TOYOTA HIGHLANDER HYBRID 2006 XU40 / 2.G Owners Manual

’06 HIGHLANDER HB_U (L/O 0503)
319
2006 HIGHLANDER (Hybrid) from Mar. ’05 Prod. (OM48530U)
Vehicle load limits include total load
capacity, seating capacity, towing ca-
pacity and cargo capacity. Follow the
load limits shown below. Total load ca-
pacity and seating capacity are also
described on the tire and loading in-
formation label. For location of the tire
and loading information label, see
“Checking tire inflat ion pr es s ur e” on
page 391.
Total load capacity:
Without third seat390 kg (860 lb.)
With third seat 526 kg (1159 lb.)
Total load capacity means combined
weight of occupants, cargo and lug-
gage. Tongue load is included when
trailer towing.
Seating capacity:
Without third seatTotal 5 (Front 2, Rear 3)
With third seat
Total 7 (Front 2, Rear 5) Seating capacity means the maximum
number of occupants whose esti-
mated average weight is 68 kg (150
lb.) per person. Depending on the
weight of each person, the seating ca-
pacity given may exceed the total
load capacity.
NOTICE
Even if the number of occupants
are within the seating capacity,
do not exceed the total load ca-
pacity.
Towing capacity:Without towing package 905 kg (2000 lb.)
With towing package
1588 kg (3500 lb.)
Towing capacity means the maximum
gross trailer weight (trailer weight plus
its cargo weight) that your vehicle is
able to tow. Cargo capacity
Cargo capacity may increase or de-
crease depending on the size (weight)
and the number of occupants. For de-
tails, see “—Capacity and distribu-
tion” on page 321.
CAUTION
Do not apply the load more than
each load limit. That may cause
not only damage to the tires, but
also deterioration to the steering
ability and braking ability, which
may cause an accident.
Veh icle lo ad limit s

’06 HIGHLANDER HB_U (L/O 0503)
320
2006 HIGHLANDER (Hybrid) from Mar. ’05 Prod. (OM48530U)
When stowing cargo and luggage in
the vehicle, observe the following:
 Put cargo and luggage in the lug-
gage compartment when at all
possible. Be sure all items are se-
cured in place.
 Be careful to keep the vehicle bal-
anced. Locating the weight as far
forward as possible helps maintain
balance.
 For better fuel economy, do not
carry unneeded weight.CAUTION
To prevent cargo and l uggage
from sliding forward during
braking, do not stack anything
in the luggage compartment
higher than the seatbacks.
Keep cargo and luggage low,
as close to the floor as pos-
sible.
 Never allow anyone to ride in
the luggage compartment. It is
not designed for passengers.
They should ride in their seats
with their seat belts properly
fastened. Otherwise, they are
much more likely suffer seri-
ous bodily injury, in the event
of sudden braking or a colli-
sion.
 Do not place anything on the
flattened seat, or it may slide
forward during braking.
Do not place anything on the
luggage cover. Such items may
be thrown about and possibly
injure people in the vehicle
during sudden braking or an
accident. Secure all items in a
safe place.
 Do not drive with objects left
on top of the instrument panel.
They may interfere with the
driver’s field of view. Or they
may move during sharp vehicle
acceleration or turning, and im-
pair the driver’s control of the
vehicle. In an accident they
may injure the vehicle occu-
pants.
 Do not put objects in the con-
tainer which can shift, roll out
or be thrown out in the event
of sudden stops or accidents.
Objects which come out of the
container can create a safety
hazard due to interference with
pedal operation or driver dis-
traction.
Cargo and luggage—
—Stowage precautions

’06 HIGHLANDER HB_U (L/O 0503)
321
2006 HIGHLANDER (Hybrid) from Mar. ’05 Prod. (OM48530U)
Cargo capacity depends on the to-
tal weight of the occupants.
(Cargo capacity) = (Total load capac-
ity) – (Total weight of occupants)
STEPS FOR DETERMINING
CORRECT LOAD LIMIT
1. Locate the statement “The com- bined weight of occupants and
cargo should never exceed XXX
pounds” on your vehicle’s placard.
2. Determine the combined weight of the driver and passengers that will
be riding in your vehicle.
3. Subtract the combined weight of the driver and passengers from
XXX kilograms or XXX pounds. 4. The resulting figure equals the
available amount of cargo and lug-
gage load capacity. For example,
if the “XXX” am ount equals 1400
lbs. and there will be five 150 lb.
passengers in your vehicle, the
amount of available cargo and lug-
gage load capacity is 650 lbs.
(1400–750 (5x150)=650 lbs).
5. Determine the combined weight of luggage and cargo being loaded
on the vehicle. That weight may
not safely exceed the available
cargo and luggage load capacity
calculated in Step 4.
6. If your vehicle will be towing a trailer, load from your trailer will
be transferred to your vehicle.
Consult this manual to determine
how this reduces the available car-
go and luggage load capacity of
your vehicle.
For details about trailer towing, see
page 332.
Cargo
capacity
Total load
capacity
EXAMPLE ON YOUR VEHICLE
In case that 2 people with the com-
bined weight of 166 kg (366 lb.) are
riding in your vehicle, the available
amount of cargo and luggage load ca-
pacity will be as follows:
Without third seat
Total load capacity: 390 kg (860 lb.) 390 kg – 166 kg = 224 kg.
( 860 lb. – 366 lb. = 494 lb. )
With third seat
Total load capacity: 526 kg (1159 lb.) 526 kg – 166 kg = 360 kg.
( 1159 lb. – 366 lb. = 793 lb. )
—Capacity and distribution

’06 HIGHLANDER HB_U (L/O 0503)
322
2006 HIGHLANDER (Hybrid) from Mar. ’05 Prod. (OM48530U)
From this condition, if 3 more passen-
gers with the combined weight of 176
kg (388 lb.) get on, the av ailable car-
go and luggage load will be reduced
as follows:
Without third seat 224 kg – 176 kg = 48 kg.
( 494 lb. – 388 lb. = 106 lb. )
With third seat 360 kg – 176 kg = 184 kg.
( 793 lb. – 388 lb. = 405 lb. )
As shown in the above example, if the
number of occupants increases, the
cargo and luggage load equaling the
combined weight of occupants who
got on later must be reduced. In other
words, if the incr ease in the number
of occupants causes the excess of
the total load capacity (combined
weight of occupants plus cargo and
luggage load), you have to reduce the
cargo and luggage on your vehicle.
For details about total load capacity,
see “Vehicle load limits” on page 319.CAUTION
Even if the total load of occu-
pant’s weight and the cargo load
is less than the total load capac-
ity, do not apply the load uneven-
ly. That may cause not only dam-
age to the tire but also deteriora-
tion to the steering ability due to
unbalance of the vehicle, causing
an accident.
Determine what kind of tires your
vehicle is originally equipped with.
1. Summer tires
Summer tires are high −speed capabil-
ity tires best suited to highway driving
under dry conditions.
Since summer tires do not have the
same traction performance as snow
tires, summer tires are inadequate for
driving on snow −covered or icy roads.
For driving on snow −covered or icy
roads, we recommend using snow
tires. If installing snow tires, be sure
to replace all four tires.
2. All season tires
All season tires are designed to pro-
vide better traction in snow and to be
adequate for driving in most winter
conditions, as well as for use all year
round.
Types of tires

’06 HIGHLANDER HB_U (L/O 0503)
323
2006 HIGHLANDER (Hybrid) from Mar. ’05 Prod. (OM48530U)
All season tires, however, do not have
adequate traction performance
compared with snow tires in heavy or
loose snow. Also, all season tires fall
short in acceleration and handling
performance compared with summer
tires in highway driving.
CAUTION
Do not mix summer and all sea-
son tires on your vehicle as
this can cause dangerous han-
dling characteristics, resulting
in loss of control.
 Do not use tire other than the
manufacturer’s designated
tires, and never mix tires or
wheels of the sizes different
from the originals.

’06 HIGHLANDER HB_U (L/O 0503)
324
2006 HIGHLANDER (Hybrid) from Mar. ’05 Prod. (OM48530U)

’06 HIGHLANDER HB_U (L/O 0503)
325
2006 HIGHLANDER (Hybrid) from Mar. ’05 Prod. (OM48530U)
STARTING AND DRIVING
Starting and driving
Before starting the hybrid system 326
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How to start the hybrid system 326
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tips for driving in various conditions 327
. . . . . . . . . . . . . . . . . . . . . . . . . .
Off −road driving precautions 328
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Winter driving tips 330
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . .
Dinghy towing 331
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Trailer towing 332
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
How to save fuel and make your vehicle last longer 337
. . . . . . . . . . . . .
SECTION 3

’06 HIGHLANDER HB_U (L/O 0503)
326
2006 HIGHLANDER (Hybrid) from Mar. ’05 Prod. (OM48530U)
1. Check the area around the vehicle be-
fore getting in.
2. Adjust seat position, seatback angle, seat cushion angle, seat height, head
restraint height and steering wheel
angle.
3. Adjust the inside and outside rear view mirrors.
4. Lock all side doors and back door.
5. Fasten seat belts.
When you get in the vehicle, check
whether the “READY” light is on or
not.
CAUTION
Your vehicle does not produce any
noise or vibration when the vehicle is
ready to be driven with the “READY”
indicator light on. Move your foot
carefully from the brake pedal to the
acceleration pedal when driving.
1. Apply the parking brake firmly.
2. Turn off unnecessary lights and acces- sories.
3. Put the selector lever in “P”.
4. Depress the brake pedal and hold it to the floor until driving off.
As the hybrid system starts only with the
transmission in the “P” position, put the
selector lever in “P” whenever starting the
system.
Before starting the hybrid system, be sure
to follow the instructions in “(a) Before
starting”.
Starting procedure
With your foot off the accelerator pedal,
turn the key to “START” briefly and firmly.
After a few seconds, the “READY” light
will come on and a beep will sound. If the
ambient temperature is low, such as dur-
ing winter driving conditions, it may take
time until the “READY” light comes on.
The engine may not start even with the
“READY” light on.
Before starting the hybrid
system How to start the hybrid
system—
(a) Before starting (b) Starting the hybrid system

’06 HIGHLANDER HB_U (L/O 0503)
327
2006 HIGHLANDER (Hybrid) from Mar. ’05 Prod. (OM48530U)
You may hear a sound in the engine
compartment when the brake pedal is de-
pressed with the hybrid system off. How-
ever, this does not indicate any trouble.
When the hybrid system is started or
stopped, you may hear a sound coming
from the traction battery under the rear
seats. However, this does not indicate any
trouble.
When the hybrid system is started or
stopped, or while the vehicle is idling, you
may hear a sound coming from the trans-
mission. However, this does not indicate
any trouble.
When applying brakes, you may hear a
sound coming from the regenerative
brakes. However, this does not indicate
any trouble.
When the gasoline engine is started or
stopped with the hybrid system on, you
may feel a vibration. However, this does
not indicate any trouble.
If there is a problem somewhere in the
hybrid system, “CHECK HYBRID SYSTEM”
warning message will appear on the multi −
information display. Have your vehicle
checked by your Toyota dealer as soon as
possible. If the hybrid system will not start...
See “If your vehicle will not start” on page
340 in Section 4.
CAUTION
Never start the hybrid system from
outside the vehicle, or an accident
may occur. Be sure to sit in the driv-
er seat, then start the system.
NOTICE

If any service reminder indicator
light comes on or warning message
appears on the multiinformation
display (see page 144 and page 155
for details) or the auxiliary battery
is disconnected, the hybrid system
may not start. In that case, turn the
ignition on again. If the “READY”
light does not come on, contact
your Toyota dealer.
 When you start the hybrid system
at a lower outside temperature, it
may take longer before the blinking
“READY” light changes to constant
on.
Always slow down in gusty crosswinds.
This will allow you much better control.
Drive slowly onto curbs and, if pos-
sible, at a right angle. Avoid driving
onto high, sharp− edged objects and
other road hazards. Failure to do so
can lead to severe tire damage such
as a tire burst.
Drive slowly when passing over bumps
or travelling on a bumpy road. Other-
wise, the impact could cause severe
damage to the tires and/or wheels.
When parking on a hill, turn the front
wheels until they touch the curb so
that the vehicle will not roll. Apply the
parking brake, and place the transmis-
sion in “P”. If necessary, block the
wheels.
Washing your vehicle or driving through
deep water may get the brakes wet. To
see whether they are wet, check that
there is no traffic near you, and then
press the pedal lightly. If you do not
feel a normal braking force, the brakes
are probably wet. To dry them, drive
the vehicle cautiously while lightly
pressing the brake pedal with the park-
ing brake applied. If they still do not
work safely, pull to the side of the road
and call a Toyota dealer for assistance.
Tips for driving in various
conditions

’06 HIGHLANDER HB_U (L/O 0503)
328
2006 HIGHLANDER (Hybrid) from Mar. ’05 Prod. (OM48530U)
CAUTION
Before driving off, make sure that
the parking brake is fully released
and the parking brake reminder
light is off.
Do not leave your vehicle unat-
tended while the hybrid system is
on.
Do not rest your foot on the brake
pedal while driving. It can cause
dangerous overheating, needless
wear, and poor fuel economy.
To drive down a long or steep hill,
reduce your speed and downshift.
Remember, if you ride the brakes
excessively, they may overheat and
not work properly.
Be careful when accelerating, down-
shifting or braking on a slippery
surface. Sudden acceleration or en-
gine braking, could cause the ve-
hicle to skid or spin.
Do not drive in excess of the speed
limit. Even if the legal speed limit
permits it, do not drive over 140
km/h (85 mph) unless your vehicle
has highspeed capability tires.
Driving over 140 km/h (85 mph) may
result in tire failure, loss of control
and possible injury. Be sure to con-
sult a tire dealer to determine
whether the tires on your vehicle
are highspeed capability tires or
not before driving at such speeds.
Do not continue normal driving
when the brakes are wet. If they are
wet, your vehicle will require a
longer stopping distance, and it
may pull to one side when the
brakes are applied. Also, the park-
ing brake will not hold the vehicle
securely.
Your vehicle is not designed to be driv-
en offroad
However, in the event that off−road driving
cannot be avoided, please observe the
following precautions to help avoid the
areas prohibited to vehicles.
a. Drive your vehicle only in areas where off−road vehicles are permitted to trav-
el.
b. Respect private property. Get owner ’s permission before entering private prop-
erty.
c. Do not enter areas that are closed. Honor gates, barriers and signs that re-
strict travel.
d. Stay on established roads. When condi- tions are wet, driving techniques should
be changed or travel delayed to pre-
vent damage to roads.
Offroad driving precautions
