- SUSPENSION AND AXLEFRONT WHEEL ALIGNMENT
SA-9
1959 Author
: Date
:
2004 LAND CRUISER (RM1071U)
(d) Torque the front and/or rear adjusting cam nuts.
Torque: 98 N´m (1,000 kgf´cm, 72 ft´lbf)
5. INSPECT TOE-IN
Toe-in:
Toe-in
(total)A + B: 0°06' ± 12' (0.1° ± 0.2°)
C - D: 1 ± 2 mm (0.04 ± 0.08 in.)
If the toe-in is not within the specified value, adjust it at the rack
ends.
6. ADJUST TOE-IN
(a) Check or adjust the lengths of the rack ends, then adjust
the toe-in.
Rack end length difference: 3.0 mm (0.118 in.) or less
(b) Remove the boot clamps.
(c) Loosen the tie rod end lock nuts.
(d) Turn the right and left rack ends by an equal amount to
adjust the toe-in.
HINT:
Try to adjust the toe-in to the center of the specified value.
(e) Tighten the tie rod end lock nuts.
Torque: 55 N´m (560 kgf´cm, 41 ft´lbf)
(f) Place the boots on the seats and install the clamps.
HINT:
Make sure that the boots are not twisted.
(g) Perform the zero point calibration of yaw rate and decel-
eration sensor (See page DI-505).

SA15C-02
F05438
123 (1,250, 91)

Oil Seal

O-Ring
Parking Brake Assembly
Disc
103 (1,050, 76)
Brake Caliper

Bearing Retainer

ABS Speed Sensor Rotor

Snap Ring
Bearing Case
Backing Plate
Serration Bolt

Oil Seal

Hub Bolt
Oil Deflector

Gasket
Axle Shaft
N´m (kgf´cm, ft´lbf): Specified torque

Non-reusable partx5
15 (150, 11)

Hub Bolt
Clip

Bearing Retainer

Plate Washer

Bearing
- SUSPENSION AND AXLEREAR AXLE SHAFT
SA-83
2033 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REAR AXLE SHAFT
COMPONENTS

SA15E-02
F05100
F05101
F05102
F05103
SST
F05104
SA-86
- SUSPENSION AND AXLEREAR AXLE SHAFT
2036 Author
: Date
:
2004 LAND CRUISER (RM1071U)
DISASSEMBLY
1. REMOVE BEARING RETAINER (DIFFERENTIAL SIDE)
AND ABS SPEED SENSOR ROTOR
(a) Attach 4 nuts to the serration bolts and using a hammer,
remove the serration bolts from the backing plate.
NOTICE:
Do not reuse the nuts previously removed from the vehicle.
(b) Grind the retainer and sensor rotor surfaces using a grind-
er, then pry them out with a chisel and hammer.
2. REMOVE SNAP RING FROM AXLE SHAFT
Using a snap ring expander, remove the snap ring.
3. REMOVE AXLE SHAFT FROM BACKING PLATE
(a) Attach 4 washers and nut to the serration bolts, then
torque the nuts to install the serration bolts to the backing
plate.
(b) Remove the 4 nuts and washers from the serration bolts.
(c) Position SST on the backing plate with the 4 nuts.
SST 09521-2501 1, 09521-25021
(d) Using a press, remove the axle shaft, bearing retainer
and plate washer from the backing plate.
(e) Remove the SST.
SST 09521-2501 1, 09521-25021
4. REMOVE OIL DEFLECTOR
Using a brass bar and hammer, remove the 5 hub bolts, oil de-
flector and gasket.

SA15I-06
SA-92
- SUSPENSION AND AXLEREAR AXLE SHAFT
2042 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSTALLATION
Installation is in the reverse order of removal (See page SA-84).
HINT:
After installation, fill the brake reservoir with brake fluid, bleed the brake system (See page BR-4), check
for leaks and check the ABS speed sensor signal (See page DI-505).

F05114
SST
SST
- SUSPENSION AND AXLEREAR AXLE SHAFT
SA-91
2041 Author
: Date
:
2004 LAND CRUISER (RM1071U)
7. INSTALL ABS SPEED SENSOR ROTOR AND BEAR-
ING RETAINER
Using SST and a press, install a new ABS speed sensor rotor
and bearing retainer.
SST 09631-12090, 09950-60020 (09951-01030)
Standard length: 170.7 ± 1.0 mm (6.720 ± 0.039 in.)

SA15R-1 1
SA-1 16
- SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER
2066 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSTALLATION
Installation is in the reverse order of removal (See page SA-100).
HINT:
After installation, fill the differential with hypoid gear oil (See page SA-95), fill the brake reservoir with brake
fluid, bleed the brake system (See page BR-4), check for leaks and check the ABS speed sensor signal (See
page DI-505).

SA15X-09
SA-138
- SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER (w/ Diff. Lock)
2088 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSTALLATION
Installation is in the reverse order of removal (See page SA-100).
AFTER INSTALLATION, FILL DIFFERENTIAL WITH HYPOID GEAR OIL (See page SA-95)
HINT:
After installation, fill the differential with hypoid gear oil (See page SA-95), fill the brake reservoir with brake
fluid, bleed the brake system (See page BR-4), check for leaks and check the ABS speed sensor signal (See
page DI-505).

SA164-10
SA-162
- SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER (w/ LSD)
2112 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSTALLATION
Installation is in the reverse order of removal (See page SA-141).
HINT:
After installation, fill the differential with hypoid gear oil for LSD (See page SA-95), fill the brake reservoir
with brake fluid, bleed the brake system (See page BR-4), check for leaks and check the ABS speed sensor
signal (See page DI-505).

SA16I-02
F05240
ABS Speed Sensor
Wire Harness
Lower Control Arm
N´m (kgf´cm, ft´lbf) : Specified torque
18 (185, 13)
150 (1,530, 111)
150 (1,530, 111)
150 (1,530, 111)
150 (1,530, 111)
Upper Control Arm
Heat Insulator
150 (1,530, 111)









Non-reusable part
- SUSPENSION AND AXLEREAR UPPER AND LOWER CONTROL ARM
SA-181
2131 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REAR UPPER AND LOWER CONTROL ARM
COMPONENTS

SA16J-02
F04397
F04398
SA-182
- SUSPENSION AND AXLEREAR UPPER AND LOWER CONTROL ARM
2132 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. REMOVE REAR WHEEL
Torque: 131 N´m (1,340 kgf´cm, 97 ft´lbf)
2. SUPPORT REAR AXLE HOUSING WITH JACK
3. REMOVE UPPER CONTROL ARM
(a) Disconnect the ABS speed sensor wire harness.
(b) RH side:
Remove the bolt and heat insulator.
Torque: 18 N´m (185 kgf´cm, 13 ft´lbf)
(c) Remove the 2 nuts, washers, bolts and upper control arm.
Torque: 150 N´m (1,530 kgf´cm, 111 ft´lbf)
HINT:
At the time of installation, after stabilizing the suspension,
torque the nuts.
4. REMOVE LOWER CONTROL ARM
Remove the 2 nuts, washers, bolts and lower control arm.
Torque: 150 N´m (1,530 kgf´cm, 111 ft´lbf)
HINT:
At the time of installation, after stabilizing the suspension,
torque the nuts.
