TOYOTA HIGHLANDER 2021 Accessories, Audio & Navigation (in English)

1814-7. Rear seat entertainment system
4
Audio/visual system
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
1Press the button to
turn on/off the speaker out-
put.
On: The sound is available from
both vehicle speakers and
headphones.
Off: The sound is available from
the headphones only.
1 Press the “DISC”, “SD” or
“INPUT” button to change the
audio/visual source.
 Every time “INPUT” button is
pressed, the DLNA/Mira-
cast
®/HDMI mode will be
changed.
1 Press the , , or
button to select the control
icon on the screen.
2 Press the “ENT” button to
enter. 1
Press the “SIZE” button to
change the screen size.
DISC/SD/DLNA/Miracast®
mode
“Normal”: Displays the screen at
the original ratio (16:9)
“Full”: Displays the screen in full
screen mode
HDMI mode
“Normal 1”: Displays the screen
at the original ratio (4:3)
“Normal 2”: Displays the screen
in wide screen aspect (16:9)
“Full”: Displays the screen in full
screen mode
●The screen size can be changed
for each media mode individually.
You can adjust the contrast and
brightness of the screen. The
screen setting levels can be
adjusted for day mode and night
mode individually.
1 Press the “SETTING” button.
2 The screen settings can be
adjusted.
Turning on/off the speaker
output
Changing the audio/visual
source
Selecting a control icon
Changing the screen size
Adjusting the screen set-
tings

1824-7. Rear seat entertainment system
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
Turning on/off the speaker
output
Select to turn the over scan
function on/off.
*
When turned on, this function
hides image distortion at the
edge of the screen. (Part of
the image may be cut off.)
Turning on/off the “LCD AI”.
The “LCD AI” is automatically
determines the tone of the
video image and sets the
contrast to an optimum level,
displaying a sharp image.
Select to turn the screen off.
Weakens the contrast of the
screen
Strengthens the contrast of
the screen
Darkens the screen
Brightens the screen
*: This function is not available
depending on the screen.
1 Remove the insulating sheet.
●An insulating sheet is set to pre-
vent the batteries from being dis-
charged.
A
B
C
D
E
F
G
H
Before using the remote
controller (for new vehicle
owners)

1834-7. Rear seat entertainment system
4
Audio/visual system
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
1Remove the cover.
2 Remove the depleted batter-
ies and install 2 new AA bat-
teries.
●If the remote controller batteries
are discharged, the following
symptoms may occur.
• The rear seat entertainment sys- tem control will no t function prop-
erly.
• The operational range is reduced.
●When replacing the AA batteries
• Batteries can be purchased at your Toyota dealer, electric appli-
ance shop, or camera stores.
• Replace only with the same or equivalent type recommended by
a Toyota dealer.
• Dispose of used ba tteries accord-
ing to local laws.
When the remote control-
ler batteries are fully
depletedWA R N I N G
●To prevent acci dents and elec-
tric shock
• Do not disassemble or modify the remote controller.
●When the remote controller is
not used
• Stow the remote c ontroller. Inju-
ries may result i n the event of
an accident or sudden braking.
●Removed batteries and other
parts
• Keep away from children. These parts are small and if
swallowed by a child, they can
cause choking.
NOTICE
●To prevent damage to the
remote controller
• Keep the remote controller away from direct sunlight, heat
and high humidity.
• Do not drop or strike the remote controller against hard objects.
• Do not sit on or place heavy objects on the remote controller.
●For normal operation after
replacing the batteries, observe
the following precautions to pre-
vent accidents.
• Always work with dry hands. Moisture may cause the battery
to rust.
• Do not touch or move any other components inside the remote
controller.
• Do not bend any of the battery terminals.

1844-7. Rear seat entertainment system
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
For the rear seat entertainment
system, aftermarket head-
phones can be used to listen to
audio.
Wireless headphones can be
used.
When using wireless head-
phones, use headphones that
comply with the following condi-
tions.
■Communication system
Infrared rays
●With some wireless headphones
generally available in the market,
it may be difficult to catch signals
properly.
Toyota recomme nds the use of
Toyota genuine wireless head-
phones. Please contact your Toy-
ota dealer for further details.
●When the sound volume needs to
be changed while a wireless
headphone is used, adjust the vol-
ume using the wireless head-
phone’s volume switch.
The rear seat entertainment
system can be operated from
the front seats.
1 Press the “AUDIO” button.
8-inch display model
12.3-inch display model
2 Select “Source” on the
screen or press “AUDIO” but-
ton again.
3 Select “Rear”.
Using headphones
Using wireless head-
phones (sold separately)
Operating from the front
seats

1854-7. Rear seat entertainment system
4
Audio/visual system
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
4The rear seat entertainment
system can be operated from
this screen.
Adjusting the sound settings
Turning on/off the rear sys-
tem lock
• The operation lock on the rear
seat entertainment system can be
turned on or off.
Selecting the rear seat enter-
tainment system’s media
mode
Audio/visual operation but-
tons
Turning on/off the rear seat
entertainment system
A
B
C
D
E

1864-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
4-8.Rear seat entertainment system operation
Selecting a control icon
Inputting the selected control
icon
Volume up/down
Fast-forward/rewind
Play/pause
Stop
Displaying the menu screen
Displaying the option screen
Changing the audio language
Selecting a chapter
Turning on the BD/DVD
mode
Playing a Blu-ray
Disc™ (BD) and DVD
discs
This system can play
Blu-ray Disc™ (BD) videos
with digital sound. In addi-
tion to commercial BD and
DVD titles, AVCHD, BDAV
videos and Video CD can be
played on this system, so
digital TV recorded by home
digital video recorders and
BD/DVD home videos
recorded by home digital
video cameras can also be
played on this system.
Press the “DISC” button if a
disc has already been
loaded in the disc slot.
WA R N I N G
●BD/DVD video precaution
• Conversational speech on some
BDs/DVDs is recorded at a low
volume to emphasize the
impact of sound effects. If you
adjust the volume assuming
that the conversations represent
the maximum volume level that
the BD/DVD will play, you may
be startled by louder sound
effects or startled when you
change to a different audio
source. Loud sounds may have
a significant impact on the
human body or pose a driving
hazard. Keep this in mind when
you adjust the volume.
Remote controller
A
B
C
D
E
F
G
H
I
J
K

1874-8. Rear seat entertainment system operation
4
Audio/visual system
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
1Insert a disc or press the
“DISC” button.
 The player will start to play
the disc automatically.
1 Press the button to
play/pause.
 Press and hold the but-
ton while pausing, the video is
played slowly.
1 Press the “MENU” button.
2 Select the menu item, and
press the “ENT” button to
enter.
Press the “OPTION” button
while watching a BD/DVD video,
the following screen appears.
Press the “OPTION” button
once again or select “Hide But-
tons” to turn off the option
screen.
When there are two pages,
select “>” or “<” to change the
page.
BD video
DVD video
Turning on the BD/DVD
mode
Playing/pausing a disc
Operating the disc menu
Option screen

1884-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
AV C H D
BDAV
Video CDDisplaying the initial setup
screen
Turning off the option screen
Displaying the top menu
screen
Displaying the pop-up menu
Rewind
Stop
Play/pause
Fast-forward
Searching for a title
Searching for a chapter
Returning to the predeter-
A
B
C
D
E
F
G
H
I
J
K

1894-8. Rear seat entertainment system operation
4
Audio/visual system
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
mined scene
Changing the audio language
Changing the subtitle lan-
guage
Changing the angle
Displaying the color key but-
tons
Displaying the 10 key pad
Displaying the secondary
video (Picture-in-picture)
Changing the secondary
audio
Displaying the menu screen
Changing the playback mode
Changing the audio channel
Searching by track
Returning to the previous
page screen (with the disc
menu displayed)
Proceeding to the next page
screen (with the disc menu
displayed)
BD video
Some BD video discs have a
pop-up navigation menu that
can be called up and be oper-
ated on the screen without inter-
rupting playback.
1 Select “Pop-up Menu”.
2 Select the menu item, and
press the “ENT” button to
enter.
BD video, DVD video,
AVCHD, BDAV
1 Select “Title”, “Chapter” or
“Search”.
2 Input the title number or
chapter number, and select
“OK”.
BD video, DVD video, BDAV
The angle can be changed for
discs that are multi-angle com-
patible when the angle mark
appears on the screen.
1 Select “Angle”.
2 Each time “Angle” is
selected, the angle changes.
Displaying the pop-up menu
L
M
N
O
P
Q
R
S
T
U
V
W
X
6HDUFKLQJIRUDWL\
WOHRUFKDS
WHU
&KDQJLQJWKHDQJOH

1904-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
BD video, DVD video, AVCHD
The subtitle language can be
changed for discs with multiple
subtitle languages.
1 Select “Subtitle”.
2 Each time “Subtitle” is
selected, another language
available on the disc is
selected.
“Hide”: Subtitle can be hidden.
BD video
“Style”: Subtitle style can be
changed.
BD video, DVD video,
AVCHD, BDAV
The audio language can be
changed for discs with multiple
audio languages.
1 Select “Audio”.
2 Each time “Audio” is
selected, another language
available on the disc is
selected.
BDAV, Video CD
The audio channel can be
changed for discs with multiple
audio channels.
1 Each time “Main/Sub” is
selected, the mode changes
in the following order:
“Main”: Main audio channel
Changing the subtitle lan-
guage
Changing the audio lan-
guage
Changing the audio channel
