TOYOTA FJ CRUISER 2007 1.G Owners Manual

1312007 FJ CRUISER from Oct. ’06Prod. (OM35873U)
TS17018
The vehicle stability control system au-
tomatically turns off, and the “VSC
OFF” indicator light is illuminated,
when either one of the following condi-
tions applies:
The transfer is set into “HL” or “LL”
position. (full−time four −wheel drive
models)
The transfer is set into “H4” or “L4”
position. (part −time four −wheel drive
models)
The rear differential is locked. (vehicles
with rear differential lock) The “VSC OFF” indicator light comes on
for a few seconds when the ignition key
is turned to “ON”, and then turns off. If
either one of the above conditions applies,
the indicator light is illuminated again.
The “VSC OFF” indicator light comes on
for a few seconds when the ignition key
is turned to “ON”. It will come on again
when you push the center differential lock
switch to turn off the system.
In the following cases, contact your Toyota
dealer:
The indicator light does not come on
when the ignition key is turned to
“ON”.
The indicator light remains on after the
ignition key is turned to “ON”.
The indicator light comes on when the
system is on while driving.
TS17008
“VSC TRAC” warning light
This light warns that there is a problem
somewhere in the following.
Vehicle stability control system
Traction control system
Active traction control system
(four
−wheel drive models with rear dif-
ferential lock)
“AUTO LSD” system
(two −wheel drive models)

1322007 FJ CRUISER from Oct. ’06Prod. (OM35873U)
The light will come on when the ignition
key is turned to “ON”, and will go off after
about a few seconds.
The light may come on for 60 seconds
after the ignition key is turned to “ON”. It
is normal if they go out after a while.
Depressing the brake pedal repeatedly
may turn on the light. It is normal if they
go out after a few seconds.
If the “VSC TRAC” waning light comes on
while driving, the vehicle stability control
system does not work. However, as nor-
mal braking operates when being applied,
there is no problem to continue your driv-
ing.
In the following cases, contact your Toyota
dealer:
The warning light does not come on
after the ignition key is turned to “ON”.
The warning light remains on after the
ignition key is turned to “ON”.
The warning light comes on while driv-
ing.Four
−wheel drive models, and the vehicles
with rear differential lock—
The “VSC OFF” indicator light comes on
when the “VSC TRAC” warning light
comes on, even when the four −wheel
drive control lever is in the “H” (full −time
four −wheel drive models) or “H2” (part −
time four −wheel drive models) or the rear
differential is unlocked.
TS17009
The rear differential lock system is pro-
vided for use only when wheel spinning
occurs in a ditch or on a slippery or
ragged surface.
This differential lock system is effective in
case one of the rear wheels is spinning.
Full −time four −wheel drive models—
Before using the rear differential lock sys-
tem, first shift the four −wheel drive control
lever into “LL” to see if this is sufficient.
If this has no effect, additionally use the
rear differential lock system.
Rear differential lock system

1332007 FJ CRUISER from Oct. ’06Prod. (OM35873U)
Part−time four −wheel drive models—
Before using the rear differential lock sys-
tem, first shift the four −wheel drive control
lever into “L4” to see if this is sufficient.
If this has no effect, additionally use the
rear differential lock system.
CAUTION
Do not use the rear differential lock
in the conditions other than above.
Large steering effort and careful cor-
nering control will be required.
TS17016
To lock the rear differential, push the
switch.
Be sure to stop the wheels before locking
the differential.
For easy locking on vehicle with manual
transmission, depress the clutch pedal,
push the lock switch and slowly release
the clutch pedal. On vehicle with automat-
ic transmission, push the lock switch and
gently depress the accelerator pedal.
The indicator light will blink when the
switch is turned on. Wait a few seconds
for the system to complete operation. Af-
ter the differential is locked, the light will
stop blinking and remain on. The following systems do not operate
when the rear differential is locked. It is
normal operation for the “ABS” warning
light, “VSC OFF” indicator light and slip
indicator light to be on at this time.
Anti
−lock brake system
Brake assist system
Vehicle stability control system
Traction control system
CAUTION
Do not lock the differential until the
wheels have stopped spinning.
Otherwise, the vehicle may move in
an unexpected direction when the
differential lock is engaged, result-
ing in an accident. This may also
lead to possible damage to differen-
tial lock component parts.
Do not drive over 8 km/h (5 mph)
when the differential is locked.

1342007 FJ CRUISER from Oct. ’06Prod. (OM35873U)
To unlock the differential, push the
switch once again.
Unlock the differential as soon as the ve-
hicle moves out.
For easy unlocking, slightly turn the steer-
ing wheel in either direction while the ve-
hicle is in motion.
When the differential lock is disengaged,
the indicator light will go out.
Full−time four −wheel drive models—
The differential will also unlock if you shift
the four −wheel drive control lever to the
“H” or “HL” position. Never forget to turn
off the switch after using this feature.
Part −time four −wheel drive models—
The rear differential will also unlock if you
shift the four −wheel drive control lever to
the “H2” or “H4” position. Never forget to
turn off the switch after using this feature.
To check the indicator bulb, turn the igni-
tion key to the “ON” position, but do not
start the engine.
CAUTION
Do not keep driving with the differen-
tial lock switch on.
TS17012
When parking, firmly apply the parking
brake to avoid inadvertent creeping.
To set: Pull up the lever. For better hold-
ing power, first depress the brake pedal
and hold it while setting the parking
brake.
To release: Pull up the lever slightly (1),
press the thumb button (2), and lower (3).
To remind you that the parking brake is
set, the parking brake reminder light in
the instrument panel remains on until you
release the parking brake.
CAUTION
Before driving, be sure the parking
brake is fully released and the park-
ing brake reminder light is off.
Parking brake

1352007 FJ CRUISER from Oct. ’06Prod. (OM35873U)
The cruise control is designed to main-
tain a set cruising speed without requir-
ing the driver to operate the accelera-
tor. Cruising speed can be set to any
speed above 40 km/h (25 mph).
Within the limits of the engine’s capabili-
ties, cruising speed can be maintained up
or down grades. However, changes in ve-
hicle speed may occur on steeper grades.
CAUTION
To help maintain maximum control
of your vehicle, do not use the
cruise control when driving in
heavy or varying traffic, or on slip-
pery (rainy, icy or snowcovered) or
winding roads.
Avoid vehicle speed increases when
driving downhill. If the vehicle
speed is too fast in relation to the
cruise control set speed, cancel the
cruise control then downshift the
transmission to use engine braking
to slow down.
TS17013
TURNING THE SYSTEM ON AND OFF
To turn the cruise control on, press the
“ON−OFF” button. The “CRUISE” indicator
light on the instrument panel will come on
to indicate that the cruise control is opera-
tional. Pressing the “ON −OFF” button
again turns the system off.
When the system is turned off, cruising
speed must be reset when the cruise con-
trol is turned on again.
CAUTION
Due to the cruise control switch be-
ing located just behind the steering
wheel, there is a possibility that it
may be touched accidentally. To avoid
accidentally engaging the cruise con-
trol, turn the system off when it is
not in use. Make sure the “CRUISE”
indicator light is off.
Cruise control

1362007 FJ CRUISER from Oct. ’06Prod. (OM35873U)
TS17014
SETTING THE CRUISING SPEED
On vehicles with automatic transmission,
the transmission must be in “D” or “4”
before you set the cruising speed.
Bring your vehicle to the desired speed,
push the lever down in the “− SET” direc-
tion and release it. This sets the vehicle
at that speed. If the speed is not satisfac-
tory, tap the lever up for a faster speed,
or tap it down for a slower speed. Each
tap changes the set speed by 1.6 km/h
(1.0 mph). You can now take your foot off
the accelerator pedal. If you need acceleration—for example,
when passing—depress the accelerator
pedal enough for the vehicle to exceed
the set speed. When you release it, the
vehicle will return to the speed set prior
to the acceleration.
CAUTION
For manual transmission:
While driving with the cruise control
on, do not shift to neutral without
depressing the clutch pedal, as this
may cause engine racing or overrev-
ving.
CANCELLING THE CRUISE CONTROL
The cruise control may be temporarily
cancelled by the driver or by the system
itself under certain circumstances. Tempo-
rary cancellation allows the set cruising
speed to remain in memory.
The cruise control can be temporarily can-
celled by doing the following:
Pulling the lever in the “CANCEL” di-
rection and releasing it
Depressing the brake pedal
Depressing the clutch pedalUnder certain circumstances, the cruise
control is temporarily cancelled:
When vehicle speed falls below 40
km/h (25 mph)
When vehicle stability control is acti-
vated
When vehicle speed drops 16 km/h (10
mph) below the set speed, the cruise con-
trol is cancelled and the set speed is
erased from memory.
The “CRUISE” indicator light remains on
to indicate that the system is still in op-
eration.
To turn the cruise control off, press the
“ON −OFF” button. Make sure the
“CRUISE” indicator light is off.
If the cruise control automatically cancels
out other than for the above cases, have
your vehicle checked by your Toyota deal-
er at the earliest opportunity.
RESUMING THE CRUISE CONTROL
If the cruise control is temporarily can-
celled, the cruising speed can be resumed
by pushing the lever up in the “+ RES”
direction.
Vehicle speed must be above 40 km/h (25
mph).

1372007 FJ CRUISER from Oct. ’06Prod. (OM35873U)
RESETTING TO A FASTER SPEED
Push the lever up in the “+ RES” direction
and hold it. Release the lever when the
desired speed is attained. While the lever
is held up, the vehicle will gradually gain
speed.
However, a faster way to reset is to ac-
celerate the vehicle and then push the
lever down in the “− SET” direction.
RESETTING TO A SLOWER SPEED
Push the lever down in the “− SET” direc-
tion and hold it. Release the lever when
the desired speed is attained. While the
lever is held down, the vehicle speed will
gradually decrease.
However, a faster way to reset is to de-
press the brake pedal and then push the
lever down in the “− SET” direction.
On vehicles with automatic transmission,
even if you downshift from “D” to “4”, with
the cruise control on, engine braking will
not be enabled because the cruise control
is not cancelled. To decrease the vehicle
speed, reset to a slower speed with the
cruise control lever or depress the brake
pedal. If you use the brake pedal, cruise
control is cancelled. CRUISE CONTROL FAILURE WARNING
If the “CRUISE” indicator light flashes
when using the cruise control, press the
“ON
−OFF” button to turn the system off
and then press it again to turn it on.
If any of the following conditions then oc-
curs, there is some trouble in the cruise
control system.
The indicator light does not come on.
The indicator light flashes again.
The indicator light goes out after it
comes on.
If this is the case, contact your Toyota
dealer and have your vehicle inspected.
TS17019
To crank the engine without depressing
the clutch pedal, push the switch with
the ignition on.
The switch stays on as long as the igni-
tion is on. And it will automatically turn off
when the ignition is off. An indicator light
will illuminate to indicate the system is
operating.
This switch cancels the clutch start sys-
tem, which is designed to keep the starter
motor from operating if the clutch pedal is
not depressed all the way down.
The switch allows the vehicle to be driven
out of difficult situations by cranking the
engine with the clutch engaged.
Clutch start cancel switch

1382007 FJ CRUISER from Oct. ’06Prod. (OM35873U)
Never use the switch for normal engine
starting. Be sure to follow the starting
procedure instructed in “How to start the
engine” on page 232 in Section 3.

1392007 FJ CRUISER from Oct. ’06Prod. (OM35873U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Audio system
Reference140
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . .
Using your audio system 140
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
Display color change function 159
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio remote controls 160
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . .
AUX adapter 161
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . .
Sub woofer 162
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . .
Audio system operating hints 162
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 1 8

1402007 FJ CRUISER from Oct. ’06Prod. (OM35873U)
PS18502
Type 1: AM·FM radio/compact disc player
/MP3/WMA player (with compact disc
changer controller)
TS18001a
Type 2: AM·FM radio/compact disc player
with changer/MP3/WMA player (with XM
satellite radio
∗ controller)
∗: Use of satellite radio requires XM
tuner and service. Contact your Toyota
dealer for details. This section describes some of the basic
features on Toyota audio systems. Some
information may not pertain to your sys-
tem.
Your audio system works when the ignition
key is in the “ACC” or “ON” position.
Welcome function (type 2)
When you turn the ignition switch to the
“ACC” or “ON” position, “FJ CRUISER”
will appear scrolling on the display. And
then “FJammer” will appear for 6 seconds.
While this function is operating, the dis-
play is illuminated with full intensity and
the instrument panel light control dial is
disabled. However, you can turn off the
display illumination by pushing the
“PWR·VOL” knob.
TURNING THE SYSTEM ON AND OFF
Push “PWR·VOL” to turn the audio system
on and off.
Push “AM”, “FM1”, “FM2”,
“AM·SAT”∗ or
“DISC·AUX” to turn on that function with-
out pushing “PWR·VOL”. To turn on the
compact disc player, a compact disc must
be loaded in the player.
You can turn on the compact disc player
by inserting a compact disc.
Reference Using your audio system—
—Some basics
