H01019H16275H16623
Curtain Shield
Squib LHAirbag
Sensor
Assembly
ICL+
(-)
(+) ICL-
Floor No. 1 Wire
DI-870
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1063 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION PROCEDURE
1 Prepare for inspection (See step 1 on page DI-923).
2 Check floor No. 1 wire (curtain shield squib LH circuit).
PREPARATION:
Release the airbag activation prevention mechanism built in the
connector of the floor No. 1 wire on the airbag sensor assembly
side (See page DI-692).
CHECK:
Measure the resistance between ICL+ and ICL- of the floor No.
1 wire connector on the curtain shield airbag assembly LH (cur-
tain shield squib LH) side.
OK:
Resistance: 1 MW or Higher
NG Repair or replace floor No. 1 wire.
OK
Page 1652 of 3115
AB0119H01017H10600H11648H13064
Curtain Shield
Squib LHAirbag
Sensor
Assembly
" u
ON
DTC B1165/87 DLC3
TC
CG
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-871
1064 Author: Date:
2004 LAND CRUISER (RM1071U)
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch or ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B1165/87 is not output.
HINT:
Codes other than code B1165/87 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK
Page 1653 of 3115
H11648H10600 H01018 AB0119H13065
"uAirbag
Sensor
Assembly
DTC B1165/87 DLC3
TC CGON Curtain Shield
Squib LH
DI-872
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1065 Author: Date:
2004 LAND CRUISER (RM1071U)
4 Check curtain shield squib LH.
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect the negative (-) terminal cable from the bat-
tery, and wait at least for 90 seconds.
(c) Connect the curtain shield airbag assembly LH (curtain
shield squib LH) connector.
(d) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B1165/87 is not output.
HINT:
Codes other than code B1165/87 may be output at this time, but
they are not relevant to this check.
NG Replace curtain shield airbag assembly LH
(curtain shield squib LH).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check.
Page 1654 of 3115
H01019H16275H16623
Curtain Shield
Squib LHAirbag
Sensor
Assembly
(-) (+)
ICL-
ICL+ Floor No. 1 Wire
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-873
1066 Author: Date:
2004 LAND CRUISER (RM1071U)
DTC B1166/88 Open in Curtain Shield Squib LH
Circuit
CIRCUIT DESCRIPTION
The curtain shield squib LH circuit consists of the airbag sensor assembly and the curtain shield airbag as-
sembly LH.
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS-3.
DTC B1166/88 is recorded when an open is detected in the curtain shield squib LH circuit.
DTC No.DTC Detecting ConditionTrouble Area
B1166/88
Open in curtain shield squib LH circuit
Curtain shield squib LH malfunction
Airbag sensor assembly malfunctionCurtain shield airbag assembly LH (Curtain shield squib LH)
Airbag sensor assembly
Floor No. 1 wire
HINT:
DTC B1166/88 is indicated only for the vehicle equipped with the side airbag.
WIRING DIAGRAM
See page DI-869.
INSPECTION PROCEDURE
1 Prepare for inspection (See step 1 on page DI-923).
2 Check floor No. 1 wire (curtain shield squib LH circuit).
CHECK:
Measure the resistance between ICL+ and ICL- of the floor No.
1 wire connector on the curtain shield airbag assembly LH (cur-
tain shield squib LH) side.
OK:
Resistance: Below 1 W
NG Repair or replace floor No. 1 wire.
OK
DI6PG-22
Page 1655 of 3115
AB0119H10600
H01017
H11649H16278H21146
Curtain Shield
Squib LHAirbag
Sensor
Assembly
ICL+
CGDTC B1166/88
" u
DLC3ON
ICL-
TCFloor No. 1 Wire
DI-874
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1067 Author: Date:
2004 LAND CRUISER (RM1071U)
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Using a service wire, connect ICL+ and ICL- of the floor
No. 1 wire connector on the curtain shield airbag assem-
bly LH (curtain shield squib LH) side.
(c) Connect the negative (-) terminal cable to the battery,
and wait at least 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B1166/88 is not output.
HINT:
Codes other than code B1166/88 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK
Page 1656 of 3115
H11649H10600H01018AB0119H13067
"u
Airbag
Sensor
Assembly Curtain Shield
Squib LH
ON
DLC3
DTC B1166/88
TC
CG
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-875
1068 Author: Date:
2004 LAND CRUISER (RM1071U)
4 Check curtain shield squib LH.
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect the negative (-) terminal cable from the bat-
tery, and wait at least for 90 seconds.
(c) Connect the curtain shield airbag assembly LH (curtain
shield squib LH) connector.
(d) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B1166/88 is not output.
HINT:
Codes other than code B1166/88 may be output at this time, but
they are not relevant to this check.
NG Replace curtain shield airbag assembly LH
(curtain shield squib LH).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check.
Page 1657 of 3115
H16276H01016H21147
Curtain Shield
Squib LH
Airbag
Sensor
Assembly
(-)
(+)
ICL+ Floor No. 1 Wire
DI-876
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1069 Author: Date:
2004 LAND CRUISER (RM1071U)
DTC B1167/85 Short in Curtain Shield Squib LH
Circuit (to Ground)
CIRCUIT DESCRIPTION
The curtain shield squib LH circuit consists of the airbag sensor assembly and the curtain shield airbag as-
sembly LH.
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS-3.
DTC B1167/85 is recorded when ground short is detected in the curtain shield squib LH circuit.
DTC No.DTC Detecting ConditionTrouble Area
B1167/85
Short in curtain shield squib LH circuit (to ground)
Curtain shield squib LH malfunction
Airbag sensor assembly malfunctionCurtain shield airbag assembly LH (Curtain shield squib LH)
Airbag sensor assembly
Floor No. 1 wire
HINT:
DTC B1167/85 is indicated only for the vehicle equipped with the side airbag.
WIRING DIAGRAM
See page DI-856.
INSPECTION PROCEDURE
1 Prepare for inspection (See step 1 on page DI-923).
2 Check floor No. 1 wire (curtain shield squib LH circuit).
CHECK:
Measure the resistance between the body ground and ICL+ of
the floor No. 1 wire connector on the curtain shield airbag as-
sembly LH (curtain shield squib LH) side.
OK:
Resistance: 1 MW or Higher
NG Repair or replace floor No. 1 wire.
OK
DI6PH-22
Page 1658 of 3115
AB0119H10600 H01017H11646H16278H21148
Curtain Shield
Squib LH
Airbag
Sensor
Assembly
ICL+ICL-
" u
DLC3ON
CGTCDTC B1167/85 Floor No. 1 Wire
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-877
1070 Author: Date:
2004 LAND CRUISER (RM1071U)
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Using a service wire, connect ICL+ and ICL- of the floor
No. 1 wire connector on the curtain shield airbag assem-
bly LH (curtain shield squib LH) side.
(c) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B1167/85 is not output.
HINT:
Codes other than code B1167/85 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK
Page 1659 of 3115
H10600 H01018 AB0119H11646H13069
"u
TCAirbag
Sensor
Assembly Curtain Shield
Squib LH
DTC B1167/85 ON
DLC3
CG
DI-878
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1071 Author: Date:
2004 LAND CRUISER (RM1071U)
4 Check curtain shield squib LH.
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect the negative (-) terminal cable from the bat-
tery, and wait at least for 90 seconds.
(c) Connect the curtain shield airbag assembly LH (curtain
shield squib LH) connector.
(d) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B1167/85 is not output.
HINT:
Codes other than code B1167/85 may be output at this time, but
they are not relevant to this check.
NG Replace curtain shield airbag assembly LH
(curtain shield squib LH).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check. If the malfunctioning part can not be
detected by the simulation method, replace all SRS components including the wire harness.
Page 1660 of 3115
H01016AB0119
H16277H16627
Curtain Shield
Squib LHAirbag
Sensor
Assembly
ICL+
(-)(+)
ON
Floor No. 1 Wire
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-879
1072 Author: Date:
2004 LAND CRUISER (RM1071U)
DTC B1168/86 Short in Curtain Shield Squib LH
Circuit (to B+)
CIRCUIT DESCRIPTION
The curtain shield squib LH circuit consists of the airbag sensor assembly and the curtain shield airbag as-
sembly LH.
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS-3.
DTC B1168/86 is recorded when a B+ short is detected in the curtain shield squib LH circuit.
DTC No.DTC Detecting ConditionTrouble Area
B1168/86
Short in curtain shield squib LH circuit (to B+)
Curtain shield squib LH malfunction
Airbag sensor assembly malfunctionCurtain shield airbag assembly LH (Curtain shield squib LH)
Airbag sensor assembly
Floor No. 1 wire
HINT:
DTC B1168/86 is indicated only for the vehicle equipped with the side airbag.
WIRING DIAGRAM
See page DI-869.
INSPECTION PROCEDURE
1 Prepare for inspection (See step 1 on page DI-923).
2 Check floor No. 1 wire (curtain shield squib LH circuit).
PREPARATION:
Connect the negative (-) terminal cable to the battery, and wait
at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON.
(b) Measure the voltage between the body ground and ICL+
of the floor No. 1 wire connector on the curtain shield air-
bag assembly LH (curtain shield squib LH) side.
OK:
Voltage: Below 1 V
NG Repair or replace floor No. 1 wire.
OK
DI6PI-22
