Page 431 of 436
’07 HIGHLANDER HV_U (L/O 0608)
419
2007 HIGHLANDER HV from July ’06 Prod. (OM48685U)
REPORTING SAFETY DEFECTS FOR U.S.
OWNERS
Reporting safety defects for U.S. owners
Reporting safety defects for U.S. owners420
. . . . . . . . . . . . . . . . . . . . . .
SECTION 9
Page 432 of 436
’07 HIGHLANDER HV_U (L/O 0608)
420
2007 HIGHLANDER HV from July ’06 Prod. (OM48685U)
If you believe that your vehicle has a de-
fect which could cause a crash or could
cause injury or death, you should immedi-
ately inform the National Highway Traffic
Safety Administration (NHTSA) in addition
to notifying Toyota Motor Sales, U.S.A.,
Inc.
(Toll−free: 1 −800− 331−4331).
If NHTSA receives similar complaints, it
may open an investigation, and if it finds
that a safety defect exists in a group of
vehicles, it may order a recall and remedy
campaign. However, NHTSA cannot be-
come involved in individual problems be-
tween you, your dealer, or Toyota Motor
Sales, U.S.A., Inc. To contact NHTSA, you may either call
the Auto Safety Hotline toll
−free at
1 −888− 327−4236 (or 366 −0123 in Wash-
ington, DC area) or write to: NHTSA, U.S.
Department of Transportation, Washington,
DC 20590. You can also obtain other in-
formation about motor vehicle safety from
the Hotline.
Reporting safety defects for
U.S. owners
Page 433 of 436
’07 HIGHLANDER HV_U (L/O 0608)
2007 HIGHLANDER HV from July ’06 Prod. (OM48685U)
Publication No. OM48685U
Part No. 01999-48685
Printed in Japan 01−0608 −00
HV (U)
Quick index
If a service reminder indicator or warning buzzer comes on 144 . . . . . . . . . . .
If a warning message appears 155 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
If your vehicle will not start 338 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . .
If your vehicle overheats 341 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
If you have a flat tire 342 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
If your vehicle needs to be towed 353 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If a road accident occurs 11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . .
Tips for driving during break −in period 299 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How to start the hybrid system 324 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
General maintenance 371 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
Gas station information
Fuel type:
UNLEADED gasoline, Octane Rating 87 (Research Octane Number 91) or
higher
See page 299 for detailed information.
Fuel tank capacity:
65 L (17.2 gal., 14.3 Imp.gal.)
Engine oil:
ILSAC multigrade engine oil is recommended.
See page 387 for detailed information.
Tire information: See pages 390 through 398.
Tire inflation pressure: See page 415.
U 5
C
Page 434 of 436
’07 HIGHLANDER HV_U (L/O 0608)
2007 HIGHLANDER HV from July ’06 Prod. (OM48685U)
You should know as much about the quality and
importance of proper main tenance of your new
vehicle as the people who built it.
The Toyota authorized Repair Manual
tells you how to maint ain your vehicle and
enables you to correct ly perform your own
maintenance.
The best way to keep your new vehicle in top
running order is to maintain it properly from
the moment you drive it off the showroom
floor.
The Toyota authorized Repair Manual is
packed with literally everything you need to
know to perform your own maintenance in
virtually every area of your new vehicle.
Hybrid vehicles contain high voltage parts and cables that are extremely dangerous and may cause severe injury or
even death if handled improperly. Only technicians who ha ve participated in technical training for the inspection
and servicing of high voltage systems are qualified to do maintenance work on components related to the vehicle’s
hybrid system. For repair of your hybrid system, visit your Toyota dealer or other qualified technicians.
Page 435 of 436
’07 HIGHLANDER HV_U (L/O 0608)
2007 HIGHLANDER HV from July ’06 Prod. (OM48685U)
Where to obtain the Repair Manual
The repair manual for HIGHLANDER may be pur-
chased from any Toyota dealer or the Material Dis-
tribution Center. To purchase the repair manual,
please contact your Toyota dealer or call the Mate-
rial Distribution Center toll free at
1 800 622 2033.
Maintenance procedures for the engine,
chassis, body, electric al system, and more,
are clearly explained and illustrated.
Periodic maintenance and tune up
Periodic maintenance and tune up helps to prevent
small problems from growing into larger ones later on.
The repair manual outlines exactly what maintenance
is required and clearly explains how to do the work
yourself step by step.
Areas covered include such things as spark plug re-
placement, valve clearance adjustment and engine oil
and filter replacement.
Page 436 of 436
’07 HIGHLANDER HV_U (L/O 0608)
2007 HIGHLANDER HV from July ’06 Prod. (OM48685U)
WE REALLY CARE ABOUT YOU PLEASE BUCKLE UP
Toyota has made a special effort to encourage use of seat belts.
Toyota belts are:
Comfortable
Easy to use
Convenient
We encourage you to use your belts every time you drive.
U
