horn TOYOTA HIGHLANDER 2014 XU50 / 3.G Owners Manual

172
HIGHLANDER_U (OM48A12U)
3-4. Adjusting the steering wheel and mirrors
Hold the steering wheel and
push the lever down.
Adjust to the ideal position by
moving the steering wheel hori-
zontally and vertically.
After adjustment, pull the lever up
to secure the steering wheel.
To sound the horn, press on or
close to the mark.
Steering wheel
Adjustment procedure
1
2
Horn

1733-4. Adjusting the steering wheel and mirrors
3
Operation of each component
HIGHLANDER_U (OM48A12U)
WARNING
■Caution while driving
Do not adjust the steering wheel while driving.
Doing so may cause the driver to mishandle the vehicle and cause an acci-
dent, resulting in death or serious injury.
■ After adjusting the steering wheel
Make sure that the steering wheel is securely locked.
Otherwise, the steering wheel may move suddenly, possibly causing an
accident, and resulting in death or serious injury. Also, the horn may not
sound if the steering wheel is not securely locked.

6158-2. Steps to take in an emergency
8
When trouble arises
HIGHLANDER_U (OM48A12U)
One of the following may be the cause of the problem:
●There may not be sufficient fuel in the vehicle’s tank.
Refuel the vehicle.
● The engine may be flooded.
Try to restart the engine again following correct starting procedures.
( P. 225, 228)
● There may be a malfunction in the engine immobilizer system.
( P. 8 0 )
One of the following may be the cause of the problem:
● The battery may be discharged. ( P. 621)
● The battery terminal connections may be loose or corroded.
The engine starting system may be malfunctioning due to an electrical
problem such as electronic key battery depletion or a blown fuse.
However, an interim measure is available to start the engine.
( P. 615)
If the engine will not start
If the engine will not start even though correct starting proce-
dures are being followed ( P. 225, 228), consider each of the fol-
lowing points:
The engine will not start even though the starter motor operates
normally.
The starter motor turns over slowly, the interior lights and head-
lights are dim, or the horn does not sound or sounds at a low
volume.
The starter motor does not turn over (vehicles with a smart key
system)

6168-2. Steps to take in an emergency
HIGHLANDER_U (OM48A12U)
One of the following may be the cause of the problem:
●One or both of the battery terminals may be disconnected.
● The battery may be discharged. ( P. 621)
● There may be a malfunction in the steering lock system.
Contact your Toyota dealer if the problem cannot be repaired, or if repair
procedures are unknown.
When the engine does not start, the following steps can be used as an
interim measure to start the engine if the engine switch is functioning
normally:
Set the parking brake.
Shift the shift lever to P.
Turn the engine switch to ACCESSORY mode.
Press and hold the engine switch for about 15 seconds while
depressing the brake pedal firmly.
Even if the engine can be started using the above steps, the system
may be malfunctioning. Have the vehicle inspected by your Toyota
dealer.
The starter motor does not turn over, the interior lights and head-
lights do not turn on, or the horn does not sound.
Emergency start function (vehicles with a smart key system)
1
2
3
4

691What to do if... (Troubleshooting)
HIGHLANDER_U (OM48A12U)
●The auto power off function will be operated if the vehicle is left in ACCES-
SORY or IGNITION ON mode (the engine is not running) for a period of
time. (P. 230)
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts? ( P. 565)
●The parking brake indicator is on
Is the parking brake released? (P. 240)
Depending on the situation, other types of warning buzzer may also sound.
(  P. 563, 572)

●Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. ( P. 82)
Vehicles without a smart key system:
To stop the alarm, turn the engine switch to the “ON” position or start the
engine.
Vehicles with a smart key system:
To stop the alarm, turn the engine switch to IGNITION ON mode or start the
engine.
The engine switch is turned off automatically
(vehicles with a smart key system)
A warning buzzer sounds during driving
An alarm is activated and the horn sounds
(vehicles with an alarm)

700Alphabetical index
HIGHLANDER_U (OM48A12U)
Front side marker lights.......... 241Light switch ........................... 241
Replacing light bulbs............. 539
Wattage ................................ 645
Front turn signal lights ........... 239 Replacing light bulbs............. 539
Turn signal lever ................... 239
Wattage ................................ 645
Fuel ........................................... 257 Capacity ................................ 635
Fuel gauge .............................. 94
Fuel pump shut off system.... 562
Information ............................ 646
Refueling............................... 257
Type .............................. 257, 635
Warning light ......................... 565
Fuel consumption Average fuel economy .... 97, 103
Current fuel consumption ................. 97, 103
Fuel filler door.......................... 257 If the fuel filler door cannot be opened............... 259
Refueling............................... 257
Fuel pump shut off system ..... 562
Fuses ........................................ 535
Garage door opener ................ 466
Gauges ....................................... 94
Glass hatch .............................. 142
Glove box ................................. 447
Grocery bag hooks .................. 453 Hands-free system
(for cellular phone)
*............. 371
Head restraints ........................ 168
Headlights ................................ 241 Automatic High Beam
system ................................ 241
Light switch ........................... 241
Replacing light bulbs ............ 539
Wattage ................................ 645
Heaters Front automatic air
conditioning system............ 428
Front manual air conditioning system ................................ 422
Heated steering wheel .......... 442
Outside rear view mirrors ........................ 424, 430
Rear automatic air conditioning system............ 438
Rear manual air conditioning system ................................ 435
Seat heaters ......................... 442
Hill-start assist control ........... 298
Hood ......................................... 500
Open ..................................... 500
Hooks Cargo hooks ......................... 453
Coat hooks ........................... 464
Grocery bag hooks ............... 453
Retaining hooks (floor mat) .... 26
Horn .......................................... 172
G
H
