho me and preset
destinations from the current posi-
tion will be displayed.
 “Intersection Zoom Map”
Select to set display of a guidance
screen on/off.
“Automatic Zoom”
Select to set automatic zoom func-
tion on/off. When it is enabled, as
the vehicle approaches a guidance
point, the map will change to a
detailed map automatically.
 “State Border Guidance”
Select to set cross-border guidance
on/off.
“Map Color Customization”
Select to set the map display color.
“Map Animation”
Select to set map animation on/off.
“Dynamic Route”*
Select to enable/disable routes
sourced from the Toyota Entune
center. ( P.89)
 “Restore the default settings”
Select to reset all setup items.
*: This function is not made avail-
able in some countries or areas.
When the fuel level is low, a
warning message will pop up on
the screen.
Detailed navigation set-
tings screen
Low fuel warning

1043-4. Setup
COROLLA_H/B_Navi_U
1Display the detailed naviga-
tion settings screen.
( P.102)
2 Select “Low Fuel Warning
Pop-up”.
3 Select “On” or “Off”.
A nearby gas station can be
selected as a destination when
the fuel level is low.
1 Select “Yes” when the low
fuel warning appears.
2 Select the desired nearby
gas station.
3 Select “Enter” to set as a
destination.
“Info”: Select to display gas station
information. ( P. 7 5 )
Up to 6 POI icons, which are
used for selecting POIs on the
map screen, can be selected as
favorites.
1 Display the detailed naviga-
tion settings screen.
( P.102)
2 Select “Favorite POI Catego-
ries”. 3
Select the desired category
to be changed.
“Default”: Select to set the default
categories.
4 Select the desired POI cate-
gory.
“List All Categories”: Select to dis-
play all POI categories.
5Select the desired POI icon.
6 Select “OK”.
The current position mark can
be adjusted manually. Miscalcu-
lation of the distance caused by
tire replacement can also be
adjusted.
1 Display the detailed naviga-
tion settings screen.
( P.102)
2 Select “Calibration”.
3 Select the desired item.
 For additional information on
the accuracy of a current
position: P. 1 1 1
Searching gas station in low
fuel warning
Favorite POI categories
(Select POI icons)
Current position/Tire
change calibration

1053-4. Setup
COROLLA_H/B_Navi_U
3
Navigation system
When driving, the current posi-
tion mark will be automatically
corrected by GPS signals. If
GPS reception is poor due to
location, the current position
mark can be adjusted manually.
1 Select “Position/Direction”.
2 Scroll the map to the desired
point ( P.71) and select
“OK”.
3 Select an arrow to adjust the
direction of the current posi-
tion mark and select “OK”.
The tire change calibration func-
tion will be used when replacing
the tires. This function will adjust
miscalculation caused by the
circumference difference
between the old and new tires.
1 Select “Tire Change”.
 The message appears and
the quick distance calibration
starts automatically.
●If this procedure is not performed
when the tires are replaced, the
current position mark may be
incorrectly displayed.
*: This function is not made avail-
able in some countries or areas.
1 Press the “MENU” button.
2 Select “Setup”.
3 Select “Traffic”.
4 Select the desired items to
be set.
Position/Direction calibra-
tion
Tire change calibration
Traffic settings*
Traffic information such as
traffic congestion or traffic
incident warnings can be
made available.
Displaying the traffic set-
tings screen
Screen for traffic settings

1063-4. Setup
COROLLA_H/B_Navi_U
Select to set specific routes
(such as frequently used
routes) on which you wish to
receive traffic information.
(P.106)
Select to set the avoid traffic
function auto/manual.
( P.108)
Select to set the usage of
traffic information for the esti-
mated arrival time on/off.
Select to set the display of an
arrow of free flowing traffic
on/off.
Select to set to on/off
whether to consider the pre-
dictive traffic information
( P.77) with estimated
arrival time and detoured
route search.
Select to set traffic incident
voice warning on/off.
Select to reset all setup
items.
Specific routes (such as fre-
quently used routes) on which
you wish to receive traffic infor-
mation can be registered as “My Traffic Routes”. A route is set by
defining a start point and end
point, and can be adjusted by
setting up to 2 preferred roads.
1
Display the traffic settings
screen. ( P.105)
2 Select “My Traffic Routes”.
3 Select the desired item.
Select to register personal
traffic routes. ( P.106)
Select to edit personal traffic
routes. ( P.107)
Select to delete personal traf-
fic routes. ( P.107)
1 Select “New”.
2 Select “Name”.
3 Enter the name and select
“OK”.
4 Select “Start”.
5 Select the desired item to
search for the location.
( P.79)
6 Select “End”.
My traffic routesA
B
C
D
E
F
G
5HJLVWHULQJSHUVRQDOWUDIILF
URXWHV
A
B
C

1073-4. Setup
COROLLA_H/B_Navi_U
3
Navigation system
7 Select the desired item to
search for the location.
( P. 7 9 )
8 Select “OK”.
9 Confirm the route overview
displayed.
Select the desired route from
3 possible routes. ( P. 8 7 )
Select to modify the route.
The routes can be adjusted
by setting preferred roads.
( P.107)
10 Select “OK”.
●Up to 5 routes can be registered.
1Select “Edit”.
2 Select the desired traffic
route. 3
Select the desired item to be
edited.
Select to edit the name of the
personal traffic route.
( P.106)
Select to edit start location.
( P.106)
Select to edit end location.
( P.106)
Select to see and modify the
entire route. ( P.107)
4 Select “OK”.
5 Follow the steps in “Register-
ing personal traffic routes”
from step 9. (  P.106)
1 Select “Delete”.
2 Select the desired traffic
route to be deleted and
select “Delete”.
3 Select “Yes” when the confir-
mation screen appears.
“My Traffic Routes” can be
adjusted by setting up to 2 pre-
Editing personal traffic
routes
A
B
'HOHWLQJSHUVRQDOWUDIILF
URXWHV
6HWWLQJSUHIHUUHGUR\
DGV
A
B
C
D

1083-4. Setup
COROLLA_H/B_Navi_U
ferred roads.
1Select “Set Preferred
Roads”.
2 Select the desired item.
Select to add preferred
roads. ( P.108)
Select to modify preferred
roads. ( P.108)
Select to delete preferred
roads. ( P.108)
■Adding preferred roads
1 Select “Add”.
2 Scroll the map to the desired
point ( P.71) and select
“OK”.
3 Select “OK” to use this road.
“Next”: Select to change road.
Available only when 1 pre-
ferred road is set
4 Select “Add Here” for the
desired location. 
If a preferred road is already
set, a second preferred road
can be added anywhere
between the start point, the
end point and the existing
preferred road.
■Modifying preferred roads
1 Select “Modify”.
2 Select the desired preferred
road to be modified if 2 pre-
ferred roads have been set.
3 Scroll the map to the desired
point ( P.71) and select
“OK”.
4 Select “OK” to use this road.
“Next”: Select to change road.
■Deleting preferred roads
1 Select “Delete”.
2 Select the desired preferred
road to be deleted if 2 pre-
ferred roads have been set.
“Delete All”: Select to delete all pre-
ferred roads on the list.
3Select “Yes” when the confir-
mation screen appears.
1 Display the traffic settings
screen. ( P.105)
2 Select “Avoid Traffic”.
A
B
C
Avoid traffic

1093-4. Setup
COROLLA_H/B_Navi_U
3
Navigation system
3 Select the desired item.
Select to automatically
change routes when conges-
tion information of the guid-
ance route has been
received.
Select to select manually
whether or not to change
routes when congestion
information of the guidance
route has been received. In
this mode, a screen will
appear to ask if you wish to
reroute.
Select to not reroute when
congestion information for
the guidance route has been
received.
When the navigation system
calculates a new route, a confir-
mation screen will be displayed. 1
Select the desired item.
Select to start route guidance
using the new route.
Select to confirm the new
route and current route on
the map.
Select to continue the current
route guidance.
Changing the route manually
A
B
C
A
B
C

1103-4. Setup
COROLLA_H/B_Navi_U
*: This function may not be avail-able immediately after purchase
of the vehicle.
1 Press the “MENU” button.
2 Select “Setup”.
3 Select “Navigation”.
4 Select “Useful Navi. Informa-
tion Settings”.
5 Select the desired items to
be set.
Use of infor mation
accumulated by
navigation system
*
(vehicles with DCM)
When enabled, information
collected by the navigation
system will be analyzed to
give advice for safe driving.
Displaying the useful nav-
igation information set-
tings screen
