2001MY ECHO (U) L/O0008
1532001 ECHO (OM52440U)
IN CASE OF AN EMERGENCY
If your vehicle will not start154
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your engine stalls while driving 157
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your vehicle overheats 157
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
If you have a flat tire 158
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
If your vehicle needs to be towed 166
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If you cannot shift automatic transmission selector lever 169
. . . . . . . .
If you lose your keys 170
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . .
If you lose your wireless remote control transmitter 170
. . . . . . . . . . . . .
SECTION 4
2001MY ECHO (U) L/O0008
2172001 ECHO (OM52440U)
Tires
Tire size:Compact spare tireT115/70D14
Except compact spare tire P175/65R14 81S
Tire pressure, kPa (kgf/cm
2 or bar, psi):
Compact spare tire 420 (4.2, 60)
Except compact spare tire 220 (2.2, 32)
Wheel size: Compact spare tire14 x 4T
Except compact Spare tire 14 x 5.5J
14 x 5.5JJ
Wheel nut torque, N´m (kgf´m, ft´lbf):
103 (10.5, 76)
Fuses
SU81001
Engine room J/B
Fuses (type A)1. H±LP (RH) 10 A: Right±hand headlight
2. H±LP (LH) 10 A: Left±hand headlight
3. ST 30 A: Starter system
4. AM2 15 A: Starter system, SRS airbag
system, multiport fuel injection sys-
tem/sequential multiport fuel injection
system, engine immobiliser system,
discharge warning system
5. HORN 15 A: Horn
6. EFI 15 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system
SU81002
Instrument panel J/B
7. DOME 15 A: Clock, radio, interior light,
gauges of meters, wireless remote con-
trol system
8. SPARE 15 A: Spare
9. SPARE 30 A: Spare
10. GAUGE 10 A: Back±up lights, charging
system, air c onditioning system, power
window system, gauges of meters
11. ACC 15 A: Clock, radio, outside rear
view mirror system, cigarette lighter
12. A/C 7.5 A: Air conditioning system
