navigation TOYOTA COROLLA HATCHBACK 2023 Owners Manual

812-1. Instrument cluster
2
Vehicle status information and indicators
■Navigation system-linked
display (if equipped)
Select to display the following
navigation system-linked infor-
mation:
 Route guidance to destination
 Compass display (head-
ing-up display)
Select to enable selection of an
audio source or track on the
meter using the meter control
switches.
This menu icon can be set to be
displayed/not displayed in .
■Drive information
Displays drive information such
as the following:
Drive information type
Drive information items
Displays the following depend-
ing on which drive information type and drive information items
were selected in . (
P.81)
 After start
• Distance: Displays the distance
driven since engine start
• Elapsed time: Displays the elapsed time since engine start
• Average vehicle speed: Displays the average vehicle speed since
engine start
 After reset
• Distance: Displays the distance
driven since the display was
reset
*
• Elapsed time: Displays the elapsed time since the display
was reset
*
• Average vehicle speed: Displays the average vehicle speed since
the display was reset
*
*
: To reset, display the desired item and press and hold the
meter control switch.
■Meter display settings that
can be changed
 Language
Select to change the language dis-
played.
Units
Select to change the units of mea-
sure displayed.
Eco Driving Indicator Light
Select to enable/disable the Eco
Driving Indi cator Light.
Audio system-linked dis-
play
Vehicle information dis-
play
Settings display

862-1. Instrument cluster
■Navigation system-linked
display (if equipped)
Select to display the following
navigation system-linked infor-
mation:
 Route guidance to destination
 Compass display (head-
ing-up display)
Select to enable selection of an
audio source or track on the
meter using the meter control
switches.
This menu icon can be set to be
displayed/not displayed in .
■Drive information
Displays drive information such as
the following:
Drive information 1
Drive information 2
Displays the following depend-
ing on which drive information type and drive information items
were selected in . (
P.86)
 After start
• Distance: Displays the distance
driven since engine start
• Elapsed time: Displays the elapsed time since engine start
• Average vehicle speed: Displays the average vehicle speed since
engine start
 After reset
• Distance: Displays the distance
driven since the display was
reset
*
• Elapsed time: Displays the elapsed time since the display
was reset
*
• Average vehicle speed: Displays the average vehicle speed since
the display was reset
*
*
: To reset, display the desired item and press and hold the
meter control switch.
■Meter display settings that
can be changed
 Language
Select to change the language dis-
played.
Units
Select to change the units of mea-
sure displayed.
Meter Type
Select to change the meter type.
Audio system-linked dis-
play
Vehicle information dis-
play
Settings display

2074-5. Using the driving support systems
4
Driving
detects a sign or information
of a sign is available from the
navigation system, the sign
will be displayed on the dis-
play.
 Multiple signs can be dis-
played.
Depending on the specifications of
the vehicle, the number of dis-
played signs may be limited.
■Operating conditions of sign
display
Signs will be displayed when the fol-
lowing conditions are met:
●The system has detected a sign
In the following si tuations, a dis-
played sign may stop being dis-
played:
●When a new sign has not been
detected for a certain distance
●When the system determines that
the road being driven on has
changed, such as after a left or
right turn
■Situations in which the display
function may not operate prop-
erly
In the following si tuations, the RSA
system may not operate properly
and may not detect signs or may
display the incorrect sign. However,
this does not indicate a malfunction.
●When a sign is dirty, faded, tilted
or bent
●When the contrast of an electronic
sign is low
●When all or part of a sign is hidden
by a tree, ut ility pole, etc.
●When a sign is detected by the
front camera for a short amount of
time
●When the driving state (turning,
changing lanes, etc.) is judged
incorrectly
●W h e n a s i g n i s i m m e d i a t e l y a f t e r a
freeway junction or in an adjacent
lane just before merging
●When stickers are attached to the
rear of a preceding vehicle
●When a sign similar to a system
compatible sign is detected as a
system compatible sign
●When a speed limit sign for a
frontage road is within detection
range of the front camera
●When driving around a round-
about
●When a sign inte nded for trucks,
etc. is detected
●When the navigation system map
data is out of date
●When the navigation system can-
not be used
In this case, the speed limit signs
displayed on the multi-information
display and navigation system dis-
play may differ.
In the following situations, the
RSA system will output a warn-
ing to notify the driver.
 If the vehicle speed exceeds
the speed warning threshold
of the speed limit sign dis-
played on the display, the sign
display will be emphasized
and a buzzer will sound.
 When the RSA system
detects a do not enter sign
and determines that the vehi-
cle has entered a no-entry
area, the do not enter sign
displayed on the display will
flash and a buzzer will sound.
Notification function

3537-2. Steps to take in an emergency
7
When trouble arises
WARNING
■When using the compact
spare tire
●Remember that the compact
spare tire provided is specifi-
cally designed for use with your
vehicle. Do not use your com-
pact spare tire on another vehi-
cle.
●Do not use more than one com-
pact spare tires simultaneously.
●Replace the compact spare tire
with a standard tire as soon as
possible.
●Avoid sudden acceleration,
abrupt steering, sudden brak-
ing and shifting operations that
cause sudden engine braking.
■When the compact spare tire
is attached
The vehicle speed may not be
correctly detecte d, and the follow-
ing systems may not operate cor-
rectly:
• ABS & Brake assist
• VSC
• TRAC
• Automatic High Beam
• Dynamic radar cruise control
• EPS
• PCS (Pre-Collision System)
• LDA (Lane Departure Alert)
• LTA (Lane Tracing Assist)
• BSM (if equipped)
• RCTA (if equipped)
• SEA (if equipped)
• Tire pressure warning system
• Navigation system (if equipped)
■Speed limit when using the
compact spare tire
Do not drive at speeds in excess
of 50 mph (80 km /h) when a com-
pact spare tire is installed on the
vehicle.
The compact spare tire is not
designed for driving at high
speeds. Failure to observe this
precaution may lead to an acci-
dent causing death or serious
injury.
■After using the tools and jack
Before driving, ma ke sure all the
tools and jack are securely in
place in their storage location to
reduce the possibility of personal
injury during a collision or sudden
braking.
NOTICE
■Be careful when driving over
bumps with the compact
spare tire installed on the
vehicle
The vehicle becomes lower when
driving with the compact spare tire
compared to when driving with
standard tires. Be careful when
driving over uneven road sur-
faces.

417Alphabetical Index
Navigation system-linked display....................................... 80, 85
Settings ............................ 81, 86
Tire pressure ........................ 285
Vehicle information display81, 86
Warning message ................ 330
N
Navigation system-linked display ........................................... 80, 85
Noise from under vehicle .......... 5
O
Odometer ............................ 73, 76
Odometer and trip meter display
Display change button...... 73, 76
Display items .................... 73, 76
Oil Engine oil ............................. 368
Open tray ................................ 247
Opener Back door ............................. 101
Fuel filler door ...................... 157
Hood..................................... 273
Outside rear view mirrors Adjustment ........................... 115
BSM (Blind Spot Monitor)..... 209
Folding ................................. 116
Outside rear view mirror defog-gers .................................... 237
RCTA function ...................... 214
Safe Exit Assist .................... 219
Outside temperature .......... 72, 75
Overheating ............................ 362
P
Paddle shift switches ..... 139, 140
Panic mode ............................... 93
Parking brake Operation ............................. 142 Parking brake engaged warning
buzzer.................................144
Warning light.........................326
Warning message.................144
Parking lights Light switch...........................148
Replacing light bulbs ............309
PCS (Pre-Collision System) ...167 Function................................168
Warning light.........................324
PDA(Proactive driving assist)[PDA(Proactive driving
assist)] ...................................187
Personal lights ........................243 Wattage ................................372
Power outlets ..........................251
Power steering (Electric power steering system) ...................226Warning light.........................322
Power windows Door lock linked window opera-tion...................................... 118
Jam protection function ........ 117
Operation.............................. 117
Window lock switch .............. 119
Pre-Collision System (PCS) ...167 Function................................168
Warning light.........................324
R
Radiator ...................................278
RCTAFunction................................214
RCTA function .........................215
Rear Cross Traffic Alert (RCTA) ...............................................214
Rear seats ...............................108 Head restraints ..................... 110
Rear side marker lights Light switch...........................148
Rear turn signal lights Replacing light bulbs ............309

421Alphabetical Index
Open window ....................... 118
PDA (Proactive Driving Assist)........................................... 325
Seat belt ............................... 323
Warning lights ........................ 320 ABS ...................................... 322
Brake hold operated indicator........................................... 327
Brake Override System ........ 322
Brake system ....................... 320
Charging system .................. 321
Cruise control indicator ........ 325
Drive-Start Control ............... 322
Driving assist information indica- tor ....................................... 326
Dynamic radar cruise control indicator.............................. 325
Electric power steering ......... 322
High coolant temperature ..... 320
LDA indicator ........................ 325
Low engine oil pressure ....... 321
Low fuel level ....................... 323
LTA indicator ......................... 324
Malfunction indicator lamp ... 321
Parking brake indicator ........ 326
PDA indicator ....................... 325
Pre-collision system ............. 324
Seat belt reminder light ........ 323
Slip indicator......................... 326
SRS ...................................... 321
Tire pressure ........................ 324
Warning messages................. 330
Washer Checking .............................. 281
Preparing and c hecking before
winter.................................. 230
Switch................................... 154
Washing and waxing .............. 260
Weight Cargo capacity ..................... 131
Load limits ............................ 131
Weight .................................. 366 Wheels .....................................301
Replacing .............................301
Size ......................................370
Window lock switch ............... 119
Windows Power windows .................... 117
Rear window defogger .........237
Washer .................................154
Windshield wipers ..................154
Winter driving tips ..................230
Wireless charger.....................251
Wireless remote control Battery-Saving Function .......103
Locking/Unlocking ..................93
Replacing the battery ...........304
Refer to “MULTIMEDIA OWNER’S MANUAL” for
information regarding the
equipment listed below.
· Navigation system
· Audio/visual system
· Rear view monitor system
