Page 2899 of 3115
SA146-04
F04340
Matchmarks
F04341
SST
F04342
SST
RA0009
SA0412
MP Grease SA-14
- SUSPENSION AND AXLEFRONT AXLE HUB
1964 Author: Date:
2004 LAND CRUISER (RM1071U)
REASSEMBLY
1. INSTALL DISC
(a) Mount the disc in a soft jaw vice.
NOTICE:
Close vice until it holds disc, do not tighten further.
(b) Align the matchmarks on the axle hub and disc.
(c) Install the 5 bolts to the axle hub.
Torque: 74 N´m (750 kgf´cm, 54 ft´lbf)
2. INSTALL BEARING OUTER RACES
(a) Using SST and a hammer, carefully install a new outside
bearing outer race.
SST 09950-60020 (09951-00730),
09950-70010 (09951-07100)
(b) Using SST and a hammer, carefully install a new inside
bearing outer race.
SST 09950-60020 (09951-00890),
09950-70010 (09951-07100)
NOTICE:
Be careful not to damage the ABS speed sensor rotor.
3. PACK BEARING WITH MP GREASE
(a) Place MP grease in the palm of your hand.
(b) Pack grease into a new bearing, continuing until the
grease oozes out from the other side.
(c) Employ the same manner around the bearing circumfer-
ence.
4. COAT INSIDE OF AXLE HUB WITH MP GREASE
5. INSTALL INNER BEARING AND OIL SEAL
(a) Place the inner bearing into the axle hub.
Page 2900 of 3115
F04343
SST
- SUSPENSION AND AXLEFRONT AXLE HUB
SA-15
1965 Author: Date:
2004 LAND CRUISER (RM1071U)
(b) Using SST and a hammer, install a new oil seal into the
axle hub.
SST 09950-60020 (09951-01030),
09950-70010 (09951-07100)
NOTICE:
Be careful not to damage the ABS speed sensor rotor.
(c) Coat the lip of the oil seal with MP grease.
Page 2901 of 3115
SA144-04
F04367
F04368
F04369
F04370SST SA-12
- SUSPENSION AND AXLEFRONT AXLE HUB
1962 Author: Date:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. REMOVE FRONT WHEEL
2. REMOVE BRAKE CALIPER
(a) Remove the bolt and disconnect the flexible hose from
the steering knuckle.
(b) Remove the 2 bolts, washers and brake caliper.
(c) Support the brake caliper securely.
3. REMOVE FLANGE
(a) Using a screwdriver and hammer, remove the grease cap
from the flange.
(b) Using a snap ring expander, remove the snap ring.
(c) Remove the 6 nuts and washers.
(d) Install the 6 nuts temporarily to protect the threads of the
stud bolts.
(e) Using a brass bar and hammer, tap on the bolt heads and
remove the 6 nuts and cone washers.
(f) Remove the flange and gasket.
4. REMOVE AXLE HUB WITH DISC
(a) Using a screwdriver, release the lock washer.
(b) Using SST, remove the lock nut.
SST 09607-60020
(c) Remove the lock washer.
(d) Using SST, remove the adjusting nut.
SST 09607-60020
(e) Remove the axle hub with disc.
NOTICE:
Be careful not to damage the ABS speed sensor rotor and
oil seal.
(f) Remove the claw washer and bearing from the axle hub.
Page 2902 of 3115
SA1SE-01
F05442
Grease Cap
Steering Knuckle Arm
Cotter Pin
Drive Shaft
N´m (kgf´cm, ft´lbf) Snap Ring Steering Knuckle with
Axle HubBrake Caliper ABS Speed Sensor
and Wire Harness
Cotter Pin
: Specified torque
Non-reusable part
Precoated part
28 (290, 21)
13 (130, 10)
8.0 (82, 71 in.´lbf)
110 (1,125, 81)
159 (1,625, 117)
147 (1,500, 108)
123 (1,250, 91)
28 (290, 21)
Snap Ring
SA-36
- SUSPENSION AND AXLEFRONT DIFFERENTIAL CARRIER
1986 Author: Date:
2004 LAND CRUISER (RM1071U)
FRONT DIFFERENTIAL CARRIER
COMPONENTS
Page 2926 of 3115
SA14E-04
F05436
110 (1,125, 81)
Cotter Pin
Drive Shaft
28 (290, 21)
13 (130, 10)
ABS Speed Sensor
and Wire Harness
8.0 (82, 71 in.´lbf)
Brake Caliper
Steering Knuckle
with Axle Hub
Snap Ring
Grease Cap
159 (1,625, 117)
Cotter Pin
Dust Cover
Inboard Joint Tulip
Cage
Inner Race
Ball
Boot Boot Clamp
Boot
147 (1,500, 108)
Steering Knuckle Arm
Supply Parts
Boot Clamp
Outboard Joint Shaft
Dust Seal
N´m (kgf´cm, ft´lbf) : Specified torque
Non-reusable part
Precoated part
28 (290, 21)
123 (1,250, 91)
Snap Ring Snap Ring
Snap Ring
- SUSPENSION AND AXLEFRONT DRIVE SHAFT
SA-25
1975 Author: Date:
2004 LAND CRUISER (RM1071U)
FRONT DRIVE SHAFT
COMPONENTS
Page 2929 of 3115
SA14I-08
- SUSPENSION AND AXLEFRONT DRIVE SHAFT
SA-33
1983 Author: Date:
2004 LAND CRUISER (RM1071U)
INSTALLATION
Installation is in the reverse order of removal (See page SA-26).
HINT:
After installation, check the ABS speed sensor signal (See page DI-505).
Page 2932 of 3115
SA14F-04
F04367
F04368
F05795
A
B
C
F05161
SA-26
- SUSPENSION AND AXLEFRONT DRIVE SHAFT
1976 Author: Date:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. REMOVE FRONT WHEEL
Torque: 131 N´m (1,340 kgf´cm, 97 ft´lbf)
2. REMOVE BRAKE CALIPER
(a) Remove the bolt and disconnect the flexible hose from
the steering knuckle.
Torque: 28 N´m (290 kgf´cm, 21 ft´lbf)
(b) Remove the 2 bolts, washers and brake caliper.
Torque: 123 N´m (1,250 kgf´cm, 91 ft´lbf)
(c) Support the brake caliper securely.
3. REMOVE SNAP RING
(a) Using a screwdriver and hammer, remove the grease cap
from the flange.
(b) Using snap ring pliers, remove the snap ring.
4. DISCONNECT ABS SPEED SENSOR AND WIRE HAR-
NESS
Remove the 3 bolts and disconnect the ABS speed sensor and
wire harness.
Torque:
A: 8.0 N´m (82 kgf´cm, 71 in.´lbf)
B: 13 N´m (130 kgf´cm, 10 ft´lbf)
C: 28 N´m (290 kgf´cm, 21 ft´lbf)
5. DISCONNECT STEERING KNUCKLE ARM
Remove the 2 bolts and disconnect the steering knuckle arm.
Torque: 147 N´m (1,500 kgf´cm, 108 ft´lbf)
HINT:
At the time of installation, please refer to the following items.
Clean the threads of the 2 bolts and steering knuckle with
toluene or trichloroethylene.
Page 2935 of 3115
SA14J-04
F05437
Oil Seal
Drive Shaft Cotter PinBrake Caliper
Steering Knuckle
with Axle Hub
Snap Ring
Cotter Pin
Grease Cap
Steering Knuckle Arm
147 (1,500, 108)
123 (1,250, 91)
28 (290, 21)
8.0 (82, 71 in.´lbf)
13 (130, 10)
ABS Speed Sensor
and Wire Harness
28 (290, 21)
159 (1,625, 117)
110 (1,125, 81)
Snap Ring
N´m (kgf´cm, ft´lbf): Specified torque
Non-reusable part
Precoated part SA-34
- SUSPENSION AND AXLEFRONT DIFFERENTIAL SIDE GEAR SHAFT OIL SEAL
1984 Author: Date:
2004 LAND CRUISER (RM1071U)
FRONT DIFFERENTIAL SIDE GEAR SHAFT OIL SEAL
COMPONENTS
Page 2955 of 3115
SA14Z-02
F05249
Front Fender Apron
No. 1 Camber Adjust Cam
ABS Speed Sensor
Wire Harness
No. 2 Camber Adjust CamUpper Suspension
Arm
Cotter Pin
Bushing Bushing
Upper Suspension Arm
Wire
Dust Cover
13 (130, 10)
98 (1,000, 72)
110 (1,125, 81)
Non-reusable part
N´m (kgf´cm, ft´lbf) : Specified torque
- SUSPENSION AND AXLEFRONT UPPER SUSPENSION ARM
SA-69
2019 Author: Date:
2004 LAND CRUISER (RM1071U)
FRONT UPPER SUSPENSION ARM
COMPONENTS
Page 2958 of 3115
SA150-02
F04377
F04378
SST
F04379
Matchmarks
SA-70
- SUSPENSION AND AXLEFRONT UPPER SUSPENSION ARM
2020 Author: Date:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. REMOVE FRONT WHEEL
Torque: 131 N´m (1,340 kgf´cm, 97 ft´lbf)
2. REMOVE FRONT FENDER APRON
3. DISCONNECT ABS SPEED SENSOR WIRE HARNESS
Remove the 2 bolts and disconnect the ABS speed sensor wire
harness.
Torque: 13 N´m (130 kgf´cm, 10 ft´lbf)
4. DISCONNECT STEERING KNUCKLE FROM UPPER
SUSPENSION ARM
(a) Support the lower suspension arm with a jack.
(b) Remove the cotter pin and nut.
Torque: 110 N´m (1,125 kgf´cm, 81 ft´lbf)
HINT:
At the time of installation, if the holes for the cotter pin are not
aligned, tighten the nut further up to 60°.
(c) Using SST, disconnect the steering knuckle from the up-
per suspension arm.
SST 09628-6201 1
5. REMOVE UPPER SUSPENSION ARM
(a) Place matchmarks on the front and rear No. 2 adjust cams
and body.
(b) Remove the 2 nuts, No. 1 and No. 2 camber adjust cams
and upper suspension arm.
Torque: 98 N´m (1,000 kgf´cm, 72 ft´lbf)
HINT:
At the time of installation, after stabilizing the suspension,
torque the nuts.
