2004 LAND CRUISER (EWD548U)
85 G
Connector Joining Wire Harness and Wire Harness
CodeJoining Wire Harness and Wire Harness (Connector Location)
Ia1Dash Wire and Dash Wire (Behind the Combination Meter)
Ib1
Ib2Dash Wire and Dash Wire (Behind the Combination Meter)
Ib3
()
Ic2Dash Wire and Dash Wire (Behind the Center Panel)
Id1
Id2Dash Wire and Dash Wire (Instrument Panel Center)Id3Dash Wire and Dash Wire (Instrument Panel Center)
Id4
Ie1Dash Wire and Dash Wire (Behind the Glove Box)
If1Engine Wire and Engine Wire (Behind the Glove Box)
Ig1Dash Wire and Floor No.2 Wire (Right Side of Front Console)
Ih1Dash Wire and Dash Wire (Center Side of Front Console)

2004 LAND CRUISER (EWD548U)
86G ELECTRICAL WIRING ROUTING
: Location of Connector Joining Wire Harness and Wire Harness
: Location of Ground Points

2004 LAND CRUISER (EWD548U)
87 G
Connector Joining Wire Harness and Wire Harness
CodeJoining Wire Harness and Wire Harness (Connector Location)
BA3Rear Door LH Wire and Floor No 1 Wire (Left Side of Center Pillar)BA4Rear Door LH Wire and Floor No.1 Wire (Left Side of Center Pillar)
BB1Floor No.1 Wire and Fuel Tank Wire (Near the Fuel Tank)
BC3Rear Door RH Wire and Floor No 2 Wire (Right Side of Center Pillar)BC4Rear Door RH Wire and Floor No.2 Wire (Right Side of Center Pillar)
BD2
BD3Floor No.3 Wire and Floor No.1 Wire (Left Rear Side Quarter Panel)
BD4
(Q)
BF2Frame Wire and Floor No.3 Wire (Left Side of Rear Floor Crossmember)
BH1Pillar No 1 Wire and Back Door Upper Wire (Left Side of Back Door)BH2Pillar No.1 Wire and Back Door Upper Wire (Left Side of Back Door)
BI1Roof No.2 Wire and Floor No.2 Wire (Right Side Rear Quarter Panel)

2004 LAND CRUISER (EWD548U)
88G ELECTRICAL WIRING ROUTING
: Location of Connector Joining Wire Harness and Wire Harness
: Location of Splice Points

2004 LAND CRUISER (EWD548U)
89 G
Connector Joining Wire Harness and Wire Harness
CodeJoining Wire Harness and Wire Harness (Connector Location)
BL1
BL3Floor No 2 Wire and Floor No 3 Wire (Right Side of Rear Floor Crossmember)BL4Floor No.2 Wire and Floor No.3 Wire (Right Side of Rear Floor Crossmember)
BL5
BP3Pillar No 1 Wire and Floor No 1 Wire (Left Rear Side Quarter Panel)BP4Pillar No.1 Wire and Floor No.1 Wire (Left Rear Side Quarter Panel)
BQ2Back Door Lower Wire and Floor No.1 Wire (Left Rear Side Quarter Panel)
BR1Roof No.3 Wire and Roof No.1 Wire (Front Side of Roof)
BS1Door Lock LH Sub Wire and Front Door LH Wire (Front Door LH)
BT1Door Lock RH Sub Wire and Front Door RH Wire (Front Door RH)
BU1Floor No.1 Wire and Floor No.1 Wire (Near the Left Rear Suspension Support)
BV1Floor No.2 Wire and Floor No.2 Wire (Near the Right Rear Suspension Support)
BW1Floor No.2 Wire and A/C Sub Wire (Right Side Rear Quarter Panel)
BX1Frame No.4 Wire and Floor No.3 Wire (Left Side of Rear Floor Crossmember)
BY1Pillar No.1 Wire and Floor No.3 Wire (Left Rear Side Quarter Panel)
BZ1Floor No.3 Wire and Floor No.2 Wire (Right Side of Rear Floor Crossmember)

2004 LAND CRUISER (EWD548U)
90G ELECTRICAL WIRING ROUTING
: Location of Connector Joining Wire Harness and Wire Harness
: Location of Splice Points

2004 LAND CRUISER (EWD548U)
91 G
Connector Joining Wire Harness and Wire Harness
123
451 2 3
4 51 2 4
5 6 7 8 103
9 12
534
6789101221
123
451 2 3
4 51 2 4
5 6 7 8 103
9 12
534
678910
BM2Gray
BO2Gray
BM3BN1
BO3
CodeJoining Wire Harness and Wire Harness (Connector Location)
BM2Floor No 1 Wire and Front Seat LH Wire (Front Side Under the Driver's Seat)BM3Floor No.1 Wire and Front Seat LH Wire (Front Side Under the Driver's Seat)
BN1Seat No.2 Wire and Front Seat LH Wire (Rear Side Under the Driver's Seat)
BO2Floor No 2 Wire and Front Seat RH Wire (Front Side Under the Front Passenger's Seat)BO3Floor No.2 Wire and Front Seat RH Wire (Front Side Under the Front Passenger's Seat)

2004 LAND CRUISER (EWD548U)
92HINT
WIRE COLOR AND TERMINAL NUMBER
In some parts of the instrumental panel wiring harness, the
same wire color (i.e. SB: Sky Blue) is used for all the wiring
to a specific connector.
In order to identify the wiring, the terminal number is printed
on the wiring.
Install the wiring to the connector position with the same
terminal number.
Some early production Vehicles may not have these terminal
numbers printed.

2004 LAND CRUISER (EWD548U)
68G ELECTRICAL WIRING ROUTING
Position of Parts in Engine Compartment
A 1 A/C Ambient Temp. Sensor
A 4 Pressure SW
A 5 A/C Lock Sensor
A/C Magnetic Clutch
A 12 ABS Speed Sensor Front LH
A 13 ABS Speed Sensor Front RH
A 15 Airbag Sensor Front LH
A 16 Airbag Sensor Front RH
A 17 Auto Antenna Motor
A 37 ABS & BA & TRAC & VSC Actuator
A 38 ABS & BA & TRAC & VSC Actuator
A 39 ABS & BA & TRAC & VSC Actuator
A 40 ABS & BA & TRAC & VSC Actuator
C 1 Camshaft Position Sensor
C 2 Center Diff. Lock Control Motor
C 3 Crankshaft Position Sensor
D 1 Data Link Connector 1
D 2 Daytime Running Light Relay No.3
D 3 Daytime Running Light Relay No.3
D 4 Detection SW (Center Diff. Lock)
D 5 Detection SW (Transfer L Position)
D 6 Detection SW (Transfer Neutral Position)E 1 Electronically Controlled Transmission Solenoid
E 2 Engine Coolant Temp. Sensor
E 3 Engine Hood Courtesy SW
F 1 Front Fog Light LH
F 2 Front Fog Light RH
F 3 Front Turn Signal Light LH
Side Marker Light LH
F 4 Front Turn Signal Light RH
Side Marker Light RH
F 5 Front Wiper Motor
F 14 Fuel Pump Resistor
F 15 Fusible Link Block
F 16 Fusible Link Block
F 17 Fusible Link Block
F 18 Fusible Link Block
F 19 Fusible Link Block
G 1 Generator
G 2 Generator

2004 LAND CRUISER (EWD548U)
69 G
Position of Parts in Engine Compartment
H 1 Headlight LH (High)
H 2 Headlight LH (Low)
H 3 Headlight RH (High)
H 4 Headlight RH (Low)
H 5 Heated Oxygen Sensor (Bank 1 Sensor 1)
H 6 Heated Oxygen Sensor (Bank 1 Sensor 2)
H 7 Heated Oxygen Sensor (Bank 2 Sensor 1)
H 8 Heated Oxygen Sensor (Bank 2 Sensor 2)
H 9 Horn LH
H 10 Horn RH
I 1 Ignition Coil and Igniter No.1
I 2 Ignition Coil and Igniter No.2
I 3 Ignition Coil and Igniter No.3
I 4 Ignition Coil and Igniter No.4
I 5 Ignition Coil and Igniter No.5
I 6 Ignition Coil and Igniter No.6
I 7 Ignition Coil and Igniter No.7
I 8 Ignition Coil and Igniter No.8
I 9 Injector No.1
I 10 Injector No.2
I 11 Injector No.3
I 12 Injector No.4
I 13 Injector No.5
I 14 Injector No.6
I 15 Injector No.7
I 16 Injector No.8K 1 Knock Sensor 1
K 2 Knock Sensor 2
M 1 Mass Air Flow Meter
M 4 Master Cylinder Pressure Sensor
N 1 Noise Filter (Ignition)
O 2 Oil Pressure Sender
P 1 Park/Neutral Position SW
P 2 Parking Light LH
P 3 Parking Light RH
S 1 Starter
S 2 Starter
T 1 Theft Deterrent Horn
T 16 Throttle Control Motor and Sensor
T 17 Turbine Speed Sensor
V 2 Vehicle Speed Sensor (Combination Meter)
V 3 Vehicle Speed Sensor
(Electronically Controlled Transmission)
V 4 VSV (EVAP)
V 9 VSV (Canister Closed Valve)
W 1 Washer Motor
