sensor TOYOTA LAND CRUISER 1998 Factory Owner's Manual

D12734
AT07Y-02
D12736
D12734
AT-4
- AUTOMATIC TRANSMISSIONVEHICLE SPEED SENSOR
1858 Author
: Date
:
2004 LAND CRUISER (RM1071U)
VEHICLE SPEED SENSOR
ON-VEHICLE REPAIR
1. DISCONNECT NO. 1 VEHICLE SPEED SENSOR CON-
NECTOR
2. REMOVE NO. 1 VEHICLE SPEED SENSOR
Remove the bolt and the No. 1 vehicle speed sensor.
3. DISASSEMBLE NO. 1 VEHICLE SPEED SENSOR
(a) Remove the O-ring from the speedometer driven gear
assembly.
(b) Remove the clip and the speedometer driven gear from
the speedometer driven gear sleeve.
4. ASSEMBLE NO. 1 VEHICLE SPEED SENSOR
(a) Install the speedometer driven gear and the clip to the
speedometer driven gear sleeve.
(b) Coat a new O-ring with ATF.
(c) Install the O-ring to the speedometer driven gear assem-
bly.
5. INSTALL NO. 1 VEHICLE SPEED SENSOR
Install the No. 1 vehicle speed sensor with the bolt.
Torque: 16 N´m (160 kgf´cm, 12 ft´lbf)
6. CONNECT NO. 1 VEHICLE SPEED SENSOR CON-
NECTOR

D12737
Speed Sensor NT
Speed Sensor SP2
D02395
D12737
Speed Sensor NT
Speed Sensor SP2
- AUTOMATIC TRANSMISSIONVEHICLE SPEED SENSOR
AT-5
1859 Author
: Date
:
2004 LAND CRUISER (RM1071U)
7. DISCONNECT SPEED SENSOR NT AND SP2 CON-
NECTORS
8. REMOVE SPEED SENSOR NT AND SP2
(a) Remove the 2 bolts, speed sensor NT and SP2.
(b) Remove 2 O-rings from the speed sensor NT and SP2.
9. INSTALL SPEED SENSOR NT AND SP2
(a) Coat 2 new O-rings with ATF and install them to the
speed sensor NT and SP2.
(b) Install the speed sensor NT and SP2 with 2 bolts.
Torque: 5.4 N´m (55 kgf´cm, 48 in.´lbf)
10. CONNECT SPEED SENSOR NT AND SP2 CONNEC-
TORS

BE0G9-04
I09910
Antenna
Antenna Motor
View ºAº
View ºAºView ºBº
View ºCºView ºDº Passenger Airbag
Sensor Assembly
RainforcementPiller
Rear Door GlassFront Door Glass
View ºBº
View ºCº
View ºDº
Radio Assembly : Clamp
Radio assembly
Front Door Glass
Quater Window
Glass BE-174
- BODY ELECTRICALANTENNA
2547 Author
: Date
:
2004 LAND CRUISER (RM1071U)
ANTENNA
LOCATION

MET Fuse Light Control Switch Flasher Relay
ABS, TRC, VSC ECU ABS, TRC, VSC ECU Drive Monitor H/L R-HI Fuse Body ECU
ABS, TRC, VSC ECU
ABS & BA & TRAC & VSC Actuator ECM
ABS, TRC, VSC ECU
Airbag ECU
Oil Pressure Sender Gauge Airbag ECU Body ECUWiring connector side No.107 6
19 18 175 3
12
20 15
16
17
18
19
7 4 1
C14 C13 C12
11
Gateway ECU
ECM Engine Ground
Main Fuel Sender Gauge
7
19
201
2
4
C15Key Unlock Warning Switch 9CTR DIFF Switch 14
Drive Monitor 16 10 ECM
Body (Door Courtesy Switch Signal) 10Flasher Relay 4
ABS, TRC, VSC ECU
ABS, TRC, VSC ECU
ABS, TRC, VSC ECU
GAUGE1 Fuse
ECU-B2 Fuse
ACC Fuse
DOME Fuse
Speed Sensor 11
12
13
14
15Main Fuel Sender Gauge
Light Control Rheostat 6 Main Fuel Sender GaugeBody Ground 9
Speed Control Unit 16PANEL Fuse 8
11 Driver Seat Belt Buckle Switch
- BODY ELECTRICALCOMBINATION METER
BE-61
2434 Author
: Date
:
2004 LAND CRUISER (RM1071U)

BE0HJ-1 1
I24912
Meter Cover
Inclination Sensor
Meter Glass
BE-62
- BODY ELECTRICALCOMBINATION METER
2435 Author
: Date
:
2004 LAND CRUISER (RM1071U)
COMPONENTS

I24950
Connector C15
161
3
2
1
I25536
BE-66
- BODY ELECTRICALCOMBINATION METER
2439 Author
: Date
:
3. INSPECT SPEEDOMETER VOLTAGE
(a) While driving the vehicle at the speed of 10 km/h, check
the voltage between the terminals 16 and 1 of the com-
bination meter assy.
STANDARD: Fluctuation between 10 to 14 V or less is
repeated 7 times within 1 sec.
4. INSPECT VEHICLE SPEED SENSOR OPERATION
(a) Connect the positive (+) lead from the battery to terminal
1 and negative (-) lead to terminal 2.
(b) Connect the positive (+) lead from the tester to terminal
3 and the negative (-) lead to terminal 2.
(c) Rotate the shaft.
(d) Check that there is voltage change from approx. 0V to 11
V or more between terminals 2 and 3.
HINT:
The voltage change should be performed 4 times for every rev-
olution is not as specified, replace the sensor.
5. INSPECT TACHOMETER / ON-VEHICLE
(a) Connect a tune-up test tachometer, and start the engine.
(b) Compare the tester and tachometer indications.
DC 13.5 V 25 °C at (77°F):
Standard indication (rpm)Allowable range (rpm)
( ): estimated reference values
700630 - 770
1,000900 - 1,100
2,0001,850 - 2,150
3,0002,800 - 3,200
4,0003,800 - 4,200
5,0004,800 - 5,200
6,0005,750 - 6,250
7,0006,700 - 7,300

I04109
Press
Seat Lower Cushion
Sensing part
I24953
- BODY ELECTRICALCOMBINATION METER
BE-69
2442 Author
: Date
:
Tester connectionConditionSpecified condition
4 - GroundConstantContinuity
If continuity is not as specified, inspect the ground circuit.
17. Passenger seat only:
INSPECT SEAT BELT WARNING OCCUPANT DETEC-
TION SENSOR CONTINUITY
Check that continuity exists between the terminals 1 and 2
when pressing the sensing part of the lower seat cushion.
If operation is not as specified, replace the sensor.
18. INSPECT LIGHT CONTROL RHEOSTAT
(a) Turn the rheostat knob OFF, and check that there is no
continuity between terminal 5 and 4 (Rheostat knob
turned to fully counterclockwise).
(b) Gradually, turn the rheostat knob from the dark side to
bright side, and check that there is continuity between ter-
minal 5 and 4 (Rheostat knob turned to clockwise).
If operation is not as specified, replace the rheostat.

I25813
1
2
3
4
5
6
7
8
9
1012
13
14
15
16
17
18
19
20 11
I29078
Inclination Sensor
IGN+ E/G EARTH
OUT VccGND
Bottom Surface of Sensor
Connector C15 BE-70
- BODY ELECTRICALCOMBINATION METER
2443 Author
: Date
:
19. INSPECT INCLINATION SENSOR
(a) The inclination sensor is installed in the combination me-
ter. Inspect the inclination sensor by connecting a battery
positive (+) lead to terminal 11 (IGN+) of the meter con-
nector, and a battery negative (-) lead to terminal 1 (E/G
EARTH).
(b) Check if the voltage between terminal Vcc and GND of the
inclination sensor connector is 5 V.
(c) Check the voltage between terminal OUT and GND when
the bottom surface of the inclination sensor is in a level
position. Also check the voltage when it is inclined back-
ward or forward.
Standard Value:
Bottom surface of sensor is set in a level position:
about 4.5 V
Bottom surface of sensor is inclined:
about 0.5 V

I24744
Seat Belt Warning
Occupant Detection Sensor
Fuel Tank

Fuel Sender Gauge
Park/ Neutral Position Switch Engine Coolant
Tempareture Sender Gauge
Speed Sensor
Oil Pressure Gauge
- BODY ELECTRICALCOMBINATION METER
BE-57
2430 Author
: Date
:
2004 LAND CRUISER (RM1071U)

I25040
Built in relayExcept built in relay
I22144
Wire Harness Side:
1
2
3
4
56
I22145
From Back Side:
1 2
3 4
5 6
- BODY ELECTRICALHEADLIGHT AND TAILLIGHT SYSTEM
BE-33
2406 Author
: Date
:
2004 LAND CRUISER (RM1071U)
4. INSPECT ENGINE ROOM R/B RELAY CIRCUIT (See
Pase BE-15)
HINT:
The (Headlight, DIM, Tail relay) is built in engine room junction
block. Also the relay is constructed with a relay block that is in
the junction block as a unit. To disconnect the wire harness con-
necting with relay block is impossible. If the relay has a malfunc-
tion, replace it with junction block assembly wire harness to-
gether.
5. Connector disconnected:
INSPECT AUTOMATIC LIGHT CONTROL SENSOR
CIRCUIT
Disconnect the connector from the sensor and inspect the con-
nector on the wire harness side, as shown in the chart.
HINT:

Ignition switch is ON.

Light control switch is in AUTO.

Vehicle's surroundings are bright.
Tester connectionConditionSpecified condition
6 - GroundConstantContinuity
3 - GroundClose the driver's door again while the ignition
switch OFFNo voltage
3 - GroundIgnition switch position ON5.2 - 9.0V
If circuit is as specified, perform the inspection on the following
page.
If the circuits is not as specified, inspect the circuit connected
to other parts.
6. Connector disconnected:
INSPECT AUTOMATIC LIGHT CONTROL SENSOR
CIRCUIT
Connect the wire harness side connector to the sensor and in-
spect wire harness side connector from the back side, as
shown.
HINT:

Ignition switch is ON.

Light control switch is in AUTO.

Vehicle's surroundings are bright.
Tester connectionConditionSpecified condition
4 - Ground
(CLTS - Body ground)ConstantPulse generation
3 - Ground
(CLTB - Body ground)Ignition switch ON10 - 14V
If the circuits is not as specified, try replacing the sensor with a
new one.
