AC-2
- AIR CONDITIONINGAIR CONDITIONING SYSTEM
2727 Author
: Date
:
2004 LAND CRUISER (RM1071U)
9. SUPPLEMENTAL RESTRAINT SYSTEM (SRS)
The LAND CRUISER is equipped with SRS (Supplemental Re-
straint System) such as the driver airbag and the front passen-
ger airbag. Failure to carry out service operation in the correct
sequence could cause the SRS to unexpectedly deploy during
servicing, possibly leading to a serious accident. Before servic-
ing (including removal or installation of parts, inspection or re-
placement), be sure to read the precautionary notices in the RS
section.

BE0G9-04
I09910
Antenna
Antenna Motor
View ºAº
View ºAºView ºBº
View ºCºView ºDº Passenger Airbag
Sensor Assembly
RainforcementPiller
Rear Door GlassFront Door Glass
View ºBº
View ºCº
View ºDº
Radio Assembly : Clamp
Radio assembly
Front Door Glass
Quater Window
Glass BE-174
- BODY ELECTRICALANTENNA
2547 Author
: Date
:
2004 LAND CRUISER (RM1071U)
ANTENNA
LOCATION

BE01I-05
- BODY ELECTRICALBODY ELECTRICAL SYSTEM
BE-1
2374 Author
: Date
:
2004 LAND CRUISER (RM1071U)
BODY ELECTRICAL SYSTEM
PRECAUTION
HINT:
Take care to observe the following precautions when performing inspections or removal and replacement
of body electrical related parts.
1. HEADLIGHT SYSTEM
Halogen bulbs have pressurized gas inside and require special handling. They can burst if scratched or
dropped. Hold a bulb only by its plastic or metal case. Don't touch the glass part of a bulb with bare hands.
2. SRS (SUPPLEMENTAL RESTRAINT SYSTEM)
The LAND CRUISER is equipped with an SRS (Supplemental Restraint System) such as the driver airbag
and front passenger airbag. Failure to carry out service operation in the correct sequence could cause the
SRS to unexpectedly deploy during servicing, possibly leading to a serious accident. Before servicing (in-
cluding removal or installation of parts, inspection or replacement), be sure to read the precautionary notices
in the RS section.
3. AUDIO SYSTEM

If the negative (-) terminal cable is disconnected from the battery, the preset AM, FM 1 and FM 2 sta-
tions stored in memory are erased, so be sure to note the stations and reset them after the negative
(-) terminal cable is reconnected to the battery.

If the negative (-) terminal cable is disconnected from the battery, the ºANTI-THEFT SYSTEMº will
operate when the cable is reconnected, but the radio, tape player and CD player will not operate. Be
sure to input the correct ID number so that the radio, tape player and CD player can be operated again.
4. MOBILE COMMUNICATION SYSTEM
If the vehicle is equipped with a mobile communication system, refer to precautions in the IN section.

MET Fuse Light Control Switch Flasher Relay
ABS, TRC, VSC ECU ABS, TRC, VSC ECU Drive Monitor H/L R-HI Fuse Body ECU
ABS, TRC, VSC ECU
ABS & BA & TRAC & VSC Actuator ECM
ABS, TRC, VSC ECU
Airbag ECU
Oil Pressure Sender Gauge Airbag ECU Body ECUWiring connector side No.107 6
19 18 175 3
12
20 15
16
17
18
19
7 4 1
C14 C13 C12
11
Gateway ECU
ECM Engine Ground
Main Fuel Sender Gauge
7
19
201
2
4
C15Key Unlock Warning Switch 9CTR DIFF Switch 14
Drive Monitor 16 10 ECM
Body (Door Courtesy Switch Signal) 10Flasher Relay 4
ABS, TRC, VSC ECU
ABS, TRC, VSC ECU
ABS, TRC, VSC ECU
GAUGE1 Fuse
ECU-B2 Fuse
ACC Fuse
DOME Fuse
Speed Sensor 11
12
13
14
15Main Fuel Sender Gauge
Light Control Rheostat 6 Main Fuel Sender GaugeBody Ground 9
Speed Control Unit 16PANEL Fuse 8
11 Driver Seat Belt Buckle Switch
- BODY ELECTRICALCOMBINATION METER
BE-61
2434 Author
: Date
:
2004 LAND CRUISER (RM1071U)

- BODY ELECTRICALTROUBLESHOOTING
BE-7
2380 Author
: Date
:
2004 LAND CRUISER (RM1071U) Seat belt warning light does not light up.
1. LED
2. Seat Belt Buckle Switch
3. Wire Harness
4. Body ECU-
BE-63
BE-63
DI-1038
Discharge warning light does not light up.
1. METER Fuse
2. LED
3. Wire Harness
4. Generator-
-
-
CH-2
Brake warning light does not light up.
1. LED
2. Parking Brake Switch
3. Brake Fluid Level Warning Switch
4. LED Check Relay
5. Combination Meter
6. Wire Harness-
BE-63
BE-63
BE-63
BE-58
-
SRS warning light does not light up.
1. ECU-B2 Fuse
2. LED
3. Airbag Sensor Assembly
4. Combination Meter
5. Wire Harness-
-
DI-690
BE-58
-
Open door warning light does not light up.
1. DOME Fuse
2. LED
3. Door Courtesy Switch
4. Combination Meter
5. Wire Harness-
-
BE-44
BE-58
-
A/T oil temperature warning light does not light up.
1. LED
2. Combination Meter
3. Wire Harness
4. ECM-
BE-63
BE-58
DI-1
COMBINATION METER (Indicator Light):
SymptomSuspect AreaSee page
Cruise control indicator light does not light up.
1. LED
2. Combination Meter
3. Wire Harness
4. ECM-
BE-58
-
DI-1
High-beam indicator light does not light up.
1. LED
2. Combination Meter
3. Wire Harness
4. Headlight System-
BE-58
-
BE-30
Turn indicator light does not light up.
1. LED
2. Combination Meter
3. Wire Harness
4. Turn Signal and Hazard Warning System-
BE-58
-
BE-39
Shift indicator lights do not light up.
1. LED
2. Combination Meter
3. Park/Neutral Position Switch
4. Wire Harness-
BE-58
-
-
Only one shift indicator does not light up.1. LED
2. Combination Meter-
BE-58
Malfunction indicator light does not light up.
1. LED
2. Combination Meter
3. Wire Harness
4. ECM-
BE-58
-
DI-1

BO1KT-04
H18928
Headrest
Headrest Support
Seatback Board
Lumber Support Seatback Frame
Seatback Pad Armrest
Seat Cushion Cover
Seat Cushion Pad
Seat Cushion Frame
Seat Cushion
Inner Shield
Front Seat Inner BeltReclining Adjuster Inside Shield
Lower Seat Cushion Shield
Seat Cushion
Outer Shield
Power Seat
Switch Knob Power Seat SwitchLumber Support Switch
Front Seat
Cushion ShieldSeat Position Control Relay Seatback Cover
Hog Ring

Hog Ring
: Specified torqueN´m (kgf´cm, ft´lbf)

Non-reusable part
Seat HeaterSeat Heater
Seat WireSeat Wire
Seat Adjuster Assembly
w/ Side Airbag:
Side Airbag Assembly
37 (380, 27)
21 (210, 15)
21 (210, 15)
43 (440, 32)
21 (210, 15)
42 (430, 31)
8.0 (82, 71 in.´lbf)
Seat Position Sensor Driver's Side:
42 (430, 31)


42 (430, 31)
42 (430, 31)
Armrest Cap
Armrest Bush
Spacer
4.7 (48, 42 in.´lbf)
w/ Side Airbag:
5.5 (56, 49 in.´lbf)
5.5 (56, 49 in.´lbf)
42 (430, 31)
43 (440, 32)
BO-104
- BODYFRONT SEAT
2678 Author
: Date
:
2004 LAND CRUISER (RM1071U)
FRONT SEAT
COMPONENTS

H20963
H19941
H21292
H20961
BO-108
- BODYFRONT SEAT
2682 Author
: Date
:
2004 LAND CRUISER (RM1071U)
12. REMOVE SEATBACK ASSEMBLY
(a) Remove the hog rings.
(b) Disengage the hook as shown in the illustration.
(c) Disconnect the connectors.
(d) Remove the 4 bolts and the seatback assembly.
NOTICE:
When handling the airbag connector take care not to dam-
age the airbag wire harness.
(e) Remove the screw and the RH reclining adjuster inside
shield.
(f) w/ Side Airbag:
Disconnect the side airbag connector.
NOTICE:
When handling the airbag connector take care not to dam-
age the airbag wire harness.
(g) Remove the screw and the LH reclining adjuster inside
shield.
13. REMOVE ARMREST
14. w/o Side Airbag:
REMOVE SEATBACK FRAME
(a) Remove the hog rings.
(b) Remove the 2 headrest supports.
(c) Remove the seatback frame from the seatback cover with
pad.
15. w/ Side Airbag:
REMOVE SEATBACK FRAME
(a) Remove the hog rings, the clamps and the 2 bolts.
(b) Remove the 2 headrest supports.
(c) Remove the seatback frame from the seatback cover with
pad.

BO4J3-01
H18929
H04785
H04468
H21292
BO-1 14
- BODYFRONT SEAT
2688 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REASSEMBLY
1. Driver 's Side:
INSTALL SEAT POSITION SENSOR
Install the seat position sensor with a new bolt, then connect the
connector.
Part No.:
Bolt: 90119-06871
Torque: 8.0 N´m (82 kgf´cm, 71 in.´lbf)
2. INSTALL SEAT POSITION CONTROL RELAY
Install the seat position control relay with the 2 bolts, then con-
nect the connectors.
Torque: 5.5 N´m (56 kgf´cm, 49 in.´lbf)
3. INSTALL SEATBACK COVER
Install the seatback cover to the seatback pad with new hog
rings.
4. INSTALL LUMBER SUPPORT
Install the lumber support and the spacer with the 2 bolts.
5. w/o Side Airbag:
INSTALL SEATBACK FRAME
(a) Install the seatback cover to the seatback frame.
(b) Install new hog rings.
(c) Install the 2 headrest supports.

H20961
H21294
H19941
H21291
H20959
- BODYFRONT SEAT
BO-1 15
2689 Author
: Date
:
2004 LAND CRUISER (RM1071U)
6. w/ Side Airbag:
INSTALL SEATBACK FRAME
(a) Install the seatback cover to the seatback frame.
(b) Install new hog rings, the clamps and the 2 bolts.
Torque: 4.7 N´m (48 kgf´cm, 42 in.´lbf)
(c) Install the 2 headrest supports.
7. INSTALL SEATBACK ASSEMBLY
(a) w/o Side Airbag:
Install the RH reclining adjuster inside shield with a screw.
(b) w/ Side Airbag:
Place the airbag connector along the inner seat adjuster,
and then install the RH reclining adjuster inside shield
with a screw so that the connector is placed in between.
NOTICE:
When handling the airbag connector, take care not to dam-
age the airbag wire harness.
(c) Install the LH reclining adjuster inside shield with a screw.
(d) Install the seatback assembly with the 4 bolts.
Torque: 43 N´m (440 kgf´cm, 32 ft´lbf)
(e) Install new hog rings.
(f) Hang the hook.
(g) Connect the connectors.
8. INSTALL ARMREST
Torque: 37 N´m (380 kgf´cm, 27 ft´lbf)
9. INSTALL HEADREST
10. INSTALL SEAT CUSHION COVER (See page BO-1 10)
11. INSTALL SEAT CUSHION FRAME
(a) Install the seat cushion frame with new hog rings to the
seat cushion cover with pad.
(b) Hang the hook.
12. INSTALL SEAT CUSHION ASSEMBLY
(a) Install the seat cushion assembly with the 4 bolts to the
seat adjuster.
Torque: 21 N´m (210 kgf´cm, 15 ft´lbf)
(b) Engage the wire harness clamp.

BO1KU-04
- BODYFRONT SEAT
BO-105
2679 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. REMOVE SEAT TRACK OUTER COVERS
Using a screwdriver, remove the 4 seat track outer covers.
HINT:
Tape up the screwdriver tip before use.
2. REMOVE FRONT SEAT
(a) Remove the 4 bolts.
Torque: 42 N´m (430 kgf´cm, 31 ft´lbf)
(b) Disconnect the connectors, then remove the front seat.
NOTICE:

When handling the airbag connector, take care not to damage the airbag wire harness.

Be careful not to damage the body.
