3428-1. Phone operation (Hands-free system for cellular phones)
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
1Display the phone top
screen. ( P.334)
2 Select “Keypad” and enter
the phone number.
3 Select or press the
switch on the steering wheel.
4 Check that the dialing screen
is displayed.
●Depending on the type of Blue-
tooth® phone being connected, it
may be necessary to perform
additional steps on the phone.
1 Display the home screen.
( P. 3 3 )
2 Select the desired contact.
3 Check that the dialing screen
is displayed.
■Registering a new contact
1 Select and hold the screen
button to add a contact.
2 Select the desired contact.
3 Select the desired number.
●If there is no contact in the con-
tacts list, the contacts cannot be
registered at the home screen.
●The contact cannot be registered
at the home screen while driving.
1Select “Answer” or press the
switch on the steering
wheel to talk on the phone.
“Decline”: Select to refuse to
receive the call.
To adjust the volume of a received
call: Turn the “POWER VOL-
UME”/“PWR/VOL” knob, or use the
volume control switch on the steer-
ing wheel.
●The contact image picture can be
displayed only when the vehicle is
not moving.
●During international phone calls,
the other party’s name or number
may not be displayed correctly
depending on the type of Blue-
tooth
® phone you have.
●The incoming call display mode
can be set. ( P.352)
●The ringtone that has been set in
the sound settings screen can be
heard when there is an incoming
By keypad
By home screen
Receiving a call using
the Bluetooth®
hands-free system
When a call is received, the
following screen is dis-
played with a sound.
Incoming calls

3438-1. Phone operation (Hands-free system for cellular phones)
8
Phone
HIGHLANDER_HIGHLANDER HV_NAVI_(U)call. Depending on the type of
Bluetooth
® phone, both the sys-
tem and Bluetooth® phone may
ring simultaneously when there is
an incoming call. ( P.352)
Select to display the keypad
to send tones. ( P.344)
Select to send tones. This
button only appears when a
number that contains a (w) is
dialed in hands-free mode.
( P.344)
Select to adjust your voice
volume that the other party
hears from their speaker.
( P.345)
Select to mute your voice to
the other party.
Select to mute the naviga-
tion route guidance during a
phone call.
*
Select to change handset
modes between hands-free
Talking on the Blue-
tooth® hands-free sys-
tem
While talking on the phone,
the following screen is dis-
played. The operations out-
lined below can be
performed on this screen.
Call screen operation
A
B
C
D
E
F

3448-1. Phone operation (Hands-free system for cellular phones)
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
and cellular phone.
Select to put a call on hold.
To cancel this function, select
“Activate”.
Select to hang up the phone.
*: Premium Audio/12.3-inch display model
●Changing from hands-free call to
cellular phone call is not possible
while driving.
●Only when the vehicle is not mov-
ing, the contact image can be dis-
played.
●When cellular phone call is
changed to hands-free call, the
hands-free screen will be dis-
played and its functions can be
operated on the screen.
●Changing between cellular phone
call and hands-free call can be
performed by operating the cellu-
lar phone directly.
●Transferring methods and opera-
tions will be diffe rent depending
on the type of Bluetooth
® phone
you have.
●For the operation of the cellular
phone, see the manual that
comes with it.
■By keypad
1 Select “0-9”.
2 Enter the desired number.
■By selecting “Release
Tones”
“Release Tones” appear when a
continuous tone signal(s) con-
taining a (w) is registered in the
contact list.
1 Select “Release Tones”.
●A continuous tone signal is a char-
acter string that consists of num-
bers and the characters “p” or “w”.
(e.g. 056133w0123p#1)
●When the “p” pause tone is used,
the tone data up until the next
pause tone will be automatically
sent after 2 seconds have
elapsed. When the “w” pause tone
is used, the tone d ata up until the
next pause tone will be automati-
cally sent after a user operation is
performed.
●Release tones can be used when
automated operation of a phone
based service such as an answer-
ing machine or bank phone ser-
vice is desired. A phone number
with continuous tone signals can
be registered in the contact list.
●Tone data after a “w” pause tone
can be operated by voice com-
mand during a call.
G
H
Sending tones

3608-2. Setup
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
on/off.
Select to set display of mes-
saging account names on the
message screen on/off.
When set to on, messaging
account names used on the
cellular phone will be dis-
played.
Select to change the vehicle
signature settings. (P.360)
Select to reset all setup
items.
●Depending on the phone, these
functions may not be available.
1 Select “Vehicle Signature”.
2 Select the desired item to be
set.
Select to set adding the vehi-
cle signature to outgoing
messages on/off.
Select to edit the vehicle sig-
nature. ( P.360)
Select to reset all setup
items.
■Editing vehicle signature
1 Select “Edit Vehicle Signa-
ture”.
2 Enter desired signature with
using keyboard.
3 Select “OK”.
4 Select “OK” on the confirma-
tion screen, or select “Edit
Again” when it needs to
amend.
Vehicle signature settings
D
E
F
A
B
C

3819-2. Connected Services operation
9
Connected Services
HIGHLANDER_HIGHLANDER HV_NAVI_(U)in the United States,
https://www.toyota.ca/connected
in Canada, and
http://www.toyotapr.com/
connected-services
in Puerto Rico, to confirm if the
phone is Bluetooth
® SPP compati-
ble or not, and then activate the
Toyota mobile application.
 “Communication unsuccess-
ful. Please try again.”
Communication was disconnected.
After a few moments, retry the
operation.
A keyword can be entered to an
application by the software key-
board or voice recognition func-
tion. For details about the
functions and services provided
by each application, refer to
https://www.toyota.com/
connected-services
in the United States,
https://www.toyota.ca/connected
in Canada, and
http://www.toyotapr.com/
connected-services
in Puerto Rico.
The keyboard layout can be
changed. ( P. 6 7 )
1 Display the application
screen. ( P.378) 2
Select the desired application
screen button.
3 Select the character entering
space.
4 Enter a search term, and
then select “OK”.
5 Entering characters will be
reflected on the character
entering space.
 For details on operating the
keyboard:  P. 3 5
1 Display the application
screen. ( P.378)
2 Select the desired application
screen button.
3 Press the talk switch.
( P.246)
4 Say the desired keyword.
 Completion of the keyword
will be detected automatically.
5 Search results will be dis-
played on the screen.
Entering keyword opera-
tion
Entering a keyword using
the software keyboard
Entering a keyword using
the voice recognition func-
tion

387
HIGHLANDER_HIGHLANDER HV_NAVI_(U)DCM ......................... 372, 374, 376
Destination Assist .................. 382
Destination button (Menu
screen) .................................... 15
Destination search ................... 93
Destination search operation Address .................................. 97
Contact ................................... 96
Destination Assist ................... 95
Emergency ............................. 96
Favorite list ............................. 95
Home................................ 26, 94
Keyword ................................. 94
One-touch setting home/favorite........................................... 100
Point of interest ...................... 97
Recent destinations................ 95
Search area............................ 94
Detailed navigation settings ....................................... 114, 119
Display button (Menu screen) . 15
E
ECO button (Information screen) ................................................. 21
Editing route ........................... 110
Entering letters and num- bers/list screen operation ..... 35Entering letters and numbers . 35
List screen .............................. 36
F
FM ............................................ 141
Functional overview ............... 368
G
General button (Setup screen)
........................................... 19, 67 General settings .......................67
Displaying the general settings screen...................................67
General settings screen .........67
GPS (Global Positioning System) ...............................................129
Guiding the route......................23 Deleting destinations ..............24
H
Hands-free system .................334
HOME button.......................12, 33
Home screen .............................33
I
Info button (Menu screen) .15, 21
Information screen ...................21
Initial screen..............................28Caution screen .......................28
Maintenance information ........28
Restarting the system .............28
iPod/iPhone (Apple Carplay) .154
L
Linking multi-information display and the system .......................39
M
MAP button ...................12, 80, 82
Map database ..........................131 Temporary updates of the map...........................................132
Map screen information ...........84 Map icons ...............................90
Map options screen ................84
Map screen operation ........22, 82 Current position d isplay ....22, 82
Map scale .........................23, 82
Orientation of the map ............83
Scrolling the map ..............23, 84

388
HIGHLANDER_HIGHLANDER HV_NAVI_(U)Map screen overview ............... 80
Memory points settings ......... 114
Areas to avoid ...................... 117
Favorites list ......................... 115
Home.................................... 115
MENU button....................... 12, 15
Menu screen ............................. 15 Menu screen operation .......... 15
Microphone ..................... 246, 337
Mobile Assistant ..................... 255 Connectable devices and avail-able functions ..................... 255
Mobile Assistant operation ... 255
N
Natural language understanding ............................................... 249
Navigation ................................. 80
Navigation button (Setup screen) ................................................. 19
P
Panoramic view monitor ........ 289 Body color changing............. 315
Camera ................................ 320
Camera switch ..................... 291
Checking around the vehicle 296
Checking the front and around the vehicle .......................... 298
Checking the rear and around the vehicle .......................... 307
Checking the sides of the vehicle ........................................... 301
Customize ............................ 315
Difference between the screen and the actual road ............ 321
Display ................................. 291
Display switching.................. 293
Distortion of three-dimensional objects on the screen ......... 324
Driving precautions .............. 289 Magnifying function ..............314
Parking .................................312
Precautions ..........................316
Things you should know .......328
When approaching three-dimen-
sional objects......................325
Phone............ ......................... ..334
About the contacts in the contact list .......................................338
Phone screen operation .......334
Registering/Connecting a Blue- tooth
® phone ......................336
Some basics .........................335
Troubleshooting ....................361
Voice command system .......338
When selling or disposing of the vehicle ................................338
PHONE button...................12, 334
Phone button (Menu screen) ...15
Phone button (Setup screen) ..19
Phone settings ...... ..................351
Contacts/Call history settings353
Message settings .................359
Notifications/display settings 352
Sounds settings ....................352
Placing a call using the Blue- tooth
® hands-free system....339
By call history .......................339
By contacts list .....................340
By favorites list .....................340
By home screen ...................342
By keypad.............................342
POWER VOLUME knob ....12, 136
Projection button (Menu screen) .................................................15
PWR/VOL knob .................12, 136
R
Radio........................................141 Available HD Radio™ technol-ogy......................................147
Displaying the radi o ID .........150

389
HIGHLANDER_HIGHLANDER HV_NAVI_(U)How to subscribe to SiriusXM
Satellite Radio .................... 149
How to Subscribe to SiriusXM Satellite Radio/HOW TO SUB-
SCRIBE TO SiriusXM Radio
Services ............................. 148
Presetting a station .............. 142
Radio broadcast data system145
Refer to the table below to iden- tify the problem and take the
suggested corrective action 151
Troubleshooting guide .......... 147
Rear seat entertainment system features ................................. 177
Rear view monitor system ..... 264 Camera ................................ 266
Differences between the screen and the actual road ............ 268
Driving precautions .............. 264
Precautions .......................... 266
Screen description ............... 265
Things you should know....... 272
When approaching three-dimen- sional objects ..................... 270
Receiving a call using the Blue- tooth
® hands-free system ... 342
Registering home ............. 25, 115
Registering/Connecting a Blue- tooth
® device .......................... 40
Profiles ................................... 43
Registering a Bluetooth
® audio
player for the first time.......... 43
Registering a Bluetooth
® phone
for the first time .................... 40
Remote Connect ..................... 376
Route guidance .............. 101, 105
Route guidance screen .......... 105 Freeway ............................... 106
Intersection........................... 108
Lane recommendation ......... 106
Turn list screen ..................... 109
Turn-by-turn arrow screen .... 109 Route overview .......................102
S
Screen adjustment ...................38
SEEK/TRACK button ................12
Service Connect ...
..................377
Setup........................................ 114
Setup button (Menu screen) ...........................................15, 19
Setup screen .............................19
SiriusXM (SXM) .......................141
Status icon ................................17 Status icon explanation ..........17
Steering switch ...............162, 246 Audio switch .........................162
Talk switch ............................246
SXM (SiriusXM) .......................141
T
Talking on the Bluetooth®
hands-free system ................343 Call screen operation ...........343
Incoming call waiting ............345
Sending tones ......................344
Transmit volume setting .......345
Things you should know ...............................272, 287, 328If you notice any symptoms ...........................272, 287, 328
Tips for the navigation system ...............................................129
Touch screen ............................29 Touch screen gestures ...........29
Touch screen operation ..........30
Toyota Apps ............................378 Entering keyword operation ..381
Toyota Apps settings .............384
Toyota multi-operation touch ..31 Audio/visual system ................33
Toyota multi-operation touch operation ..............................32
