ESP TOYOTA LAND CRUISER 2002 J100 Navigation Manual

[x] Cancel search | Manufacturer: TOYOTA, Model Year: 2002, Model line: LAND CRUISER, Model: TOYOTA LAND CRUISER 2002 J100
Pages: 122, PDF Size: 1.47 MB

Page 3 of 122

TOYOTA LAND CRUISER 2002 J100 Navigation Manual iii
Safety Instruction
UN003
To use your system as safely as possible, fol-
low all the safety tips shown below.
This system is intended to assist you in
reaching your destination and, if used prop-
e

Page 9 of 122

TOYOTA LAND CRUISER 2002 J100 Navigation Manual 5
5. By Home: You can select your own home
without entering the address each time. In
this case, it is necessary to register your
home beforehand. See page 15 for the de-
tailed steps.
6. By Emerg

5
5. By Home: You can select your own home
without entering the address each time. In
this case, it is necessary to register your
home beforehand. See page 15 for the de-
tailed steps.
6. By Emergency: You can select one of
the three points of emergency service points
that have been already stored in the sys-
tem's
database. See page 15 for the detailed
steps.
7. By Intersection: You can enter the
names of two intersecting streets. This is
helpful if you do not know the specific street
address of your destination but know the
general vicinity. See page 16 for the detailed
steps.
8. By Freeway Entrance/Exit: You can en-
ter the name of the freeway (interstate) en-
trance or exit. See page 17 for the detailed
steps.
9. By Previous Starting Point: You can en-
ter a point where the system has started to
guide last time. See page 19 for the detailed
steps.
10. By Map Selection: You can select a
destination simply by touching the location
on the displayed map. See page 19 for the
detailed steps.
INFORMATION
When inputting the destination, the response to the switch may be slow.
ºPoint of Interestº are mainly regis-tered in ºDetailed map coverageareasº. The registration is madebased on the NavTech ºStandardPOI Inclusion Listº.
If there is no point registered,switches such as ºMarked Pointº,ºHomeº, ºPrevious Destinationº orºPrevious Starting Pointº are
dimmed and not available.
The route for returning may not bethe same as that for going.
The route guidance to the destina-tion may not be the shortest route or
a route without traffic congestion.
Route gui dance may not be available
if there is no road data for the speci- fied location.
When setting the destination, youshould use the map on a scale of one
half mile or smaller.
To select an ºAddressº, ºPoint of In- terestº, ºFreeway Entrance/Exitº orºIntersectionº in a different region, asearch area's change is necessary.
CAUTION
While you are driving, be sure to follow
traffic regulations and keep the road
condition in mind. If a traffic sign on
the road has been changed, the route
guidance may provide wrong informa-
tion.

Page 66 of 122

TOYOTA LAND CRUISER 2002 J100 Navigation Manual i
Overview of Touch Screen and Switches
Switch operation
This system operates mainly by the
switches on the screen. To protect the
screen, lightly touch switches on the
screen with your finger. When

Page 67 of 122

TOYOTA LAND CRUISER 2002 J100 Navigation Manual UNC001
INFO button
Push this button to display the information menu screen. For details, see page 4.
MAP/VOICE button
Push this button to repeat a
Guidance voice, cancel the one touch scroll and star

Page 102 of 122

TOYOTA LAND CRUISER 2002 J100 Navigation Manual 14
UNG622
ºRPTº switch: The repeat feature automati-
cally replays the current program.
Touch the ºRPTº switch while the program is
playing. When the program ends, it will auto-
matically be re

14
UNG622
ºRPTº switch: The repeat feature automati-
cally replays the current program.
Touch the ºRPTº switch while the program is
playing. When the program ends, it will auto-
matically be rewound and replayed. Touch
the switch again to turn off the repeat feature.
There must be at least 3 seconds of blank
space between programs for the repeat fea-
ture to work correctly.
ºSKIPº switch: The skip feature allows you
to fast forward past long stretches of blank
tape. This is especially useful at the end of
cassettes. Touch
the ºSKIPº switch. The player will au-
tomatically skip any blank portions of 15 se-
conds or more and play the next program. To
cancel it, touch the switch once again.
UNC616a
ºAutomatic program selectionº button:
The automatic program selection feature al-
lows you to program your cassette player to
skip forward or backward to locate the song
you want to hear. You can skip up to 9 pro-
grams at a time.
Push this button on the upper side to skip for-
ward. ºFFº and the number will appear on the
display. Push the button until the number
you want to skip appears on the display. Af-
ter that, the player will automatically skip for-
ward. When the end of the tape is reached, the
player automatically reverses sides and re-
sumes normal play.
Push this button on the lower side to skip
backward. Push the button until ºREWº and
the number you want to skip appear on the
display.

If you set ºREW 1º, the player will rewind
to the beginning of the current program.
When counting the number of programs
you want to rewind, remember to count
the current program as well. For example,
if you want to rewind to a song that is two
before the song you are listening to, push
this button until ºREW 3º appears on the
display.
When the beginning of the tape is reached,
the player automatically resumes normal
play.
There must be at least 5 seconds of blank
space between programs for this feature to
work correctly.
ºRPTº, ºSKIPº or ºAutomatic program
selectionº features: These features may
not work well with some spoken word, live or
classical recordings.
(c) Automatic program
selection

Page 115 of 122

TOYOTA LAND CRUISER 2002 J100 Navigation Manual 27
0201
Bashkir
0205Byelorussian
0207Bulgarian
0208Bihari
0209Bislama
0214Bengali
0215Tibetan
0218Breton
0301Catalan
0315Corsican
0319Czach
0325Welsh
0401Danish
0426Bhutani
0515Esperanto
0520Estonian

Page 120 of 122

TOYOTA LAND CRUISER 2002 J100 Navigation Manual 32For example, nearby buildings and terrain
can interfere with FM reception. Power lines
or telephone wires can interfere with AM sig-
nals. And of course, radio signals have a lim-
ited range, and

32For example, nearby buildings and terrain
can interfere with FM reception. Power lines
or telephone wires can interfere with AM sig-
nals. And of course, radio signals have a lim-
ited range, and the farther you are from a sta-
tion, the weaker its signal will be. In addition,
reception conditions change constantly as
your vehicle moves.
Here are some common reception
problems
that probably do not indicate a problem with
your radio:
FM
Fading and drifting stations - Generally,
the effective range of FM is about 40 km (25
miles). Once outside this range, you may no-
tice fading and drifting, which increase with
the distance from the radio transmitter. They
are often accompanied by distortion.
Multi-path - FM signals are reflective, mak-
ing it possible for two signals to reach your
antenna at the same time. If this happens,
the signals will cancel each other out, caus-
ing a momentary flutter or loss of reception.
Static and fluttering - These occur when
signals are blocked by buildings, trees, or
other large objects. Increasing the bass lev-
el may reduce static and fluttering. Station
swapping - If the FM signal you are
listening to is interrupted or weakened, and
there is another strong station nearby on the
FM band, your radio may tune in the second
station until the original signal can be picked
up again.
AM
Fading - AM broadcasts are reflected by the
upper atmosphere - especially at night.
These reflected signals can interfere with
those received directly from the radio station,
causing the radio station to sound alternately
strong and weak.
Station interference - When a reflected sig-
nal and a signal received directly from a radio
station are very nearly the same frequency,
they can interfere with each other, making it
difficult to hear the broadcast.
Static - AM is easily affected by external
sources of elec trical noise, such as high ten-
sion power lines, lightening, or electrical mo-
tors. This results in static.
Caring for your cassette player and tapes
For high performance from your cassette
player and tapes:
Clean the tape head and other parts regular-
ly.
A dirty tape head or tape path can de-
crease sound quality and tangle your cas-
sette tapes. The easiest way to clean
them is by using a cleaning tape. (A wet
type is recommended.)
Use high-quality cassettes:
Low-quality cassette tapes can cause
many problems, including poor sound, in-
consistent playing speed, and constant
auto-reversing. They can also get stuck
or tangled in the cassette player.
Do not use a cassette if it has been dam-
aged or tangled or if its label is peeling off.
Do not leave a cassette in the player if you
are not listening to it, especially if it is hot
outside.
Store cassettes in their cases and out of
direct sunlight.
Avoid using cassettes with a total playing
time longer than 100 minutes (50 minutes
per side). The tape used in these cas-
settes is thin and could get stuck or
tangled in the cassette player.

Page 122 of 122

TOYOTA LAND CRUISER 2002 J100 Navigation Manual 34
Your DVD player cannot play special
shaped, labeled or low-quality discs as
those shown here. Do not use them as
the player could be damaged.
Handle discs carefully, especially when
you set the
