TOYOTA LAND CRUISER 1998 Factory Repair Manual
Manufacturer: TOYOTA, Model Year: 1998, Model line: LAND CRUISER, Model: TOYOTA LAND CRUISER 1998Pages: 3115, PDF Size: 54.88 MB
Page 1641 of 3115
H01019H16275H16616
Curtain Shield
Squib RHAirbag
Sensor
Assembly
(-)
(+)
ICR+ ICR-
Floor No. 2 Wire
DI-860
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1053 Author: Date:
2004 LAND CRUISER (RM1071U)
DTC B1161/84 Open in Curtain Shield Squib RH
Circuit
CIRCUIT DESCRIPTION
The curtain shield squib RH circuit consists of the airbag sensor assembly and the curtain shield airbag as-
sembly RH.
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS-3.
DTC B1161/84 is recorded when an open is detected in the curtain shield squib RH circuit.
DTC No.DTC Detecting ConditionTrouble Area
B1161/84
Open in curtain shield squib RH circuit
Curtain shield squib RH malfunction
Airbag sensor assembly malfunctionCurtain shield airbag assembly RH (Curtain shield squib RH)
Airbag sensor assembly
Floor No. 2 wire
HINT:
DTC B1161/84 is indicated only for the vehicle equipped with the side airbag.
WIRING DIAGRAM
See page DI-856.
INSPECTION PROCEDURE
1 Prepare for inspection (See step 1 on page DI-923).
2 Check floor No. 2 wire (curtain shield squib RH circuit).
CHECK:
Measure the resistance between ICR+ and ICR- of the floor
No. 2 wire connector on the curtain shield airbag assembly RH
(curtain shield squib RH) side.
OK:
Resistance: Below 1 W
NG Repair or replace floor No. 2 wire.
OK
DI6PC-21
Page 1642 of 3115
AB0119
H10600 H01020H11645H16278H21143
Curtain Shield
Squib RHAirbag
Sensor
Assembly
ICR+
ICR-
DTC B1161/84
" u
ON
DLC3
CG TCFloor No. 2 Wire
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-861
1054 Author: Date:
2004 LAND CRUISER (RM1071U)
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Using a service wire, connect ICR+ and ICR- of the floor
No. 2 wire connector on the curtain shield airbag assem-
bly RH (curtain shield squib RH) side.
(c) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B1161/84 is not output.
HINT:
Codes other than code B1161/84 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK
Page 1643 of 3115
H10600 H01021AB0119H11645H13059
"u
Curtain Shield
Squib RHAirbag
Sensor
Assembly
DTC B1161/84 ON
DLC3
CGTC
DI-862
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1055 Author: Date:
2004 LAND CRUISER (RM1071U)
4 Check curtain shield squib RH.
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect the negative (-) terminal cable from the bat-
tery, and wait at least for 90 seconds.
(c) Connect the curtain shield airbag assembly RH (curtain
shield squib RH) connector.
(d) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B1161/84 is not output.
HINT:
Codes other than code B1161/84 may be output at this time, but
they are not relevant to this check.
NG Replace curtain shield airbag assembly RH
(curtain shield squib RH).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check.
Page 1644 of 3115
H01019H16276H16618
Airbag
Sensor
Assembly Curtain Shield
Squib RH
(+)ICR+
(-)
Floor No. 2 Wire
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-863
1056 Author: Date:
2004 LAND CRUISER (RM1071U)
DTC B1162/81 Short in Curtain Shield Squib RH
Circuit (to Ground)
CIRCUIT DESCRIPTION
The curtain shield squib RH circuit consists of the airbag sensor assembly and the curtain shield airbag as-
sembly RH.
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS-3.
DTC B1162/81 is recorded when ground short is detected in the curtain shield squib RH circuit.
DTC No.DTC Detecting ConditionTrouble Area
B1162/81
Short in curtain shield squib RH circuit (to ground)
Curtain shield squib RH malfunction
Airbag sensor assembly malfunctionCurtain shield airbag assembly RH (Curtain shield squib RH)
Airbag sensor assembly
Floor No. 2 wire
HINT:
DTC B1162/81 is indicated only for the vehicle equipped with the side airbag.
WIRING DIAGRAM
See page DI-856.
INSPECTION PROCEDURE
1 Prepare for inspection (See step 1 on page DI-923).
2 Check floor No. 2 wire(curtain shield squib RH circuit).
CHECK:
Measure the resistance between the body ground and ICR+ of
the floor No. 2 wire connector on the curtain shield airbag as-
sembly RH (curtain shield squib RH) side.
OK:
Resistance: 1 MW or Higher
NG Repair or replace floor No. 2 wire.
OK
DI6PD-22
Page 1645 of 3115
AB0119
H10600 H01020H11642H16278H21144
Airbag
Sensor
Assembly
ICR-
DLC3
" u
ICR+
TC CGON
DTC B1162/81 Curtain Shield
Squib RHFloor No. 2 Wire
DI-864
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1057 Author: Date:
2004 LAND CRUISER (RM1071U)
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Using a service wire, connect ICR+ and ICR- of the floor
No. 2 wire connector on the curtain shield airbag assem-
bly RH (curtain shield squib RH) side.
(c) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B1162/81 is not output.
HINT:
Codes other than code B1162/81 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK
Page 1646 of 3115
H11642H10600 H01021AB0119H13061
"u
DTC B1162/81
TC CGON Airbag
Sensor
Assembly Curtain Shield
Squib RH
DLC3
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-865
1058 Author: Date:
2004 LAND CRUISER (RM1071U)
4 Check curtain shield squib RH.
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect the negative (-) terminal cable from the bat-
tery, and wait at least for 90 seconds.
(c) Connect the curtain shield airbag assembly RH (curtain
shield squib RH) connector.
(d) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B1162/81 is not output.
HINT:
Codes other than code B1162/81 may be output at this time, but
they are not relevant to this check.
NG Replace curtain shield airbag assembly RH
(curtain shield squib RH).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check. If the malfunctioning part can not be
detected by the simulation method, replace all SRS components including the wire harness.
Page 1647 of 3115
H01019AB0119H16277H16621
Curtain Shield
Squib RHAirbag
Sensor
Assembly
(-) (+)ICR+
ON
Floor No. 2 Wire
DI-866
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1059 Author: Date:
2004 LAND CRUISER (RM1071U)
DTC B1163/82 Short in Curtain Shield Squib RH
Circuit (to B+)
CIRCUIT DESCRIPTION
The curtain shield squib RH circuit consists of the airbag sensor assembly and the curtain shield airbag as-
sembly RH.
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS-3.
DTC B1163/82 is recorded when a B+ short is detected in the curtain shield squib RH circuit.
DTC No.DTC Detecting ConditionTrouble Area
B1163/82
Short in curtain shield squib RH circuit (to B+)
Curtain shield squib RH malfunction
Airbag sensor assembly malfunctionCurtain shield airbag assembly RH (Curtain shield squib RH)
Airbag sensor assembly
Floor No. 2 wire
HINT:
DTC B1163/82 is indicated only for the vehicle equipped with the side airbag.
WIRING DIAGRAM
See page DI-856.
INSPECTION PROCEDURE
1 Prepare for inspection (See step 1 on page DI-923).
2 Check floor No. 2 wire (curtain shield squib RH circuit).
PREPARATION:
Connect the negative (-) terminal cable to the battery, and wait
at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON.
(b) Measure the voltage between the body ground and ICR+
of the floor No. 2 wire connector on the curtain shield air-
bag assembly RH (curtain shield squib RH) side.
OK:
Voltage: Below 1 V
NG Repair or replace floor No. 2 wire.
OK
DI6PE-23
Page 1648 of 3115
H10600AB0119 H01020H11643H16278H21145
"u
DLC3 DTC B1163/82 Curtain Shield
Squib RHAirbag
Sensor
Assembly
ICR-ICR+
ON
CG
TCFloor No. 2 Wire
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-867
1060 Author: Date:
2004 LAND CRUISER (RM1071U)
3 Check airbag sensor assembly.
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect the negative (-) terminal cable from the bat-
tery, and wait at least for 90 seconds.
(c) Connect the connector to the airbag sensor assembly.
(d) Using a service wire, connect ICR+ and ICR- of the floor
No. 2 wire connector on the curtain shield airbag assem-
bly RH (curtain shield squib RH) side.
(e) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B1163/82 is not output.
HINT:
Codes other than code B1163/82 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK
Page 1649 of 3115
AB0119H10600 H01021H11643H13063
"u
Airbag
Sensor
Assembly Curtain Shield
Squib RH
ON
CGDTC B1163/82 DLC3
TC
DI-868
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1061 Author: Date:
2004 LAND CRUISER (RM1071U)
4 Check curtain shield squib RH.
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect the negative (-) terminal cable from the bat-
tery, and wait at least for 90 seconds.
(c) Connect the curtain shield airbag assembly RH (curtain
shield squib RH) connector.
(d) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B1163/82 is not output.
HINT:
Codes other than code B1163/82 may be output at this time, but
they are not relevant to this check.
NG Replace curtain shield airbag assembly RH
(curtain shield squib RH).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check. If the malfunctioning part can not be
detected by the simulation method, replace all SRS components including the wire harness.
Page 1650 of 3115
H01454
C29
Curtain Shield Squib LHAirbag Sensor Assembly
ICL+
ICL- Y-V
Y-O 1
2109
C25
(*1)
(*1)C25
*1: w/ Side Airbag
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-869
1062 Author: Date:
2004 LAND CRUISER (RM1071U)
DTC B1165/87 Short in Curtain Shield Squib LH
Circuit
CIRCUIT DESCRIPTION
The curtain shield squib LH circuit consists of the airbag sensor assembly and the curtain shield airbag as-
sembly LH.
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS-3.
DTC B1165/87 is recorded when a short is detected in the curtain shield squib LH circuit.
DTC No.DTC Detecting ConditionTrouble Area
B1165/87
Short in curtain shield squib LH circuit
Curtain shield squib LH malfunction
Airbag sensor assembly malfunctionCurtain shield airbag assembly LH (Curtain shield squib LH)
Airbag sensor assembly
Floor No. 1 wire
HINT:
DTC B1165/87 is indicated only for the vehicle equipped with the side airbag.
WIRING DIAGRAM
DI6PF-35
