TOYOTA LAND CRUISER 1998 Factory Repair Manual

MA0055
MA02T-02
- MAINTENANCEBRAKE
MA-7
55 Author
: Date
:
2004 LAND CRUISER (RM1071U)
BRAKE
INSPECTION
1. INSPECT BRAKE LINE PIPES AND HOSES
HINT:
Check in a well lighted area. Check the entire circumference
and length of the brake hoses using a mirror as required. Turn
the front wheels fully right or left before checking the front brake.
(a) Check the all brake lines and hoses for damage.
(b) Check the all brake lines and hoses for wear.
(c) Check the all brake lines and hoses for deformation.
(d) Check the all brake lines and hoses for cracks.
(e) Check the all brake lines and hoses for corrosion.
(f) Check the all brake lines and hoses for leaks.
(g) Check the all brake lines and hoses for bends.
(h) Check the all brake lines and hoses for twists.
(i) Check all clamps for tightness and connections for leak-
age.
(j) Check that the hoses and lines are clear of sharp edges,
moving parts and the exhaust system.
(k) Check that the lines installed in grommets pass through
the center of the grommets.
2. INSPECT FRONT AND REAR BRAKE PADS AND
DISCS
(FRONT PADS: See page BR-16)
(REAR PADS: See page BR-25)
(FRONT DISCS: See page BR-21)
(REAR DISCS: See page BR-30)
3. INSPECT PARKING BRAKE LININGS AND DRUMS
(See page BR-36)

MA02U-07
B04566
Dust Cover
B04567
B06414
MA-8
- MAINTENANCECHASSIS
56 Author
: Date
:
CHASSIS
INSPECTION
1. INSPECT STEERING LINKAGE
(a) Check the steering linkage for looseness or damage.
(b) Check the tie rod ends do not have excessive play.
(c) Check the dust seals and boots are not damaged.
(d) Check the boot clamps are not loose.
(e) Check the inspect the dust cover for damage.
2. INSPECT SRS AIRBAG (See pages RS-18, RS-32)
3. INSPECT STEERING GEAR HOUSING OIL
Check the steering gear housing for oil leakage.
If leakage is found, check for cause and repair.
4. INSPECT BALL JOINTS AND DUST COVERS
(a) Jack up the front of the vehicle and support it with stands.
(b) Make sure the front wheels are in a straight-ahead posi-
tion, and depress the brake pedal.
(c) Jack up the lower suspension arm until there is about half
a load on the front suspension.
(d) Inspect the dust cover for damage.
5. INSPECT DRIVE SHAFT BOOTS
Inspect the drive shaft boots for clamp looseness, grease leak-
age or damage.
6. INSPECT AUTOMATIC TRANSMISSION OIL LEVEL
(See page AT-3-1)
7. INSPECT TRANSFER AND DIFFERENTIAL OIL LEVEL
(a) Transfer:
Remove the filler plug and feel inside the hole with your
finger. Check that the oil comes to within 5 mm (0.20 in.)
of the bottom edge of the hole. If the level is low, add oil
until it begins to run out of the filler hole.
Transfer oil: See page TR-6

B06412
B06415
Drain Plug
B06413Drain Plug
- MAINTENANCECHASSIS
MA-9
57 Author
: Date
:
(b) Differential:
Remove the filler plug and feel inside the hole with your
finger. Check that the oil comes to within 5 mm (0.20 in.)
of the bottom edge of the hole. If the level is low, add oil
until it begins to run out of the filler hole.
Front differential oil: See page SA-35
Rear differential oil: See page SA-95
8. REPLACE AUTOMATIC TRANSMISSION FLUID (See
page AT-3-1)
9. REPLACE TRANSFER AND DIFFERENTIAL OIL
(a) Remove the drain plug and drain the oil.
(b) Reinstall the drain plug securely.
(c) Add new oil until it begins to run out of the filler hole.
Transfer oil: See page TR-6
Front differential oil: See page SA-35
Rear differential oil: See page SA-95
10. REPACK FRONT WHEEL BEARINGS AND DRIVE
SHAFT BUSHING GREASE
(a) Change the front wheel bearing grease (See page
SA-16).
NOTICE:
Maintenance free for rear wheel bearing.
(b) Repack the drive shaft bushing grease (See page
SA-33).
11. LUBRICATE PROPELLER SHAFT AND TIGHTEN
BOLTS
(a) Lubricate chassis components, referring to the lubrication
chart. Before pumping in grease, wipe off any mud and
dust on the grease fitting.

B06416
Lubricating Positions: 1. Spider
2. Slide Yoke21
1
MA-10
- MAINTENANCECHASSIS
58 Author
: Date
:
Grease grade:
Lithium base chassis grease (NLGI No.2)
(b) Tightening bolts for propeller shaft (See page PR-7).

MA02S-01
MA-6
- MAINTENANCEENGINE
54 Author
: Date
:
2004 LAND CRUISER (RM1071U)
ENGINE
INSPECTION
HINT:
Inspect these items when the engine is cold.
1. REPLACE TIMING BELT (See page EM-15)
2. INSPECT VALVE CLEARANCE (See page EM-4)
3. INSPECT DRIVE BELT (See page CH-2)
4. REPLACE ENGINE OIL AND OIL FILTER (See page LU-2)
5. REPLACE ENGINE COOLANT (See page CO-2)
6. INSPECT EXHAUST PIPES AND MOUNTINGS
Visually inspect the pipes, hangers and connections for severe corrosion, leaks or damage.
7. REPLACE AIR CLEANER FILTER
Replace the air cleaner filter with a new one.
8. INSPECT FUEL LINES, CONNECTIONS AND FUEL VAPOR CONTROL VALVE (See page
EC-5)
Visually inspect the fuel lines for cracks, leakage loose connections, deformation or tank band looseness.
9. INSPECT GASKET IN FUEL TANK CAP (See page EC-5)
10. REPLACE SPARK PLUGS (See page IG-1)
11. California, Massachusetts and New York:
INSPECT CHARCOAL CANISTER (See page EC-5)

MA02Q-01
MA-2
- MAINTENANCEINSIDE VEHICLE
50 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSIDE VEHICLE
GENERAL MAINTENANCE
These are the maintenance and inspection items which are considered to be owner's responsibility. They
can be done by the owner or be can have them done at a service shop. These items include those which
should be checked on a daily basis, those which, in most cases, do not require (special) tools and those
which are considered to be reasonable for the owner to do. Items and procedures for general maintenance
are as follows.
1. GENERAL NOTES

Maintenance items may very from country and country. Check the owner's manual supplement in
which the maintenance schedule is shown.

Every service items in the periodic maintenance schedule must be performed.

Periodic maintenance service must be performed according to whichever interval in the periodic main-
tenance schedule occurs first, the odometer reading (miles) or the time interval (months).

Maintenance service after the last period should be performed at the same time interval as before un-
less otherwise noted.

Failure to do even one item an cause the engine to run poorly and increase exhaust emissions.
2. LIGHTS
(a) Check that the headlights, stop lights, taillights, turn signal lights, and other lights are all working.
(b) Check the headlights aim.
3. WARNING LIGHTS AND BUZZERS
Check that all warning lights and buzzers function properly.
4. HORN
Check that it is working.
5. WINDSHIELD GLASS
Check for scratches, pits or abrasions.
6. WINDSHIELD WIPER AND WASHER
(a) Check operation of the wipers and washer.
(b) Check that the wipers do not streak.
7. WINDSHIELD DEFROSTER
Check that air comes out from the defroster outlet when operating the heater or air conditioner at defroster
mode.
8. REAR VIEW MIRROR
Check that it is mounted securely.
9. SUN VISORS
Check that they move freely and mounted securely.
10. STEELING WHEEL
Check that it has the specified freeplay. Be alert for changes in steering condition, such as hard steering,
excessive freeplay or strange noises.
11. SEATS
(a) Check that all front seat controls such as seat adjusters, seatback recliner, etc. operate smoothly.
(b) Check that all latches lock securely in any position.
(c) Check that the head restraints move up and down smoothly and that the locks hold securely in any
latch position.
(d) For folding-down rear seat backs, check that the latches look securely.
12. SEAT BELTS
(a) Check that the seat belt system such as buckles, retractors and anchors operate properly and smooth-
ly.
(b) Check that the belt webbing is not cut, frayed, worn or damaged.

- MAINTENANCEINSIDE VEHICLE
MA-3
51 Author
: Date
:
2004 LAND CRUISER (RM1071U)
13. ACCELERATOR PEDAL
Check the pedal for smooth operation and uneven pedal effort or catching.
14. BRAKE PEDAL (See page BR-9)
(a) Check that pedal for smoothly operation.
(b) Check that the pedal has the proper reserve distance and freeplay.
15. BRAKE BOOSTER (See page BR-40)
Check the brake booster function.
16. BRAKES
At a safe place, check that the brakes do not pull to one side when applied.
17. PARKING BRAKE (See page BR-14)
(a) Check that the lever has the proper travel.
(b) On a safe incline, check that the vehicle is held securely with only the parking brake applied.
18. AUTOMATIC TRANSMISSION ºPARKº MECHANISM
(a) Check the lock release button of the selector level for proper and smooth operation.
(b) On a safe incline, check that the vehicle is held securely with the selector lever in the ºPº position and
all brakes released.

MA02P-02
- MAINTENANCEOUTSIDE VEHICLE
MA-1
49 Author
: Date
:
2004 LAND CRUISER (RM1071U)
OUTSIDE VEHICLE
GENERAL MAINTENANCE
These are some maintenance and inspection items which are considered to be the owner's responsibility.
They can be done by the owner or they can have them done at a service shop. These items include those
which should be checked on a daily basis, those which, in most cases, do not require (special) tools and
those which are considered to be reasonable for the owner to do. Items and procedures for general mainte-
nance are as follows.
1. GENERAL NOTES

Maintenance items may very from country and country. Check the owner's manual supplement in
which the maintenance schedule is shown.

Every service items in the periodic maintenance schedule must be performed.

Periodic maintenance service must be performed according to whichever interval in the periodic main-
tenance schedule occurs first, the odometer reading (miles) or the time interval (months).

Maintenance service after the last period should be performed at the same time interval as before un-
less otherwise noted.

Failure to do even one item an cause the engine to run poorly and increase exhaust emissions.
2. TIRES
(a) Check the pressure with a gauge. If necessary, adjust.
(b) Check for cuts, damage or excessive wear.
3. WHEEL NUTS
When checking the tires, check the nuts for looseness or for missing nuts. If necessary, tighten them.
4. TIRE ROTATION
Check the owner's manual supplement in which the maintenance schedule is shown.
5. WINDSHIELD WIPER BLADES
Check for wear or cracks whenever they do not wipe clean. If necessary, replace.
6. FLUID LEAKS
(a) Check underneath for leaking fuel, oil, water or other fluid.
(b) If you smell gasoline fumes or notice any leak, have the cause found and corrected.
7. DOORS AND ENGINE HOOD
(a) Check that all doors and the tailgate operate smoothly, and that all larches lock securely.
(b) Check that the engine hood secondary latch secures the hood from opening when the primary latch
is released.

MA02R-05
MA-4
- MAINTENANCEUNDER HOOD
52 Author
: Date
:
2004 LAND CRUISER (RM1071U)
UNDER HOOD
GENERAL MAINTENANCE
1. GENERAL NOTICE

Maintenance items may vary from country to country. Check the owner's manual supplement in which
the maintenance schedule is shown.

Every service item in the periodic maintenance schedule must be performed.

Periodic maintenance service must be performed according to whichever interval in the periodic main-
tenance schedule occurs first, the odometer reading (miles) or the time interval (months).

Maintenance services after the last period should be performed at the same interval as before unless
otherwise noted.

Failure to do even one item can cause the engine to run poorly and increase exhaust emissions.
2. WINDSHIELD WASHER FLUID
Check that there is sufficient fluid in the tank.
3. ENGINE COOLANT LEVEL
Check that the coolant level is between the LEVEL lines on the see-through reservoir at normal tem-
perature (20°C (68°F)).
4. RADIATOR AND HOSES
(a) Check that the front of the radiator is clean and not blocked with leaves, dirt or bugs.
(See page CO-14)
(b) Check the hoses for cracks, kinks, rot or loose connections.
5. BATTERY ELECTROLYTE LEVEL

Check the indicator.

When the indicator color is blue, the condition is satisfactory. A red color indicates that distilled water
must be added, and white indicates that charging is necessary.
6. BRAKE FLUID LEVELS
Check that the brake fluid level is near the upper level line on the see-through reservoir.
(See page BR-4)
7. ENGINE DRIVE BELTS
Check drive belt for fraying, cracks, wear or oiliness.
8. ENGINE OIL LEVEL
Check the level on the dipstick with the engine turned off.
9. POWER STEERING FLUID LEVEL

Check the level on the dipstick.

The level should be in the ºHOTº or ºCOLDº range depending on the fluid temperature.
10. AUTOMATIC TRANSMISSION FLUID LEVEL
Visually check the overflow plug and oil pan for fluid leaks or traces of fluid.

- MAINTENANCEUNDER HOOD
MA-5
53 Author
: Date
:
2004 LAND CRUISER (RM1071U)
11. EXHAUST SYSTEM
Visually inspect for cracks, holes or loose supports.
If any change in the sound of the exhaust or smell of the exhaust fumes is noticed, have the cause located
and corrected.
