TOYOTA FJ CRUISER 2008 1.G Owner's Manual

21
: If equipped
*: Vehicles without sub woofer
Shopping bag hooksP. 251
Cargo net hooksP. 250
ToolsP. 340JackP. 340
Power outletP. 240
Shopping bag hooks*P. 251
Cargo net hooks*P. 250
Luggage storage
box
*P. 248

22
For your information
Main Owners Manual
Please note that this manual applies to all models explains and all equip−
ment, including options. Therefore, you may find some explanations for
equipment not installed on your vehicle.
All specifications provided in this manual are current at the time of printing.
However, because of the Toyota policy of continual product improvement, we
reserve the right to make changes at any time without notice.
Depending on specifications, the vehicle shown in the illustrations may differ
from your vehicle in terms of equipment.
Accessories, spare parts and modification of your Toyota
A wide variety of non−genuine spare parts and accessories for Toyota
vehicles are currently available in the market. You should know that Toyota
does not warrant these products and is not responsible for their
performance, repair, or replacement, or for any damage they may cause to,
or adverse effect they may have on, your Toyota vehicle.
This vehicle should not be modified with non−genuine Toyota products.
Modification with non−genuine Toyota products could affect its performance,
safety or durability, and may even
violate governmental regulations. In
addition, damage or performance problems resulting from the modification
may not be covered under warranty.
Installation of a mobile twoway radio system
As the installation of a mobile two−way radio system in your vehicle could
affect electronic systems such as the multiport fuel injection system/sequen−
tial multiport fuel injection system, cruise control system, anti−lock brake sys−
tem, SRS airbag system and seat belt pretensioner system, be sure to check
with your Toyota dealer for precautionary measures or special instructions
regarding installation.

23
Scrapping your Toyota
The SRS airbag and seat belt pretensioner devices in your Toyota contain
explosive chemicals. If the vehicle is scrapped with the airbags and seat belt
pretensioners left as they are, this may cause an accident such as fire. Be
sure to have the systems of the SRS airbag and seat belt pretensioner
removed and disposed of by a qualified service shop or by your Toyota
dealer before you scrap your vehicle.
Perchlorate Material
Special handling may apply,
See www.dtsc.ca.gov/hazardouswaste/perchlorate.
Your vehicle has components that may contain perchlorate. These compo−
nents may include airbag, seat belt pretensioners, and wireless remote con−
trol batteries.
CAUTION
 General precautions while driving
Driving under the influence: Never drive your vehicle when under the influ−
ence of alcohol or drugs that have impaired your ability to operate your vehi−
cle. Alcohol and certain drugs delay reaction time, impair judgment and
reduce coordination, which could lead to
an accident that will hurt or kill you,
your occupants or others.
Defensive driving: Always drive defensively. Anticipate mistakes that other
drivers or pedestrians might make and be ready to avoid accidents.
Driver distraction: Always give your full
attention to driving. Anything that dis−
tracts the driver, such as adjusting controls, talking on a cellular phone or
reading can result in a collision with resulting death or serious injury to you,
your occupants or others.

24
CAUTION
 General precaution regarding children’s safety
Never leave children unattended in the vehicle, and never allow children to
have or use the key.
Children may be able to start the vehicle or shift the vehicle into neutral.
There is also a danger that children may injure themselves by playing with
the cigarette lighter, the windows, or other features of the vehicle. In addi−
tion, heat build−up or extremely cold temperatures inside the vehicle can be
fatal to children.

25
Symbols used throughout this manual
Cautions & Notices
Safety symbol
CAUTION
This is a warning against anything which may cause injury to people if the
warning is ignored. You are informed about what you must or must not do in
order to reduce the risk of injury to yourself and others.
NOTICE
This is a warning against anything which may cause damage to the vehicle or
its equipment if the warning is ignored. You are informed about what you must
or must not do in order to avoid or reduce the risk of damage to your Toyota
and its equipment.
Throughout this manual, you will also see the symbol of a circle with
a slash through it. This means “Do not”, “Do not do this”, or “Do not
let this happen”.

26

28
1−1. Key information
Ke ys
 Key number plate
Keep the plate in a safe place such as your wallet, not in the vehicle. In the
event that a key is lost, a new key can be made by your Toyota dealer using
the key number plate. (
P. 352)
NOTICE
 To prevent key damage
 Do not subject the keys to strong shocks, expose them to high tempera−
tures by placing them in direct sunlight, or get them wet.
The following keys are provided with the vehicle.
Vehicles with wireless remote control system
Master keys (with wireless
remote control function)
Operating the wireless remote
control function (
P. 30)
Va l e t k e y
Key number plate
Vehicles without wireless remote control system
Master keys
Va l e t k e y
Key number plate

29
1−1. Key information
1
Before driving
NOTICE
 To prevent key damage
 Do not expose the keys to electromagnetic materials or attach any mate−
rial that blocks electromagnetic waves to the key surface.

30
1−2. Opening, closing and locking the doors
Wireless remote control (if equipped)
 2step unlocking function
When you push the UNLOCK button, the driver ’s door is unlocked. Pushing
the button again within 3 seconds unlocks the other doors.
 Operation signals
A buzzer sounds and the emergency flashers flash to indicate that the doors
have been locked/unlocked. (Locked: Once; Unlocked: Twice)
Panic mode
 Door lock buzzer
If a door or glass hatch is not fully closed, a buzzer sounds for 10 seconds if
an attempt to lock the door and glass hatch are made. Fully close the door
and glass hatch to stop the buzzer, and lock the vehicle once more. The wireless remote control can be used to lock and unlock the vehi
cle from outside the vehicle.
Locks all doors
Unlocks all doors
Sounds alarm
(push and hold)
When PANIC button is pushed for longer
than about one second, an alarm will
sound for about 60 seconds and the vehi−
cle lights will flash to deter any person
from trying to break into or damage your
vehicle.
To stop the alarm, push any button on the
wireless remote control.
UN
LOCKLOCK
PA NIC

31
1−2. Opening, closing and locking the doors
1
Before driving
 Key battery depletion
The standard battery life is 1 to 2 years. (The battery becomes depleted
even if the key is not used.) If the wireless remote control function does not
operate, the battery may be depleted. Replace the battery when necessary.
(P. 301)
Security feature
If a door is not opened within approximately 60 seconds after the vehicle is
unlocked, the security feature automatically locks the vehicle again.
Conditions affecting operation
The wireless remote control function may not operate normally in the follow−
ing situations.
Near a TV tower, radio station, electr ic power plant, airport or other facil−
ity that generates strong radio waves
 When carrying a portable radio, cell ular phone or other wireless commu−
nication device
Conditions affecting operation
When multiple wireless keys are in the vicinity
When the wireless key has come into contact with, or is covered by a
metallic object
 When a wireless key (that emits radio waves) is being used nearby
When the wireless key has been left near an electrical appliance such as
a personal computer
 Customization that can be configured at Toyota dealer
Settings (e.g. wireless remote control system) can be changed.
(Customizable features
P. 386)
