A02856Service Bolt
A02857
Align
A04470
4
6
108
1
16
12
18 2
19 20 2221
15
3
5
97
14
1713
11
A02859
A02850
SST
Service Bolt
Turn EM-40
- ENGINE MECHANICALCYLINDER HEAD
1613 Author: Date:
2004 LAND CRUISER (RM1071U)
(c) Remove the LH camshafts.
(1) Move a service bolt of the sub-gear upward by turn-
ing the hexagon shaped port of the exhaust cam-
shaft with a wrench.
(2) Secure the sub-gear to the main gear with a service
bolt.
Recommended service bolt:
Thread diameter6 mm
Thread pitch1.0 mm
Bolt length16 - 20 mm
HINT:
When removing the camshaft, make sure that the torsional
spring force of the sub-gear is eliminated by the above opera-
tion.
(3) Align the timing mark (2 dot marks) of the camshaft
drive gear by turning the hexagon wrench head por-
tion of the exhaust camshaft with a wrench.
(4) Evenly loosen and remove the 22 bearing cap bolts
a little at a time for several times as in the sequence
shown.
(5) Remove the oil feed pipe, 9 bearing caps, and cam-
shafts.
HINT:
Arrange the bearing caps in correct order for installation.
22. DISASSEMBLE EXHAUST CAMSHAFTS
(a) Mount the hexagon wrench head portion of the camshaft
in a vise.
NOTICE:
Be careful not to damage the camshaft.
(b) Using SST, turn the sub-gear clockwise, and remove the
service bolt.
SST 09960-10010 (09962-01000, 09963-00500)
Page 1862 of 3115
A02861
A04471
Oil Seal
A04472
RH Cylinder Head
LH Cylinder HeadFront
19
108
76
5
4
32
1
351082
4697
- ENGINE MECHANICALCYLINDER HEAD
EM-41
1614 Author: Date:
2004 LAND CRUISER (RM1071U)
(c) Using snap ring pliers, remove the snap ring.
(d) Remove the wave washer.
(e) Remove the camshaft sub-gear.
(f) Remove the camshaft gear spring.
HINT:
Arrange the camshaft sub-gears and gear spring (RH and LH
sides).
NOTICE:
Be careful not to damage the camshaft timing tube.
23. REMOVE OIL SEAL FROM INTAKE CAMSHAFT
24. REMOVE SPARK PLUGS
25. REMOVE CYLINDER HEAD AND EXHAUST MAN-
IFOLD ASSEMBLIES
(a) Uniformly loosen the 10 cylinder head bolts on one side
of each cylinder head in a little at a time for several times
as in the sequence shown, then do the other side as
shown. Remove the 20 cylinder head bolts and the plate
washers.
NOTICE:
Removing the bolts in incorrect order could cause a
warp or cracks in the cylinder head.
Page 1863 of 3115
A04473
RH Cylinder Head
LH Cylinder HeadA
A
A02871
A05498
EM-42
- ENGINE MECHANICALCYLINDER HEAD
1615 Author: Date:
2004 LAND CRUISER (RM1071U)
Do not drop the plate washer of the cylinder head bolt
into A area in the illustration. It will fall down to the oil
pan through the cylinder head and the cylinder block.
(b) Lift the cylinder head from the dowels on the cylinder
block, and place the 2 cylinder heads on wooden blocks.
HINT:
After lifting off the cylinder head, pry off the cylinder head and
the cylinder block with a screwdriver.
NOTICE:
Be careful not to damage the contact surfaces of the
cylinder head and the cylinder block.
The cylinder head should not be tilted so to secure the
valve lifter. If the cylinder head is tilted, remove the
valve lifter and check that the adjusting shim is set
correctly.
26. REMOVE RH EXHAUST MANIFOLD FROM CYLINDER
HEAD
(a) Remove the 4 bolts and the heat insulator.
(b) Remove the 8 nuts, the exhaust manifold and the gasket.
Page 1864 of 3115
A05518
- ENGINE MECHANICALCYLINDER HEAD
EM-43
1616 Author: Date:
2004 LAND CRUISER (RM1071U)
27. REMOVE LH EXHAUST MANIFOLD FROM CYLINDER
HEAD
(a) Remove the 4 bolts and the heat insulator.
(b) Remove the 8 nuts, the exhaust manifold and the gasket.
Page 1865 of 3115
EM0L3-07
A03195
80-100°C
A05708
SST
A03197
Use STD Bushing size
10.285 - 10.306 Bushing bore diameterBoth intake and exhaust(0.4049 - 0.4057)
Use O/S STD mm (in.)
(0.4069 - 0.4077)10.335 - 10.356
P21844
34.5 mm
(1.358 in.)
40.5 mm
(1.594 in.) Intake Exhaust
- ENGINE MECHANICALCYLINDER HEAD
EM-55
1628 Author: Date:
2004 LAND CRUISER (RM1071U)
REPLACEMENT
1. REPLACE VALVE GUIDE BUSHINGS
(a) Gradually heat the cylinder head to 80 - 100°C (176 -
212°F).
(b) Using SST and a hammer, tap out the guide bushing.
SST 09201-10000 (09201-01060),
09950-70010 (09951-07100)
(c) Using a caliper gauge, measure the bushing bore diame-
ter of the cylinder head.
(d) Select a new guide bushing (STD or O/S 0.05).
If the bushing bore diameter of the cylinder head is greater than
10.306 mm (0.4057 in.), machine the bushing bore to the fol-
lowing dimension:
10.335 - 10.356 mm (0.4069 - 0.4077 in.)
If the bushing bore diameter of the cylinder head is greater than
10.356 mm (0.4077 in.), replace the cylinder head.
HINT:
The intake bushing and the exhaust bushing differ in their sizes.
Page 1866 of 3115
A05709
SST
A03199A03200
Sharp 5.5 mm Reamer
A04107
Pry
ClawBend
A04108
SST
SST Return
ClawDownward
EM-56
- ENGINE MECHANICALCYLINDER HEAD
1629 Author: Date:
2004 LAND CRUISER (RM1071U)
(e) Gradually heat the cylinder head to 80 - 100°C (176 -
212°F).
(f) Using SST and a hammer, tap in a new guide bushing to
the specified protrusion height.
Protrusion height:
Intake
9.2 - 9.8 mm (0.362 - 0.386 in.)
Exhaust
8.2 - 8.8 mm (0.323 - 0.346 in.)
SST 09201-10000 (09201-01060),
09950-70010 (09951-07100)
(g) Using a sharp 5.5 mm reamer, ream the guide bushing
to obtain the standard specified clearance (See page
EM-45) between the guide bushing and the valve stem.
2. REPLACE SPARK PLUG TUBE GASKETS
(a) Bend the 4 ventilation case claws installed on the cylinder
head cover to an angle of 90° or more.
(b) Using a screwdriver, pry out the gasket.
NOTICE:
Be careful not to damage the cylinder head cover. Tape up
the screwdriver tip.
(c) Using SST and a hammer, tap in a new gasket until its sur-
face is flush with the upper edge of the cylinder head cov-
er.
SST 09950-60010 (09551-00240, 09951-00440,
09952-06010) 09950-70010 (09951-07100)
NOTICE:
Be careful of the installation direction.
(d) Apply a light coat of MP grease to the gasket lip.
(e) Put the 4 ventilation case claws back to its original posi-
tion.
Page 1867 of 3115
EM0LB-09
A19473
Air Cleaner
Cap and
Intake Air
Connector
Assembly
Engine Under Cover V-Bank Cover
MAF Meter Connector
PS Air Hose
BatteryAir Inlet Hose
for EVAPHood
Windshield
Washer Hose
Battery Tray
Engine Under Cover
Battery
Negative (-)
Terminal
Cable Battery
Positive (+)
Terminal
CableBattery
Hold-Down
Clamp
PCV Hose
Vacuum Sensing
HoseFuel Return
Hose
- ENGINE MECHANICALENGINE UNIT
EM-71
1644 Author: Date:
2004 LAND CRUISER (RM1071U)
ENGINE UNIT
COMPONENTS
Page 1868 of 3115
A07248
A/C Discharge Tube
ClampRadiator Reservoir Hose
Radiator
Reservoir
Grommet
Fan Shroud
A/T Oil
Cooler Hose
Lower
Radiator
Hose
Fan Pulley RadiatorSupport CollarBracket
Clamp
Generator Drive Belt
Wire
Upper
Radiator
Hose Bracket
Clamp
Fan w/ Fluid Coupling Assembly
Charge Valve
EM-72
- ENGINE MECHANICALENGINE UNIT
1645 Author: Date:
2004 LAND CRUISER (RM1071U)
Page 1869 of 3115
A19474
PS Air Hose Engine Wire
Grommet
PS Air HoseGenerator
Wire
Batter Positive (+)
Terminal CableGround Strap Connector
Fuel Return Hose Heater Hose Engine Wire Clamp
Fuel Inlet Hose
Clamp
Battery
Negative (-)
Cable
Clamp
Hose
Clamp
Heater Hose
Generator
Connector
Engine Wire Clamp
A07249
Wire Harness Connector
ECM Connector
Grove Compartment Door
Lower No.2 PanelECM
A/B Connector
A/B Connector
Cover
- ENGINE MECHANICALENGINE UNIT
EM-73
1646 Author: Date:
2004 LAND CRUISER (RM1071U)
Page 1870 of 3115
A19475
Transfer Shift Lever Knob
Upper Console Panel
Connector Connector
Shift Lever
Assembly
Transfer Shift Lever Boot
Transfer Shift Lever Assembly
Wave
Washer Bushing
Transmission Control Rod Transfer Shift Lever Rod Gasket
Connector
Clip
x 6
Plate
Washer
N´m (kgf´cm, ft´lbf) : Specified torque
8.3 (86, 73) in.´lbf
13 (130, 9) Non-reusable part EM-74
- ENGINE MECHANICALENGINE UNIT
1647 Author: Date:
2004 LAND CRUISER (RM1071U)
