3598-2. Setup
8
Phone
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
Calls can be made by saying the
voice tag of a registered contact
in the contact list. (P.246)
1 Select “Manage Voice Tags”.
2 Select the desired item to be
set.
Select to register a new voice
tag. ( P.359)
Select to edit a voice tag.
( P.359)
Select to delete a voice tag.
( P.359)
■Registering a voice tag
Up to 50 voice tags can be reg-
istered.
1 Select “New”.
2 Select the desired contact to
register a voice tag for.
3 Select “REC” and record a
voice tag.
 When recording a voice tag,
do so in a quiet area.
“Play”: Select to play the voice tag.
4 Select “OK” when voice tag
registration is complete.
■Editing a voice tag
1 Select “Edit”. 2
Select the desired contact to
edit.
3 Follow the steps in “Register-
ing a voice tag” from step 3.
( P.359)
■Deleting the voice tag
1 Select “Delete”.
2 Select the desired contact
and select “Delete”.
3 Select “Yes” when the confir-
mation screen appears.
●Multiple data can be selected and
deleted at the same time.
●Voice tags are deleted when the
set language of the system is
changed. ( P.67)
1 Display the phone settings
screen. ( P.351)
2 Select “Messaging”.
3 Select the desired item to be
set.
Select to set automatic mes-
sage transfer on/off.
Select to set automatic mes-
sage readout on/off.
Select to set updating mes-
sage read status on phone
Setting voice tags
A
B
C
0HVVDJHVHWWL\
QJVVFUHHQ
A
B
C

3749-1. Connected Services overview
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
*: Vehicles with DCM
●Free/Open Source Software Infor-
mation
This product contains Free/Open
Source Software (FOSS).
The license information and/or the
source code of such FOSS can be
found at the following URL.
https://www.denso.com/global/en/
opensource/dcm/toyota/
●Exposure to radio frequency sig-
nals:
The Toyota audio multimedia sys-
tem installed in your vehicle
includes a low power radio trans-
mitter and receiver. The system
receives and also sends out radio
frequency (RF) signals.
●In August 1996, the Federal Com-
munications Commission (FCC)
adopted RF exposure guidelines
with safety levels for mobile wire-
less phones. Those guidelines are
consistent with the safety stan-
dards previously set by both U.S.
and international standards bod-
ies.
• ANSI (American National Stan-
dards Institute) C95.1 [1992]
• NCRP (National Council on Radi- ation Protection and Measure-
ment) Report 86 [1986]
• ICNIRP (Intern ational Commis-
sion on Non-Ionizing Radiation Protection) [1996]
●These standards are based on
comprehensive and periodic eval-
uations of the relevant scientific lit-
erature. Over 120 scientists,
engineers, and physicians from
universities, government health
agencies, and industry reviewed
the available body of research to
develop the ANSI Standard
(C95.1).
●The design of Toyota audio multi-
media system co
mplies with the
FCC guidelines in addition to
those standards.
●Contact with the Toyota response
center is dependent upon the
telematics device being in opera-
tive condition, cellular connection
availability, navigation map data,
and GPS satellite signal recep-
tion, which can lim it the ability to
reach the Toyota response center
or receive support. Enrollment and
Telematics Subscription Service
Agreement required. A variety of
subscription terms are available;
charges vary by subscription term
selected.
●The Toyota response center offers
support in multiple languages.
●Select Safety Connect-sub-
scribed vehicles are capable of
communicating vehicle informa-
tion. Please see the terms and
conditions for additional details.
Owners who do not wish to have
their vehicle transmit this informa-
tion can opt out at the time of
enrollment or by calling
1-800-331-4331 in the United
States, 1-888-869-6828 in Can-
ada, and 1-877-855-8377 in
Puerto Rico, and following the
prompts for Safety Connect.
●For further details about the ser-
vice, contact your Toyota dealer.
●Toyota audio mu ltimedia func-
tions are not subject to section
255 of the Telecommunications
Act and the system is not TTY
Type C: Function
achieved by using
DCM
*
The functionality of Safety
Connect is made possible
by the use of a DCM.
For details, refer to
“OWNER’S MANUAL”.
Safety Connect

388
HIGHLANDER_HIGHLANDER HV_NAVI_(U)Map screen overview ............... 80
Memory points settings ......... 114
Areas to avoid ...................... 117
Favorites list ......................... 115
Home.................................... 115
MENU button....................... 12, 15
Menu screen ............................. 15 Menu screen operation .......... 15
Microphone ..................... 246, 337
Mobile Assistant ..................... 255 Connectable devices and avail-able functions ..................... 255
Mobile Assistant operation ... 255
N
Natural language understanding ............................................... 249
Navigation ................................. 80
Navigation button (Setup screen) ................................................. 19
P
Panoramic view monitor ........ 289 Body color changing............. 315
Camera ................................ 320
Camera switch ..................... 291
Checking around the vehicle 296
Checking the front and around the vehicle .......................... 298
Checking the rear and around the vehicle .......................... 307
Checking the sides of the vehicle ........................................... 301
Customize ............................ 315
Difference between the screen and the actual road ............ 321
Display ................................. 291
Display switching.................. 293
Distortion of three-dimensional objects on the screen ......... 324
Driving precautions .............. 289 Magnifying function ..............314
Parking .................................312
Precautions ..........................316
Things you should know .......328
When approaching three-dimen-
sional objects......................325
Phone............ ......................... ..334
About the contacts in the contact list .......................................338
Phone screen operation .......334
Registering/Connecting a Blue- tooth
® phone ......................336
Some basics .........................335
Troubleshooting ....................361
Voice command system .......338
When selling or disposing of the vehicle ................................338
PHONE button...................12, 334
Phone button (Menu screen) ...15
Phone button (Setup screen) ..19
Phone settings ...... ..................351
Contacts/Call history settings353
Message settings .................359
Notifications/display settings 352
Sounds settings ....................352
Placing a call using the Blue- tooth
® hands-free system....339
By call history .......................339
By contacts list .....................340
By favorites list .....................340
By home screen ...................342
By keypad.............................342
POWER VOLUME knob ....12, 136
Projection button (Menu screen) .................................................15
PWR/VOL knob .................12, 136
R
Radio........................................141 Available HD Radio™ technol-ogy......................................147
Displaying the radi o ID .........150
