Introduction
This manual explains the operation of the Navigation System.
Please read this manual carefully to ensure proper use. Keep this
manual in your vehicle at all times.
The Navigation System is one of the most technologically advanced
vehicle accessories ever developed. The system receives satellite sig-
nals from the Global Positioning System (GPS) operated by the U.S.
Department of Defense. Using these signals and other vehicle sen-
sors, the system indicates your present position and assists in locating
a desired destination.
The navigation system is designed to select efficient routes from your
present starting location to your destination. The system is also designed
to direct you to a destination that is unfamiliar to you in an ef ficient manner.
The system uses DENSO maps. The calculated routes may not be the
shortest nor the least traffic congested. Your own personal local knowl-
edge or “short cut” may at times be faster than the calculated rou\
tes.
The navigation system’s database includes Point of Interest categories to
allow you to easily select destinations such as restaurants and hotels. If
a destination is not in the database, you can enter the street address o\
r
a major intersection close to it and the system will guide you there.
The system will provide both a visual map and audio instructions. The au-
dio instructions will announce the distance remaining and the direction to
turn in approaching an intersection. These voice instructions will help you
keep your eyes on the road and are timed to provide enough time to allow
you to maneuver, change lanes or slow down.

7
4 My Places
Navigation settings102
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
Setting up the “Home” 103 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting up the “Preset Destinations” 105
. . . . . . . . . . . . . . . . . . . . . .
Setting up the “Address Book” 108
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting up the “Areas to Avoid” 114
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Deleting previous destinations 119
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 Telephone and Information
Telephone (Handsfree system for cellular phone) 122
. . . . . . . . .
Enter a Bluetooth  phone 127 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Call on the Bluetooth  phone 132 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Receive on the Bluetooth  phone 139 . . . . . . . . . . . . . . . . . . . . . . . .
Talk on the Bluetooth  phone 140 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Calendar 143 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . .
6 Audio/video system
Quick reference 146
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Using your audio/video system 147
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Some basics 147
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Radio operation 155
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
Radio operation (XM  Satellite Radio broadcast) 160
. . . . . . . . . . .
CD changer operation 166
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bluetooth  audio operation 178
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DVD player operation 187
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
USB memory/iPod operation 211
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio/video remote controls (steering switches) 218
. . . . . . . . . . . . . .
Rear seat entertainment system features 221
. . . . . . . . . . . . . . . . . .
Using the DVD player (DVD video) 226
. . . . . . . . . . . . . . . . . . . . . . .
Using the DVD player (video CD) 232
. . . . . . . . . . . . . . . . . . . . . . . .
Using the DVD player (audio CD/CD text) 234
. . . . . . . . . . . . . . . . .
Using the DVD player (MP3 discs) 235
. . . . . . . . . . . . . . . . . . . . . . .
Using the video mode 236
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing the initial setting 237
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing the batteries 241
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio/video system operating hints 242
. . . . . . . . . . . . . . . . . . . . . . . . .
7 Rear View Monitor System
Rear view monitor system 254
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

8
8 Setup
General settings260
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Clock settings 265
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . .
Voice settings 267
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . .
Navigation settings 269
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
Detailed navigation settings 269
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Telephone settings 278
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
Volume setting 279
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Manage phone 280
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Phonebook 288
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . .
Setting the phonebook 289
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Speed dials setting 297
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Deleting call history 304
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting the voice tag 305
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bluetooth  309
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . .
Details 314
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . .
Audio settings 317
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Select portable player 317
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting Bluetooth audio 319
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vehicle settings 324
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . .
Maintenance 324
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . .
9 Appendix
Limitations of the navigation system 332
. . . . . . . . . . . . . . . . . . . . . . . . .
Map database information and updates 334
. . . . . . . . . . . . . . . . . . .
Changing the map DVD −ROM 343
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Index 347
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . .

22
The items shown on the “Setup” screen can be set. To display the “Setup” screen, push
the “SETUP” button.
1“General”
Settings are available for language selec-
tion, operation sounds, automatic screen
change, etc. 260 . . . . . . . . . . . . . . . . . . . .
2“Clock”
Used for changing settings for time zones,
daylight saving time, etc. 265 . . . . . . . . .
3“Voice”
Voice guidance can be set. 267 . . . . . . .
4“Navi.”
Settings are available for average cruising
speed, displayed screen contents, POI
icon categories, etc. 269 . . . . . . . . . . . . .
5“Vehicle”
Settings are available for vehicle informa-
tion such as maintenance information. 324
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6“Audio”
Settings are available for portable audio
devices, Bluetooth  audio devices etc.
317
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7“Phone”
Bluetooth  phones and phone numbers
can be registered, and the receiver volume
can be adjusted. 278 . . . . . . . . . . . . . . . .
Quick reference (“Setup” screen)

TELEPHONE AND INFORMATION
122
Handsfree system allows you to make
or receive a call without taking your
hands off the steering wheel by con-
necting your cellular phone.
This system supports Bluetooth .
Bluetooth  is a wireless data system by
which you can call without your cellular
phone being connected with a cable or
placed on a cradle.
If your cellular phone does not support
Bluetooth , this system can not function.
The operating procedure of the phone is
explained here.
For registering and setting of the phone,
see “Telephone settings” on page 278.
CAUTION
While driving, do not use a cellular
phone or connect the Bluetooth
phone.
An antenna for the Bluetooth
connection is built in the display.
People with implanted pacemakers
or cardiac defibrillators should
maintain a reasonable distance
between themselves and the
Bluetooth  antennas. The radio
waves may affect the operation of
such devices.
Before using cellular phones, us-
ers of any electrical medical device
other than implanted pacemakers
and implanted cardiac defibrilla-
tors should consult the manufac-
turer of the device for information
about its operation under the influ-
ence of radio waves. Radio waves
could have unexpected effects on
the operation of such medical de-
vices.
NOTICE
Do not leave your cellular phone in
the car. The temperature inside may
be high and damage the phone.
INFORMATION
In the following conditions, the
system may not function.
 The cellular phone is turned off.
 The current position is outside
the communication area.
 The cellular phone is not connec-
ted.
 The cellular phone has a low bat-
tery.
Even if your cellular phone sup-
ports both handsfree and audio
Bluetooth  connections, it may not
be able to connect to the hands
free connection at the same time.
When using Bluetooth  audio and
handsfree at the same time, the
following problems may occur.
 The Bluetooth connection may
be cut.
 Noise may be heard on the
Bluetooth  audio playback.
Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
Telephone
(Handsfree system for
cellular phone) —

TELEPHONE AND INFORMATION
123
INFORMATION
This system supports the following
service.
Bluetooth  Specification
Ver.1.1 or higher
(Recommended: Ver.2.0+EDR or
higher)
 Profiles
 HFP (Hands Free Profile)
Ver.1.0 or higher
(Recommended: Ver.1.5 or
higher)
 OPP (Object Push Profile)
Ver.1.1
 PBAP (Phone Book Access
Profile) Ver.1.0
If your cellular phone does not
support HFP, you cannot enter the
Bluetooth  phone, and take OPP or
PBAP service individually.
Please go to “http://www .toyota.com/
bluetooth” to find approved
Bluetooth  phones for this system.
By pushing the telephone switch above,
you can receive a call or hang up without
taking your hands off the steering wheel.
You can use the microphone above
when talking on the phone.
The other party’s voice outputs from the
front speaker. When the received calls or
received voice outputs, the audio from the
audio system or voice guidance from the
navigation system will be muted.

TELEPHONE AND INFORMATION
130
INFORMATION
It may take time, the phone connec-
tion is carried out during Bluetooth
audio play.
MANUALLY
When the auto connection has failed or
“Handsfree power” is turned off, you
have to connect Bluetooth manually.
1. Push the “INFO/PHONE” button.
