783-1. Basic operation
COROLLA_H/B_Navi_U
3Scroll the map to the desired
point ( P.71) and set the
time of predictive traffic infor-
mation.
 The time of the predictive traf-
fic information can be
changed in 15-minute inter-
vals up to +45 minutes.
“<”: Moves the time forward 15 min-
utes.
“>”: Moves the time back 15 min-
utes.
Traffic information along the
saved routes can be displayed.
To use this function, it is neces-
sary to register a route.
( P.106)
1 Display the traffic incidents
screen. ( P.76)
2 Select “My Traffic Routes”.
 If map data has been
updated, a confirmation
screen will be displayed.
Select “OK” or “Do Not Tell
Me Again”.
3 Select the desired route.
“Options”: Select to add, edit or
delete personal traffic routes.
( P.106)
 If routes have not been regis-
tered yet, a confirmation
screen will be displayed.
Select “Yes” to register the
route.
4 Select the desired traffic
information. 5
Check that the traffic informa-
tion is displayed.
“Detail”: Select to display detailed
traffic information.
1Select on the map
screen. ( P. 6 8 )
2 Select “Traffic Information”.
3 Check that the traffic informa-
tion is displayed.
●The icons indicate traffic incidents
such as construction, accidents,
etc. Select an icon to hear more
detail by voice.
●The arrows indicate the flow of
traffic. The color changes depend-
ing on the speed.
My traffic routes
Displaying traffic informa-
tion on the map

803-2. Destination search
COROLLA_H/B_Navi_U
(province) by using “Address” or
“Point of Interest”.
1Display the destination
screen. ( P.79)
2 Select “Address” or “Point of
Interest”.
3 Select “Select State/Prov-
ince” or “Change State/Prov-
ince”.
 If a state (province) has not
been selected yet, “Select
State/Province” is displayed.
4 Select the desired state
(province).
 To change countries, select
“United States”, “Canada” or
“Mexico”.
To use this function, it is neces-
sary to register a home address.
( P. 9 7 )
1 Display the destination
screen. ( P.79)
2 Select .
 The navigation system per-
forms a search for the route
and the route overview is dis- played. (
P.87)
The destination can be
searched by entering various
keywords.
1 Display the destination
screen. ( P. 7 9 )
2 Select “Search”.
3 Enter characters on the key-
board.
4 Select “Search”.
5 When there is more than 1
result, select the desired item
from the list.
: Select to display updated infor-
mation about the selected entry.
(vehicles with DCM)
●To search for a facility name using
multiple search words, put a
space between each word.
●Search results may differ depend-
ing on the Toyota Entune sub-
scription status and
communication status.
To use this function, it is neces-
sary to register a favorites list
entry. ( P. 9 8 )
1 Display the destination
screen. ( P. 7 9 )
2 Select “Favorites”.
3 Select the desired favorites
list entry.
Setting home as destina-
tion
Searching by keyword
Searching by favorites list

813-2. Destination search
COROLLA_H/B_Navi_U
3
Navigation system
*: This function is not made avail- able in some countries or areas.
A Destination Assist operator
can search for a destination.
You can request a specific busi-
ness, address, or ask for help
locating your desired destina-
tion. ( P.230)
1 Display the destination
screen. ( P.79)
2 Select “Dest Assist”.
1 Display the destination
screen. ( P.79)
2 Select “Recent”.
3 Select the desired destina-
tion.
“Sort/Delete”: Select to sort (date,
name) or delete destination(s).
●Up to 100 previously set destina-
tions are displayed on the screen.
1Select “Sort/Delete”.
2 Select “Delete Recent Desti-
nations”.
3 Select the desired recent
destination(s) to be deleted.
4 Select “Yes” when the confir-
mation screen appears.
“Sort/Delete All”: Select to sort
(date, name) desti nations or delete
all.
1 Display the destination
screen. ( P. 7 9 )
2 Select “Emergency”.
3 Select the desired emer-
gency category.
4 Select the desired destina-
tion.
●The navigation system does not
guide in areas where route guid-
ance is unavailable. ( P. 111 )
To use this function, it is neces-
sary to have contact data which
had been transferred to the nav-
igation system from a registered
Bluetooth
® phone. ( P.188)
1 Display the destination
screen. ( P. 7 9 )
2 Select “Contacts”.
3 Select the desired contact.
4 Select “Addresses”.
5 Select the desired address.
6 Follow the steps in “Search-
ing by keyword” from step 4.
( P.80)
●This function may not be available
depending on the type of
Bluetooth
® phone.
Searching by Destination
Assist Connect*
Searching by recent desti-
nations
Deleting recent destina-
tions
Searching by emergency
Searching by contact

823-2. Destination search
COROLLA_H/B_Navi_U
There are 2 methods to search
for a destination by address.
1Display the destination
screen. ( P.79)
2 Select “Address”.
3 Select the desired search
method.
Select to change the search
area. ( P.79)
Select to search by city.
( P. 8 2 )
Select to search by street
address. ( P.82)
1 Select “City”.
2 Enter a city name and select
“Search”.
“Last 5 Cities”: Select the
desired city name from the list of
the last 5 cities.
3 Select the desired city name.
4 Enter a street name and
select “Search”.
5 Select the desired street
name. 6
Enter a house number and
select “Search”.
 If multiple locations with the
same address exist, the
address list screen will be dis-
played. Select the desired
address.
1 Select “Street Address”.
2 Enter a house number and
select “Search”.
3 Enter a street name and
select “Search”.
4 Select the desired street
name.
5 Enter a city name and select
“Search”.
6 Select the desired city name.
 If multiple locations with the
same address exist, the
address list screen will be dis-
played. Select the desired
address.
●A street name can be searched
using only the body part of its
name.
For example: S WESTERN AVE
• A search can be performed by entering “S WESTERN AVE”,
“WESTERN AVE” or “WEST-
ERN”.
There are 3 methods to search
Searching by address
Searching by city
A
B
C
6HDUFKLQJE\VWUHHW
DGGUHVV
6HDUFKLQJE\\
SRLQWRI
LQWHUHVW

833-2. Destination search
COROLLA_H/B_Navi_U
3
Navigation system
for a destination by Points of
Interest.
1 Display the destination
screen. ( P.79)
2 Select “Point of Interest”.
3 Select the desired search
method.
Select to change the search
area. ( P.79)
Select to search by name.
( P. 8 3 )
Select to search by category.
( P. 8 3 )
Select to search by phone
number. ( P.84)
1 Select “Name”.
2 Enter a POI name and select
“Search”.
3 Select the desired POI.
“Sort/Category/Cit y”: Select to sort
(name, distance) the displayed
entries, change the POI category,
or enter a city name.
 When entering the name of a
specific POI, and there are 2
or more sites with the same
name, the list screen will be displayed. Select the desired
POI.
●To search for a facility name using
multiple search words, put a
space between each word.
1
Select “Sort/Category/City”.
2 Select “Enter a city name”.
3 Enter a city name and select
“Search”.
“Any City”: Select to cancel the city
setting.
4Select the desired city name.
5 Select the desired POI.
1 Select “Sort/Category/City”.
2 Select “Change POI cate-
gory”.
3 Select the desired category.
 If there is more than 1 result
for the selected category, a
detailed list will be displayed.
“List All Categories”: Select to dis-
play all POI categories.
4 Select the desired POI.
1 Select “Category”.
Searching by name
A
B
C
D
6HOHFWLQJDFLW\WRVHDUFK
6HOHFWLQJIURPWKHFDWHJR
ULHV
6HDUFKLQJE\FDWHJRU\

843-2. Destination search
COROLLA_H/B_Navi_U
2Select the desired search
point.
Select to search for POIs
near your current position.
Select to search for POIs
along the set route.
Select to search for POIs
near a specific city center.
( P. 8 4 )
Select to search for POIs
near a destination.
When more than 1 destina-
tion has been set, a list will
be displayed on the screen.
Select the desired destina-
tion.
3 Select the desired POI cate-
gory.
 If there is more than 1 result
for the selected category, a
detailed list will be displayed.
“List All Categories”: Select to dis-
play all POI categories.
“Favorite POI Categories”: Select to
use the 6 POIs tha t have been pre-
viously set. ( P.104)
4 Select the desired POI.
●The names of POIs located within
approximately 200 miles (320 km)
from the selected search point can
be displayed. They are displayed up to 200 names.
1
Select “Near a City Center in
XX
*”.
2 Enter a city name and select
“Search”.
“Last 5 Cities”: Select the desired
city name from the list of the last 5
cities.
3Select the desired city name.
4 Select “OK” when the city
center map screen is dis-
played.
5 Follow the steps in “Search-
ing by category” from step 3.
( P.83)
*: XX represents the selected
search area name.
●If the navigation system has never
been used, selecting the city
name from “Last 5 Cities” will not
be available.
1 Select “Phone #”.
2 Enter a phone number and
select “OK”.
 If multiple locations with the
same phone number exist,
the list screen will be dis-
played.
●If there is no match for the entered
phone number, a list of identical
numbers with different area codes
A
B
C
D
When “Near a City Center in
XX
*” is selected
Searching by phone num-
ber

853-2. Destination search
COROLLA_H/B_Navi_U
3
Navigation system
will be displayed.
To use this function, it is neces-
sary to register a home and/or a
favorite location. Up to 2 favor-
ites can be registered as preset
destinations. ( P.97, 98)
To set the home or a preset des-
tination as the destination,
select the corresponding button.
1 Turn the engine switch to
ACC or ON.
2 Press the “MAP” button.
3 Select the desired item.
Select to set the registered
home as the destination.
Select to set a registered
favorite as the destination.
(Up to 2 favorites can be reg-
istered as preset destina-
tions.)
 The estimated time of arrival
to the registered home and
preset destinations from the
current position will be dis-
played. 
If the home or a preset desti-
nation has not been regis-
tered, “Save Home” or “Save
Favorite” will be displayed,
respectively. To register a
home or preset destination,
select the corresponding but-
ton.
●When the destination is very close
to the current po sition, “Nearby”
will be displayed.
●The one-touch buttons for home
and favorites will disappear after
the vehicle has been driven for a
while.
●The color of the estimated arrival
time indicator may change
depending on the traffic informa-
tion received.
●This function is available when
“Automatic Destination List Info” is
set to on. ( P.102)
One-touch setting
home/favorite as a desti-
nation
A
B

863-2. Destination search
COROLLA_H/B_Navi_U
1Select “Go” on the confirm
destination screen.
 For details about this screen:
P. 8 6
2 Select “OK” on the route
overview screen.
 For details about this screen:
P. 8 7
●The route for returning may not be
the same as that for going.
●The route guidance to the destina-
tion may not be the shortest route
or a route without traffic conges-
tion.
●Route guidance may not be avail-
able if there is no road data for the
specified location.
●When setting the destination on a
map with a scale more than 0.5
mile (800 m), the map scale
changes to 0.5 mile (800 m) auto-
matically. If this occurs, set the
destination again.
●If a destination that is not located
on a road is set, the vehicle will be
guided to the point on a road near-
est to the destination. The road
nearest to the selected point is set
as the destination.
Select to adjust the position
in smaller increments.
( P.72)
Select to search for the route.
( P.86)
• If a destination has already been
set, “Go Directly” and “Add to
Route” will be displayed.
Starting route
guidance
When the destination is set,
the confirm destination
screen will be displayed.
Starting route guidance
WA R N I N G
●Be sure to obey traffic regula-
tions and keep road conditions
in mind while driving. If a traffic
sign on the road has been
changed, the r oute guidance
may not indicate such changed
information.
Confirm destination
screen
A
B

873-2. Destination search
COROLLA_H/B_Navi_U
3
Navigation system
“Go Directly”: Select to delete the
existing destination(s) and set a
new one.
“Add to Route”: Select to add a
destination to the current route.
Select to register as a mem-
ory point.
Select to call the registered
number.
Select to update information
about the selected entry.*
*: This function is displayed only when there is information from
the Toyota Entune center.
( P. 8 0 )
Current position
Destination point
Select to display a list of the
turns required to reach the
destination. ( P.88)
Select the desired route from
3 possible routes. ( P. 8 7 )
Select to change the route.
( P. 8 8 )
Type of route and its distance
Distance of the entire route
Select to start guidance. Select and hold to start demo
mode. (
P.87)
Displayed when the route
displayed is from the Toyota
Entune center. ( P.89)
Before starting the route guid-
ance, the demonstration of the
route guidance can be viewed.
1 Select and hold “OK” on the
route overview screen until a
beep sounds.
 Press the “HOME” or “MAP”
button to end demo mode.
1 Select “3 Routes”.
2 Select the desired route.
Displayed when the route
displayed is available from
the Toyota Entune center.
()
Select to display the quick-
est route.
Select to display the route
that is the shortest distance
to the set destination.
Route overview screen
C
D
E
A
B
C
D
E
F
G
H
6WDUWLQJGHPRPRGH
URXWHVVHOHFWLRQ
I
A
B
C

883-2. Destination search
COROLLA_H/B_Navi_U
Select to display the alterna-
tive route.
Select to display the informa-
tion about the 3 routes.
(P. 8 8 )
1 Select “Info”.
2 Check that the 3 routes infor-
mation screen is displayed.
Time necessary for the entire
trip
Distance of the entire trip
Distance of the toll road
Distance of the freeway
Distance of the ferry trip
A list of turn information from the
current position to the destina-
tion can be displayed.
1 Select “Turn List”. 2
Check that the turn list is dis-
played.
Current position
Distance to the next turn
Turn direction at the intersec-
tion
Select to display the map of
the selected point.
●Not all road names on the route
may appear on the list. If a road
changes its name without requir-
ing a turn (such as on a street that
runs through 2 or more cities), the
name change will not appear on
the list. The str eet names will be
displayed in order from the start-
ing point, along with the distance
to the next turn or the destination.
Destinations can be added,
reordered or deleted, and condi-
tions for the route to the destina-
tion can be changed.
1Select “Edit Route”.
Displaying 3 routes informa-
tion
Displaying turn list
D
E
A
B
C
D
E(GLWLQJURXWH
A
B
C
D
