TOYOTA LAND CRUISER 1996 J80 Workshop Manual

AB0163
Wire Harness
Diameter
Stripped Wire Harness Section
−
SUPPLEMENTAL RESTRAINT SYSTEM FRONT PASSENGER AIRBAG ASSEMBLY
RS−27
1996 LAND CRUISER (RM451U)
(e) Dispose of the front passenger airbag assembly.
CAUTION:
The front passenger airbag assembly is very hot
when the airbag is deployed, so leave it alone for at
least 30 minutes after deployment.
Use gloves and safety glasses when handling a front
passenger airbag assembly with deployed airbag.
Always wash your hands with water after completing
the operation.
Do not apply water, etc. to a front passenger airbag
assembly with deployed airbag.
(1) When scrapping a vehicle, deploy the airbag and scrap the vehicle with the front passenger airbag
assembly still installed.
(2) When moving a vehicle for scrapping which has a front passenger airbag assembly with deployed air-
bag, use gloves and safety glasses.
2. DEPLOYMENT WHEN DISPOSING OF FRONT PAS- SENGER AIRBAG ASSEMBLY ONLY
NOTICE:
When disposing of the front passenger airbag assem-
bly only, never use the customer’s vehicle to deploy
the airbag.
Be sure to follow the procedure given below when de-
ploying the airbag.
HINT:
Have a battery ready as the power source to deploy the airbag.
(a) Remove the front passenger airbag assembly. (See page RS−22 )
CAUTION:
When removing the front passenger airbag assembly,
work must be started 90 seconds after the ignition
switch is turned to the ”LOCK” position and the nega-
tive (−) terminal cable is disconnected from the bat-
tery.
Store the front passenger airbag assembly with the
airbag deployment side facing upward.
(b) Using a service− purpose wire harness for the vehicle, tie
down the front passenger airbag assembly to the tire.
Wire harness: Stripped wire harness section
1.25 mm
2 or more (0.0019 in.2 or more)
HINT:
To calculate the square of the stripped wire harness section: Square = 3.14 X (Diameter)
2 divided by 4
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

R11891
WidthInner
Diam.
AB0158
Battery
SST
R09689
Tires
(5 or more)
RS−28
−
SUPPLEMENTAL RESTRAINT SYSTEM FRONT PASSENGER AIRBAG ASSEMBLY
1996 LAND CRUISER (RM451U)
CAUTION:
If the front passenger airbag assembly is tied down with
too thin wire harness, it may snap. This is highly danger-
ous. Always use a wire harness which is at least 1.25 mm
2
(0.0019 in.2)
(1) Wind the wire harness around the tire, passing the wire harness through the installation holes indi-
cated by arrows in the illustration.
(2) Position the front passenger airbag assembly in- side the tire with the airbag deployment side facing
inside.
Tire size: Must exceed the following dimensions −
Width: 185 mm (7.28 in.)
Inner diameter: 360 mm (14.17 in.)
CAUTION:
Make sure that the wire harness is tight. It is very dan-
gerous if looseness in the wire harness results in the
front passenger airbag assembly coming free due to
the shock from the airbag deploying.
Always tie down the front passenger airbag assembly
with the airbag deployment side facing inside.
NOTICE:
The tire will be marked by the airbag deployment, so use a
redundant tire.
(c) Check functioning of the SST. SST 09082−00700
(d) Place tires. (1) Place at least 2 tires under the tire to which the frontpassenger airbag assembly is tied.
(2) Place at least 2 tires over the tire to which the front passenger airbag assembly is tied. The top tire
should have the wheel installed.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

R05403
R09690
Battery
SST Front Passenger
Airbag Assembly
10 mm (33 ft) or more
R09687
−
SUPPLEMENTAL RESTRAINT SYSTEM FRONT PASSENGER AIRBAG ASSEMBLY
RS−29
1996 LAND CRUISER (RM451U)
(3) Tie the tires together with 2 wire harnesses.
CAUTION:
Make sure that the wire harnesses are tight. It is very dan-
gerous if loose wire harnesses result in the tires coming
free due to the shock from the airbag deploying.
HINT:
Place the SST connector and wire harness inside tires. Provide
at least 1 m (3 ft) of slack for the wire harness.
(e) Install the SST. Connect the SST connector to the front passenger airbag
assembly connector.
SST 09082−00700
NOTICE:
To avoid damaging the SST connector and wire harness,
do not lock the secondary lock of the twin lock.
(f) Deploy the airbag (1) Connect the SST red clip to the battery positive (+)terminal and the black clip to the battery negative
(−) terminal.
(2) Confirm that no one is within 10 m (33 ft) area around the tire which the front passenger airbag as-
sembly is tied to.
(3) Press the SST activation switch and deploy the air-
bag.
HINT:
The airbag deploys simultaneously as the LED of the SST ac-
tivation switch lights up.
(g) Dispose of the front passenger airbag assembly.
CAUTION:
The front passenger airbag assembly is very hot
when the airbag is deployed, so leave it alone for at
least 30 minutes after deployment.
Use gloves and safety glasses when handling a front
passenger airbag assembly with deployed airbag.
Always wash your hands with water after completing
the operation.
Do not apply water, etc. to a front passenger airbag
assembly with deployed airbag.
(1) Remove the front passenger airbag assembly from
the tire.
(2) Place the front passenger airbag assembly in a vi- nyl bag, tie the end tightly and dispose of it in the
same way as other general parts disposal.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

RS0PA−01
RS−30
−
SUPPLEMENTAL RESTRAINT SYSTEM FRONT PASSENGER AIRBAG ASSEMBLY
1996 LAND CRUISER (RM451U)
REPLACEMENT
REPLACEMENT REQUIREMENTS
In the following cases, replace the front passenger airbag assembly, instrument panel or instrument panel
reinforcement.
CaseReplacing part
If the airbag has been deployed.Front passenger airbag assembly
If the front passenger airbag assembly has been found to be faulty in tr\
ouble-
shooting.Front passenger airbag assembly
If the front passenger airbag assembly has been found to be faulty durin\
g
checking items. (See page RS−23)Front passenger airbag assembly
If the instrument panel has been found to be faulty during checking item\
s.
(See page RS−23)Instrument panel
If the instrument panel reinforcement has been found to be faulty during\
checking items. (See page RS−23)Instrument panel reinforcement
If the front passenger airbag assembly has been dropped.Front passenger airbag assembly
CAUTION:
For replacement of the front passenger airbag assembly, see page RS−22 and RS−31 .
Be sure to follow the correct procedure.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

RS0PC−03
−
SUPPLEMENTAL RESTRAINT SYSTEM FRONT PASSENGER AIRBAG ASSEMBLY
RS−31
1996 LAND CRUISER (RM451U)
INSTALLATION
NOTICE:
Never use airbag parts from another vehicle. When replac-
ing parts, replace with new parts.
1. INSTALL FRONT PASSENGER AIRBAG ASSEMBLY
Install the airbag door and front passenger airbag assembly to
the instrument panel.
CAUTION:
Make sure that no foreign objects are trapped be-
tween the airbag and the module.
Do not damage the strap when installing the module.
If the airbag door is cracked or its surface is peeling,
always replace it with a new airbag door.
NOTICE:
If the front passenger airbag assembly has been dropped,
or there are cracks, dents or other defects in the case or
connector, replace the front passenger airbag assembly
with a new one.
2. INSTALL INSTRUMENT PANEL (See page BO−80)
Install the 2 bolts to instrument panel reinforcement. Torque: 20 N·m (210 kgf·cm, 15 ft·lbf)
NOTICE:
Make sure the front passenger airbag assembly is installed
to the specified torque.When installing the instrument pan-
el, take care that the airbag wire harness does not interfere
with other parts and is not pinched between other parts.
3. CONNECT AIRBAG CONNECTOR
(a) Connect the airbag connector.
(b) Install the airbag connector to the airbag bracket.
(c) Install the glove compartment door.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

RS0PD−01
RS−32
−
SUPPLEMENTAL RESTRAINT SYSTEM AIRBAG SENSOR ASSEMBLY
1131
Author: Date:
1996 LAND CRUISER (RM451U)
AIRBAG SENSOR ASSEMBLY
COMPONENTS
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

RS0PE−01
−
SUPPLEMENTAL RESTRAINT SYSTEM AIRBAG SENSOR ASSEMBLY
RS−33
1996 LAND CRUISER (RM451U)
REMOVAL
NOTICE:
Do not open the cover or the case of the ECU and various
computers unless absolutely necessary.
(If the IC terminals are touched, the IC may be destroyed by
static electricity.)
1. REMOVE THESE PARTS:
(a) Transfer shirt knob
(b) Front console box
2. REMOVE AIRBAG SENSOR ASSEMBLY
(a) Disconnect the connector.
NOTICE:
Remove the connector with the sensor assembly installed.
(b) Using a torx wrench remove the 4 screws and the airbag sensor assembly.
Torx wrench: T40 (Part No. 09042 −00020 or locally
manufactured tool)
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

RS0PH−01
RS−34
−
SUPPLEMENTAL RESTRAINT SYSTEM AIRBAG SENSOR ASSEMBLY
1996 LAND CRUISER (RM451U)
INSPECTION
1. VEHICLE NOT INVOLVED IN COLLISION
Do a diagnostic system check. (See page DI−240)
2. VEHICLE INVOLVED IN COLLISION AND AIRBAG IS NOT DEPLOYED
Do a diagnostic system check. (See page DI−240)
3. VEHICLE INVOLVED IN COLLISION AND AIRBAG IS DEPLOYED
Replace the airbag sensor assembly. (See page RS−32)
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

RS0PG−01
−
SUPPLEMENTAL RESTRAINT SYSTEM AIRBAG SENSOR ASSEMBLY
RS−35
1996 LAND CRUISER (RM451U)
REPLACEMENT
REPLACEMENT REQUIREMENTS
In the following cases, replace the airbag sensor assembly.
If the SRS has been deployed in a collision.
If the airbag sensor assembly has been found to be faulty in troubleshoo\
ting.
If the airbag sensor assembly has been dropped.
CAUTION:
For removal and installation of the airbag sensor assembly, see page RS−33 and RS−36 . Be sure to
follow the correct procedure.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

RS0PF−01
RS−36
−
SUPPLEMENTAL RESTRAINT SYSTEM AIRBAG SENSOR ASSEMBLY
1996 LAND CRUISER (RM451U)
INSTALLATION
NOTICE:
Never use SRS parts from another vehicle. When replacing parts, replace with \
new parts.
Never reuse the airbag sensor assembly involved in a collision when the airbag has deployed.
Never repair a sensor in order to reuse it.
1. INSTALL AIRBAG SENSOR ASSEMBLY
(a) Using a torx wrench, install the airbag sensor assembly with the 4 screw\
s. Torx wrench: T40 (Part No. 09042 −00020 or locally manufactured tool)
Torque: 21 N·m (210 kgf·cm, 15 ft·lbf)
(b) Connect the connector.
NOTICE:
Installation of the connector is done with the sensor assembly installed\
.
Make sure the sensor assembly is installed to the specified torque.
If the sensor assembly has been dropped, or there are cracks, dents or o\
ther defects in the
case, bracket or connector, replace the sensor assembly with a new one.
When installing the sensor assembly, take care that the SRS wiring does not interfere with other
parts and is not pinched between other parts.
After installation, shake the sensor assembly to check that there is no \
looseness.
2. INSTALL THE REMOVED PARTS
