service reset TOYOTA COROLLA HATCHBACK 2020 Owners Manual (in English)

2805-3. Connectivity settings
COROLLA H/B_U
Select to check/change the
access point password.
(P.280)
Select to display hints for
connecting to the vehicle via
Wi-Fi
®.
Select to make the access
point searchable/unsearch-
able.
Select to check/change the
security protocol of the
access point (for authentica-
tion and encryption).
( P.281)
Select to change the access
point name (SSID). ( P.281)
Select to change the Wi-Fi
®
connection channel (within
the 2.4GHz frequency band).
( P.281)
●If any settings have been
changed, it will be necessary to
reset the Wi-Fi
® system to com-
plete the changes. To reset the
Wi-Fi
® system, select “Yes” on the
pop-up displayed after changing
the settings.
When the Wi-Fi® Hotspot func-
tion is enabled, the system
checks for a valid Hotspot ser-
vice subscription.
If a hotspot service subscription
has not been started, connect
your device to the in-vehicle access point to start your sub-
scription. A trial subscription
may be available.
1
Select “Password”.
2 Check that the following
screen is displayed.
Displays the password
Select to display/hide the
entered password.
Select to change the pass-
word.
1 Select “Change Password”.
2 Enter the desired password
and select “OK”.
 When setting/changing a
password, observe the follow-
ing guidelines to help prevent
the password from being
cracked by a third party:
• Use an 8-character or longer
password consisting of letters
and numbers. (Non-ASCII char-
acters will not be recognized by
the system.)
Enabling/disabling the
Wi-Fi
® Hotspot function
Checking/changing the
password
Changing the password

3765-16. Connected Services Overview
COROLLA H/B_U
the United States Virgin
Islands.
●Data usage fees may apply while
using Toyota apps function. Con-
firm data usage fees before using
this function.
●For details regarding operation of
the Toyota apps, refer to
https://www.toyota.com/con-
nected-servicesin the United States,
https://www.toyota.ca/connected
in Canada, and
http://www.toyotapr.com/con-
nected-services
in Puerto Rico.
●These functions are not made
available in some countries or
areas. Availability of functions of
the Toyota apps is dependent on
network reception level.
■Initializing personal data
The personal data used in appli-
cations can be reset. ( P.293)
 The following personal data
can be deleted and returned
to their default settings:
• Downloaded contents
• Radio stations that were listened
to
●Once initialized, the data and set-
tings will be erased. Pay much
attention when initializing the data.
■Settings required to use
Toyota mobile application
Perform the settings in the fol-
lowing order. 1
Download the Toyota mobile
application to your smart
phone or the system.
2 Register the smart phone
with the system.
In order to use Toyota mobile appli-
cation, the following must first be
performed:
Download the Toyota mobile
application onto your smart
phone or the system, and
login to the application.
( P.376)
 Register the smart phone, on
which the Toyota mobile appli-
cation was installed, with the
system. ( P.376)
 Register a Bluetooth
® phone
with the hands-free system.
( P.376)
■Registering the Toyota
mobile application applica-
tion
 Registration is optional.
1 Download the Toyota mobile
application to your smart
phone or the system.
2 Run the Toyota mobile appli-
cation on your smart phone
or the system.
3 Enter the information
required into the Toyota
mobile application. Login to
the application.
●Applications can only be used
when the Toyota mobile applica-
tion has been downloaded to your
smart phone or the system, and
Preparation before using
Toyota mobile application

4207-2. Maintenance
COROLLA H/B_U
■Resetting the message indicat-
ing maintenance is required
After the required maintenance is
performed according to the mainte-
nance schedule, please reset the
message.
To reset the messa ge, follow the
procedure described below:
1 Press or of the meter
control switch to select .
2 Press or to select “Vehi-
cle Settings” and then press and
hold .
3 Press or to select
“Scheduled Maintenance” and
then press .
4 Press or to select “Yes”
and then press .
A message will be displayed on the
multi-information display when the
reset procedure has been com-
pleted.
You can perform some mainte-
nance procedures by yourself.
Please be aware that do-it-your-
self maintenance may affect
warranty coverage.
The use of Toyota repair manuals is
recommended.
For details about warranty cover-
age, refer to the separate “Owner’s
Warranty Information Booklet” or
“Owner’s Manual Supplement”.
Do-it-yourself mainte-
nance
General maintenance
Listed below are the general
maintenance items that
should be performed at the
intervals specified in the
“Owner’s Warranty Informa-
tion Booklet” or “Owner’s
Manual Supplement/Sched-
uled Maintenance Guide”. It
is recommended that any
problem you notice should
be brought to the attention
of your Toyota dealer or
qualified service shop for
advice.
WARNING
■If the engine is running
Turn the engine off and ensure
that there is adequate ventilation
before performing maintenance
checks.
Engine compartment
ItemsCheck points
BatteryCheck the connec-
tions. ( P.433)
Brake fluid
Is the brake fluid at
the correct level?
( P.432)
Engine coolant
Is the engine cool-
ant at the correct
level? ( P.431)
Engine oil
Is the engine oil at
the correct level?
( P.429)

564Alphabetical Index
COROLLA H/B_U
Rear view mirror Inside rear view mirror.......... 122
Outside rear view mirrors ..... 123
Rear view monitor system ..... 232 If you notice any symptoms.. 237
Rear window defogger ........... 389
Rear window wiper ................. 168
Receiving a call using the Blue- tooth
® hands-free system ... 351
Refueling Capacity ............................... 511
Fuel types............................. 511
Opening the fuel tank cap .... 170
Registering/Connecting a Blue- tooth
® device ........................ 266
Profiles ................................. 269
Registering a Bluetooth
® audio
player for the first time........ 269
Registering a Bluetooth
® phone
for the first time .................. 266
Replacing Electronic key battery ........... 450
Fuses ................................... 452
Light bulbs ............................ 455
Reporting safety defects for U.S. owners................................... 542
Resetting the message indicat- ing maintenance is required 420
Road Sign Assist .................... 224
RSA (Road Sign Assist) ......... 224
S
Safety Connect ......................... 58
Screen adjustment ................. 264
Seat belt reminder light . 471, 472
Seat belts .................................. 25 Automatic Locking Retractor .. 27
Child restraint system installation............................................. 47
Cleaning and maintaining the seat belt.............................. 416
Emergency Locking Retractor 27 How to wear your seat belt .....26
How your child should wear the
seat belt ................................26
Pregnant women, proper seat belt use .................................25
Reminder light and buzzer .471, 472
Seat belt extender ..................26
Seat belt pretensioners ..........28
SRS warning light .................469
Seat heaters ............................393
Seating capacity .....................140
Seats Adjustment ........................... 115
Adjustment precautions ........ 115
Child seats/child restraint system installation ............................45
Cleaning ...............................416
Head restraints ..................... 118
Properly sitting in the seat ......23
Seat heaters ....... ..................393
Secondary Collision Brake ....241
Sensor Automatic headlight system .161
Automatic High Beam system...........................................163
BSM (Blind Spot M onitor) .....227
LDA (Lane Departure Alert with steering control)..................196
LTA (Lane Tracing Assist) .....186
Radar sensor ................172, 229
Service reminder message ....420
Setup button (Menu screen) 253, 256
Setup screen ...........................256
Shift lever Continuously variable transmis-sion .....................................147
Manual transmission ............151
Side airbags ..............................29
Side marker lights Light switch...........................160
