TOYOTA COROLLA HYBRID 2020 Accessories, Audio & Navigation (in English)

713-1. Basic operation
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
1 Select on the map
screen.
2 Check that the micro city
map is displayed.
●To return to the normal map dis-
play, select .
●If the map or the c urrent position
is moved to the are a which is not
covered by the micro city map, the
screen scale automatically
changes to 150 ft. (50 m).
●On the micro city map, a one way
street is displayed by .
●Scrolling the micro city map is not
available while driving.
●Certification
Building micro cities in the database
were created and provided by
HERE.
The orientation of the map can
be changed between 2D
north-up, 2D heading-up and 3D
heading-up by selecting the ori-
entation symbol displayed at the
top left of the screen.
: North-up symbol
Regardless of the direction of
vehicle travel, north is always
up. : Heading-up symbol
The direction of vehicle travel is
always up.
: 3D Heading-up symbol
The direction of vehicle travel is
always up.
 The letter(s) under this sym-
bol indicate the vehicle’s
heading direction (e.g. N for
north).
The map can be scrolled to view
locations that are different than
your current position.
1 Select the desired point on
the map screen.
 Move the desired point on the
center of the map screen.
Cursor mark
Distance from the current
position to the cursor mark
Select to register as a mem-
ory point. To change the icon,
name, etc.:  P. 9 7
Select to set as a destination.
( P.86)
 The map screen can be
scrolled by touching, dragging
Orientation of the map
Map scroll operation
A
B
C
D

723-1. Basic operation
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
or flicking it. (P.27)
 Press the “MAP” button to
return to the current position.
The cursor location can be
adjusted in small increments. 8
directional arrows may appear
in the following cases.
• When “Adjust Location” is selected on the map screen
• When changing the location of memory points on the edit-
ing screen ( P.97, 98, 100)
• When adjusting the current position mark manually on the
calibration screen ( P.104)
1 Select one of the 8 direc-
tional arrows to move the
cursor to the desired point
and then select “OK”. 1
Select on the map
screen. ( P. 6 8 )
2 Select the desired items to
be displayed.
Select to display the desired
map mode. ( P.73)
Select to select or change
POI icons. ( P.74)
Select to display speed limit
icon.
Select to display traffic infor-
mation.
* (  P. 7 6 )
Select to display route trace.
( P.75)
Select to display the map
version and coverage area.
( P. 1 1 3 )
*: This function is not made avail-
Adjusting location in
small increments
Map screen informa-
tion
Information such as POI
icons, route trace, speed
limit, etc. can be displayed
on the map screen.
Displaying the map
options screen
A
B
C
D
E
F

733-1. Basic operation
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
able in some countries or areas.
1 Select on the map
screen. ( P.68)
2 Select “Map Mode”.
3 Select the desired configura-
tion button.
Select to display the single
map screen.
Select to display the dual
map screen. ( P.73)
Select to display the com-
pass mode screen. ( P. 7 3 )
Select to display the turn list
screen. ( P.93)
Select to display the freeway
exit list screen. ( P. 9 1 )
Select to display the intersec-
tion guidance screen or the
guidance screen on the free-
way. ( P. 9 2 )
Select to display the
turn-by-turn arrow screen.
( P. 9 3 )
 Depending on the conditions,
certain screen configuration
buttons cannot be selected. The map on the left is the main
map. The right side map can be
edited.
1
Select any point on the right
side map.
2 Select the desired item.
Select to change the orienta-
tion of the map. ( P. 7 1 )
Select to display POI icons.
( P.74)
Select to show traffic infor-
mation.
* (  P. 7 6 )
Select to change the map
scale. ( P. 7 0 )
*: This function is not made avail-
able in some countries or areas.
3 Select “OK”.
Information about the destina-
Switching the map mode
A
B
C
D
E
F
G
'XDOPDS
&RPSDVV
A
B
C
D

743-1. Basic operation
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
tion, current position and a com-
pass are displayed on the
screen.
●The destination mark is displayed
in the direction of the destination.
When driving, refer to the longi-
tude and latitude coordinates, and
the compass, to make sure that
the vehicle is headed in the direc-
tion of the destination.
●When the vehicle travels out of
the coverage area, the guidance
screen changes to the whole com-
pass mode screen.
1Select on the map
screen. ( P.68)
2 Select “POI Icons”.
3 Select the desired POI cate-
gory and select “OK”.
Displays up to 5 selected POI
icons on the map screen.
Select to cancel the selected
POI icons.
Displays up to 6 POI icons as
favorite POI categories.
( P.104) If a POI category is
selected to be displayed on
the map, its icon will be dis-
played above. Select to display other POI
categories if the desired POIs
cannot be found on the
screen.
Select to search for the near-
est POIs. (
P.74)
1 Select “Other POIs”.
2 Select the desired POI cate-
gories and select “OK”.
“List All Categories”: Select to
display all POI categories.
POIs that are within 20 miles (32
km) of the current position will
be listed from among the
selected categories.
1 Select “Around Me”.
2 Select the desired POI.
“Sort/Search Area”: Select to
sort (distance, name, category)
POIs or search area.
 Select “Near Here” to search
for POIs near the current
position.
 Select “Along My Route” to
search for POIs along the
route.
3 Check that the selected POI
is displayed on the map
screen.
Selecting the POI icons
A
B
C
6HOHFWLQJRWKHU32,LFRQVWR
EHGLVSOD\HG
'LVSOD\LQJWKHORFDO32,OLVW
D
E

753-1. Basic operation
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
The traveled route can be stored
and retraced on the map screen.
This feature is available when
the map scale is 30 miles (50
km) or less.
1 Select on the map
screen. ( P.68)
2 Select “Route Trace”.
 The route trace starts.
3 Check that the traveled line is
displayed.
1 Select on the map
screen. ( P.68)
2 Select “Route Trace” again.
3 A confirmation screen will be
displayed.
“Yes”: Select to keep the recorded
route trace.
“No”: Select to era se the recorded
route trace.
●The traveled rou te can be stored up to approximately 621 miles
(1000 km).
When the cursor is placed over
an icon on the map screen, the
name is displayed at the top of
the screen. If “Info” is shown to
the right of the name, detailed
information can be displayed.
1
Place the cursor over an
icon.
2 Select “Info”.
3 Check that the information
screen is displayed.
“Save”: Select to register as
a memory point. To change
the icon, name, etc.:  P. 9 7
“Go” / “Enter”: Select to set
as a destination.
: Select to call the regis-
tered number.
“Delete”: Select to delete
destination or memory point.
“Edit”: Select to display the
edit memory point screen.
●Even when traffi c information is
not currently being received, traffic
Route trace
Start recording the route
trace
Stop recording the route
trace
Displaying information
about the icon where the
cursor is set

763-1. Basic operation
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)information and “
Info” will be dis-
played for a while after traffic infor-
mation has been received.
●In some situations, calls to a POI
may automatically change to an
international call or may not be
possible as a domestic call.*: This function is not made avail-
able in some countries or areas.
1 Press the “MENU” button.
2 Select “Info”.
3 Select “Traffic Incidents”.
When the route has not been
set
Select to display traffic infor-
mation for the current road.
( P.77)
Standard map icons
IconName
Park/Recreation
Business facility
Airport
Military
University
Hospital
Stadium
Shopping
Golf course
Traffic infor mation*
Traffic data can be received
via HD Radio broadcast or
via DCM (Data Communica-
tion Module) to display traf-
fic information on the map
screen.
Displaying the traffic
screen
A

773-1. Basic operation
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
Select to display nearby traf-
fic information. ( P.77)
Select to display a map with
predictive traffic data.
( P. 7 7 )
Select to display traffic along
the saved routes. ( P.78)
When the route has been set
Select to display traffic infor-
mation for the set route.
( P. 7 7 )
Select to display nearby traf-
fic information. ( P.77)
Select to display a map with
predictive traffic data.
( P. 7 7 )
Select to display traffic along
the saved routes. ( P.78)
●If a large amount of information is
being received, it may take longer
than normal for the information to
be displayed on the screen.
●If traffic information cannot be
received because the vehicle is
outside of HD Ra dio coverage
area, it may still be able to be
received using DCM. ( P.168)
A list of current traffic informa-
tion can be displayed along with
information on the location of
each incident.
1 Display the traffic incidents
screen. ( P. 7 6 )
2 Select “Traffic Events on Cur-
rent Road”, “Traffic Events on
Current Route” or “Traffic
Events Nearby”.
3 Select the desired traffic
information.
When “Traffic Events Nearby”
is selected, depending on
whether the traffic flow infor-
mation is enabled/disabled,
the following will be displayed:
When enabled: Traffic event and
congestion information
When disabled: Traffic event infor-
mation only
4Check that the traffic informa-
tion is displayed.
“Detail”: Select to display detailed
traffic information.
A map with predictive traffic data
can be displayed.
1Display the traffic incidents
screen. ( P. 7 6 )
2 Select “Predictive Traffic
Map”.
B
C
D
A
B
C
D
Displaying traffic informa-
tion
Displaying predictive traf-
fic information

783-1. Basic operation
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3Scroll the map to the desired
point ( P.71) and set the
time of predictive traffic infor-
mation.
 The time of the predictive traf-
fic information can be
changed in 15-minute inter-
vals up to +45 minutes.
“<”: Moves the time forward 15 min-
utes.
“>”: Moves the time back 15 min-
utes.
Traffic information along the
saved routes can be displayed.
To use this function, it is neces-
sary to register a route.
( P.106)
1 Display the traffic incidents
screen. ( P.76)
2 Select “My Traffic Routes”.
 If map data has been
updated, a confirmation
screen will be displayed.
Select “OK” or “Do Not Tell
Me Again”.
3 Select the desired route.
“Options”: Select to add, edit or
delete personal traffic routes.
( P.106)
 If routes have not been regis-
tered yet, a confirmation
screen will be displayed.
Select “Yes” to register the
route.
4 Select the desired traffic
information. 5
Check that the traffic informa-
tion is displayed.
“Detail”: Select to display detailed
traffic information.
1Select on the map
screen. ( P. 6 8 )
2 Select “Traffic Information”.
3 Check that the traffic informa-
tion is displayed.
●The icons indicate traffic incidents
such as construction, accidents,
etc. Select an icon to hear more
detail by voice.
●The arrows indicate the flow of
traffic. The color changes depend-
ing on the speed.
My traffic routes
Displaying traffic informa-
tion on the map

793-2. Destination search
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
3-2.Destination search
The destination screen enables
to search for a destination. The
destination screen can be
reached by the following meth-
ods:
■From the map screen
1 Press the “MAP” button.
2 Select .
3 Follow the steps in “From the
menu screen” from step 3.
( P. 7 9 )
■From the menu screen
1 Press the “MENU” button.
2 Select “Destination”.
3 Select the desired search
method.
Select to set a destination by home. (
P.80)
Select to search for a desti-
nation by entering keywords.
( P.80)
Select to search for a desti-
nation from a registered entry
in “Favorites”. ( P. 8 0 )
Select to search for a desti-
nation via the Toyota Entune
center.
* (  P.227)
Select to search for a desti-
nation from recent set desti-
nations. ( P. 8 1 )
Select to search for a desti-
nation from emergency ser-
vice points. ( P.81)
Select to search for a desti-
nation from contact data
which had been transferred
to the navigation system from
a registered Bluetooth
®
phone. ( P.81)
Select to search for a desti-
nation by address. ( P. 8 2 )
Select to search for a desti-
nation by point of interest.
( P.82)
*: This function is not made avail-
able in some countries or areas.
●To hide the destination screen,
touch any part of the map screen.
The selected state (province)
can be changed to set a desti-
nation from a different state
Destination search
operation
Destination screen
A
6HOHFWLQJVHDUFKDUHD
B
C
D
E
F
G
H
I

803-2. Destination search
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
(province) by using “Address” or
“Point of Interest”.
1Display the destination
screen. ( P.79)
2 Select “Address” or “Point of
Interest”.
3 Select “Select State/Prov-
ince” or “Change State/Prov-
ince”.
 If a state (province) has not
been selected yet, “Select
State/Province” is displayed.
4 Select the desired state
(province).
 To change countries, select
“United States”, “Canada” or
“Mexico”.
To use this function, it is neces-
sary to register a home address.
( P. 9 7 )
1 Display the destination
screen. ( P.79)
2 Select .
 The navigation system per-
forms a search for the route
and the route overview is dis- played. (
P.87)
The destination can be
searched by entering various
keywords.
1 Display the destination
screen. ( P. 7 9 )
2 Select “Search”.
3 Enter characters on the key-
board.
4 Select “Search”.
5 When there is more than 1
result, select the desired item
from the list.
: Select to display updated infor-
mation about the selected entry.
(vehicles with DCM)
●To search for a facility name using
multiple search words, put a
space between each word.
●Search results may differ depend-
ing on the Toyota Entune sub-
scription status and
communication status.
To use this function, it is neces-
sary to register a favorites list
entry. ( P. 9 8 )
1 Display the destination
screen. ( P. 7 9 )
2 Select “Favorites”.
3 Select the desired favorites
list entry.
Setting home as destina-
tion
Searching by keyword
Searching by favorites list
