Page 412 of 3115
BO1KK-04
H18910
Reinforcement
Floor Brace
No. 1 BraceNo. 3 Heater to
Register Duct
Instrument PanelCenter Register
Radio With A/C Control Assembly
Front Ash Receptacle Retainer Center Lower
Cluster Finish Panel
Front Ash
Receptacle BoxLower No. 2
Panel
Glove Compartment Door
Rear Console Cup Holder Box Front
Console
Panel
Front
Console Box
Rear Console
Box
Rear Radio
Control Panel
Console Rear End Panel Combination Meter
Cluster Finish
Panel
LH Lower Panel
Lower No. 1 Panel No. 2 Heater to
Register Duct
Combination
Switch
Steering WheelSteering Wheel Pad
Front Pillar Garnish
Cowl Side Trim
Front Door Scuff Plate Front Assist Grip No. 4 Heater to
Register Duct
Front Pillar Garnish
Front Assist Grip
Cowl Side Trim
Front Door Scuff Plate
AA
A
A
BBB
C
C
C
C
CC
C
C
C
D
H
A
F
20 (204, 15)
EE
Glove Compartment
Door Damper
50 (510, 37)
BB
Rear Console BoxNo. 1 Under Cover
Console Box
Hole Cover
w/ Disc Player
Changer:
B
Column Cover
Transfer
Shift
Lever
Knob
: Specified torqueN´m (kgf´cm, ft´lbf)
H
H
H
H
I
I
EE
JJ
F
F
F
F
F
H
HH
H
H
BB
BB
HH
H
H
H
H
F
F
F
FF
D Front Console
Box bracket
- BODYINSTRUMENT PANEL
BO-81
2655 Author: Date:
2004 LAND CRUISER (RM1071U)
INSTRUMENT PANEL
COMPONENTS
Page 537 of 3115
BR0JI-1 1
F04993
F04994
F04995
BR-16
- BRAKEFRONT BRAKE PAD
2152 Author: Date:
2004 LAND CRUISER (RM1071U)
REPLACEMENT
1. REMOVE FRONT WHEEL
2. INSPECT PAD LINING THICKNESS
Check the pad thickness through the caliper inspection hole
and replace the pads if they are not within the specification.
Minimum thickness: 1.0 mm (0.039 in.)
3. REMOVE CLIP AND 2 PINS
4. REMOVE 2 PAD RETAINER CLIPS
5. REMOVE 2 PADS, ANTI-SQUEAL SHIMS AND PAD
RETAINERS
NOTICE:
The pad retainer clip and clip can be used again provided
that they have sufficient rebound, no deformation, cracks
or wear, and have had all rust, dirt and foreign particles
cleaned off.
6. CHECK DISC THICKNESS AND DISC RUNOUT
(See page BR-21)
7. INSTALL NEW PADS
NOTICE:
When replacing worn pads, the anti-squeal shims must be
replaced together with the pad.
(a) Draw out a small amount of brake fluid from the reservoir.
(b) Press in the piston with a hammer handle or an equiva-
lent.
HINT:
Always change the pads on one wheel at a time as there
is a possibility of opposite piston fling out.
If the piston is difficult to push in, loosen the bleeder plug
and push in the piston while letting some brake fluid es-
cape.
(c) Install the 2 pad retainers to each caliper piston.
(d) Install the anti-squeal shim to each pad.
HINT:
Apply disc brake grease to both sides of the anti-squeal shims
(See page BR-15).
(e) Install the 2 pads.
HINT:
Apply disc brake grease to the pads indicated by the arrows
(See page BR-15).
Page 591 of 3115
F04989
BR0TB-04
F04990
F04991
- BRAKEREAR BRAKE PAD
BR-25
2161 Author: Date:
2004 LAND CRUISER (RM1071U)
REPLACEMENT
1. REMOVE REAR WHEEL
2. INSPECT PAD LINING THICKNESS
Check the pad thickness through the caliper inspection hole
and replace pads if not within the specification.
Minimum thickness: 1.0 mm (0.039 in.)
3. REMOVE BRAKE CALIPER
(a) Remove the 2 mounting bolts.
(b) Remove the caliper and suspend it so the hose is not
stretched.
HINT:
Do not disconnect the flexible hose.
4. REMOVE 2 PADS AND 4 ANTI-SQUEAL SHIMS
5. REMOVE 4 PAD SUPPORT PLATES
NOTICE:
The pad support plates can be used again provided that
they have sufficient rebound, no deformation, cracks or
wear, and have had all rust, dirt and foreign particles
cleaned off.
6. CHECK DISC THICKNESS AND RUNOUT
(See page BR-30)
7. INSTALL PAD SUPPORT PLATES
8. INSTALL NEW PADS
NOTICE:
When replacing worn pads, the anti-squeal shims must be
replaced together with the pads.
Install the 4 anti-squeal shims to the pads.
HINT:
Apply disc brake grease to both sides of the inner anti-squeal
shims (See page BR-24).
NOTICE:
Do not allow oil or grease to get on the rubbing face.
9. INSTALL CALIPER
(a) Draw out a small amount of brake fluid from the reservoir.
(b) Press in the pistons with a hammer handle or an equiva-
lent.
HINT:
Always change the pads on one wheel at a time as there
is a possibility of the opposite piston flying out.
If the piston is difficult to push in, loosen the bleeder plug
and push in the piston while letting some fluid escape.
Page 798 of 3115
DI-546- DIAGNOSTICSABS & VEHICLE STABILITY CONTROL (VSC) &
BRAKE ASSIST (BA) SYSTEM
739 Author: Date:
2004 LAND CRUISER (RM1071U)
DTCC1231 / 31, C1335 / 35Steering Angle Sensor Circuit
CIRCUIT DESCRIPTION
DTC No.DTC Detecting ConditionTrouble Area
C1231 / 31
Detection of any of the conditions 1. through 3.:
1. When the condition that ECU terminal IG1 voltage is 9.5
V or more, and does not receive data from steering
angle sensor continues for 1 sec. or more.
2. When the steering angle sensor value changes by 360°
or more with SSC signal from steering angle sensor
remaining ON or OFF.
3. When the condition that difference between the steering
angle value at edge occurring in SSC signal and the
value at edge occurring in SSC signal after turning the
steering wheel one-turn is out of the range from 355.5°
- 364.5° occurs 10 times or more.
Steering angle sensor
Steering angle sensor circuit
C1335 / 35
When the ECU IG1 terminal voltage is 9.5 V or more, data
transmission from the steering angle sensor is impossible
for 1 sec. or more.Steering angle sensor
Steering angle sensor circuit
DIC9J-02
Page 800 of 3115
F17609
ESS (-)
IG (+)
BAT (+)
DI-548- DIAGNOSTICSABS & VEHICLE STABILITY CONTROL (VSC) &
BRAKE ASSIST (BA) SYSTEM
741 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION PROCEDURE
HINT:
Start the inspection from step 1 in case of using the hand-held tester and start from step 2 in case of not
using the hand-held tester.
1 Check output value of the steering angle sensor.
PREPARATION:
(a) Connect the hand-held tester to the DLC3.
(b) Turn the ignition switch ON and push the hand-held tester main switch ON.
(c) Select the DATALIST mode on the hand-held tester.
CHECK:
Check that the steering wheel turning angle value of the steering angle position sensor displayed on the
hand-held tester is changing when turning the steering wheel.
HINT:
After certifying ºZeroº point calibration of the steering angle sensor (Speed: 21 mph (35 km/h), driving straight
ahead for 10 sec. or more), the value will change.
OK:
Steering wheel turning angle value must be changing.
OK Go to step 5.
NG
2 Check input voltage of the steering angle sensor.
PREPARATION:
Remove the column lower cover.
CHECK:
(a) Turn the ignition switch ON.
(b) Measure voltage between terminals 1 and 2, 2 and 9 of
the combination switch wire harness side connector.
OK:
Voltage: 10 to 14 V
NG Check and replace harness and connector.
OK
Page 801 of 3115
F03003
1 2
6 3 (+)(-)
(+)
(-)
(Oscilloscope) LOCK
F04441
(Reference)
3 ms
2,288 ms
104 ms 5 V
0 V
5 V
0 V
- DIAGNOSTICSABS & VEHICLE STABILITY CONTROL (VSC) &
BRAKE ASSIST (BA) SYSTEMDI-549
742 Author: Date:
2004 LAND CRUISER (RM1071U)
3 Check steering angle sensor.
PREPARATION:
(a) Remove the steering wheel lower No. 2 and No. 3 covers,
steering wheel pad, steering wheel column upper and
lower covers (See page SR-29).
(b) Disconnect the combination switch connector (for steer-
ing angle sensor).
(c) Connect the oscilloscope to terminals 3 and 6 of the com-
bination switch connector (for steering angle sensor).
(d) Apply battery positive voltage between terminals 1 and 2.
CHECK:
Turn the steering wheel slowly and check the signal waveform.
OK:
HINT:
The above signal waveform does not repeat ON and OFF regu-
larly and this combination changes case by case according to
the data.
NG Replace steering angle sensor.
OK
4 Check that slits of the steering sensor disc are clogged up.
NG Repair or replace steering sensor disc.
OK
Page 850 of 3115
F04506
LOCKON
PH
PHG
F06043
LOCK
PH
PHG
DI-598- DIAGNOSTICSABS & VEHICLE STABILITY CONTROL (VSC) &
BRAKE ASSIST (BA) SYSTEM
791 Author: Date:
2004 LAND CRUISER (RM1071U)
3 Check pressure switch (PH) operation.
PREPARATION:
(a) Turn the ignition switch OFF, and depress the brake pedal
40 times or more.
HINT:
When pressure in the power supply system is released, reac-
tion force becomes light and stroke becomes longer.
(b) Install the LSPV gauge (SST) to the rear brake caliper
and bleed air.
SST 09709-29018
CHECK:
While checking the voltage between terminals PH and PHG of
the hydraulic brake booster, depress the brake pedal with a
force of more than 294 N (30 kgf, 66 lbf) and turn the ignition
switch ON, then check the rear wheel cylinder pressure when
voltage changes from 6 V to 0 V.
OK:
12,553 to 20,104 kpa (128 to 205 kgf´cm2, 1,820 to
2,916 psi)
PREPARATION:
Turn the ignition switch OFF and disconnect the connector (5P)
from the hydraulic brake booster.
CHECK:
While checking the resistance between terminals PH and PHG,
depress the brake pedal changing the force in a range of 197
N (20 kgf, 44 lbf) to 294 N (30 kgf, 66 lbf) and check the rear
wheel cylinder pressure when resistance changes from 0 kW to
1 kW between PH and PHG.
OK:
11,964 to 18,240 kpa (122 to 186 kgf´cm2, 1,735 to
2,645 psi)
HINT:
After inspection, connect the connector, fill brake reservoir with
brake fluid and clear the DTC (See page DI-505).
OK Go to step 5.
NG
Page 851 of 3115
F06042
LOCKON
PLG
PL
- DIAGNOSTICSABS & VEHICLE STABILITY CONTROL (VSC) &
BRAKE ASSIST (BA) SYSTEMDI-599
792 Author: Date:
2004 LAND CRUISER (RM1071U)
4 Check for open circuit in harness and connector between pressure switch (PH)
and skid control ECU (See page IN-36).
NG Repair or replace harness or connector.
OK
Replace hydraulic brake booster assembly.
5 Check pressure switch (PL) operation.
PREPARATION:
(a) Turn the motor switch OFF, and depress the brake pedal
40 times or more.
HINT:
When pressure in the power supply system is released, reac-
tion force becomes light and stroke becomes longer.
(b) Install the LSPV gauge (SST) to the rear brake caliper
and bleed air.
SST 09709 -29018
(c) Disconnect the connector (8P) from the hydraulic brake
booster.
CHECK:
While checking the resistance between terminals PL and PLG
of the hydraulic brake booster, depress the brake pedal with a
force of more than 294 N (30 kgf, 66 lbf) and turn the ignition
switch ON, then check the rear wheel cylinder pressure when
the resistance changes from 5.7 kW to 1.0 kW.
OK:
9,022 to 15,102 kpa (92 to 154 kgf´cm2, 1,308 to 2,190
psi)
PREPARATION:
Turn the ignition switch OFF and disconnect the connector (8P)
from the hydraulic brake booster.
CHECK:
While checking the resistance between terminals PL and PLG
of the hydraulic brake booster, depress the brake pedal chang-
ing the force in a range of 197 N (20 kgf, 44 lbf) to 294 N (30 kgf,
66 lbf) and check the rear wheel cylinder pressure when resis-
tance changes from 1.0 kW to 5.7 kW.
OK:
8,532 to 13,337 kpa (87 to 136 kgf´cm2, 1,237 to 1,934
psi)
Page 868 of 3115
DIC94-02
BR3583
BR3582F00010
RotorSpeed Sensor
Magnet
To ECU
+V
-VHigh Speed
Low Speed
CoilNS
- DIAGNOSTICSABS & VEHICLE STABILITY CONTROL (VSC) &
BRAKE ASSIST (BA) SYSTEMDI-615
808 Author: Date:
2004 LAND CRUISER (RM1071U)
CIRCUIT INSPECTION
DTC
C0200 / 31 - C1239 / 39Speed Sensor Circuit
CIRCUIT DESCRIPTION
The speed sensor detects wheel speed and sends the ap-
propriate signals to the ECU. These signals are used for control
of the ABS & BA & TRAC & VSC control system. The front and
rear rotors each have 48 serrations.
When the rotors rotate, the magnetic field emitted by the perma-
nent magnet in the speed sensor generates AC voltage. Since
the frequency of this AC voltage changes in direct proportion to
the speed of the rotor, the frequency is used by the ECU to de-
tect the speed of each wheel.
DTC No.DTC Detecting ConditionTrouble Area
C0200 / 31
C0205 / 32
C0210 / 33
C0215 / 34
Detection of any of the conditions 1. through 4.:
1. At a vehicle speed of 6 mph (10 km/h) or more, pulses
are not input for 15 sec.
2. Momentary interruption of the speed sensor signal oc-
curs at least 7 times in the time between switching the
ignition switch ON and switching it OFF.
3. Continuous noise occurs into the speed sensor signals
with a vehicle speed at 12 mph (20 km/h) or more.
4. The condition that the speed sensor signal circuit is
open continues for 0.12 sec. or more.
ABS does not function
Brake pedal is not depressed
Parking brake is not set
Rear differential does not lock
Under the above conditions, when the difference in velocity
between the highest rotating and the second highest rotat-
ing wheels is within 1 mph (2 km/h), the slowest wheel ro-
tates at 0 mph (0 km/h), and the second slowest wheel
rotates at 7 mph (12 km/h) for 1 second or more.
Right front, left front, right rear and left rear speed sensor
Each speed sensor circuit
Sensor rotor
C1235 / 35
C1236 / 36
C1238 / 38
C1239 / 39Continuous noise occurs into the speed sensor
signals with a vehicle speed at 12 mph (20 km/h)
or more continues for 5 sec or more.Right front, left front, right rear, left rear speed sensor
Speed sensor rotor
HINT:
DTC No. C0200 / 31 and C1235 / 35 are for the right front speed sensor.
DTC No. C0205 / 32 and C1236 / 36 are for the left front speed sensor.
DTC No. C0210 / 33 and C1238 / 38 are for the right rear speed sensor.
DTC No. C0215 / 34 and C1239 / 39 are for the left rear speed sensor.
Page 903 of 3115
DI-508- DIAGNOSTICSABS & VEHICLE STABILITY CONTROL (VSC) &
BRAKE ASSIST (BA) SYSTEM
701 Author: Date:
2004 LAND CRUISER (RM1071U)WHEEL SPD FL
Front Left wheel speed/
Min.: 0km/h, Max.: 326.4 km/hActual wheel speedSpeed indicated on speedometer
WHEEL SPD RRRear Right wheel speed/
Min.: 0km/h, Max.: 326.4 km/hActual wheel speedSpeed indicated on speedometer
WHEEL SPD RLRear Left wheel speed/
Min.: 0km/h, Max.: 326.4 km/hActual wheel speedSpeed indicated on speedometer
DECELERAT SENSG sensor (GL1 filter)/
Min.: -1.869 G, Max.: 1.869Approximately 0 ± 0.13 G at still
conditionReading changes when vehicle is
bounced
DECELERAT SENS2G sensor (GL2 filter)/
Min.: -1.869 G, Max.: 1.869Approximately 0 ± 0.13 G at still
conditionReading changes when vehicle is
bounced
IG VOLTAGEECU IG power voltage/
UNDER or NORMAL or OVER--
SFRRSFRR/ ON or OFF--
SFRHSFRH/ ON or OFF--
SFLRSFLR/ ON or OFF--
SFLHSFLH/ ON or OFF--
SRRR (SRR)SRRR (SRR)/ ON or OFF--
SRRH (SRH)SRRH (SRH)/ ON or OFF--
SRLRSRLR/ ON or OFF--
SRLHSRLH/ ON or OFF--
SRCF (SA1)SRCF (SA1)/ ON or OFF--
SRCR (SA2)SRCR (SA2)/ ON or OFF--
SRMF (SMCF, SA3)SRMF (SMCF, SA3)/ ON or OFF--
SRMR (SMCR, STR)SRMR (SMCR, STR)/ ON or OFF--
THROTTLEThrottle position sensor/
Min.: 0 deg, Max.: 125 deg--
ENGINE SPDEngine Speed/
Min.: 0 rpm, Max.: 6000 rpmActual engine speed-
YAW R AT EYaw rate sensor/
Min.: -128 deg/s, Max.: 128 deg/s--
YAW ZERO VALUEMemorized zero value/
Min.: -128 deg/s, Max.: 128 deg/s--
STEERING ANG
Steering sensor/
Min.: -1682 deg,
Max.: 1877 deg
-1682 to 1877 deg
Turning the steering wheel
changes the value
Left : Becomes grater
Right : Becomes smaller
MAS CYL PRS 1Master cylinder pressure 1/
Min.: 0 V, Max.: 5 VWhen brake pedal is released:
0.3 - 0.9 VReading increases when brake
pedal is depressed
AIR BLD SUPPORTAir bleed support/
NOT SUP or SUPPORTw/ BA: Supported
w/ VSC: Not supported-
TEST MODETest mode operation/
NORMAL or TESTNORMAL: Normal mode
TEST: During test mode-
#CODESNumber of Trouble Code/
Min.: 0, Max.: 255MIn.: 0, Max.: 45-
