Page 792 of 1399
EM0494
−
ENGINE MECHANICAL VALVE CLEARANCE
EM−7
510
Author: Date:
1996 LAND CRUISER (RM451U)
9. Rear valves of No. 6 cylinder
ADJUST VALVE CLEARANCE
(a) Remove the distributor (See page IG−10).
(b) Remove the camshafts (See page EM−28).
(c) Remove the adjusting shim with a small screwdriver.
(d) Determine the replacement adjusting shim size by follow- ing the Formula or Charts:
Using a micrometer, measure the thickness of the
removed shim.
Calculate the thickness of a new shim so that the
valve clearance comes within specified value.
T ....... Thickness of removed shim
A ....... Measured valve clearance
N ....... Thickness of new shim
Intake: N = T + (A − 0.20 mm (0.008 in.))
Exhaust: N = T + (A − 0.30 mm (0.012 in.))
Select a new shim with a thickness as close as pos-
sible to the calculated value.
HINT:
Shims are available in 17 sized in increments of 0.05 mm
(0.0020 in.), from 2.50 mm (0.0984 in.) to 3.30 mm (0.1299 in.).
(e) Place a new adjusting shim on the valve lifters.
(f) Install the camshafts (See page EM−54 ).
(g) Recheck the valve clearance.
(h) Install the distributor (See page IG−11 ).
10. REINSTALL CYLINDER HEAD COVER
(a) Install the gasket to the cylinder head cover.
(b) Install the cylinder head cover with the 13 bolts.
11. RECONNECT HIGH −TENSION CORDS TO SPARK
PLUGS (See page IG−1 )
12. RECONNECT HEA TER VALVE AND ENGINE WIRE TO
COWL PANEL
(a) Connect the heater valve with the 2 bolts.
(b) Connect the ground strap and engine wire with the 2 bolts.
13. REINSTALL THROTTLE BODY (See page SF−48 )
14. REFILL RADIATOR WITH ENGINE COOLANT
15. CHECK AND ADJUST IGNITION TIMING (See page EM−10 )
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
Page 900 of 1399
IG0152
P03783
−
IGNITION IGNITION SYSTEM
IG−5
739
Author: Date:
1996 LAND CRUISER (RM451U)
(b) Install the No.1 and No.2 cord clamps with the 2 bolts.
11. INSTALL NO.2 AND NO.3 CYLINDER HEAD COVERS
Install the head covers with the 4 bolts.
12. CONNECT THROTTLE CABLE
13. INSTALL AIR CLEANER HOSE
Install the air cleaner hose with the 2 clamp bolts.
14. INSTALL NO.2 PCV HOSE
15. DISCONNECT HIGH −TENSION CORDS FROM SPARK
PLUGS
16. REMOVE SPARK PLUGS
Using a 16 mm plug wrench, remove the spark plug.
17. CLEAN SPARK PLUGS
Using a spark plug cleaner or wire brush, clean the spark plug.
18. VISUALLY INSPECT SPARK PLUGS
Check the spark plug for electrode wear, threads damage and
insulator damage.
If abnormal, replace the plugs. Recommended spark plugs:
ND: K16R −U
NGK: BKR5EYA
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
Page 901 of 1399
P03792
IG−6
−
IGNITION IGNITION SYSTEM
740
Author: Date:
1996 LAND CRUISER (RM451U)
19. ADJUST ELECTRODE GAP
Carefully bend the outer electrode to obtain the correct elec-
trode gap.
Correct electrode gap: 0.8 mm (0.031 in.)
20. INSTALL SPARK PLUGS
Using a 16 mm plug wrench, install the spark plug. Torque: 20 N·m (200 kgf·cm, 14 ft·lbf)
21. RECONNECT HIGH −TENSION CORDS TO SPARK
PLUGS
NOTICE:
”Cold” and ”Hot” in the following sentences express the
temperature of the coils themselves. ”Cold” is from −10° C
(14 °F) to 50° C (122°F) and ”Hot” is from 50 °C (122° F) to
100 °C (212 °F).
22. DISCONNECT IGNITION COIL CONNECTOR
23. DISCONNECT HIGH−TENSION CORD
24. INSPECT PRIMARY COIL RESISTANCE
Using an ohmmeter, measure the resistance between the posi-
tive (+) and negative (−) terminals. Primary coil resistance:
Cold: 0.36 − 0.55 Ω
Hot: 0.45 − 0.65 Ω
If the resistance is not as specified, replace the ignition coil.
25. INSPECT SECONDARY COIL RESISTANCE
Using an ohmmeter, measure the resistance between the posi-
tive (+) and high −tension terminals.
Secondary coil resistance:
Cold: 9.0 − 15.4 kΩ
Hot: 11.4 − 18.1 kΩ
If the resistance is not as specified, replace the ignition coil.
26. RECONNECT HIGH−TENSION CORD
27. RECONNECT IGNITION COIL CONNECTOR
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
Page 937 of 1399
MA04U−01
P04771
−
MAINTENANCE ENGINE
MA−5
45
Author: Date:
1996 LAND CRUISER (RM451U)
ENGINE
INSPECTION
HINT:
Inspect these items when the engine is cold.
1. INSPECT DRIVE BELT (See page CH−2)
2. INSPECT AIR FILTER
(a) Visually check that the air cleaner element is not exces- sively dirty, damaged or oily.
If necessary, replace the air cleaner element.
(b) Clean the element with compressed air. First blow from the inside thoroughly, then blow off the
outside of the element.
3. REPLACE AIR FILTER
Replace the air cleaner element with a new one.
4. REPLACE SPARK PLUGS (See page IG−1 )
5. REPLACE ENGINE OIL AND OIL FILTER (See page LU−2)
6. REPLACE ENGINE COOLANT (See page CO−2)
7. INSPECT CHARCOAL CANISTER (See page EC−6 )
8. REPLACE GASKET IN FUEL TANK CAP (See page
EC−6)
9. INSPECT FUEL LINES AND CONNECTIONS (See page EC−6)
10. INSPECT EXHAUST PIPES AND MOUNTINGS
Visually inspect the p ipes, hangers and connections for severe
corrosion, leaks or damage.
11. ADJUST VALVE CLEARANCE (See page EM−4)
