- SUSPENSION AND AXLEFRONT AXLE HUB
1962 Author: Date:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. REMOVE FRONT WHEEL
2. REMOVE BRAKE CALIPER
(a) Remove the bolt and disconnect the flexible hose from
the steering knuckle.
(b) Remove the 2 bolts, washers and brake caliper.
(c) Support the brake caliper securely.
3. REMOVE FLANGE
(a) Using a screwdriver and hammer, remove the grease cap
from the flange.
(b) Using a snap ring expander, remove the snap ring.
(c) Remove the 6 nuts and washers.
(d) Install the 6 nuts temporarily to protect the threads of the
stud bolts.
(e) Using a brass bar and hammer, tap on the bolt heads and
remove the 6 nuts and cone washers.
(f) Remove the flange and gasket.
4. REMOVE AXLE HUB WITH DISC
(a) Using a screwdriver, release the lock washer.
(b) Using SST, remove the lock nut.
SST 09607-60020
(c) Remove the lock washer.
(d) Using SST, remove the adjusting nut.
SST 09607-60020
(e) Remove the axle hub with disc.
NOTICE:
Be careful not to damage the ABS speed sensor rotor and
oil seal.
(f) Remove the claw washer and bearing from the axle hub.
Page 2902 of 3115
SA1SE-01
F05442
Grease Cap
Steering Knuckle Arm
Cotter Pin
Drive Shaft
N´m (kgf´cm, ft´lbf) Snap Ring Steering Knuckle with
Axle HubBrake Caliper ABS Speed Sensor
and Wire Harness
Cotter Pin
: Specified torque
Non-reusable part
Precoated part
28 (290, 21)
13 (130, 10)
8.0 (82, 71 in.´lbf)
110 (1,125, 81)
159 (1,625, 117)
147 (1,500, 108)
123 (1,250, 91)
28 (290, 21)
Snap Ring
SA-36
- SUSPENSION AND AXLEFRONT DIFFERENTIAL CARRIER
1986 Author: Date:
2004 LAND CRUISER (RM1071U)
FRONT DIFFERENTIAL CARRIER
COMPONENTS
Page 2903 of 3115
F05231N´m (kgf´cm, ft´lbf) : Specified torquePropeller Shaft
Differential
Support Mount StopperDifferential Carrier
AssemblyBreather Hose
No. 3 Frame
Crossmember
Mount Stopper
Mount Stopper
Mount
StopperDifferential Support
186 (1,900, 137)
17 (173, 13)
78 (800, 58)
68 (695, 50)
68 (695, 50)186 (1,900, 137)
186 (1,900, 137)
186 (1,900, 137)
80 (820, 59)
- SUSPENSION AND AXLEFRONT DIFFERENTIAL CARRIER
SA-37
1987 Author: Date:
2004 LAND CRUISER (RM1071U)
Page 2904 of 3115
F11449
Rear Bearing
Oil Slinger
Companion Flange
See page SA-47
Oil Seal Bearing Spacer
Oil Storage Ring Dust Deflector
105 (1,070, 77)
Differential Tube
49 (500, 36)
Filler Plug
Gasket
49 (500, 36)
Drain Plug
Gasket
WasherDifferential Carrier
Drive Pinion Front Bearing
Breather Plug
Oil Deflector7.3 (74, 64 in.´lbf)
Differential
Carrier Cover
47 (475, 34)
x8
Thrust Washer
Side Gear
Spider
Pinion Gear
Thrust Washer
Pinion Gear
N´m (kgf´cm, ft´lbf) : Specified torque
Non-reusable part
Precoated part
Side Gear ShaftBearing
Snap Ring
Oil Seal
x10
x5LH Differential Case
Ring Gear
Plate Washer
Bearing Cap
85 (870, 63)
97 (985, 71)
x8
Side Bearing
RH Differential Case
SA-38
- SUSPENSION AND AXLEFRONT DIFFERENTIAL CARRIER
1988 Author: Date:
2004 LAND CRUISER (RM1071U)
Page 2905 of 3115
SA14N-14
W00493
30 mm
(1.18 in.)
F05229
F05228
SA-40
- SUSPENSION AND AXLEFRONT DIFFERENTIAL CARRIER
1990 Author: Date:
2004 LAND CRUISER (RM1071U)
DISASSEMBLY
1. REMOVE DIFFERENTIAL CARRIER COVER
(a) Remove the 9 bolts and nut from the carrier cover.
(b) Using a brass bar and hammer, separate the cover from
carrier.
(c) Remove the breather plug from the differential carrier cov-
er.
(d) Remove the 2 bolts and oil deflector from the differential
carrier cover.
2. SET DIFFERENTIAL CARRIER TO OVERHAUL
STAND, ETC.
3. CHECK RUNOUT OF COMPANION FLANGE
Using a dial indicator, measure the vertical and lateral runout of
the companion flange.
Maximum: 0.09 mm (0.0035 in.)
If the runout is greater than the maximum, replace the compan-
ion flange.
4. CHECK RING GEAR RUNOUT
Using a dial indicator, measure the ring gear runout.
Maximum runout: 0.07 mm (0.0028 in.)
If the runout is greater than the maximum, replace the ring gear
and drive pinion as a set.
5. CHECK RING GEAR BACKLASH
Using a dial indicator, while holding the drive pinion flange mea-
sure the ring gear backlash.
Backlash: 0.13 - 0.18 mm (0.0051 - 0.0071 in.)
HINT:
Measure at 3 or more places on the circumference of the ring
gear.
If the backlash is not within the specification, adjust the back-
lash.
Page 2906 of 3115
SA2352
F05221
SST
F05222
SST
F05223
SST
- SUSPENSION AND AXLEFRONT DIFFERENTIAL CARRIER
SA-41
1991 Author: Date:
2004 LAND CRUISER (RM1071U)
6. MEASURE DRIVE PINION PRELOAD
Using a torque wrench, measure the drive pinion preload using
the backlash of the drive pinion and ring gear.
Preload (at starting):
0.5 - 0.8 N´m (5 - 8 kgf´cm, 4.3 - 6.9 in.´lbf)
7. CHECK TOTAL PRELOAD
Using a torque wrench, measure the total preload.
Total preload (at starting):
Drive pinion preload plus
0.4 - 0.6 N´m (4 - 6 kgf´cm, 3.5 - 5.2 in.´lbf)
If necessary, disassemble and inspect the differential.
8. INSPECT TOOTH CONTACT BETWEEN RING GEAR
AND DRIVE PINION (See page SA-47)
9. REMOVE SIDE GEAR SHAFT OIL SEALS
Using SST, remove the 2 side gear shaft oil seals.
SST 09308-00010
10. REMOVE DIFFERENTIAL TUBE ASSEMBLY
(a) Using SST, remove the snap ring.
SST 09350-30020 (09350-07060)
(b) Using a snap ring expander, remove the snap ring.
(c) Remove the 4 bolts and differential tube with side gear
shaft from the differential carrier.
(d) Remove the side gear shaft from the differential tube.
11. REMOVE SIDE GEAR BEARING
Using SST and a press, remove the bearing from side gear
shaft.
SST 09950-60010 (09951-00410), 09950-70010
(09951-07100)
12. REMOVE COMPANION FLANGE
(a) Using a chisel and hammer, unstake the nut.
Page 2907 of 3115
SA2349
SST
R11391
SST
SA2348
SST
Z00641
SST
F11453
Matchmarks
SA-42
- SUSPENSION AND AXLEFRONT DIFFERENTIAL CARRIER
1992 Author: Date:
2004 LAND CRUISER (RM1071U)
(b) Using SST to hold the flange, remove the nut.
SST 09330-00021
(c) Using SST, remove the companion flange.
SST 09950- 30012 (09951- 03010, 09953- 03010,
09954-03010, 09955-03030, 09956-03020)
13. REMOVE OIL SEAL AND OIL SLINGER
(a) Using SST, remove the oil seal from the differential carrier.
SST 09308-10010
(b) Remove the oil slinger.
14. REMOVE REAR BEARING
Using SST, remove the rear bearing from the drive pinion.
SST 09556-22010
If the rear bearing is damaged or worn, replace the rear bearing.
15. REMOVE DIFFERENTIAL CASE ASSEMBLY
(a) Place matchmarks on the bearing cap and differential car-
rier.
(b) Remove the 4 bolts and 2 bearing caps.
Page 2908 of 3115
F11454
SST
R02482
SST
F05168
SST
F05169
Oil Storage Ring Outer Race
- SUSPENSION AND AXLEFRONT DIFFERENTIAL CARRIER
SA-43
1993 Author: Date:
2004 LAND CRUISER (RM1071U)
(c) Using SST and a hammer, remove the 2 side bearing
plate washers.
SST 09504-22012
HINT:
Measure the plate washer and note down the thickness.
(d) Remove the differential case with the bearing outer races
from the differential carrier.
HINT:
Tag the bearing outer races to show the location for reassem-
bling.
16. REMOVE DRIVE PINION AND BEARING SPACER
FROM DIFFERENTIAL CARRIER
17. REMOVE DRIVE PINION FRONT BEARING
(a) Using SST and a press, remove the front bearing from the
drive pinion.
SST 09950-00020
HINT:
If the drive pinion or ring gear is damaged, replace them as a
set.
(b) Remove the washer.
18. REMOVE DRIVE PINION FRONT AND REAR BEARING
OUTER RACES AND OIL STORAGE RING
(a) Using SST, remove the rear bearing outer race.
SST 09308-00010
(b) Using a brass bar and hammer, remove the oil storage
ring and front bearing outer race.
Page 2909 of 3115
FA1998Matchmarks
F05210
R11392
SST
SST SA-44
- SUSPENSION AND AXLEFRONT DIFFERENTIAL CARRIER
1994 Author: Date:
2004 LAND CRUISER (RM1071U)
19. REMOVE RING GEAR
(a) Place matchmarks on the ring gear and differential case.
(b) Using a screwdriver and hammer, unstake the 5 lock
plates.
(c) Remove the 10 bolts and 5 lock plates.
(d) Using a plastic hammer, tap on the ring gear to separate
it from the differential case.
20. CHECK DIFFERENTIAL CASE RUNOUT
(a) Place the bearing outer races on their respective bear-
ings. Check that the left and right outer races are not inter-
changed.
(b) Install the assembled plate washers onto the side bear-
ing.
(c) Install the differential case in the differential carrier.
HINT:
If it is difficult to install the differential case into the carrier, re-
place the plate washer with a thinner one.
However, select a plate washer that allows no clearance be-
tween it and the carrier.
(d) Align matchmarks on the bearing cap and differential car-
rier.
(e) Install and uniformly tighten the 4 bolts a little at a time.
(f) Using a dial indicator, measure the differential case run-
out.
Maximum case runout: 0.07 mm (0.0028 in.)
If the runout is greater than the maximum, replace the differen-
tial case and side bearings as a set.
(g) Remove the differential case.
21. REMOVE SIDE BEARINGS
Using SST, remove the 2 side bearings from the differential
case.
SST 09950- 40011 (09951- 04020, 09952- 04010,
09953- 04030, 09954- 04010, 09955- 04061,
09957- 04010, 09958- 04011), 09950- 60010
(09951-00480)
HINT:
Fix the claws of SST to the notches in the differential case.
Page 2910 of 3115
FA2046
Matchmarks
- SUSPENSION AND AXLEFRONT DIFFERENTIAL CARRIER
SA-45
1995 Author: Date:
2004 LAND CRUISER (RM1071U)
22. DISASSEMBLE DIFFERENTIAL CASE
(a) Place matchmarks on the LH and RH cases.
(b) Remove the 8 bolts uniformly, a little at a time.
(c) Using a plastic hammer, separate the LH and RH cases.
(d) Remove the spider, 2 side gears, side gear thrust wash-
ers, 4 pinion gears and pinion gear thrust washers from
the RH differential case.
