Page 1821 of 3115
EM0L7-05
A04874A04885A05180
Sized MarkLH
Piston
RH
Piston
Sized Mark
P20665
SST
P20666
Oil
Hole EM-104
- ENGINE MECHANICALCYLINDER BLOCK
1677 Author: Date:
2004 LAND CRUISER (RM1071U)
REPLACEMENT
1. REPLACE OVERSIZED (O/S) PISTONS FOR CYL-
INDER BORING
HINT:
Bore all the 8 cylinders to the oversized piston outside di-
ameter.
Replace all the piston rings with the ones to match the
oversized pistons.
(a) Keep 8 new O/S pistons.
O/S 0.50 piston diameter:
94.402 - 94.430 mm (3.7166 - 3.7177 in.)
HINT:
The shape of the piston varies for the LH and RH banks. The
LH piston is marked with ºLHº and º2Lº, the RH piston with ºRHº
and º2Rº.
(b) Using a micrometer, measure the piston diameter at right
angles to the piston pin center line, 30.75 mm (1.2106 in.)
from the piston head.
(c) Calculate the amount for each cylinder to be rebored as
follows:
Size to be rebored = P + C - H
P = Piston diameter
C = Piston clearance:
0.090 - 0.111 mm (0.0035 - 0.0044 in.)
H = Allowance for honing: 0.02 mm (0.0008 in.) or less
(d) Bore and hone the cylinders to calculated dimensions.
Maximum honing: 0.02 mm (0.0008 in.)
NOTICE:
Excess honing will destroy the finished roundness.
2. REPLACE CONNECTING ROD BUSHINGS
(a) Using SST and a press, press out the bushing.
SST 09222-30010
(b) Align the oil holes of a new bushing and the connecting
rod.
(c) Using SST and a press, press in the bushing.
SST 09222-30010
Page 1822 of 3115
P20667
P20668
A04865
A04866
SST
A04863Cut Position
- ENGINE MECHANICALCYLINDER BLOCK
EM-105
1678 Author: Date:
2004 LAND CRUISER (RM1071U)
(d) Using a pin hole grinder, hone the bushing to obtain the
standard specified clearance (See page EM-97) be-
tween the bushing and piston pin.
(e) Check the piston pin fit at normal room temperature. Coat
the piston pin with engine oil, and push it into the connect-
ing rod with your thumb.
3. REPLACE CRANKSHAFT FRONT OIL SEAL
HINT:
There are 2 methods ((a) and (b)) to replace the oil seal.
(a) If the oil pump is removed from the cylinder block:
(1) Using a screwdriver, pry out the oil seal.
(2) Using SST and a hammer, tap in a new oil seal until
its surface is flush with the oil pump body edge.
SST 09316-6001 1 (09316-00011)
(3) Apply MP grease to the oil seal lip.
(b) If the oil pump is installed to the cylinder block:
(1) Using a knife, cut off the oil seal lip.
(2) Using a screwdriver, pry out the oil seal.
NOTICE:
Be careful not to damage the crankshaft. Tape up the
screwdriver tip.
Page 1823 of 3115
A04864
SST
A04868
A04867
SST
A04858Cut Position
A04859
SST
EM-106
- ENGINE MECHANICALCYLINDER BLOCK
1679 Author: Date:
2004 LAND CRUISER (RM1071U)
(3) Apply MP grease to a new oil seal lip.
(4) Using SST and a hammer, tap in the oil seal until its
surface is flush with the oil pump body edge.
SST 09316-6001 1 (09316-00011)
4. REPLACE CRANKSHAFT REAR OIL SEAL
HINT:
There are 2 methods ((a) and (b)) to replace the oil seal.
(a) If the rear oil seal retainer is removed from the cylinder
block:
(1) Using a screwdriver and hammer, tap out the oil
seal.
(2) Using SST and a hammer, tap in a new oil seal until
its surface is flush with the rear oil seal retainer
edge.
SST 09223-56010
(3) Apply MP grease to the oil seal lip.
(b) If the rear oil seal retainer is installed to the cylinder block:
(1) Using a knife, cut off the oil seal lip.
(2) Using a screwdriver, pry out the oil seal.
NOTICE:
Be careful not to damage the crankshaft. Tape up the
screwdriver tip.
(3) Apply MP grease to a new oil seal lip.
(4) Using SST and a hammer, tap in the oil seal until its
surface is flush with the rear oil seal retainer edge.
SST 09223-56010
Page 1824 of 3115
EM1V7-01
A09750
P/S Air HoseRadiator
Reservoir Tank
Intake Air
Connector
Radiator Assembly
EVAP HoseV-Bank Cover
Engine Under Cover No.1
N´m (kgf´cm, ft´lbf) : Specified torque Generator
Drive Belt
A/C CompressorA/C Compressor
Connector
A/T Oil Cooler Hose
Fan w/ Fluid
Coupling
Fan Pulley
49 (500, 36)
5.0 (50, 43 in.´lbf)
18 (185, 13)
Air Hose
x 8Fan Shroud Fuel Return
Hose
20 (200, 15)
A/T Oil Cooler
Hose
A/C Discharge
Tube
Clamp
BracketWireClamp
Clamp
Lower Radiator Hose
Bracket
EM-28
- ENGINE MECHANICALCYLINDER HEAD
1601 Author: Date:
2004 LAND CRUISER (RM1071U)
CYLINDER HEAD
COMPONENTS
Page 1825 of 3115
A19471
Gasket
Gasket20 (200, 14)
40 (400, 30)
Heated Oxygen Sensor
(Bank 2 Sensor 1)
RH Front Exhaust Pipe Gasket
LH Front Exhaust Pipe
Heated Oxygen Sensor
(Bank 1 Sensor 1)
20 (200, 14)
Gasket
Gasket
Gasket
Non-reusable part
N´m (kgf´cm, ft´lbf) : Specified torquePS Pump
Oil Dipstick and
Guide for A/T
62 (632, 46)
40 (400, 30)
62 (632, 46)
62 (632, 46)
- ENGINE MECHANICALCYLINDER HEAD
EM-29
1602 Author: Date:
2004 LAND CRUISER (RM1071U)
Page 1826 of 3115
A04460
RH No. 3 Timing Belt Cover
No. 2 Timing
Belt Cover
LH No. 3 Timing Belt Cover Drive Belt Idler Pulley
Camshaft Position
Sensor ConnectorCover Plate
Engine Wire
16 (160, 12)
7.5 (80, 16 in.´lbf)
N´m (kgf´cm, ft´lbf) : Specified torque
Oil Cooler PipeWire Grommet
39 (400, 29)
7.5 (80, 66 in.´lbf)
Camshaft Position Sensor
A04327
Timing BeltRH Camshaft Timing Pulley
LH Camshaft Timing Belt Pulley
Timing Belt Tensioner
Fan BracketDust Boot
108 (1,100, 80)
245 (2,500, 181)
16 (160, 12)
32 (330, 24)26 (270, 19)N´m (kgf´cm, ft´lbf) : Specified torque
EM-30
- ENGINE MECHANICALCYLINDER HEAD
1603 Author: Date:
2004 LAND CRUISER (RM1071U)
Page 1827 of 3115
A19470
EVAP Hose EVAP PipeRear Water
Bypass Joint
Engine Wire
Gasket
Injection Connector
Fuel Inlet Hose
Ignition Coil
Connector
Ignition Coil Throttle Control
Connector
Water Bypass
Hose
ECT
Sensor Connector
Front Water
Bypass Joint
Water Inlet and Inlet
Housing AssemblyWater Bypass Hose Water
Sender Gauge
LH No.1 Timing Belt Rear Plate
Non-reusable partEngine WireEngine Wire
Gasket
O-Ring
RH No.1 Timing
Belt Rear PlateEVAP Hose
Engine Wire
GasketHeater
Hose V-Bank Cover
Bracket
V-Bank Cover
BracketPS Hose
VSV Connector
for EVAP Fuel Return Hose
V-Bank Cover
Bracket
Engine Wire
EVAP VSV Hose
Heater Hose
Wire Bracket
- ENGINE MECHANICALCYLINDER HEAD
EM-31
1604 Author: Date:
2004 LAND CRUISER (RM1071U)
Page 1828 of 3115
A17674
A19480
Upper Intake ManifoldVSV for EVAP
18 (185, 13)
Gasket
Fuel
Pressure
Pulsation
Damper
Upper
Gasket
* 33 (340, 24)
39 (400, 29)
Lower Gasket Spacer
Spacer RH Delivery Pipe
LH Delivery Pipe
N´m (kgf´cm, ft´lbf) : Specified torque
Non-reusable part
* For use with SST Grommet
Injector O-Ring
Insulator
Fuel Return Pipe
Fuel Return
Hose
Front Fuel Pipe Gasket
Gasket
Throttle Body Assembly
39 (400, 29)
39 (400, 29)
O-Ring Fuel Pressure Regulator
Spacer Gasket
Lower
Intake
Manifold
Vacuum Hose
21 (214, 15)
21 (214, 15)
7.5 (80, 66 in.´lbf)
EM-32
- ENGINE MECHANICALCYLINDER HEAD
1605 Author: Date:
2004 LAND CRUISER (RM1071U)
Page 1829 of 3115
A05561
RH Cylinder Head CoverSpark Plug
LH Cylinder Head
Cover
Gasket
RH Intake Camshaft
RH Exhaust Camshaft Bearing Cap
Bearing CapOil Feed
Pipe
Camshaft Sub Gear Engine Hanger
Heated Oxygen Sensor
(Bank 1 Sensor 1) Connector RH Cylinder
Head Gasket Engine Wire Bracket
7.5 (77, 66 in.´lbf)
16 (160,12)
Heated Oxygen Sensor
(Bank 2 Sensor 1)
Connector RH Cylinder Head and
Exhaust Manifold AssemblyCamshaft
Housing
Plug Snap Ring
Wave WasherBearing Cap
Oil Seal Oil Seal
Non-reusable part
N´m (kgf´cm, ft´lbf) : Specified torque
See page EM-59
1st 32 (326, 24)
2nd Turn 90°
3rd Turn 90°
Semi-Circular
Plug Camshaft Sub GearCamshaft Gear Spring Spark Plug
Tube Gasket
Gasket
LH Intake
Camshaft
LH Exhaust
Camshaft
Camshaft Gear SpringSnap Ring
Wave Washer
Camshaft Housing Plug
Semi-Circular Plug
Engine Wire
Bracket
Engine
Hanger
LH Cylinder
Head Gasket
O-Ring
Oil Dipstick and Guide
for Engine
LH Cylinder Head and
Exhaust Manifold
Assembly
Engine Wire
Protector
7.5 (77, 66 in.´lbf)
- ENGINE MECHANICALCYLINDER HEAD
EM-33
1606 Author: Date:
2004 LAND CRUISER (RM1071U)
Page 1830 of 3115
A05527
RH Cylinder Head
Gasket
Valve Lifter
RH Exhaust Manifold
Heat Insulator Oil Seal Spring SeatValve SpringSpring RetainerAdjust Shim
Keeper
Non-reusable part
N´m (kgf´cm, ft´lbf) : Specified torque Valve Guide Bushing
Valve
Gasket
Heat Insulator
LH Exhaust Manifold
RH Cylinder Head
44 (450, 32)
7.5 (77, 66 in.´lbf)
7.5 (77, 66 in.´lbf)
EM-34
- ENGINE MECHANICALCYLINDER HEAD
1607 Author: Date:
2004 LAND CRUISER (RM1071U)
