TOYOTA LAND CRUISER 2004 J100 Navigation Manual

141
AUDIO SYSTEM
Audio system142 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION VI

 For the JBL brand audio system, “JBL” logo is provided on the panel.
142
Audio system
Quick reference for your audio system
Page
1 Audio operation screen display
button 143. . . . . . . . . . . . . . . . . . . . . . . .
2 Function switch display
screen 144. . . . . . . . . . . . . . . . . . . . . . .
3 Cassette tape slot 151. . . . . . . . . . . . .
4 Frequency turning knob 148. . . . . . .
5 [Radio mode] Preset tuning 148. . . .
[Tape mode] Side change of
cassette tape 151. . . . . . . . . . . . . . . . .
[DISC mode] Disc selection 155. . . .
6 SCAN button 149, 156. . . . . . . . . . . . . .
7 Mode selectors 144. . . . . . . . . . . . . . . .
8 Stopping and ejecting a
cassette tape 151. . . . . . . . . . . . . . . . .
9 [Radio mode] Seek tuning 148. . . . . .
[Tape/DISC mode] Direct access to
a desired program 152/156. . . . . . . . . .
10 Turning the system on and
adjusting volume 143. . . . . . . . . . . . . .

143
Using your audio system:
some basics
This section describes some of the basic fea-
tures of the Toyota audio system. Some in-
formation may not pertain to your system.
Your audio system works when the ignition
key is in the “ACC” or “ON” position.
NOTICE
To prevent the battery from being
discharged, do not leave the car audio
on longer than necessary when the
engine is not running.
oxu002
By pushing the switch above, you can op-
erate the speech command system.
For the operation of the speech command
system and the command, see page 126 and
127.
(a) Turning the system on and off
UNX602
POWERVOL: Push this knob to turn the au-
dio system on and off. Turn this knob to adjust
the volume. The system turns on in the last
mode used.
AUDIO: Push this button to display switches
for audio system.
VI

144
Push the “AM”, “FM”, “TAPE” or “DISC”
button to turn on that mode. The selected
mode turns on directly.
Push these buttons if you want to switch from
one mode to another.
If the tape or disc is not set, the cassette play-
er or compact disc player does not turn on.
You can turn off the cassette player by eject-
ing the cassette tape. If the audio system was
previously off, then the entire audio system
will be turned off when you eject the cassette
tape. If another function was previously play-
ing, it will come on again.The switches for radio, cassette tape and
disc player operation are displayed on the
liquid crystal display. Touch them lightly
and directly on the screen.
The selected switch is highlighted in green.

145
(b) Automatic sound levelizer
When the audio sound becomes difficult to be
heard due to road noise, wind noise, etc. dur-
ing driving, touch the “ASL” switch. The sys-
tem adjusts to the optimum volume and tone
quality according to the noise level.
(c) Tone and balance
How good an audio program sounds to you is
largely determined by the mix of the treble,
mid−range, and bass levels. In fact, different
kinds of music and vocal programs usually
sound better with different mixes of treble,
mid−range, and bass.
A good balance of the left and right stereo
channels and of the front and rear sound lev-
els is also important.
Keep in mind that if you are listening to a ste-
reo recording or broadcast, changing the
right/left balance will increase the volume of
one group of sounds while decreasing the
volume of another.
Touching the “SOUND” switch on the
screen displays the sound adjustment
screen.
VI

146
BASS “+” or “–”: Adjusts low−pitched
tones.
MID “+” or “–”: Adjusts mid−pitched tones.
TREB “+” or “–”: Adjusts high−pitched
tones.
“FRONT” or “REAR”: Adjusts sound bal-
ance between the front and rear speakers.
“L” or “R”: Adjusts sound balance between
the left and right speakers.
“OK”: The previous screen returns.
(d) Your radio antenna
The antenna automatically extends when the
radio is on or the radio system is on, and re-
tracts when the radio mode is off.
UNX602
To adjust the height of the antenna manu-
ally, push the switch.
Clean the antenna mast periodically with a
clean dry cloth.
CAUTION
Before extending the antenna, confirm
that no one is close enough to get
injured.
NOTICE
To prevent damage to the antenna,
make sure it is retracted before
driving your vehicle through an
automatic car wash.
Antenna mast have to be extended
higher than 100 mm (3.94 in.) length
when the audio is on. Extend the an-
tenna mast when the radio signal is
weak.

147
(e) Your cassette player
When you insert a cassette, the exposed tape
should be to the right.
NOTICE
Do not oil any part of the cassette player,
and do not insert anything except a
cassette tape into the slot.
(f) Your automatic changer
UNG603
If your Lexus is equipped with an automatic
changer, it can play selected discs or continu-
ously play all the discs set in the magazine.
When you set discs into the magazine, make
sure they face the correct way. If not, the play-
er will display “DISC CHECK” and the disc
number.
NOTICE
Never try to disassemble or oil any part
of the automatic changer. Do not insert
anything except a compact disc or DVD
video disc into the magazine.
The player is intended for use with 12 cm (4.7
in.) discs only.
Radio operation
(a) Listening to the radio
UNG610
Push these buttons to choose either an
AM or FM station.
“AM”, “FM1”, “FM2” or “FM TYPE” appears on
the display.
VI

148
UNX611
Turn this knob to step up the station band
or to step down.
Your radio automatically changes to stereo
reception when a stereo broadcast is re-
ceived. “ST” appears on the display. If the
signal becomes weak, the radio reduces the
amount of channel separation to prevent the
weak signal from creating noise. If the signal
becomes extremely weak, the radio switches
from stereo to mono reception. In this case,
“ST” disappears from the display.
(b) Presetting a station
1. Tune in the desired station.
2. Touch one of the station selector
switches (16) and hold it until a beep is
heard. This sets the station to the switch
and the frequency appears on the switch.
Each switch can store FM1, FM2 and AM. To
change the preset station to a different one,
follow the same procedure.
The preset station memory is cancelled when
the power source is interrupted by battery dis-
connection or a blown fuse.
(c) Selecting a station
Your Lexus has an electronic tuning radio
(ETR). Tune in the desired station using one
of the following methods.
Preset tuning: Touch the switch (1−6) or
push the “
” or “” button of the “CH” button
for the station you want. The switch (1−6) is
highlighted in green and station frequency ap-
pears on the display.
Manual tuning: Turn the “TUNE” knob briefly.
Each time you turn the knob, the radio will
step up or down to another frequency.
Seek tuning: Push the “
” or “” button of
the “SEEK” button and hold it until you hear a
beep. The radio will begin seeking up or down
for a station of the nearest frequency and will
stop on reception. Each time you push the
button, the stations will be searched out one
after another.

149
Scan tuning:Touch the “SCAN” switch brief-
ly. “SCAN” appears on the display. The radio
will find the next station up or down the band,
stay there for a few seconds, and then scan
again. To select a station, touch the “SCAN”
switch a second time.
Preset scan tuning: Touch the “SCAN”
switch and hold it until you hear a beep. “P.
SCAN” appears on the display. The radio will
tune in the next preset station up or down the
band, stay there for a few seconds, and then
move to the next preset station. To select a
station, touch the “SCAN” switch a second
time.
(d) RDS (Radio Data System)
Program type
When you touch the “TYPE ” or “TYPE ”
switch on the screen, the current program
type receiving from RDS station appears on
the display.
If the system receives no RDS stations, “NO
PTY” appears on the display.Each time you touch the “TYPE ” or “TYPE
” switch, the program type changes as in
the following:
ROCK
EASY LIS (Easy listening)
CLS/JAZZ (Classical music and Jazz)
R&B (Rhythm and Blues)
INFORM (Information)
RELIGION
MISC.
ALERT (Emergency message)
VI

150
7u006
When a program is set, “TYPE SEEK” switch
appears. Touch the switch and the system
starts to seek the station in the relevant pro-
gram type.
Traffic program: A station that regularly
broadcasts traffic information is automati-
cally located.
When you push the “TRAF” button, “TRAF
SEEK” appears on the display and the radio
will start seeking any traffic program station.
If any traffic program station is not found,
“NOTHING” appears and the previous mode
returns.
If the traffic program station is found, the name
for traffic program station is displayed and
“TRAF” is lit for a while until traffic announce-
ment is received.
Radio text
If the system receives a radio text from RDS
station, “MSG” appears on the display. Touch
the “MSG” switch, and a text message is dis-
played on the screen.
In case a text message is not accepted in a
screen, you can touch the “MSG” switch and
hold it to display the rest of the message.
When the system can show the station name,
“RDS” appears on the display. Each time you
touch the “MSG” switch, indication on the
display changes from the band to the station
name, a radio text in this order. After six sec-
onds passes, indication returns to the band.
