TOYOTA FJ CRUISER 2008 1.G Owners Manual

254 3−5. Other interior features
After calibration, leave the syst em for 6 seconds or press the
SET button for about 2 seconds.
If the display returns to the outside temperature display, the calibra−
tion is complete.
 Circling calibration
Stop the vehicle where it is safe to drive in a circle.
Press the SET button
until the zone number
appears on the outside
temperature display.
Push the SET button.
“– –” will start moving.
Drive the vehicle in a cir−
cle at 5 mph (8 km/h).
If there is not enough space
to drive in a circle, drive
around the block until the
direction is displayed.
When the compass display
returns to the outside tem−
perature display, calibration
is complete.
When circling calibration fails, Er is displayed for 2 seconds and then COM−
PASS flashes. It also flashes when circling calibration is not completed.
If you want to cancel the calibration before it is complete, press the SET but−
ton for about 2 seconds.

255
3−5. Other interior features
3
Interior features
 Conditions unfavorable to correct operation
The compass may not show the correct direction in the following conditions:
The vehicle is stopped immediately after turning.
The compass does not adjust while the vehicle is stopped.
The engine switch is turned off immediately after turning.
The vehicle is on an inclined surface.
The vehicle is in a place where the earth’s magnetic field is subject to
interference by artificial magnetic fields (underground car park/parking
lot, under a steel tower, between buildings, roof car park/parking lot, near
an intersection, near a large vehicle, etc.).
 The vehicle has become magnetized.
(There is a magnet or metal object on or near the accessory meter.)

The battery has been disconnected.
CAUTION
 While driving the vehicle
Do not adjust the display. Be sure to adjust the display only when the vehicle
is stopped.
 When doing the circling calibration
Be sure to secure a wide space, and watch out for people and vehicles in the
neighborhood. Do not violate any local traffic rules while performing circling
calibration.

256 3−5. Other interior features
NOTICE
 To avoid the compass malfunctions
Do not place magnets or any metal objects on or near the accessory meter.
Doing this may cause a malfunction of the compass sensor.
 To ensure normal operation of the compass
 Do not perform circling calibration of the compass in a place where the
earth’s magnetic field is subject to interference by artificial magnetic fields.

During calibration, do not operate electric systems (power windows, etc.)
as they may interfere with the calibration.

258
4−1. Maintenance and care
Cleaning and protecting the vehicle exterior
 Automatic car washes
 Before washing the vehicle, do the following.
Fold the mirrors back.
Remove the antenna.
 Brushes used in automatic car washes may scratch the vehicle surface
and harm your vehicle’s paint.
High pressure automatic car washes
Do not allow the nozzles of the car wash to come within close proximity of
the windows. Before entering an automatic car wash, check that the fuel filler
door on your vehicle is closed properly.
 Touchup paint (if equipped)
Touch−up paint may be used to cover small chips or scratches.
Apply the paint soon after the damage occurs or corrosion may set in. To
apply the touch−up paint so it is hardly noticeable the trick is to apply it only
to the bare spots. Apply only the smallest amount possible and do not paint
the surface around the scratch or chip. Perform the following to protect the vehicle and maintain it in prime
condition.
 Working from top to bottom, liber
ally apply water to the vehicle
body, wheel wells and underside of the vehicle to remove any
dirt and dust.
Wash the vehicle body using a sponge or soft cloth, such as a
chamois.
 For hard−to−remove marks, use car wash soap and rinse thor−
oughly with water.

Wipe away any water.

Wax the vehicle when the waterproof coating deteriorates.
If water does not bead on a clean surface, apply wax when the vehicle
body is cool.

259
4−1. Maintenance and care
4
Maintenance and care
 Aluminum wheels (if equipped)
Remove any dirt immediately by using a neutral detergent. Do not use hard
brushes or abrasive cleaners. Do not use strong or harsh chemical cleaners.
Use the same mild detergent and wax as used on the point.
 Bumpers and side moldings
Do not scrub with abrasive cleaners.
To prevent deterioration and body corrosion
Wash the vehicle immediately in the following cases:
After driving near the sea coast
After driving on salted roads
If you see coal tar or tree sap on the paint surface
If you see dead insects or insect droppings on the paint
After driving in an area contaminated with soot, oily smoke, mine dust,
iron powder or chemical substances
If the vehicle becomes heavily soiled in dust or mud
If liquids such as benzene and gasoline are spilled on the paint surface

If the paint is chipped or scratched, have it repaired immediately.
CAUTION
 Caution about the exhaust pipe
Exhaust gasses cause the exhaust pipe to become quite hot.
When washing the vehicle, be careful not to touch the pipe until it has cooled
sufficiently, as touching a hot exhaust pipe can cause burns.
NOTICE
 To protect your vehicle’s painted surfaces
Do not use organic cleaners such as benzene or gasoline.
Cleaning the exterior lights
Wash carefully. Do not use organic substances or scrub with a hard brush.
This may damage the surfaces of the lights.
 Do not apply wax on the surfaces of the lights.
Wax may cause damage to the lenses.

260
4−1. Maintenance and care
Cleaning and protecting the vehicle interior
 Cleaning the inside of the rear window
Do not use glass cleaner to clean the rear window, as this may cause dam−
age to the rear window defogger heater wires. Use a cloth dampened with
lukewarm water to gently wipe the window clean. Wipe the window in
strokes running parallel to the heater wires.
 Caring for leather areas
Toyota recommends cleaning the interior of the vehicle at least twice a year
to maintain the quality of the vehicle’s interior.
 Shampooing the carpets
There are several commercial foaming−type cleaners available. Use a
sponge or brush to apply the foam. Rub in overlapping circles. Do not apply
water. The excellent results are obtained when keeping the carpet as dry as
possible. The following procedures will help protect your vehicle’s interior and
keep it in top condition:
 Protecting the vehicle interior
Remove dirt and dust using a vacuum cleaner. Wipe dirty sur−
faces with a cloth dampened with lukewarm water.
 Cleaning the leather areas
 Remove dirt and dust using a vacuum cleaner.
Wipe any excess dirt and dust with a soft cloth dampened with
diluted detergent.
Use a diluted water solution of approximately 5% neutral wool deter−
gent.
 Wring out any excess water
from the cloth and thoroughly
wipe off all remaining traces of detergent.

Wipe the surface with a dry, soft cloth to remove any remain−
ing moisture. Allow the leather to dry in a shaded and venti−
lated area.

261
4−1. Maintenance and care
4
Maintenance and care
 Seat belts
Clean with mild soap and lukewarm water using a cloth or sponge. Also
check the belts periodically for excessive wear, fraying or cuts.
CAUTION
 Water in the vehicle
 Be careful not to splash or spill liquid on the floor.
Do not get any of the SRS components or wiring in the vehicle interior wet.
(P. 7 3 )
Electrical malfunction may cause the airbags to deploy or not function
properly, resulting in death or severe injury.
NOTICE
 Cleaning detergents
Do not use organic substances such as benzene or gasoline, acidic or alka−
line solutions, dye, bleach or other detergent. Doing so may discolor the
vehicle interior or cause streaks or damage to painted surfaces.
 Preventing damage to leather surfaces
Observe the following precautions to avoid damage to and deterioration of
leather surfaces.
 Remove any dust or dirt on leather surfaces immediately.
Do not expose the vehicle to direct sunlight for extended periods of time.
Park the vehicle in the shade, especially during summer.
 Do not place items made of vinyl, plastic, or that contain wax on the uphol−
stery, as they may stick to the leather surface if the vehicle interior heats
up significantly.
 Water on the floor
Do not wash the vehicle floor with water.
Vehicle systems such as the audio system may be damaged if water comes
into contact with electrical components under the floor of the vehicle, and
may also cause the body to rust.

262 4−1. Maintenance and care
NOTICE
 Cleaning the inside of the rear window
Be careful not to scratch or damage the heater wires.

263
4
Maintenance and care
4−2. Maintenance
Maintenance requirements
 Repair and replacement
It is recommended that genuine Toyota parts be used for repair to ensure
performance of each system. If non−Toyota parts are used in replacement or
if a repair shop other than Toyota deal
er performs repairs, confirm the war−
ranty coverage. To ensure safe and economical driv ing, daytoday care and regular
maintenance is essential. It is the owner ’s responsibility to perform
regular checks. Toyota recommends the following maintenance.
 General maintenance
Should be performed on a daily basis. This can be done by your−
self or by a Toyota dealer.
 Scheduled maintenance
Should be performed at specified intervals according to the
maintenance schedule.
For details about maintenance items and schedules, refer to the
“Scheduled Maintenance Guide” or “Owner ’s Manual Supplement”.
 Doityourself maintenance
You can perform some maintenance procedures yourself.
Please be aware that do−it−yourself maintenance may affect war−
ranty coverage.
The use of Toyota Repair Manuals is recommended.
For details about warranty coverage, see the separate “Owner ’s
y Warrant Information Booklet”, “Owner ’s Manual Supplement”.

264 4−2. Maintenance
 Allow inspection and repairs to be performed by a Toyota dealer
 Toyota technicians are well−trained specialists and are kept up to date
with the latest service information. They are well informed about the
operations of all systems on your vehicle.
 Keep a copy of the repair order. It proves that the maintenance that has
been performed is under warranty coverage. If any problem should arise
while your vehicle is under warranty, your Toyota dealer will promptly
take care of it.
CAUTION
 Warning in handling of battery
 Engine exhaust, some of its constituents, and a wide variety of automobile
components contain or emit chemicals known to the State of California to
cause cancer and birth defects and other reproductive harm. Work in a
well ventilated area.
 Oils, fuels and fluids contained in vehicles as well as waste produced by
component wear contain or emit chemicals known to the State of Califor−
nia to cause cancer and birth defects or other reproductive harm. Avoid
exposure and wash any affected area immediately.
 Battery posts, terminals and related accessories contain lead and lead
compounds which are known to cause brain damage. Wash your hands
after handling. (
P. 283)
