oil type TOYOTA DYNA 100/150 2014 Owners Manual (in English)

INFORMATION BEFORE DRIVING YOUR TOYOTA11 3
NOTICE
To prevent damage to the system and
a fire hazard, observe the following
precautions:
zUse only diesel fuel.
zDo not drive for long periods of
time while the DPF system indicator
light is flashing.
zDo not use fuel other than the spe-
cified type.
zDo not use engine oil other than
the recommended type.
zDo not modify the exhaust pipe.
zOperating the vehicle when the en-
gine oil contains a significant
amount of diesel fuel may result in
damage to the engine. If a signifi-
cant amount of fuel is present,
change the oil as soon as possible.
zDo not drive with an extremely low
fuel level; running out of fuel could
cause the engine to misfire, creat-
ing an excessive load on the cata-
lytic converter.
zDo not pull−or push−start your ve-
hicle.
zDo not turn off the engine switch
while the vehicle is moving.
zKeep your engine switch in good
running order. Malfunctions in the
engine electrical system or fuel sys-
tem could cause an extremely high
catalytic converter temperature.
zIf the engine becomes difficult to
start or stalls frequently, take your
vehicle in for a check−up to any
authorized Toyota dealer or repairer,
or another duly qualified and
equipped professional.
zTo ensure that the catalytic convert-
er and the entire emission control
system operate properly, your ve-
hicle must receive the periodic in-
spections required by the Toyota
Maintenance Schedule. For sched-
uled maintenance information, refer
to the “Toyota Service Booklet” or
“Toyota Warranty Booklet”.
Dyna100/150_EE

STARTING AND DRIVING129
When encountering flooded roads
Do not drive on a road that has flooded
after heavy rain etc. Doing so may cause
serious damage to the vehicle.
NOTICE
Driving on a flooded road may cause
the engine to stall as well as cause
serious vehicle malfunctions such as
shorts in electrical components and
engine damage from water immersion.
In the event that you drive on a
flooded road and the vehicle is
flooded, be sure to have any autho-
rized Toyota dealer or repairer, or
another duly qualified and equipped
professional check brake function,
changes in quantity and quality of oil
and fluid used for the engine, trans-
mission, differential, etc. and lubricant
condition for the propeller shaft, bear-
ings and suspension joints (where
possible) and the function of all joints
and bearings.
Make sure your coolant is properly pro-
tected against freezing.
Only use “Toyota Super Long Life Coolant”
or similar high quality ethylene glycol
based non−silicate, non−amine, non−nitrite,
and non−borate coolant with long−life
hybrid organic acid technology. (Coolant
with long−life hybrid organic acid
technology is a combination of low
phosphates and organic acids.)
See “Checking the engine coolant level”
on page 190 in Section 7−2 for details of
coolant type selection.
“Toyota Super Long Life Coolant” is a mix-
ture of 50% coolant and 50% deionized
water. This coolant provides protection
down to about−35_C(−31_F).
NOTICE
Do not use plain water alone.
Check the condition of the battery and
cables.
Cold temperatures reduce the capacity of
any battery, so it must be in top shape
to provide enough power for winter start-
ing. Section 7−3 tells you how to visually
inspect the battery. Any authorized Toyota
dealer or repairer, or another duly quali-
fied and equipped professional, will be
pleased to check the level of charge.
Make sure the engine oil viscosity is
suitable for the cold weather.
See page 188 in Section 7−2forrecom-
mended viscosity. Leaving a heavy sum-
mer oil in your vehicle during winter
months may cause harder starting. If you
are not sure about which oil to use, call
any authorized Toyota dealer or repairer,
or another duly qualified and equipped
professional—who will be pleased to help.
Dyna100/150_EE
Winter driving tips

148IN CASE OF AN EMERGENCY
If your engine coolant temperature
gauge indicates overheating, if you ex-
perience a loss of power, or if you hear
a loud knocking or pinging noise, the
engine has probably overheated. You
should follow this procedure...
1. Pull safely off the road, stop the ve-
hicle, and turn on your emergency
flashers. Put the transmission in neu-
tral and apply the parking brake. Turn
off the air conditioning if it is being
used.
2. If coolant or steam is boiling out of the
radiator or reservoir, stop the engine.
Wait until the steam subsides before
opening the engine access hole cover
or tilting the cab. If there is no coolant
or steam boiling over, leave the engine
running and make sure the electric
cooling fan is operating. If it is not,
turn the engine switch off.
CAUTION
To help avoid serious injury, keep the
engine access hole cover closed or
the cab lowered until there is no
steam. Escaping steam or coolant is
a sign of very high pressure.
3. Visually check to see if the engine
drive belt (fan belt) is broken or loose.
Look for obvious coolant leaks from the
radiator, hoses, and under the vehicle.
However, note that water draining from
the air conditioning is normal if it has
been used.
CAUTION
When the engine is running, keep
hands and clothing away from the
moving fan and engine drive belts.
4. If the engine drive belt is broken or the
coolant is leaking, stop the engine im-
mediately. Call any authorized Toyota
dealer or repairer, or another duly qual-
ified and equipped professional, for as-
sistance.
5. If the engine drive belt is O.K. and
there are no obvious leaks, you may
help the engine cool down more quickly
by running it at about 1500 rpm for a
few minutes with the accelerator pedal
lightly depressed.
6. Check the coolant reservoir. If it is dry,
add coolant to the reservoir while the
engine is running. Fill it about half full.
For the coolant type, see “Coolant type
selection” on page 191 in Section 7−2.
CAUTION
Do not attempt to remove the radiator
cap when the engine and radiator are
hot. Serious injury could result from
scalding hot fluid and steam blown
out under pressure.
7. After the engine coolant temperature
has cooled to normal, again check the
coolant level in the reservoir. If neces-
sary, bring it up to half full again.
Serious coolant loss indicates a leak in
the system. You should have it
checked as soon as possible at any
authorized Toyota dealer or repairer, or
another duly qualified and equipped
professional.
Dyna100/150_EE
If your vehicle overheats

188DO−IT−YOURSELF MAINTENANCE: Engine and Chassis
Low level Full level
Add oil O.K. Too full
With the engine at operating tempera-
ture and turned off, check the oil level
on the dipstick.
1. To get a correct reading, the vehicle
should be on level ground. After warm-
ing up the engine and turning it off,
wait more than five minutes for the oil
to drain back into the bottom of the
engine.
2. Pull the dipstick out, hold a rag under
the end and wipe it clean.
3. Reinsert the dipstick—push it in as far
as it will go, or the reading will not be
correct.
4. Pull the dipstick out and look at the oil
level while holding a rag under the
end.
NOTICE
Be careful not to drop engine oil on
the vehicle components.
If the oil level is below or only slightly
above the low level, add engine oil of
the same type as already in the engine.
Remove the oil filler capand add engine
oil in small quantities at a time, checking
the dipstick. We recommend that you use
a funnel when adding oil.The approximate quantity of oil needed to
raise the level between low and full on the
dipstick is indicated as follows:
1.9L(2.0qt.,1.7Imp.qt.)
For the engine oil capacity, see “Service
specifications” on page 216 in Section 8.
When the level reaches within the correct
range, install the filler cap hand−tight.
NOTICE
zBe careful not to spill engine oil on
the vehicle components.
zAvoid overfilling, or the engine
could be damaged.
zCheck the oil level on the dipstick
once again after adding the oil.
Dyna100/150_EE
Checking the engine oil level

190DO−IT−YOURSELF MAINTENANCE: Engine and Chassis
To ensure excellent lubrication perfor-
mance for your engine, Toyota recom-
mends the use of “Toyota Genuine Motor
Oil”, which has been specifically tested
and approved for all Toyota engines.
Please contact any authorized Toyota
dealer or repairer for further details about
“Toyota Genuine Motor Oil”. Other motor
oils of matching quality also be used.Look at the see−through coolant reser-
voir when the engine is cold. The cool-
ant level is satisfactory if it is between
the “FULL” and “LOW” lines on the
reservoir. If the level is low, add the
coolant. (For the coolant type, see
“Coolant type selection” described be-
low.)
The coolant level in the reservoir will vary
with engine temperature. However, if the
level is on or below the “LOW” line, add
coolant. Bring the level up to the “FULL”
line.
If the coolant level drops within a short
time after replenishing, there may be a
leak in the system. Visually check the
radiator, hoses, radiator cap and drain
cock and water pump.
If you can find no leak, have any autho-
rized Toyota dealer or repairer, or another
duly qualified and equipped professional,
test the cap pressure and check for leaks
in the cooling system.
CAUTION
To prevent burning yourself, do not
remove the radiator cap when the en-
gine is hot.
Dyna100/150_EE
Checking the engine coolant
level

216SPECIFICATIONS
ENGINE
Valve clearance (engine cold), mm (in.):
Intake 0.20—0.30 (0.008—0.012)
Exhaust 0.35—0.45 (0.014—0.018)
ENGINE LUBRICATION
Oil capacity (drain andrefill—reference

),
L (qt., Imp. qt.):
With filter 7.0 (7.4, 6.2)
Without filter 6.8 (7.2, 6.0)

: The engine oil capacity is a reference
quantity to be used when exchanging.
Warm up and turn off the engine, wait
more than 5 minutes, and check the oil
level on the dipstick.
“Toyota Genuine Motor Oil” is used in
your Toyota vehicle. Toyota recommends
the use of approved “Toyota Genuine
Motor Oil”. Another motor oil of matching
quality can also be used.
Oil grade:
ACEA C2
NOTICE
Using engine oil other than ACEA C2
may damage the catalytic converter.
Recommended viscosity (SAE):
Temperature range anticipated before
next oil change
Preferred
Please contact any authorized Toyota
dealer or repairer, or another duly quali-
fied and equipped professional, for further
details.
COOLING SYSTEM
Total capacity, L (qt., Imp. qt.):
With front and rear heaters
11.5 (12.2, 10.1)
With front heater 10.7 (11.3, 9.4)
Coolant type:
Your Toyota vehicle is filled with “Toyota
Super Long Life Coolant” at the factory.
In order to avoid technical problems,
only use “Toyota Super Long Life
Coolant” or similar high quality ethylene
glycol based non−silicate, non−amine,
non−nitrite, and non−borate coolant with
long−life hybrid organic acid technology.
(Coolant with long−life hybrid organic
acid technology is a combination of low
phosphates and organic acids.)
Do not use plain water alone.
Please contact any authorized Toyota
dealer or repairer, or another duly quali-
fied and equipped professional, for fur-
ther details.
BATTERY
Specific gravity reading at 20_C(68_F):
1.250—1.290 Fully charged
1.160—1.200 Half charged
1.060—1.100 Discharged
Charging rates:
Quick charge 15 A max.
Slow charge 5 A max.
CLUTCH
Pedal free play, mm (in.):
5—18 (0.2—0.7)
Fluid type:
SAE J1703 or FMVSS No.116 DOT 3
Dyna100/150_EE
Service specifications

SPECIFICATIONS217
MANUAL TRANSMISSION
Oil capacity, L (qt., Imp. qt.):
Dyna 100

2.6 (2.7, 2.3)
Dyna 150
2.4 (2.5, 2.1)
Oil type:
Gear oil API GL−4orGL−5
Recommended oil viscosity:
SAE 75W−90

: See “Model code” on page vi in the
beginning of this manual if you are not
sure of your vehicle model.
DIFFERENTIAL
Oil capacity, L (qt., Imp. qt.):
Dyna 100

2.30 (2.43, 2.02)
Dyna 150
3.45 (3.65, 3.04)
Your Toyota vehicle is filled with “Toyota
Genuine Differential Gear Oil” at the
factory. Toyota recommends the use of
approved “Toyota Genuine Motor Oil”.
Another motor oil of matching quality can
also be used.
Oil type:
Standard differential
Hypoid gear oil API GL−5
Limited slip differential
Hypoid gear oil LSD API GL−5
Recommended oil viscosity:
Above−18_C(0_F)
SAE 90
Below−18_C(0_F)
SAE 80W or 80W−90

: See “Model code” on page vi in the
beginning of this manual if you are not
sure of your vehicle model.
Please contact any authorized Toyota
dealer or repairer, or another duly quali-
fied and equipped professional, for further
details.CHASSIS LUBRICATION
Wheel bearings:
Lithium base wheel bearing grease,
NLGI No.2
Ball joints:
Molybdenum−disulfide lithium base chas-
sis grease, NLGI No.1 or No.2
Propeller shafts:
Lithium base chassis grease, NLGI No.2
BRAKES
Minimum pedal clearance when depressed
with the force of 490 N (50 kgf, 110 lbf)
with the engine running, mm (in.):
Dyna 100

59 (2.3)
Dyna 150
51 (2.0)
Pedal free play, mm (in.):
1—6 (0.04—0.24)
Parking brake adjustment when pulled with
the force of 245 N (25 kgf, 55 lbf):
Dyna 100

4—6 clicks
Dyna 150
6—8 clicks
Fluid type:
SAE J1703 or FMVSS No.116 DOT 3

: See “Model code” on page vi in the
beginning of this manual if you are not
sure of your vehicle model.
STEERING
Wheel free play:
Less than 40 mm (1.6 in.)
Power steering fluid type:
Automatic transmission fluid DEXRONrII
or III
Dyna100/150_EE

222INDEX
A
Adding washer fluid 204..................
Adjustment
Driver ’s seat 25.......................
Seat belt 28...........................
Air bleeding 142.........................
Air conditioning filter 93..................
Air conditioningsystem 84...............
Airbag 38...............................
Anti−lock brake system
warning light 73.......................
Anti−theft steering column lock 80........
Appearance care
Cleaning the interior 173...............
Protecting your Toyota from
corrosion 170.......................
Washing and waxing 171...............
Auxiliary box 102........................
B
Battery
Access 182...........................
Checking battery condition 200.........
Gas caution 200.......................
Handling safety 200...................
Recharging precautions 202............
Winter driving tips 129.................
Before starting the engine 124............
Brake pad wear indicators 119............
Brake system 116.......................
Brake system warning light 73............
Brakes
Pad wear indicators 119................
Parking 82............................
Break−in tips 108........................
C
Carbon monoxide caution 114............
Card holder 104.........................
Center console box 103..................
Charging system warning light 73.........
Checking and replacing fuses 203........
Checking the engine oil level 188.........
Checking the radiator, condenser and
intercooler 192........................Child restraint
Child restraint system 45...............
Installation 48,51......................
Precautions 44........................
Types of child restraint system 46.......
Cigarette lighter and ashtrays 100........
Cleaning the interior 173.................
Cold weather
Operation 129.........................
Condenser
Checking the condenser 192...........
Controls, Instrument panel 2,6...........
Cooling system
Coolant level 190......................
Engine overheating 148................
Radiator and reservoir 190.............
Radiator cap 148......................
Winter driving tips 129.................
Corrosion prevention 170................
Cup holder 102..........................
D
Diesel particulate filter system 110........
Differential, Limited slip 120..............
Dimmer switch, Headlight 62.............
Directional signals 62....................
Do−it−yourself maintenance
Service precautions 185...............
Does your vehicle need repairing? 177....
Doors
Side doors 13.........................
DPF system 110.........................
Driver ’s seat 25.........................
Driving
Driving tips 124........................
Manual transmission 81................
Driving in the rain 128....................
Driving tips
Driving in the rain 128..................
Driving tips in various conditions 127....
Driving with a manual
transmission 81.....................
Economical driving 138................
Good driving practice 81...............
Pre−trip safety check 126..............
Winter driving tips 129.................
During
Break−in 108..........................
Dyna100/150_EE
